USER'S MANUAL
ASH-28AT
TITAN SERIES

CONTENTS
Please read this
OWNERS MANUAL
carefully prior to
use
Care and maintenanceStructure and mechanism Remote control operation procedure
Functions and Working temperature range
Operation mechanism
Technical specifications
Important notices
Structure description
Name and Function-Remote control
COOL mode operation procedure
HEAT mode operation procedure
DRY mode operation procedure
SLEEP mode operation procedure
AUTO mode operation procedure
TIMER mode operation procedure
How to insert batteries
Emergency run operation procedure
Air flow direction adjustment procedure
Special performance
Operation conditions
Installation precaution
Care and maintenance
When malfunction happening
Installation dimension diagram
Installation location
Install the indoor unit
Install the outdoor unit
Routine check after installation
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
21
22
23
25
27
Name and Function-Remote control(Remove the cover)

For to prevent flicker impressions during the start of the compressor (technical process)following installation
conditions do apply.
1 ASH-28AT will be connected only to a supply with the relevant system impedance no
more than Zmax=0.267
2The power connection for the air conditioner has to be done at the main power distribution. This distribution has to
be of an low impedance. Normally the required impedance is eached at a 32A fusing point.
3 No other equipment has to be connected to this power line.
4For detailed installation acceptance please refer to your contract with the power supplier, if restrictions do apply
far products like washing machines air conditioners or electrical ovens.
5For power details of the air conditioner refer to the rating plate of the product.
6For any question contact your local seller.
7 This product must not be disposed together with the domestic waste.
This product has to be disposed at an authorized place for recycling
of electrical and electronic appliances.
8 The fuse indoor: T5AL, AC250V, outdoor: T3.15AL, AC250V.

1
Working voltage:50Hz 230V
Installation precaution:
To prevent possible hazards due to insulation failure,the unit must be grounded.
Provide a power outlet to be used exclusively for each unit,and a power supply disconnect and circuit breaker and
current fuse protector should be provide in the exclusive line.
Each wiring connection must be done in accordance with the wiring system diagram.Wrong wiring may cause the unit
to misoperate or become damage.
Please cut off power supply when unit will not be used for a long time.
Functions
Dehumidifying in rainy or humid season
Without reducing room temp.,air conditioner can
dehumidify and make room air dry and comfortable.
Heating in winter (heat pump type)
In cold winter,air conditioner can supply warm air to
rise room temp.
Indoor side DB/WB( ) Outdoor side DB/WB( )
Maximum cooling32/2343/26
Minimum cooling 21/15
Maximum heating 27/ 24/18
Minimum heating 5/ 6
Cooling in summer
In hot summer,air conditioner can cool room air by
transfering heat out.
Operating automatically
According to room temp. change,microcomputer can
automaticlly set COOL or HEAT or FAN operation mode,
so as for best effect.
Working temperature range
AUTO
An all-pole disconnection switch having a contact separation of at least 3mm in all poles should be connected in fixed wiring.
⑤

2
Operation mechanism
Cooling cycle
Connected with pipes,indoor unit and outdoor unit form a refrigeration system.With power,compressor takes in
low temp.and low pressure refrigerant vapour from evaporator of indoor unit,presses it into high temp.and high
pressure gas,then discharges it into condenser of outdoor unit.By help of axialflow fan,heat is removed to outdoor
air from the gas which then condenses into liquid.After capillary tube throtting,the liquid drops temp.and pressure,
flows into evaporator.There,by help of cross-flow fan,the liquid absorbs heat from room air,evaporates and
becomes low pressure vapour which then flows into compressor again,beginning next cooling cycle.Therefore,
heat is transfered from indoor to outdoor,and room gets cool.
Ventilation cycle
Ventilation cycle divides into indoor and outdoor two parts.With suction of cross-flow fan,room air flows through
filters,exchanges heat in evaporator,then returns to room.In this way,room air can be cool and dehumidified.At
the same time,pumped by axial-flow fan,outdoor air flows through condenser and exchanges heat.
Heating cycle
Heat pump type air conditioner uses a commutator (4-way electromagnetic valve) to change refrigerant flow
direction.When heating,refrigerant firstly enters indoor heat-exchanger,releasing heat and condensing.Then it
enters outdoor heat-exchanger,absorbing heat and evaporating.Because consumption power changes into heat
which is discharged in room,heating efficiency is very good.

3
(1) Schematic diagram of cool only type
1.Compressor 2.Outdoor heat-exchanger 3.Filter 4.Capillary tube
5.Stop valve 6.Connecting pipes 7.Indoor heat-exchanger 8.Accumulator
(2) Schematic diagram of heat pump type
1.Compressor 2. 4-way electromagnetic valve 3.Outdoor heat-exchanger 4.Filter
5.Master capillary tube 6.Check valve 7.Auxiliary capillary tube 8.Stop valve
9.Connecting pipes 10.Indoor heat-exchanger 11.Accumulator

4
Technical specification
Model ASH-28AT
Funcitions Cool/Heat
Cooling capacity(W) 8000
Heating capacity(W) 8800
Power supply 230V~50Hz
Cooling(W) 4000 Rated input
Heating(W) 3600
Cooling(W) 2800 Input power
Heating(W) 2800
Refrigerant R410A 2600g
Indoor 49 Noise dB(A)
Outdoor 60
Climate type T1
Moisture protection IP24
Isolation I
Indoor unit 1178*326*227Dimension
(mm) Outdoor unit 1006*340*847
Indoor unit 17.5Weight(kg)
Outdoor unit 90
All above should be changed without notice. There are latest and accurate specification
on the nameplate of your air conditioner.

Smell
Sometimes there is some smell out
of indoor unit,as does not mean any
machine failure,but because of
suction air mixed with smell of
furniture or smoking etc.
Important notices
Do not cut or pull strongly power
lines and connecting lines.
Close doors and windows
(better using contains)while
operating air conditioner,to
avoid cool or heat leakage
which affects air condition.
If room air is quite turbid,you
should open a door or
window a little for a
moment to get some outdoor
fresh air.
It is only specific technician who can operate the stop valve of outdoor unit,otherwise it is possible to make refrigerant leak
out and compressor breakdown.
Air Conditioner should be
operated with stable voltage
in range of 198-253V1Ph,
otherwise, compressor
would vibrate terribly to
damage refrigeration
system.
Do not insert any foreign
materials into the air inlet
or air outlet, it is very
dangerous.
Delay operation
To avoid action of overload protector
or other security devices,we design a
delay for 3 4 minutes before starting
cooling or heating or dehumidifying
cycle in following situations:
To start again immediatelly after
stopping;
To adjust operation mode.
Electric circuit
Must use special electric circuit,do
not use longer power lines,do not
share a same socket with other
electric appliances to avoid fire etc.
230V
5

⑴Handling switch
⑵Wiring cover
⑶Surface panel
⑷Filter
⑸Deflector
⑹Singal window
⑺Front panel
⑻Piping and wiring
⑼Drain hose
⑽Air outlet net
Structuredescription
Signal transmit
⑴
⑻
⑵
⑶
⑷⑸⑹
⑺
⑼
⑽
⑾
Air in
Air out
Air in
Air out
Outdoor unit
Indoor unit
⑹
⑴
AUTO
TEST
RUN
STOP
6
HEAT
COOL
RUN

7
Remote control operation procedure
Name and Function-Remote control
Note:
Be sure that there are no obstructions.
The remote control signal can be received at a distance of up to about 10m.
Don’t drop or throw the remote control.
Don’t place the remote control in a location exposed to direct sunlight.
SWING button
When it is pressed, the louvers
start to rotate automatically and
stop when repressed.
TEMP. button
SET TEMP. increases 1 by
pressing button once,and decreases
1by pressing button once.
At COOL mode operation, SET
TEMP. can be selected from 16 to
30 .
At DRY mode operation, SET
TEMP. can be selected from 16 to
30 .
At HEAT mode operation, SET
TEMP. can be selected from 16 to
30 .
MODE button
Press this button to change the
operation mode in order of mode
in order of:
FAN button
Press this button to change
the fan speed of:
“ ” COOL mode
“ ” DRY mode
“ ” FAN mode
“ ” HEAT mode
ON/OFF button
Press this button to turn on
or turn off the unit.
REMOTE CONTROL OPERATION PROCEDURE
AUTO

8
Name and Function-Remote control. (Remove the cover)
Note:This type of remote controller is a kind of new current controller.
some buttons of the controller which are not available to this Air condi-
tioner will not be described below.
Liquid crystal displayer.
It shows all set contents.
SLEEP button
Press this button to set
SLEEP operation.
TIMER OFF button
At operating, press TIMER
OFF button, set OFF TIME
in range of 0 to 24 hour to
stop the unit automatically.
TIMER ON button
At stopping, press TIMER
ON button, set ON TIME in
range of 0 to 24 hour to start
the unit automatically.

9
COOL mode operation procedure
According to difference between room temp. and set temp., microcomputer can control cooling on or
not.
If room temp. is higher than set temp., compressor runs at COOL mode.
If room temp. is lower than set temp., compressor stops and only indoor fan motor runs.
SET TEMP. should be in range of 16 to 30
4.Press FAN button, set
fan speed.
5.Press TEMP. but-
ton, set suitable SET
TEMP.
2.Press MODE button,
set operation
mode.
3.Press SWING button,
the louvers start to ro-
tate automatically, and
stop when repress.
1.Plug in, press ON/OFF button,
then air conditioner is turned on.

10
HEAT mode operation procedure
If room temp. is lower than set temp., compressor runs at HEAT mode;
If room temp. is higher than set temp., compressor and outdoor fan motor stop, only indoor fan
motor runs.
SET TEMP. should be in range of 16 to 30
4.Press FAN button, set
fan speed.
5.Press TEMP. but-
ton, set suitable
SET TEMP.
1.Plug in, press ON/OFF button,
then air conditioner is turned on.
2.Press MODE button,
set operation
mode.
3.Press SWING button, the
louvers start to rotate
automatically, and stop
when repress it.

11
DRY mode operation procedure
If room temp. is lower than set temp., compressor , outdoor and indoor fan motor stop. If room
temp. is between 2of set temp., Air conditioner is drying. If room temp. is higher than set
temp., it’s at COOL mode.
SET TEMP. should be in range of 16 to 30
3.Press SWING button,
the louvers start to ro-
tate automatically, and
stop when repress it.
4.Press TEMP. button,
set suitable SET TEMP.
2.Press MODE button,set
operation mode.
1.Plug in,pressON/OFF button,
then air conditioner is turned on.

12
SLEEP mode operation procedure
4.Press FAN button, set
fan speed.
5.Press TEMP. but-
ton, set suitable
SET TEMP.
1.Plug in, press ON/OFF button,
then air conditioner is turned on.
2.Press MODE button,
set or op-
eration mode.
3.Press SWING button, the
louvers start to rotate
automatically, and stop
when repress.
6.SLEEP button
Press it to set SLEEP
operation.
When the unit is cooling or drying, if SLEEP operation is set, SET TEMP. would increase 1 in 1 hour
and 2 in 2 hours. Indoor fan motor runs at low speed.
When the unit is heating , if SLEEP operation is set, SET TEMP. would decrease 1 in 1 hour and
2in 2 hours. Indoor fan motor runs at low speed.

13
AUTO mode operation procedure
At AUTO mode operation, standard SET TEMP. is 25 for COOL mode and 20 for HEAT mode.
2.According to room temp., micro-
computer can automatically set
operation
mode,so as for best effect.
1.Plug in, Press ON/OFF button,
then air conditioner is turned on.

14
TIMER mode operation procedure
At stopping,press TIMER
ON button, set ON TIME
in range of 0 to 24 hour to
start the unit automatically.
At operating, press TIMER
OFF button.set OFF TIME
in range of 0 to 24 hour to
stop the unit automatically.

15
How to insert batteries
1.Remove the cover from the back
of the remote control.
2.Insert the two batteries ( Two AAA
dry - cell batteries ) and press but-
ton “ACL”.
3.Re - attach the cover.
NOTE:
Don’t confuse the new
and worn or different
batteries.
Remove batteries when
not in use for a long
time.
The remote control sig-
nal can be received at a
distance of up to about
10m.
1 Remove the cover
3 Re - attach the cover.
2 Insert the two AAA batteries

16
Emergency run operation procedure
If Wireless remote controller lost,open the surface panel and operate as following:
d. When turning it to Stop position, the unit will stop running.
c. When turning it to Run position, the main unit will run at the
received remote control order.
b. When turning it to Test position, the main unit will enter into
Cool mode, indoor fan will run at high fan speed, if there is remote
control signal, main unit will run at the remote control signal, at
this time to shield the low pressure switch.
a. When turning it to Auto position, unit will run in Auto mode,
if there is remote control signal, it will run at the remote control
signal.
Manual switch (Auto, Test, Run, Stop)
Air flow direction adjustment procedure
1.Adjusting up/down air flow direction
With wireless remote controller,adjust air flow direction
by rotating the UP/DOWN deflectors up and down
automatically or stopping at an angle.
* Press SWING button,the deflectors start to rotate and
stop when repress.
2.Adjusting left/right air flow direction
As shown,move the LEFT/RIGHT deflectors by hand,
adjust air flow left or right or three different directions
to every corner of room so as to make everywhere temp.
average.
deflectorsAdjusting left/right air flow direction
