Simrad P2005 User manual

ENGLISH
P2005 / P3007
Operator Manual
www.navico.com/commercial

Preface
Disclaimer
As Navico is continuously improving this product, we retain the
right to make changes to the product at any time which may not be
reflected in this version of the manual. Please contact your nearest
distributor if you require any further assistance.
It is the owner’s sole responsibility to install and use the equipment
in a manner that will not cause accidents, personal injury or
property damage. The user of this product is solely responsible for
observing maritime safety practices.
NAVICO HOLDING AS AND ITS SUBSIDIARIES, BRANCHES AND
AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE OF THIS PRODUCT
IN A WAY THAT MAY CAUSE ACCIDENTS, DAMAGE OR THAT MAY
VIOLATE THE LAW.
This manual represents the product as at the time of printing.
Navico Holding AS and its subsidiaries, branches and affiliates
reserve the right to make changes to specifications without notice.
Governing language
This statement, any instruction manuals, user guides and other
information relating to the product (Documentation) may be
translated to, or has been translated from, another language
(Translation). In the event of any conflict between any Translation of
the Documentation, the English language version of the
Documentation will be the official version of the Documentation.
Copyright
Copyright © 2019 Navico Holding AS.
Warranty
The warranty card is supplied as a separate document. In case of any
queries, refer to the brand website of your unit or system:
www.navico-commercial.com
Preface | P2005/P3007 Operator Manual 3

Compliance statements
Europe
Navico declare under our sole responsibility that the product
conforms with the requirements of:
P3007
•European Council Directive 2014/90/EU on Marine Equipment
modified by Commission Implementing Regulation (EU)
2018/773 (MED) - Wheelmark
ÚNote: The unit(s) are Wheelmark approved only when installed
according to the relevant MED-B certificate.
P2005
•CE under EMC Directive 2014/30/EU
The relevant declaration of conformity and certificates are available
in the product's section at the following website:
www.navico-commercial.com
United States of America
This product has been assigned U.S. Coast Guard Module B
number in accordance with the European Council Decision
2004/425/EC dated 21 April 2004 on the conclusion of an
Agreement between the European community and the United
Stated of America on Mutual Recognition of Certificates of
Conformity for Marine Equipment.
Warning: The user is cautioned that any changes or
modifications not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
Australia and New Zealand
Navico declare under our sole responsibility that the product
conforms with the requirements of:
•level 2 devices of the Radiocommunications (Electromagnetic
Compatibility) standard 2017
4Preface | P2005/P3007 Operator Manual

Trademarks
Navico®is a registered trademark of Navico Holding AS.
Simrad®is used by license from Kongsberg.
NMEA®and NMEA 2000®are registered trademarks of the National
Marine Electronics Association.
SD™and microSD™are trademarks or registered trademarks of
SD-3C, LLC in the United States, other countries or both.
Preface | P2005/P3007 Operator Manual 5

6Preface | P2005/P3007 Operator Manual

Contents
9 Introduction
9 About this unit
10 Page layout
11 Position quality
12 Card reader
13 Basic operation
13 Turning the unit ON
13 Menu overview
14 Backlight settings
14 Man over board
15 Simulator mode
16 Screen capture
17 Pages
17 Selecting a page
17 Missing or faulty data
17 Customizable data fields
18 Default pages
22 Manage waypoints and routes
22 Manage waypoints
23 Manage routes
24 Importing routes and waypoints
24 Exporting waypoints and routes
26 Software setup
26 Software setup overview
26 Introduction to Lightweight Ethernet
27 First time startup
27 Software setup sequence
28 The settings dialog
28 System settings
30 Page settings
31 Trip log settings
31 AIS settings
32 GNSS settings
34 Navigation settings
Contents | P2005/P3007 Operator Manual 7

36 Units settings
36 Local port setup
39 Calibration
39 Network settings
46 Maintenance
46 Preventive maintenance
46 Cleaning the display unit
46 Restoring factory default settings
47 Backup and restore of system data
48 Software updates
50 Alerts
50 Type of alerts
50 Alert notifications
51 Alert dialogs
51 External bridge alert systems
52 Alphabetic alert list
53 Appendix
53 Menu overview
56 Terms and abbreviations
58 Icons
61 Supported data
66 LWE Transmission groups
8Contents | P2005/P3007 Operator Manual

Introduction
About this unit
The P2005 and P3007 units are touch controlled color displays.
P2005 units support several languages, while P3007 support English
language in menus and dialogs.
Both units offer multiple analog-style gauges as well as configurable
digital data display layouts. The units support a wide variety of I/O
signal types.
The P2005 unit can be used in GPS systems for workboats in the
light professional segment and for other non-SOLAS vessels. The
P2005 can be paired with a wide range of Simrad GPS antenna or
GPS compasses.
The P3007 unit can be used for SOLAS vessels. Paired with high-
precision antennas, the P3007 system can be configured as GPS,
DGPS and THD (Transmitting Heading Device).
Type approved pages
The following pages are type approved:
•Position page
•Navigation page
•Heading page
•Trip log page
An AIS page is available if a compatible AIS receiver is connected to
the network. The AIS page is not type approved.
NMEA 0183 equivalence with IEC 61162-1
This device uses the term NMEA 0183 in menus and dialogs. NMEA
0183 is equivalent with the IEC standard IEC 61162-1.
1
Introduction | P2005/P3007 Operator Manual 9

Page layout
APage selection button
BPicture freeze indicator
CStatus bar
DMenu button
Picture freeze indicator
The image includes a picture freeze indicator. The small dot blinks at
an interval of 1 second to show that the screen is alive and that
information from sensors is updated.
If the picture freezes the unit must be restarted.
The status bar
The status bar includes status icons. The images in the table are
examples only. Only active icons are visible.
Navigating
RAIM status
GNSS mode
GPS/DGPS mode and signal strength
Un-read AIS message
Alert
For a full list of GPS and DGPS icons, refer to "Appendix" on page 53.
10 Introduction | P2005/P3007 Operator Manual

Position quality
The accuracy of the GPS position depends on available satellites, the
signal quality and the signal strength.
Signal strength indicator
The number of highlighted bars indicate the signal strength. The
more highlighted bars, the stronger signal.
The RAIM feature
RAIM (Receiver Autonomous Integrity Monitoring) is a fault-
detection feature required by IMO for type-approved GPS units. This
feature requires signal from at least five satellites to determine the
accuracy of the position.
ÚNote: The RAIM function is available only if the antenna is
supporting this feature.
The system alerts the operator that a condition may exist in the GPS
positioning solution that reduces the accuracy of the ship’s position.
The RAIM alert can be turned OFF and the error limits set. Refer to
"Softwaresetup" on page 26.
RAIM status indicators
Icon Status Description
Safe Any position error is within the specified
limit
Caution No RAIM, the system is receiving signals
from less than five GPS satellites
Unsafe The statistical position error exceeds the
specified limit.
Introduction | P2005/P3007 Operator Manual 11

Satellites
The Satellites option displays a graphical view and numeric values
for available satellites.
ÚNote: The content in the Satellites dialogs varies with
connected antenna.
Card reader
5”
7”
A memory card can be used for:
•Software updates
•Transfer of user data
•System backup
The protective door should always be securely shut immediately
after inserting or removing a card, in order to prevent possible water
ingress.
12 Introduction | P2005/P3007 Operator Manual

Basic operation
Turning the unit ON
The unit does not have a power key.
The unit will be automatically turned ON once power is applied.
Menu overview
Page menu
Not all pages have the same page menu options. See the page
specific sections in this manual for page menu options.
The settings dialog
The software setup is done from the settings dialog.
2
Basic operation | P2005/P3007 Operator Manual 13

Backlight settings
The display backlight can be adjusted at any time from the
backlight settings dialog.
To access the dialog:
•Press the brilliance key
Repeated short presses on the brilliance key cycles thru the preset
backlight levels.
ÚNote: All changes made to the display setup will apply to all
units belonging to the same display group. For more
information about network groups, refer to "Softwaresetup" on
page 26.
Man over board
This display can receive a MOB signal from an external connected
key, or from a connected device.
When a MOB event is received, the following actions are
automatically performed:
•A MOB waypoint is created at the vessel’s position
•A MOB dialog is displayed
When navigation is confirmed:
•The display switches to the navigation page
•The system displays navigation information back to the MOB
waypoint
14 Basic operation | P2005/P3007 Operator Manual

Multiple MOB waypoints can be created. The vessel continues to
show navigation information to the initial MOB waypoint.
Navigation to subsequent MOB waypoints needs to be done
manually.
Stop navigating to MOB
The system continues to display navigational information towards
the MOB waypoint until you cancel the navigation from the menu.
Simulator mode
The simulate option lets you operate the unit without being
connected to sensors or other devices.
It is not possible to simulate commissioning and setup.
If the unit is turned off while in simulator mode, this mode will still
be active on next power on.
Active simulator mode is indicated with a flashing notification on
the image.
Basic operation | P2005/P3007 Operator Manual 15

Screen capture
To take a screen capture:
•Press the screen for 5 seconds
The screen capture function is only available when a memory card is
inserted in the unit. Screen captures are automatically saved to the
memory card.
16 Basic operation | P2005/P3007 Operator Manual

Pages
Selecting a page
Selecting page layout
Some of the pages have two layouts. Use the menu option to
specify which layout is displayed on the page.
Missing or faulty data
If a data type is missing or if the data is out of scale, there will be no
data reading on the display. The example shows a page with
missing information.
Customizable data fields
Some pages have customizable data fields. You can specify the data
displayed in those data fields. Refer to "Softwaresetup" on page 26.
3
Pages | P2005/P3007 Operator Manual 17

Default pages
Position page
Layout1 Layout2
ACustomizable data fields
Navigation page
Layout1 Layout2
ACustomizable data fields
BCross track distance (XTD)
18 Pages | P2005/P3007 Operator Manual

Navigating
The navigation function allows you to navigate towards a waypoint,
a coordinate, or along a predefined route.
When navigating, the page menu includes options for cancelling
and restarting the navigation, and for skipping the active waypoint.
Active navigation mode is indicated in the status panel.
The navigation function can be started from any page, but only the
Navigation page includes by default navigational information.
Heading page
Layout1 Layout2
ACustomizable data fields
AIS page
ÚNote: The AIS page is not Wheelmark approved.
If a compatible AIS receiver is connected to the network, then any
targets detected by those devices can be displayed on the AIS page.
You can also see messages and position from SARTs and AtoNs
within the defined range.
Pages | P2005/P3007 Operator Manual 19

AB
D
C
AAIS mode
BNumber of displayed icons versus total number of targets
CDistance between range rings
DSelected range
AIS page menu
Range
Defines the display range on the AIS page.
AIS icon orientation
Sets the orientation of the AIS icons.
Target list
The target list displays basic information for all received AIS targets.
Select an item in the list to see details.
Messages
All received messages are listed in the message listing.
To display a message:
20 Pages | P2005/P3007 Operator Manual
