Simpli Home brooklyn+max WyndenHall 3AXCCON-04 User manual

Connaught / Hampshire / Somerset
Entryway Storage Cabinet
Model # 3AXCCON-04
1

Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
üAcvate your 1-year warranty
üAutomac entry to win a $500 gi cerficate
üEarn instant rewards and save simpli-home.com/product-registraon
2

Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Review your product and collect rewards!
Send us images or share them on social and qualify for instant rewards.
You may even receive store credit on your enre purchase!
simpli-home.com/share-images
Share photos and get your cash back!
3

For Fastest Customer Service:
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
Visit Us
Visit our site directly at
www.simpli-home.com
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
Email Us
customer[email protected]
Other ways to contact us…
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order informaon and issue.
6. Submit form.
7. A customer service associate will contact you.
4

We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
furniture.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
May require 2 people for ease of assembly.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
customer service department in order to obtain another kit before using the
CAUTION: Injuries and damage can occur from furniture tip over if product is not
properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided
with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Safety Information
5

Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
• If you can avoid it, don't put furniture near heating vents; if you can’t, keep the item 3 to
4 inches away from the wall, giving the heat and air space to circulate
• Dust with soft dry cloth
This furniture is designed for indoor use.
• Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
• Don't over-humidify; that can damage wood by causing it to expand and contract
• Do not use liquid or aerosol products
• For soil build-up, wipe with damp cloth & dry
• Do not use abrasive cleaners
• To avoid marking, do not place rubber on surface (foot pads, etc.)
Care & Maintenance
6

A
TOP
QTY 1
LEFT SIDE
QTY 1
BL
RIGHT SIDE
QTY 1
BR
LARGE DIVIDER
QTY 1
C
SMALL DIVIDER
QTY 1
D
MIDDLE FRAME
QTY 1
E
F
BOTTOM SHELF
QTY 1
CABINET SHELF
QTY 2
G
DOOR (L&R Same)
QTY 2
H
Front
/ Avant
Front /
Avant
Front
/ Avant
Front
/ Avant
Front
/ Avant
Front
/ Avant
Front / Avant
Front / Avant
7
Part Description
Pre-Assembly Information Model # 3AXCCON-04

IL
LEFT BACK
QTY 1
DRAWER FRONT
QTY 2
J
LEFT DRAWER SIDE
QTY 2
KL
DRAWER BACK
QTY 2
L
DRAWER BOTTOM
QTY 2
M
RIGHT DRAWER SIDE
QTY 2
KR
IR
RIGHT BACK
QTY 1
Warning Label
8
Part Description
Pre-Assembly Information Model # 3AXCCON-04

1
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
2
CAM LOCK PIN
CAM LOCK
QTY 16 SETS
3
WOOD DOWEL
Ø8 X 30 mm
QTY 16
4
ALLEN KEY
QTY 1
5
PHILLIPS SCREW
ROUND HEAD
M4 X 15 mm
QTY 21
6
SHELF SUPPORT
QTY 12
7
PHILLIPS SHORT SCREW
M3 X 12 mm
QTY 12
8
PHILLIPS MEDIUM SCREW
M3 X 15 mm
QTY 8
HANDLE
M4 X 28 mm
QTY 2 SETS
9
MAGNET and PLATE
QTY 2 SETS
10 11
HANDLE
M4 X 15 mm
QTY 2 SETS
12
FURNITURE TIP OVER
RESTRAINT
QTY 1 SET
a. M4 X 25 - QTY 2
( )1 is extra
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
9
Hardware Description
Pre-Assembly Information Model # 3AXCCON-04

BL
H
BR
H
KR
KL
IR
IL
Front
/ Avant
Front
/
Avant
Front
/
Avant
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front
/
Avant
10
Components - Key Diagram Model # 3AXCCON-04Components - Key Diagram Model # 3AXCCON-04

Step 1
Step 2
1. Slide Drawer Bottom M firmly into slots on Drawer Sides KL , KR
and Drawer Front J .
3. Insert 2 Cam Locks 2 into guide holes on each Drawer Side KL , KR.
4. Use flathead screwdriver secure Cam Locks.
1. Attach 4 Cam Lock Pins 2 to back of Drawer Front J .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides KL , KR.
KR
KL
KR
KL
M
J
J
2
11
Assembly Model # 3AXCCON-04

Step 3
1. Use Phillips Screwdriver to attach Handle 9 to Drawer Front J .
Repeat Step 1-4 for the second drawer.
Step 4
3. Use Allen Key 4 to tighten screws. Do not over-tighten.
2. Attach back using 2 Allen Key Screws 1 through guide holes on each Side KL , KR.
1. Align Drawer Back L with Drawer Bottom M and press firmly into slot .
NOTE: The screwdriver is not
included in the hardware pack.
J
KR
KL
M
L
1
4
9
12
Assembly Model # 3AXCCON-04

Step 5
Step 6
5. Place 2 Cam Locks 2 into guide holes on Large Divider C .
1. Insert 2 Dowels 3 into guide holes on Large Divider C .
4. Align and insert Cam Lock Pins on Middle Frame E into guide holes on
3. Attach 2 Cam Lock Pins 2 to Middle Frame E into pre-drilled holes.
Large Divider C .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
Dowels should be exposed.
6. Use a flathead screwdriver to tighten Cam Locks into Pins.
1. Attach Small Divider D to Middle Frame E using 2 Allen Key Screws 1 .
2. Use Allen Key 4 to tighten screws. Do not over-tighten.
Front
/
Avant
Front / Avant
Front /
Avant
Front / Avant
Front
/ Avant
Front
/
Avant
Front / Avant
1
4
Front /
Avant
3
2
13
Assembly Model # 3AXCCON-04

Step 7
3. Attach Large Divider C to Bottom Shelf F using 3 Allen Key Screws 1 through
4. Use Allen Key 4 to tighten screws. Do not over-tighten.
guide holes.
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
Dowels should be exposed.
1. Insert 2 Dowels 3 into guide holes on Large Divider C .
Front
/
Avant
Front /
Avant
Front / Avant
Front /
Avant
Front
/ Avant
1
4
3
14
Assembly Model # 3AXCCON-04

Step 8
7. Attach Middle Frame E to Sides BL , BR using 4 Allen Key Screws 1 through guide
1. Insert 4 Dowels 3 into guide holes on each Side BL , BR .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
Dowels should be exposed.
6. Use a flathead screwdriver to tighten Cam Locks into Pins.
4. Align and insert Cam Lock Pins on Sides BL , BR into guide holes on Bottom Shelf F .
5. Place 6 Cam Locks 2 into guide holes on Bottom Shelf F .
3. Attach 3 Cam Lock Pins 2 to each Side BL , BR into pre-drilled holes.
holes ( 2 Screws / each Side ).
8. Use Allen Key 4 to tighten screws. Do not over-tighten.
BR
BL
Front /
Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
3
2
1
4
3
15
Assembly Model # 3AXCCON-04

Step 9
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
4. Attach Top A to Sides BL , BR and Small Divider D using 9 Allen Key Screws 1 .
Dowels should be exposed.
5. Use Allen Key 4 to tighten screws. Do not over-tighten.
1. Insert 2 Dowels 3 into top corners of each Side BL , BR .
3. Align guide holes bottom corners of Top A with Dowels 3 in Sides BL , BR .
Step 10
IR
IL
Front
/
Avant
Front
/ Avant
Warning Label
5
1. Use Phillips screws Round Head 5 to attach Back Panels IL , IR , through guild holes
2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
from Back Panels to the back of Cabinet.
3
1
4
1
4
BR
Front
/
Avant
Front /
Avant
Front
/
Avant
Front / Avant
Front / Avant
BL
Note:
The back of the cabinet frame does not have
pre-drilled holes to aach the back panels.
16
Assembly Model # 3AXCCON-04

Step 11
- Using Phillips screwdriver to attach Screws 7 at middle hole of hinges for both top &
- Using Phillips screwdriver to tighten the rest of screws 7 into pre-drill holes ( top & bottom
holes on hinges).
2. Attach Magnet Plates 10 to bottom corner of Doors H using Phillips Screws 8 into
pre-drilled holes on Doors H .
3. Attach Magnets 10 using Phillips Screws 8 into pre-drilled holes on Bottom Shelf F .
4. Use Phillips screwdriver to attach Handles 11 to Doors H through guide holes.
1. Attach hinges on Doors H to Sides BL , BR using Phillips Screws 7 into pre-drill holes:
bottom hinges.
- Adjust the door to ensure they are aligned straight & square with bottom shelf & side.
First Step Last Step ( after adjust the door )
7
7
7
H
H
BL
BR
10
88
11
17
Assembly Model # 3AXCCON-04

Step 12
shelf level 1
shelf level 2
shelf level 3
shelf support
anti - tipping
6
6
2. 2 Shelf Supports 6 may be used on back top of each Shelf Cabinets G as a
tipping restraint.
1. Use 4 Shelf Supports 6 for each Shelf Cabinet G in desired location.
18
Assembly Model # 3AXCCON-04

Step 13
1. Insert assembled drawers into drawer glides on assembled cabinet.
19
Assembly Model # 3AXCCON-04

NOTE: The screwdriver is not
included in the hardware pack.
Serious or fatal crushing injuries can occur from furniture tip-over.
WARNING
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
Step 14
Furniture Tip Over Restraint Assembly
20
