MANUAL

TABLE BLUETOOTH SPEAKER

MODEL NO.: SXBT2500/SXBT2502

Warning Assemble Steps Assemble Steps Specifications

Function

Description of part

Wireless Charging

Automatic Power Off

Low Battery and Charging

Bluetooth Connection and Play

Call via Bluetooth

Volume Control

USB Charging

What is in the box

Main Body Qty 1

Power Cable Qty 1

Threaded Studs Qty 7

Spanner Qty 1 Plastic Cap Qty 7

EVA Pad

Spare Parts (if required)

Qty 4

‘D’ Nuts Qty 7 Nuts Qty 7

AC Power Adapter Qty 1 3.5mm Aux Cable Qty 1

Table Top Qty 1 Legs Qty 3

Legs Qty 1

Voice Reminding

Power On/Off

AUX Auto Switch

Thank you for purchasing SXBT2500/SXBT2502 Table Bluetooth Speaker,

in order to make the best use of this product and to use it safely, please

read the manual carefully before use and keep it for future reference.

1. The maximum bear weight of this product is 5Kgs, the consumers couldn't

put any item more than 5Kgs on this product, otherwise, the consumers will

bear the damage to this product by themselves.

2. This product couldn't be used as seat, no matter adult, or children, couldn't

sit on this product, otherwise, the consumers will have to bear by themselves

the damage to this product, and the damage to your health.

3. Please use the original A/C adapter for charging, if not, it may cause the

speaker to be charged slowly or cannot be charged at all. In extreme cases,

A/C adapter will be burned out or other accident occurred !

2.0CH Bluetooth Table Speaker

Bluetooth version: 4.2

Bluetooth transmit distance: Up to 10m

Bluetooth frequency: 2.402-2.480GHz

Drive units: 2.75” 3Ω 12W x 4pcs, Φ31mm 8Ω 20W x 2pcs

RMS: 30W (15W*2)

Frequency range: 90 Hz-18K Hz

S/N: > 75dB

Separation ratio: > 35dB

Working voltage: DC 16V 3A

USB Charging port: 5V 2.1A and 5V 1A

Wireless Charging: 5W (5V 1A)

Power Supply: AC adapter

Input: AC 100-240V ~ 50/60Hz 2A

Bluetooth

Hands free

Aux In

USB charger function

Wireless charger function

3. When speakers are team paired TWS mode successfully under Bluetooth,

the two speakers can still work as paired speakers by inserting the AUX cable

into the AUX socket on the first speaker (Master), the Master speaker will be

with green and blue LED light, the sub-speaker with Green LED light. TWS

mode will fail if Aux cable is inserted to the Aux socket on the second (linked)

sub-speaker.

4. Under TWS status, only the master speaker will with response, and pick up

the phone. The second speaker is without response.

After powering on the speaker without Bluetooth connection, or without LINE

IN signal, or disconnecting the Bluetooth after 10 minutes, the speaker will

power off automatically, the speaker will sound “POWER OFF”.

1. POWER ON: Connect the power supply (voice prompt when the speaker

turns on).

2. Bluetooth: Bluetooth mode

3. POWER OFF: Shut off the power supply (voice prompt when the speaker

turns off).

4. Bluetooth, waiting for connection: Pairing (enter Bluetooth mode / AUX,

and back to Bluetooth mode).

5. Bluetooth is connected: Pairing successfully, back to Bluetooth Mode

successfully again.

6. Bluetooth Disconnected, waiting for connection: switch off the connection

with the paired mobile phone or other device, long press the

【Play/Pause/Phone】to disconnect Bluetooth.

7. Maximum volume: Maximum volume level

8. Low Battery: The built-in battery need to be charged.

1. Long press【POWER/TWS】button, you can hear the audio of “Power On”

from the speaker, the speaker will enter Bluetooth mode as default, and give

voice of “Bluetooth, waiting for connection” prompt, then smart phone and

other devices can be paired with speaker.

2. Long press【POWER/TWS】button, the speaker will be turned off, you can

hear the voice of “Power Off” from the speaker prompt.

Insert the AUX cable into the AUX socket at the rear panel of the speaker, the

speaker will switch to AUX mode automatically, the blue and green LED light

will be on. The Bluetooth mode will be switched off directly.

After taking out the AUX cable, the Bluetooth mode will be switched on

automatically, then you can hear the voice of “Bluetooth, waiting for connection”

or “Bluetooth”.

1. When the speaker is in Bluetooth mode, it will automatically switch to

pairing status, the blue LED light will flash slowly, the Bluetooth device name

is “SXBT2500”/“SXBT2502”.

2. The speaker will pair with smart phone via Bluetooth, the speaker will

sound “Bluetooth is connected”after pairing, the blue LED light will be always

on. If failed, the blue LED light will flash slowly.

1. When a call comes in, the speaker will broadcast the incoming call’s phone

number and with sound of “dudu” or sound “cell phone rings” if connected with

Android smart phone. If connected with iPhone, it will broadcast the incoming

call’s phone number and sound “cell phone rings”. Shortly press the

【Play/Pause/Phone】button to answer the phone, speaker to the MIC, it will be

a clear call. Short press again to hang up, and long press to decline.

2. Double press the【Play/Pause/Phone】button for dialing the phone number

of the last call in record.

1. Press【+】button to increase the volume

2. Press【-】button to decrease the volume

When the speaker is powered on, or connected with A/C adapter, the USB

ports (2.1A / 1A) can charge iPhone and other Android mobile phone at the

same time, when the speaker is turned off, the USB port cannot charge any

external devices.

If the speaker is connected via the A/C adaptor, even the speaker is turned

off, the USB ports (2.1A / 1A) can charge iPhone and other Android mobile

phone at the same time.

The charging coil of the wireless charging devices (The mobile phone which

can support Qi standard of wireless charging) need to aim at the wireless

charging mark which in the middle of the table speaker, when the speaker

power on or connected with A/C adapter, you can see the charging mark from

your mobile phone or with a sound of “Di” after connecting with the devices for

wireless charging.

1. When the battery capacity is low, the speaker sound “Low Battery” prompt

to remind the user that the speaker need to be charged; If the user does not

charge, the speaker will be automatically powered off.

2. After connecting A/C adapter to DC port on the back of the speaker, the red

LED light will be illuminated while charging, the red LED light will turn off

when the speaker is fully charged Caution: The LED light is Red for one

second after connecting with A/C adapter, then the LED light turn off, it

means the built-in battery is full charged, it is normal phenomenon.

TWS Function

TWS feature allows you to link two speakers together. The first table will be

the master connected to the Bluetooth device and operate all controls. The

second table is a linked speaker giving True Wireless Sound.

1. Turn on both table speakers, double click 【POWER/TWS】on one of the

two table speakers, both speakers will enter team paring mode, you will hear

an acoustic signal, both blue LED indicator of both table speakers will flash

rapidly at the same time. After the team paring, the LED indicator of first

speaker (Master) will remain flash slowly, the LED of second speaker (Sub-

speaker) (linked TWS) will be green. After connecting with phone or other

Bluetooth devices, the Master speaker LED will be Blue stably, the sub-

speaker keep stable Green LED.

2. When speakers are team paired successfully, short press 【POWER/TWS】

of master speaker or sub-speaker to switch Off the team pairing TWS mode.

BA C

D E F

Step 1: Take leg ③ and

legs ④ to assemble with

threaded studs Ainto

the hole.

Step 6: Assemble main

body /legs into the table

top ②.

Step 7: Screw the fixings

Band Cto the holes on

the legs as shown.

Step 8: Use spanner Dto

tighten all fixings fully.

Step 9: Use plastic caps

Eto cover the fixings

holes in the legs and

tops.

Step 2: Put the main

body ①upside down

onto a clean flat surface.

Take one leg ③ g

assembly with threaded

studs Ato the main body

①.

Step 3: Fix Band Cto

the main body ①as

shown.

Step 4: Assemble the

left three legs ④to main

body ①with the same

procedure as step 2 and

step 3.

Step 5: Place table top②

upside down onto a

clean flat surface. Screw

threaded studs Ainto

the holes in the table top

②.

1 2 3 4

1. POWER / TWS

2. PLAY / PAUSE / PHONE

3. VOLUME-

4. VOLUME+

5. MIC

6. LED

7. USB PORTS: 5V 2.1A/ 5V 1A

8. CHARGING LED LIGHT

9. DC IN

10. AUX

11. RESET

12. WIRELESS CHARGING DOCK (Optional)
