SIP Fireball Turbo-Fan 9000 User manual

16
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR
SIP DIRECTLY ON:
TEL: 01509500400
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Ref: 270614
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
1
Fireball
Turbo-Fan 9000
09293
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.

2
15
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
Fireball Turbofan 9000 - SIP Pt. No. 09293
Conforms to the requirements of the following directive(s), as indicated.
2006/95/EC Low Voltage Directive
2004/108/EC EMC Directive
2011/65/EU RoHS Directive
And the following harmonised standard(s)
EN 60335-2-30:2009+A11:2012
EN 60335-1:2012
EN 62233:2008
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-3:2013
EN 62321:2009
Signed: …………………………………...
Mr P. Ippaso - Director - SIP (Industrial Products) Ltd
Date: 08/05/2014.
DECLARATION OF CONFORMITY

14
Ref. No. Description Sip Part No. Ref. No. Description Sip Part No.
1. Grill Cover PW09-10360 18. Switch Knob PW09-10377
2. Grill Cover Screw PW09-10361 19. Protection Ring PW09-10378
3. Grill PW09-10362 20. Cable Gland PW09-10379
4. Nut (M5) PW09-10363 21. Relay PW09-10380
5. Bolt (M5x12) PW09-10364 22. Relay Bracket PW09-10381
6. Heating Element PW09-10365 23. Fan 250mm PW09-10382
7. Inner Casing PW09-10366 24. Fan Motor PW09-10383
8. Thermostat Time Delay 45˚PW09-10367 25. Screw (M4 x 12) PW09-10384
9. Thermostat 85˚PW09-10368 26. Fan Motor Bracket PW09-10385
10. Thermostat Bracket PW09-10369 27. Handle / Frame Insert PW09-10386
11. Grommet PW09-10370 28. Foot PW09-10387
12. Outer Casing PW09-10371 29. Adjustment Angle Knob PW09-10388
13. Handle / Frame PW09-10372 30. Rivet PW09-10389
14. Handle Grip PW09-10373 31. Mains Lead PW09-10390
15. Terminal Box PW09-10374 32. Casing Bracket PW09-10391
16. On / Off / Mode Switch PW09-10375 33. Heating Element Bracket PW09-10392
17. Output Selector Switch PW09-10376
PARTS LIST
3
CONTENTS
Page No. Description
3. Contents
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
7. Electrical Connection
8. Guarantee
9. Technical Specifications
10. Getting To Know Your Heater
11. Operating Instructions
12. Maintenance
13. Exploded Drawing
14. Parts List
15. Declaration Of Conformity

4
When using your heater, basic safety precautions should always be followed to re-
duce the risk of fire, electric shock, personal injury and / or damage to the heater.
Read all these instructions before operating the heater and save this user manual for
future reference.
SIP recommends that this heater should not be modified or used for any application
other than that for which it was designed. If you are unsure of its relative applications
do not hesitate to contact us and we will be more than happy to advise you.
KNOW YOUR HEATER: Read and understand the owner's manual and labels affixed to
the heater. Learn its applications and limitations, as well as the potential hazards spe-
cific to it.
DO NOT USE THE HEATER IN DANGEROUS ENVIRONMENTS: Do not use your heater in
damp or wet locations, or expose it to rain. Always provide adequate space around
the heater.
DO NOT OPERATE THE HEATER IN EXPLOSIVE ATMOSPHERES: Do not use the heater in the
presence of flammable liquids, gases, dust or other combustible sources.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area.
STORE THE HEATER SAFELY WHEN IT IS NOT IN USE: The heater should be stored in a dry,
locked cupboard, or similar when not in use wherever possible and out of the reach of
children.
STAY ALERT: Always watch what you are doing and use common sense.
DISCONNECT THE HEATER FROM THE MAINS SUPPLY: When not in use.
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the heat-
er.
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
13
EXPLODED DRAWING

12
Before cleaning or maintenance operations always turn the thermostat to zero and run
the heater for a short while to allow it to cool.
Turn the heater off and remove the plug from the mains supply.
Clean the heater with a soft dry cloth only.
DO NOT use abrasives or solvents.
Periodically check the heater grill to ensure that it is not blocked.
Note: Dry compressed air could be used to blow away any dust etc. that may build
up inside the turbofan 9000.
Caution: Whilst using compressed air, dust and / or other particles may become air
borne; carry out the operation in a well ventilated area and use the appropriate eye
and ear protection and a dust mask.
No other maintenance is necessary.
DO NOT dismantle or tamper with the heater, as this may be dangerous and will invali-
date the warranty.
If a problem with the heater is experienced, or if the mains lead or plug become
damaged, contact your distributor for repair.
When you store the heater, let it cool down, ensure that it is dry, cover with a plastic
bag, put in a packing box and store it in a dry, ventilated place.
MAINTENANCE
5
AVOID UNINTENTIONAL STARTING: Make sure the switch is in the OFF position before
connecting the heater to the mains supply.
DO NOT ABUSE THE MAINS LEAD: Never carry the heater by the mains lead or pull it to
remove the plug from the mains socket. Keep the mains lead away from heat, oil and
sharp edges. If the mains lead is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid unwanted hazards.
HAVE YOUR HEATER REPAIRED BY A QUALIFIED PERSON: The heater is in accordance
with the relevant safety requirements. Repairs should only be carried out by qualified
persons using original spare parts, otherwise this may result in considerable danger to
the user.
DANGER! Check that the heater is in sound condition and good working order. Take
immediate action to repair or replace damaged parts.
Use recommended parts only - Unapproved parts may be dangerous and will invali-
date the warranty.
WARNING! Do not direct the front of the heater towards any combustible materials
(e.g. wooden items, cloth, plastics, paper, etc).
Only operate on a level and stable surface.
WARNING! Do not use the heater near flammable material, liquids, solids, gases or
compressed gas cylinders.
Do not allow untrained persons to operate the heater and do not operate the heater
without all covers etc. correctly fitted.
Do not move or handle the heater when it is running or still hot - always turn it off and
allow it to cool.
Do not leave the heater unattended when in use. Switch the heater off and unplug
from the mains supply before leaving the work area.
Do not obstruct the air inlet (rear) and air outlet (front) of the heater.
Do not use any form of ducting in front or at the rear of the heater.
Do not allow children or animals near the heater, particularly when in use, or while still
hot.
WARNING! RISK OF ELECTRIC SHOCK. Do not expose the heater to water spray, rain,
dripping water or moisture of any kind.
Do not touch the heater outlet or any internal parts when first switched off as these
can be hot and will take time to cool.
Ensure that the heater is correctly turned off when not in use and store in a safe, dry
area, out of reach of children.
Do not unplug the heater to switch it off - always use the on/off switch.
NEVER use this heater where flammable vapours may be present.
Keep all combustible materials away from this heater.
When using the heater for the first time, you may notice a slight emission of smoke, or
a slight burning smell. This is normal and will stop after a short time. The heating ele-
ment is made of stainless steel and was coated with protection oil during produc-
SAFETY INSTRUCTIONS….cont

6
tion. The smoke / smell is caused by any small residue of this oil which was left on
the element.
NEVER block air inlet (rear) or air outlet (front) of heater.
NEVER move or handle heater while still hot.
ALWAYS locate heater on a stable and level surface.
ALWAYS keep children and animals away from heater.
Only use the heater in an upright position
Never stand on the heater
Never connect any other electrical appliances to the same socket as the heater.
DO NOT dismantle or tamper with the heater, as this may be dangerous and will in-
validate the warranty.
If a problem with the heater is experienced, or if the mains lead or plug become
damaged, contact your distributor for repair.
WARNING: Risk of Electric Shock!
Use only the electrical power (voltage and frequency) specified on the model plate
of the heater.
Use only a three-prong, grounded outlet.
ALWAYS unplug the heater when not in use.
SAFETY INSTRUCTIONS….cont
CAUTION: The warnings and cautions mentioned in this user manual can not
cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which can-
not be built into this product, but must be applied.
Note: If the heater is to used in a place of work, all rules and laws etc. relat-
ing to the use of portable electrical appliances should be followed.
11
Position the fan heater so that it stands upright on a firm surface and at a safe
distance from wet environments and flammable objects / materials.
Connect the heaters plug to a correctly rated supply.
Select the desired mode - either heater (2 settings) or just fan.
Select the desired temperature.
Once the room reaches the required temperature, the heating element will stop work-
ing but the fan will continue to run. Once the temperature has decreased enough,
the heating element will resume operation.
The Turbofan 9000 heater now starts and stops automatically and thus keeps the room
temperature constant.
After operation; set the thermostat to zero and run the heater for a short while to allow
it to cool.
On / Off / Mode selection switch
Temperature selection
OPERATING INSTRUCTIONS

10
GETTING TO KNOW YOUR HEATER
A
B
C D E F
G
H
H
G D E G
I
Ref. Description Ref. Description
A. Front Grill / Heat Outlet F. Rear Grill / Inlet
B. Elements G. Tilt Locking Knob
C. Carrying Handle / Frame H. Rubber Feet
D. On / Off / Mode Selection Knob I. Mains Lead
E. Temperature Selection Knob
7
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit Breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current
Device (RCD) is used. It is particularly important to use an RCD with portable products
that are plugged into a supply which is not protected by an RCCB. If in any doubt
consult a qualified electrician.
Connecting to the power supply:
This SIP heater is fitted with a 3 phase plug (3 phases and earth) and has a fuse rating
of 13 amps. Before using the heater, inspect the mains lead and plug to ensure that
neither are damaged. If any damage is visible have the heater inspected / repaired
by a suitably qualified person. If it is necessary to replace the plug a heavy duty im-
pact resistant plug would be preferable.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Black Live/Phase
Grey Live/Phase
Brown Live/Phase
ELECTRICAL CONNECTION

8
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always
use a 13 amp fuse.
This SIP heater is covered by a 12 month parts and labour warranty covering failure
due to manufacturers defects. This does not cover failure due to misuse or operating
the heater outside the scope of this manual - any claims deemed to be outside the
scope of the warranty may be subject to charges Including, but not limited to parts,
labour and carriage costs, failure to regularly clean your heater will shorten its working
life and reduce performance.
GUARANTEE
Note: Proof of purchase will be required before any warranty can be hon-
oured.
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating.
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops
Warning: Never connect live/phase wires to the earth terminal of the plug.
Only fit an approved plug and the correct rated fuse. If in doubt consult
a qualified electrician.
ELECTRICAL CONNECTION….cont
9
Top - 500 mm
Minimum Clearance Around
Heater
Sides - 500 mm
Rear - 750 mm
Front - 1800 mm
Part Number 09293
Input Voltage 380v - 400v ~ 50Hz
Power 9000 Watts
Fuse Rating 13 Amps
Settings - Fan 52 watts
Settings - Heat 1 4500 watts
Settings - Heat 2 9000 watts
protection IPX4
Heater Dimensions (HxWxD) 470 x 410 x 340 mm
Net Weight 11.4 Kg
TECHNICAL SPECIFICATIONS
This manual suits for next models
1
Table of contents
Other SIP Fan manuals
Popular Fan manuals by other brands

Rubine
Rubine SETTE Series user manual

Pinnacle Climate Technologies
Pinnacle Climate Technologies MASTER INDUSTRIAL MHD-24W User's manual & operating instructions

Matsui
Matsui MTF3613RE instruction manual

Trane
Trane 4TXCB003CC3HCB Installer's guide

Bionaire
Bionaire BWF0522M-CN Instruction leaflet

AERMEC
AERMEC FCX-P Series Use and installation manual
