SIP 03688 User manual

16
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
Ref: 061114
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip and
place into the appropriate recycling bin.
3.25 Ton
Heavy Duty Floor Jack
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
03688

2
15
DECLARATION OF CONFORMITY
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
3.25 Ton Heavy Duty Floor Jack - SIP Part No. 03688
Conforms to the requirements of the following directive/s, as indicated.
2006/42/EC Machinery Directive
Signed: …………………………………...
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 27/12/2013.
And The Relevant Harmonised Standard/s, including
EN 1494+A1:2008

14
PARTS LIST
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Piston adaptor HY01-00340 24. Lock washer HY01-00363
2. Roller pin HY01-00341 25. Screw HY01-00364
3. Spring HY01-00342 26. Screw HY01-00365
4. Ram HY01-00343 27. Lock nut HY01-00366
5. C-clip HY01-00344 28. Castor HY01-00367
6. Flat plate HY01-00345 29. Lock washer HY01-00368
7. Front wheel HY01-00346 30. Nut HY01-00369
8. Body frame HY01-00347 31. Handle limiting bar HY01-00370
9. Adjust plate HY01-00348 32. C-clip HY01-00371
10. Lock nut HY01-00349 33. Limiting ring HY01-00372
11. Screw HY01-00350 34. Handle limiting bar (short) HY01-00373
12. C-clip HY01-00351 35. Tool tray HY01-00374
13. Lifting arm HY01-00352 36. Bolt HY01-00375
14. C-clip HY01-00353 37. C-clip HY01-00376
15. Saddle HY01-00354 38. Pin HY01-00377
16. Nut HY01-00355 39. Roller HY01-00378
17. Rubber pad HY01-00356 40. Handle base HY01-00379
18. Nut HY01-00357 41. Handle base screw HY01-00380
19. Lock washer HY01-00358 42. Lower handle HY01-00381
20. Lifting shaft HY01-00359 43. Handle cover HY01-00382
21. Oil cup HY01-00360 44. Upper handle HY01-00383
22. Lock washer HY01-00361 45. Handle screw HY01-00384
23. Bolt HY01-00362 46. C-clip HY01-00448
3
CONTENTS
Page No. Description
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
6. Guarantee
7. Technical Specifications
8. Getting to Know Your Jack
8. Operating Instructions
10. Maintenance
12. Troubleshooting
13. Exploded Drawing
14. Parts List
15. Declaration of Conformity

4
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
SAFETY INSTRUCTIONS
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Note: Supplementary information.
When using your jack, basic safety precautions should always be followed to reduce
the risk of personal injury and / or damage to the jack or load.
Read all of these instructions before operating the jack and save this user manual for
future reference.
The jack should not be modified or used for any application other than that for which
it was designed.
The jack was designed for safely lifting loads up to its rated capacity.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
Before operating the jack always check no parts are broken, that no oil is leaking and
that no parts are missing.
Always operate the jack safely and correctly.
KNOW YOUR JACK: Read and understand the owner's manual and labels affixed to
the jack. Learn its applications and limitations, as well as the potential hazards specific
to it.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area; never allow untrained persons
to operate the jack.
STAY ALERT: Always watch what you are doing and use common sense.
NEVER LEAVE THE JACK UNATTENDED: When in use / under load.
HAVE YOUR JACK REPAIRED BY A QUALIFIED PERSON: The jack is in accordance with
the relevant safety requirements. Repairs should only be carried out by qualified per-
sons using original spare parts, otherwise this may result in considerable danger to the
user and void the warranty.
DANGER! Check that the jack is in sound condition and good working order before
each use; Take immediate action to repair or replace damaged parts.
Important: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the trolley
jack.
13
EXPLODED DRAWING

12
TROUBLESHOOTING
Symptom Possible Causes Corrective Action
Jack will not lift load Release valve not tightly closed
Load is too heavy
Ensure release valve tightly closed
Consider higher capacity jack
Jack will lift, but not
maintain pressure
Release valve not tightly closed
Hydraulic unit malfunction
Ensure release valve tightly closed
Discontinue use, contact supplier
Jack will not lower after
unloading
Reservoir overfilled
Linkages binding
Fluid level low
Drain fluid to proper level
Clean and lubricate moving parts
Ensure proper fluid level
Fluid level low
Air trapped in system
Ensure proper fluid level
With ram fully retracted, remove oil
fill plug/screw to let pressurized air
escape. Reinstall oil fill plug/screw.
Poor lift performance
Will not lift to full extension Fluid level low Ensure proper fluid level
5
SAFETY INSTRUCTIONS….cont
WARNING! Only operate on a level and stable surface and never use on soft ground
where the jack is likely to “sink” whilst in operation.
NEVER STAND ON THE JACK: The jack is not designed for this purpose.
DO NOT dismantle or tamper with the jack, as this may be dangerous and will invali-
date the warranty.
ALWAYS ensure the load is central on the saddle.
If a problem with the jack is experienced or suspected stop using the jack immedi-
ately and contact your distributor for repair.
Do not attempt to lift a load that exceeds rated capacity of the jack.
Do not attempt to lift a load beyond the maximum height of the jack.
This jack is a lifting device only.
Immediately after lifting, support the load with a pair of appropriately rated jack
stands.
Never work on, under or around a load supported only by the jack.
Regularly inspect and lubricate the jack, ensuring that it is in good working order and
condition.
Always ensure that the work area is clean and tidy, free from unrelated materials and
has adequate lighting.
When lifting a vehicle ensure a minimum distance of 0.5m between vehicle and
static objects such as doors, walls, etc. to allow for tilting during jacking.
Ensure that all persons are out of the vehicle before jacking.
DO NOT enter the vehicle whilst it is supported on the jack or axle stands.
Check vehicle weight and recommended lifting points by referring to the vehicle’s
manual. Ensure that the lifting point is not corroded.
DO NOT allow the vehicle to move, or try to start the engine, during jacking.
DO NOT start the engine when vehicle is jacked up.
DO NOT jack a vehicle if this may result in the spillage of fuel, battery acid, or other
dangerous substances.
Check that the jack saddle is centred and stable on the lifting point (off-centre loads
can slip).
Position the jack to avoid operating it from under vehicle.
Keep hands, limbs etc. clear of moving parts during the raising and lowering of the
vehicle.
DO NOT top-up the jack with brake fluid, or other oil types; use only hydraulic oil.
DO NOT adjust the safety overload valve.
Ensure that there are no persons or obstructions beneath the load before lowering.
Clean and stow the jack correctly, with the ram in the down position, do not leave it
extended; ensure storage area is dry.
IMPORTANT! Ensure that you can see the saddle and jacking point throughout the
jacking operation in case there is any relative movement.
Failure to follow the warnings in this manual, may result in personal injury and/or prop-
erty damage.

6
SAFETY INSTRUCTIONS….cont
Danger: Never load a weight greater than what the jack was designed
for, overloading can lead to personal injury or damage to the jack.
Danger: Never use the hydraulic jack to hold the load; after
lifting, immediately support the lifted vehicle with a pair of
appropriately rated jack stands.
Caution: The warnings and cautions mentioned in this user manual can not cover all possible
conditions and situations that may occur. It must be understood by the operator that common
sense and caution are factors which cannot be built into this product, but must be applied.
GUARANTEE
This SIP hydraulic jack is covered by a 24 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the jack outside the scope of this manual - any claims deemed to be outside
the scope of the warranty may be subject to charges Including, but not limited to
parts, labour and carriage costs.
This guarantee does not cover consumables such as rubber pads and oil etc.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
11
MAINTENANCE….cont
Note: Contact your local authority on how / where to dispose of the waste
oil.
If air gets into the hydraulic system the jack will not operate correctly and will need to
be bled. To bleed air from the hydraulic system, follow the instructions below.
BLEEDING
1. Open the release valve by turning the handle counter-clockwise.
2. Pump the handle a minimum of four full strokes quickly.
3. Close the release valve by turning the handle clockwise.
4. Pump the handle with full strokes to check if it can reach the maximum height
within ten pumps.
If it does not reach the maximum height within ten pumps, please refer to the follow-
ing special purging process:
1. Open the release valve by turning the handle counter-clockwise and lower the
lifting arm to the minimum height.
2. Place the jack on a flat working table and lift the front part of the jack to ensure
the front of the jack is at least 500mm higher than the rear of the jack.
3. Pump the handle a minimum of four full strokes quickly.
4. Place the jack on a flat surface and close the release valve by turning the han-
dle clockwise.
5. Pump the handle with full strokes to check if it can reach the maximum height
within ten pumps, if not please repeat the special purging process.
Caution: Due to the weight of the jack, at least 2 persons are required to
complete this operation.

10
1. Ensure that the jack is placed on a level surface.
2. Lower the saddle to its lowest position (turn the handle anti-clockwise).
3. Loosen (do not remove) the 4 cap head bolts that hold the service cover on and
remove the cover.
4. Remove the oil filler bung from the oil reservoir.
5. Check the oil level; The level should be no more than 13mm from the top of the
reservoir - Top up with high quality hydraulic oil if required.
6. Refit the oil filler bung.
7. Wipe away any excess oil.
8. Fit the service cover and retighten the 4 cap head bolts.
ADDING OIL
MAINTENANCE
OIL CHANGE
For the best performance and longest life, completely change the oil at least once
per year. Always dispose of hydraulic oil in accordance with local regulations.
1. Lower the saddle to its lowest position (turn the handle anti-clockwise).
2. Loosen (do not remove) the 4 cap head bolts that hold the service cover on and
remove the cover.
3. Loosen and remove the cap head bolt that holds the oil reservoir in position (see
below, left).
4. Pull up and remove the oil reservoir.
5. Remove the oil filler bung and invert the reservoir over a suitable collection con-
tainer, so that the oil filler hole is at the bottom of the reservoir.
6. Press the oil valve whilst ensuring that you do not fully cover the hole (see below,
right).
Note: Do not touch or use the handle when filling with oil.
Oil Valve
Oil Filler Bung
Cap Head Bolt
Oil Reservoir
7
TECHNICAL SPECIFICATIONS
Lifting capacity 3.25 Ton
A. Depth 730 mm
B. Minimum Height 95 mm
C. Maximum Height 520 mm
D. Saddle 120 mm
E. Width 370 mm
D
E
C
B
A

8
Inspect before each use. Do not use if broken, bent, cracked or damaged parts are
noted. Any jack that appears damaged in any way, or operates abnormally should
be removed from service immediately. If the jack has been or is suspected to have
been subjected to a shock load (a load dropped suddenly, unexpectedly upon it),
immediately discontinue use until the jack has been checked by an authorised ser-
vice centre / agent (contact distributor or manufacturer for list of authorised service
centres). It is recommended that an annual inspection be done by a qualified per-
son/s.
OPERATING INSTRUCTIONS
GETTING TO KNOW YOUR JACK
PRE-OPERATION CHECKS
Handle base screw
Lifting arm
Front wheel
Rear castor
Rubber Pad
Handle base
Service Cover
Handle
Saddle
9
OPERATING INSTRUCTIONS….cont
LOWERING THE JACK
1. Push the top handle into the lower handle, use the handle screw to secure both
parts together.
2. Insert the handle into the handle base and secure using the handle base
screw.
3. Close the release valve by turning the handle clockwise until firm resistance is
felt.
4. Locate the lifting point, centre the jack saddle under the lifting point.
5. Pump the handle to contact the lifting point; continue to pump the handle until
the load reaches the desired height.
6. Transfer the load immediately to appropriately rated jack stands.
1. Raise the load high enough to allow it to clear the jack stands.
2. Carefully remove the jack stands.
3. Slowly turn the handle anti-clockwise to open the release valve - Never turn the
handle more than ½ a turn at a time.
4. Allow the load to slowly lower to its original position.
5. Remove the jack from under the vehicle.
Caution: Take care when lowering the jack that nothing can get trapped
in the moving parts of the jack, or under the load.
Note: Follow the vehicle manufacturer’s recommended guidelines for lift-
ing. Engage the emergency brake and chock each un-lifted wheel in both
directions to prevent inadvertent vehicle movement.
Note: Refer to the vehicle manufacturer owner’s manual to locate ap-
proved lifting points on the vehicle.
Note: After removing the jack from under the vehicle, fully lower the saddle
to reduce ram exposure to contamination.
Never use the hydraulic jack as a stand alone device! always trans-
fer the lifted load immediately to a pair of appropriately rated jack
stands. Use one pair of jack stands per vehicle. Do not exceed the
rated capacity.
