SINOX one SWB7310 User manual

7To avoid TV falling, anti-fall wire rope should be installed.
P-E
P-F
P-E
To avoid TV falling, anti-fall wire rope should be installed.
X
400-650mm
1100-1350mm
P-C
40mm
(1.6”)
Ø3.5mm
(Ø1/8”)
P-B
P-A
P-A
P-D
P-B
P-A
P-A
P-D
400-650mm
1100-1350mm
P-C
40mm
(1.6”)
Ø7mm
(Ø9/32”)
Use with products heavier than the rated weights indicated may result in instability causing possible injury.
Please closely follow the assembly instructions. Improper installation may result in damage or serious personal injury.
Safety gear and proper tools must be used. This product should only be installed by professionals.
Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.
Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws.
This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.
This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.
Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, contact your place of
purchase for a replacement.
Check that the product is secure and safe to use at regular intervals (at least every three months).
Læs hele instruktionsmanualen før du begynder at installere og samle produktet. Hvis du har spørgsmål omhandlende nogle af instruktionerne elle advarslerne, bedes du venligst kontakte din
lokale forhandler for assistance.
ADVARSEL: Brug af produkter tungere end hvad er angivet, kan resultere i ustabilitet, hvilket muligvis kan forårsage personskade.
• Følg venligst samlingsinstruktionerne grundigt. Samles produktet forkert, kan det resultere i beskadigelse af produktet eller alvorlig personlig skade.
• Sikkerhedsudstyr og egnet værktøj er nødvendigt. Dette produkt burde kun blive installeret af professionelle.
• Vær sikker på, at den støttende overflade sikkert understøtter udstyrets samlede vægt.
• Brug de medfølgende monteringsskruer og LAD VÆRE MED AT STRAMME MONTERINGSSKRUERNE FOR HÅRDT.
• Dette produkt indeholder små dele. De kan være en kvælningsfare, hvis de bliver slugt. Hold disse små dele væk fra børn.
• Dette produkt er kun tiltænkt indendørs brug. At bruge dette produkt udendørs, kan beskadige produktet og føre til personlig skade.
VIGTIGT: Sørg for at du har modtaget alle dele på checklisten, inden du starter installationen. Hvis nogle af delene skulle mangle eller være ødelagte, bedes du venligst kontakte indkøbsstedet
for en erstatning.
VEDLIGEHOLDELSE: Kontroller, at produktet er fast og sikkert at bruge, med jævne mellemrum (mindst hver tredje måned).
DK
INSTALLATION MANUAL
Easel Studio TV Floor Stand
40kg
(88.2lbs)
RATED
70”
MAX
SWB7310
200x200
300x200 300x300
400x200 400x300
400x400 600x400
Sinox Europe A/S
Troensevej 11. DK-9220 Aalborg

1
6
A (x1)
P-A (x1)
Safety Disclaimer
This product includes an anti-tip kit that must be used in conjunction with the product and will prevent the product falling or tipping over. Please follow the enclosed
information to properly install these safety accessories. In no event shall the Seller be liable for any direct, indirect, punitive, incidental, special consequential damages, to
property or life, whatsoever arising out of or connected with the use or misuse of this product.
Make sure the cable clips (P-B) are attached to the
upper bracket for the following security installation.
Make sure the cable clips (P-B) are attached to the
upper bracket for the following security installation.
Too Long Too Short
Too Long Too Short
P-B (x2) P-C (x2)
M-A
P-G
P-B
M-F
M-C
M-D
P-B
M-F
M-C
M-D
M-F
M-G
M-H
M-G
M-H
M-G
M-H
M-E
M-F
M-G
M-H
M-E
P-B
M-F
M-A
M-F
M-B
M-F
M-B
P-B
M-F
P-D (x1)
2mm
P-E (x4) P-F (x4) P-G (x2)
E (x1) F (x6)
B (x4)
G (x6) H (x1)
4mm
C (x2) D (x1)
M-A (x4)
M5x14
M-C (x4)
M6x30
M-E (x4)
M8x50 M-F (x4)
M-G (x8) M-H (x8)
M-D (x4)
M8x30
M-B (x4)
M6x14
A
B
2
3
4
C
E
E1
H
G
E1
F
5
D
E
D
E
Recommended 50-150mm
Note:
∙Please secure the locking collar
before attaching the TV screen.
∙Make sure the screw holes face
backwards.
