Sine Systems ACU-1 User instructions

Setting up the ACU-1 from the Front Panel
Introduction
The switches that are normally used for channel selection can be used to change some operating parameters
of the ACU-1 that may not be accessible through third party software. It is impossible to predict if third party
software will react properly if unsupported adjustments are made in hardware. If you make changes to the
system using the information contained in this document, you are accepting the responsiblity for making
alterations to the system that may not be supported by your software vendor or by Sine Systesm, Inc.
Set EEROM to Factory Default
This is the same as command 3B (hex) and is executed by pressing buttons 1 and 8 simultaneously for at least
one second.
Program User Settings from the Front Panel
(firmware version 6 and later)
All user programming in the ACU-1 can be read and altered from the front panel. To enter the front panel
programming mode, press buttons 1 and 3 simultaneously for at least one second. The POWER/SYNC LED
will begin flashing to indicate that the programming mode has been entered. The front panel will display a
memory address in binary using the left 8 LEDs of the left VU meter. The data at that address is displayed in
binary on the channel LEDs:
The starting address will be 27 (binary 00011011) which programs the "Box Address." The memory address
may be changed using buttons 5 or 6. To change the data at that address, push buttons 7 or 8. If data is
changed, the new data will be stored in EEROM and will unaffected by a power failure.
ACU-1 page 1

Setting up the ACU-1 from the Front Panel
The following table shows the locations that can be programmed:
Name Address (decimal) Address (binary) Default Data (binary)
Channel 1 Up Rate 1 00000001 00000000
Channel 2 Up Rate 2 00000010 00000000
Channel 3 Up Rate 3 00000011 00000000
Channel 4 Up Rate 4 00000100 00000000
Channel 5 Up Rate 5 00000101 00000000
Channel 6 Up Rate 6 00000110 00000000
Channel 7 Up Rate 7 00000111 00000000
Channel 8 Up Rate 8 00001000 00000000
Channel 1 Down Rate 9 00001001 00000000
Channel 2 Down Rate 10 00001010 00000000
Channel 3 Down Rate 11 00001011 00000000
Channel 4 Down Rate 12 00001100 00000000
Channel 5 Down Rate 13 00001101 00000000
Channel 6 Down Rate 14 00001110 00000000
Channel 7 Down Rate 15 00001111 00000000
Channel 8 Down Rate 16 00010000 00000000
Temperature Calibrate 17 00010001 00001000
Baud Rate 18 00010010 00000111
Momentary Relay Time 19 00010011 00110010
Left Silence Threshold 20 00010100 00000001
Right Silence Threshold 21 00010101 00000001
Left Silence Alarm Time 22 00010110 00011110
Right Silence Alarm Time 23 00010111 00011110
Silence Alarm Link 24 00011000 00000001
Parallel Input Hold Time 25 00011001 01100100
ALC Release Speed 26 00011010 00000101
Box Address 27 00011011 00000001
CONFIG1 28 00011100 10000000
CONFIG2 29 00011101 00000000
When finished reading or programming user EEROM, push any of the first four buttons to exit the programming
mode.
Read Firmware Version
Firmware version and be read by simultaneously pressing buttons 1 and 2. The firmware version is read on the
channel status LEDs in binary for as long as the buttons are held. For example, if LEDs 1 through 6 are off and
7 and 8 are on, this represents binary 00000011 or firmware version "3."
Note: If buttons 1 and 2 are pushed carefully at the same time, it will not disturb the currently selected audio
channel.
ACU-1 page 2

Setting up the ACU-1 from the Front Panel
ACU-1 Commands
FadeUp
Function: Turn one or more audio channels on.
Format: AAhex/boxnode/31hex/byte4
Set bits in byte4 to turn channel(s) on. Bit 0 is channel 1.
FadeDown
Function: Turn one or more audio channels off.
Format: AAhex/boxnode/32hex/byte4
Set bits in byte4 to turn channel(s) off. Bit 0 is channel 1.
SetLevel
Function: Sets fader level.
Format: AAhex/boxnode/33hex/byte4/byte5
Set bits in byte4 to designate channel(s). Bit 0 is channel 1. Byte5 sets level from 0 to 255 where 255 is full on.
SetUp
Function: Sets fade up rate.
Format: AAhex/boxnode/34hex/byte4/byte5
Byte4 determines the channel(s) which are to be set (bit 0 being channel 1). byte5 sets the fade up rate. 0 to
25.0 seconds = 0 to 250.
SetDown
Function: Sets fade down rate.
Format: AAhex/boxnode/35hex/byte4/byte5
Byte4 determines the channel(s) which are to be set (bit 0 being channel 1). byte5 sets the fade down rate. 0
to 25.0 seconds = 0 to 250.
SetSilence
Function: Sets silence sense threshold.
Format: AAhex/boxnode/36hex/byte4/byte5
Byte4: Active channels:
1 left channel
2 right channel
3 both channels
Byte5: Detection threshold:
0 silence detection off (both channels)
1 -42 dB
2 -39 dB
3 -36 dB
ACU-1 page 3

Setting up the ACU-1 from the Front Panel
4 -33 dB
5 -30 dB
6 -27 dB
7 -24 dB
8 -21 dB
9 -18 dB
10 -15 dB
11 -12 dB
12 -9 dB
13 -6 dB
14 -3 dB
15 0 dB
16 +3 dB
SetStime
Function: Sets silence sense activation time.
Format: AAhex/boxnode/37hex/byte4/byte5
Byte4: Channel(s) set:
1 left channel
2 right channel
3 both channels
Byte5 sets time. 1 to 250 sets 1 to 250 seconds.
SetPo
Function: Sets parallel output.
Format: AAhex/boxnode/38hex/byte4
Bits set in byte4 turn relays on. Bit 0 is relay 1.
ReadPi
Function: Reads the 16 parallel inputs.
Format: AAhex/boxnode/39hex —replybyte1/replybyte2
Bit0 in replybyte1 corresponds to parallel input 1.
ReadAud
Function: Reads the instantaneous audio level.
Format: AAhex/boxnode/3Ahex/byte4 —replybyte1
Byte4:
1 read left
2 read right
Replybyte1:
0 <-42 dB
1 -42 dB
2 -39 dB
ACU-1 page 4

Setting up the ACU-1 from the Front Panel
3 -36 dB
4 -33 dB
5 -30 dB
6 -27 dB
7 -24 dB
8 -21 dB
9 -18 dB
10 -15 dB
11 -12 dB
12 -9 dB
13 -6 dB
14 -3 dB
15 0 dB
16 +3 dB
Default
Function: Returns box to default settings.
Format: AAhex/boxnode/3Bhex/C4hex
Default settings:
Node Address: 1
Baud Rate: 57.6K
Sources: All off
Fade Up Time (all): 0 seconds
Fade Down Time (all): 0 seconds
Silence Level Left: -42 dB
Silence Level Right: -42 dB
Silence Time Left: 30 seconds
Silence Time Right: 30 seconds
Silence Link: 1 (L and R separate)
Automatic Level Control: On, 5 sec/dB increase speed, gating at -20 dBVU
Parallel Input Hold Time: 1.0 seconds
Momentary Relay Time: 0.5 seconds
Temperature Calibration: 8
Config1 10000010
Config2 00000000
ReadXP
Function: Reads the status of input sources.
Format: AAhex/boxnode/3Chex —replybyte1
Bit 0 is channel 1.
ReadSil
Function: Reads silence detector.
Format: AAhex/boxnode /3Dhex —replybyte1
ACU-1 page 5

Setting up the ACU-1 from the Front Panel
Replybyte1:
Bit0 Silence Alarm Left Channel is active
Bit1 Silence Alarm Right Channel is active
Bit2 Silence Detect Left Channel is active
Bit3 Silence Detect Right Channel is active
ReadPo
Function: Reads the current relay settings.
Format: AAhex/boxnode/3Ehex —replybyte1
Bits set in replybyte1 correspond to relays on. Bit 0 is relay 1.
SetLink
Function: Sets linking for silence sense.
Format: AAhex/boxnode/3Fhex/byte4
Byte4:
0 silence detect off
1 left and right separate
2 left or right linked
3 left and right linked
FadeUpDown
Function: Turn one or more audio channels on and off.
Format: AAhex/boxnode/51hex/byte4/byte5
Set bits in byte4 to turn channel(s) on. Set bits in byte5 to turn channel(s) off. Bit 0 is channel 1. If common
bits are set in byte4 and byte5, the byte5 (fade down) bits override.
PoMomen
Function: Operate relays momentarily
Format: AAhex/boxnode/52hex/byte4
Bits set in byte4 will cause momentary relay operation. Bit0 corresponds to relay 1. Any combination of relays
may be operated momentarily at the same time. Relays that were previously turned on and are operated
momentarily will turn off after the delay period (delay period defined in SetPoTime).
SetNode
Function: Set/read node address.
Format: AAhex/boxnode/53hex/byte4
byte4:
0 read only
1-10 set node address
11-255 read only
SetBaud
Function: Set baud rate.
Format: AAhex/boxnode/54hex/byte4
ACU-1 page 6

Setting up the ACU-1 from the Front Panel
byte4: Baud Rate:
0 2400
1 4800
2 9600
3 14.4K
4 19.2K
5 28.8K
6 38.4K
7* 57.6K default value
8 115.2K
SetClock
Function: Set clock
Format: AAhex/boxnode/55hex/byte4/byte5/byte6/byte7
Byte4, byte5 and byte6 are hours, minutes and seconds
Byte7:
0 24 hour time
1 AM (12 hour time)
2 PM (12 hour time)
ReadClock
Function: Read clock
Format: AAhex/boxnode/56hex —replybyte1/replybyte2/replybyte3/replybyte4
Replybyte1, replybyte2 and replybytebyte3 are hours, minutes and seconds
Replybyte4:
0 24 hour time
1 AM (12 hour time)
2 PM (12 hour time)
3 clock not set
SetCalendar
Function: Set calender
Format: AAhex/boxnode/57hex/byte4/byte5/byte6
Byte4, byte5 and byte6 are month, day and year
ReadCalender
Function: Read calender
Format: AAhex/boxnode/58hex —replybyte1/replybyte2/replybyte3
Replybyte1, replybyte2 and replybytebyte3 are month, day and year
SetTCal
Function: Calibrate temperature sensor
Format: AAhex/boxnode/59hex/byte4
ACU-1 page 7

Setting up the ACU-1 from the Front Panel
If byte4 is 0, this is a read only function. Replybyte1 is the current calibration value.
If byte4 is 1 to 15, the value of byte4 is programmed as the calibration value (center range =8).
ReadTemp
Function: Read temperature
Format: AAhex/boxnode/5Ahex —replybyte1/replybyte2
Replybyte is temperature plus 100 degrees.
If replybyte1=0, sensor is defective or not installed.
Replybyte2 =Temp scale, 0 for Fahrenheit and 1 for Celsius
SetALC
Function: Set/read ALC (automatic level control) mode and speed
Format: AAhex/boxnode/5Bhex/byte4
Byte4:
0 read ALC mode (value returned in replybyte1)
1 set ALC off
2-255 set ALC on, 2 to 255 seconds per 1 dB gain increase
SetPiHold
Function: Set/read parallel input hold time
Format: AAhex/boxnode/5Chex/byte4
Byte4:
0 read only
6-255 0.06 to 2.55 seconds
SetPoTime
Function: Set/read relay momentary on time
Format: AAhex/boxnode/5Dhex/byte4
Byte4:
0 read only
6-255 0.06 to 2.55 seconds
SetConfig1
Function: Set Config1 byte.
Format: AAhex/boxnode/5Ehex/byte4
Byte4:
b0 panel switches 0/1=interlocked/alternate
b1 multiplex output 0/1=always/solo only
b2 autodaylight adjust 0/1=off/on
b3 temperature scale 0/1=Fahrenheit/Celsius
b4 VU mode 0/1=bar/dot
b5 -20/+1 VU markers 0/1=off/on
ACU-1 page 8

Setting up the ACU-1 from the Front Panel
b6 VU backlight 0/1=off/on
b7 alarm LED blink 0/1=off/on
ReadConfig1
Function: Read Config1 byte.
Format: AAhex/boxnode/5Fhex —replybyte1
SetConfig2
Function: Set Config2 byte.
Format: AAhex/boxnode/61hex byte4
Byte4:
b0 data mode 0/1=8E1/8N1
b1 ALC attack speed 0/1=normal/slow (firmware version 6 and later)
b2 unused
b3 unused
b4 unused
b5 unused
b6 unused
b7 unused
ReadConfig2
Function: Read Config2 byte.
Format: AAhex/boxnode/62hex —replybyte1
ReadFirm
Function: Read Firmware Version
Format: AAhex/boxnode/63hex —replybyte1
Note: Firmware version can also be read with the front panel switches and LEDs as described elsewhere in this
document.
ACU-1 page 9

Setting up the ACU-1 from the Front Panel
Errata
Setting baud rate from front panel; Firmware Version 6.
The following table shows the required data value at address 18 to set various baud rates for Firmware Version
6 only.
Baud Rate Address (decimal) Address (binary) Data (binary)
115.2K 18 00010010 00000000
57.6K 18 00010010 00000001
38.4K 18 00010010 00010000
28.8K 18 00010010 00000010
19.2K 18 00010010 00010001
14.4K 18 00010010 00000011
9600 18 00010010 00010010
4800 18 00010010 00010011
2400 18 00010010 00010100
For later firmware versions, use the table listed under SetBaud in the ACU Commands.
