Simrad ES120-4X10 - REV D User manual

TRANSDUCER
Simrad ES 120-4x10
120 kHz Split-beam transducer
(859-130990 Rev.D)
Introduction
The ES 120-4x10 is a split-beam transducer with 108
piezo-ceramic elements arranged in four quadrants. The
speci cations below are valid when all four quadrants
are wired in parallel. The beam pattern has an elliptic
cross-section suited for horizontal ranging in shallow
waters with the narrow beam in the vertical plane. The
side lobes in the vertical plane are very low.
Order number
KSV-111646
Technical speci cations
Resonant frequency
.......................................
120 kHz
Beamwidth:
Vertical
......................................................
4.4 deg
Horizontal
.....................................................
9 deg
Directivity:
D
...............................................................
.......
850
DI=10logD
.....................................................
29.5
Equivalent two-way beam angle:
Ψ
...................................................
0.007 steradian
10 log
Ψ
....................................................
-21.5 dB
Side lobes:
Vertical
........................................
less than -25 dB
Horizontal
....................................
less than -18 dB
Back radiation
...................................
less than -25 dB
Angle sensitivity:
Vertical
..............................................................
36
Horizontal
..........................................................
18
Impedance:
Nominal
...................................................
19 ohms
Max. variation in |Z|
.........................
15 - 24 ohms
Max variation in phase angle
...................
±30 deg
Transmitting response
...........
184.5 dB re 1µPa per V
Receiving sensitivity,
open circuit
.......................
-186 dB re 1V per µPa
Electroacoustic ef ciency
....................................
0.50
Maximum pulse power input
...........................
500 W
Maximum continous power input
......................
20 W
Maximum transducer depth
...............................
20 m
Cable:
Length
...........................................................
20 m
Diameter
....................................................
11 mm
Weight without cable
..........................................
6 kg
Storage temperature
................................
-20 to 70 °C
A L W A Y S A T T H E F O R E F R O N T O F T E C H N O L O G Y
www.simrad.com

Manufacturer
:
Simrad AS
Strandpromenaden 50
P.O.Box 111
N-3191 Horten
Telephone:
[phone]
Telefax:
[phone]
