Simpli Home WyndenHall Brooklyn + max AXCBSAVN01-WH User manual

AVINGTON / MIA / HAYES
FLOOR STORAGE CABINET
MODEL # AXCBSAVN01-WH
/161
TM
TM
SI
M P
HOME®
LIFE BY DESIG N

/162
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am –4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following
information ready:
Model # _________________Part Number or Letter_____________________
Purchased at ____________Date of Purchase _________________________
If you wish to return the product, please contact the retailer where the
product was purchased.

/163
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
SAFETY INFORMATION

/164
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger, but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly. Don't over-humidify; that can damage wood
by causing it to expand and contract.
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
·If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3
to 4 inches away from the wall, giving the heat and air space to circulate.
·Dust with soft dry cloth.
·Do not use liquid or aerosol products.
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry.
·Do not use abrasive cleaners.
CARE and MAINTENANCE
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

PRE-ASSEMBLY INFORMATION MODEL # AXCBSAVN01-WH
/165
.A.BL .BR
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PART DESCRIPTION
Front /
Avant
TOP
QTY 1 LEFT SIDE
QTY 1 RIGHT SIDE QTY 1
.C.D.E
.F.G.H
Front /
Avant
Front /
Avant
MIDDLE SHELF
QTY 1 BOTTOM SHELF QTY 1 BACK BAR QTY 1
FRONT BAR
QTY 2 BACK PANEL QTY 1 DOOR QTY 1
Front /
Avant

/166
PRE-ASSEMBLY INFORMATION MODEL # AXCBSAVN01-WH
.1
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
HARDWARE DESCRIPTION
.2.3
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
.4.5.6
.7.8.9
CAM LOCK PIN
CAM LOCK
QTY 8 SETS
WOOD DOWEL
Ø8 X 30mm
QTY 24 HINGE
QTY 2
MAGNET AND PLATE
QTY 1 SET
PHILLIPS SCREW
M4 X 50mm
QTY 4
PHILLIPS SCREW
M3 X 15mm
QTY 12
HANDLE
M4 X 25 mm
QTY 1 SET
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 12
FURNITURETIPOVERRESTRAINT
QTY 1 SET
a.M4X25mm-QTY2
(1isextra)
b.M4X15mm-QTY1
c.M4X25mm-QTY1

COMPONENTS-KEY DIAGRAM MODEL # AXCBSAVN01-WH
/167
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
A
BL BR
EF
F
C
G
D
H

/168
STEP-1
ASSEMBLY MODEL # AXCBSAVN01-WH
P
X
1
Front /
Avant
Front /
Avant
2
1
1
2
6
4
BR
1
1
2
1. Attach four Cam Lock Pins 1 into pre-drilled holes on each Side BL , BR .
2. Insert two Dowels 2 into guide holes on each Side BL , BR .
3. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
4.AttachMagnets4usingPhillipsScrews6intopre-drilledholesRightSideBR.
5. Use Phillips screwdriver to secure Cam Lock Pins and Screws. Do not over-tighten.
BL

/169
STEP-2
ASSEMBLY MODEL # AXCBSAVN01-WH
1. Insert four Dowels 2 into guide holes on each part C , D , E , F .
2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
Front /
Avant
C
D
E
F
2
2
2
2
2
2
2
2
2
F
2
2

/1610
STEP-3
ASSEMBLY MODEL # AXCBSAVN01-WH
Front / Avant
Front / Avant
BR
C
D
1. Align Cam Lock Pin and Wood Dowels with guide holes on parts BR , C , D and
attach parts C , D to Right Side BR .
Front / Avant
Front / Avant
BR
C
D1
2. Insert two Cam Locks 1 into guide holes on each part C , D .
3. Use Phillips screwdriver to secure Cam Locks.
STEP-4
1. Align Wood Dowels with guide holes on parts BR and attach parts E , F
to Right Side BR .
Front / Avant
Front / Avant
Front / Avant
Front / Avant
BR BR
F
F
E
F
F
E
1
1
1

/1611
STEP-5
ASSEMBLY MODEL # AXCBSAVN01-WH
Front / Avant
Front / Avant
Front / Avant
Front / AvantFront / Avant
Front / Avant
BL
BL
BL
BR
BR
BR
C
C
C
D
D
D
F
E
F
F
E
C
BL
1
1. Repeat Step-3 and Step-4 for the Left Side BL .
1
1

/1612
STEP-6
ASSEMBLY MODEL # AXCBSAVN01-WH
Front / Avant
Front /
Avant
Front / Avant
BR
BL
A
A
BR
BL
Front / Avant
5
1. Align Wood Dowels with guide holes and
attach Top A to Sides BL , BR .
2. Use four Phillips Screws 5 to attach Top A
through guide holes from Sides BL , BR to pre-drilled holes of Top A .
3. Use Phillips screwdriver to secure Screws. Do not over-tighten.
STEP-7 Note:
Thebackofthecabinetframedoesnothave
pre-drilledholestoattachthebackpanels.
1. Attach the Back Panels G to back frame using Phillips Screws Round Head 8
through guide holes from Back Panels.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
G
Front /
Avant
Front /
Avant
8
8

/1613
STEP-8
ASSEMBLY MODEL # AXCBSAVN01-WH
H
6
6
7
1.AttachHinge3toDoorHusingPhillipsScrews6intopre-drilledholesonDoorH.
2.AttachMagnetPlates4totopcornerofDoorHusingPhillipsScrews6into
pre-drilledholesonDoorH.
3. UsePhillipsscrewdrivertoattachHandle7toDoorH.
4
3
STEP-9
1.AttachHingeonDoorHtoLeftSideBL
usingPhillipsScrews6intopre-drilledholesonLeftSideBL.
2. Use Phillips screwdriver to secure screws.Do not over-tighten.
BL
H
6

/1614
FURNITURE TIP OVER RESTRAINT ASSEMBLY
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
STEP-10
WALL
9
9

/1615
FURNITURE TIP OVER RESTRAINT ASSEMBLY
Furniture Tip Over Restraint Instructions:
1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
2. Determine where furniture is to be placed and mark location on
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
hole and gently tap until the flange on the anchor is against the
wall surface.
4. Position the bracket over the anchor and use the longer screw to
securely attach the bracket to the wall.
5. Place the furniture so the back edge is in line with the bracket on
the wall.
6. Lace an end of the nylon zip-tie strap down through each bracket.
Bring both ends together and slide the smooth side upright
through the square-shaped end and pull through to create the
“locked” position.
7. Check to make sure the strap is securely laced and locked to the
brackets.
·DO NOT put a TV or other heavy objects on top of a chest of
drawers or any other furniture not intended for use with a TV
·DO NOT place heavy objects in top drawers
·DO NOT let children climb or hang on drawers, doors or shelves
Px
P
P
x
x

/1616
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
[email protected].
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
