Nussbaum UNI-LIFT 2500 Operator's manual

UNI-LIFT 2500
Automotive-Lift date: 04/2006
Manual Datum: 24.04.2006
Operating Instruction and Documentation
Serial-number: ........................................
Nußbaum Hebetechnik GmbH & Co.KG//Korker Straße 24//D-77694 Kehl-Bodersweier//Tel: [phone]
Fax: [phone]//E-mail: in[email protected]//http://www.nussbaum-lifts.de
Retailer/Phone
UNI 2500 E 04-06.doc

Operating Instruction and Documentation
UNI-LIFT 2500
- 2 -
Table of content
Foreword ................................................................................................................. 3
Record of installation............................................................................................... 5
Record of handing over ........................................................................................... 6
1.Introduction.............................................................................................................. 7
1.1 Installation and check of the automotive lift....................................................... 7
1.2 Information of Warning ...................................................................................... 7
2.Master document of the automotive lift.................................................................... 8
2.1 Lift–manufacturer............................................................................................... 8
2.2 Application......................................................................................................... 8
2.3 Changes at the construction............................................................................. 8
2.4 Displacement of the automotive-lift.................................................................... 8
2.5 Page for notice .................................................................................................. 9
3. Technical information............................................................................................ 10
3.1 Technical ratings ............................................................................................. 10
3.2 Safety devices ................................................................................................. 10
3.3 Data sheet....................................................................................................... 11
4. Safety regulations................................................................................................. 12
5. Operating instructions........................................................................................... 12
5.1 Lifting the vehicle............................................................................................. 12
5.2 Lowering the vehicle........................................................................................ 13
5.3 Equalisation of the rails.................................................................................... 13
6. Troubleshooting.................................................................................................... 14
6.1 Driving on an obstacle..................................................................................... 14
6.2 Emergency lowering........................................................................................ 15
7. Inspection and Maintenance................................................................................. 16
7.1 Maintenance plan of the lift.............................................................................. 16
7.2 How often must the lift be cleaned?................................................................. 17
8. Security check ................................................................................................... 18
9. Installation and Initiation....................................................................................... 19
9.1 Regulations for the installation......................................................................... 19
9.2 Erection and doweling of the lift....................................................................... 19
9.3 Initiation........................................................................................................... 20
9.4 Changing the installation place........................................................................ 20
9.5 Initiation........................................................................................................... 25
9.6 Change of lift location...................................................................................... 25
First security check before installation................................................................... 27
Regular security check and Maintenance.............................................................. 28
Extraordinary security check.................................................................................. 36
Electrical diagram drawing.................................................................................... 37
Hydraulic diagram drawing.................................................................................... 44

Operating Instruction and Documentation
UNI-LIFT 2500
- 3 -
Foreword
Products of Nußbaum are results of experience of many years.
The high quality and the superior concept guarantee them reliability, a long lift time and the
economic business. To avoid unnecessary damages and dangers, read the operating instruction
attentive and observe the contents. Another or the described purpose going out use is not valid when
not as agreed. This is valid particularly for climb and go.
Company Nußbaum is not liable for damages arising from this. The user carries the risk a lonely.
For the use belonged:
- to observe all the notice in the operating instruction and
- the following of the inspection and maintenance work and the prescribed tests.
- The instruction for use have to be observed by all persons working with the lift.
- Especially the chapter “Safety/accident Prevention“ has to be observed.
- In addition to the safety remarks of the instructions for use the regulations and
instructions being valid at the place of operation have to be considered.
Obligations of the operator:
The operator is obliged to allow only those persons complying to the following requirement to work at
the unit
- being well acquainted with the basic regulations concerning labour safety and accident
prevention and being trained to operate the unit.
- having read and understood the chapter concerning safety and warning instructions and
confirmed that by their signature.
Dangers when operating with the lift:
The Nußbaum-Lifts are designed and built according to technical standard and the approved
regulations for technical security. Yet, danger for body and life of the operator may turn up when using
the lift inexpertly.
The lift must only be operated :
- for its appropriate use
- in unobjectionable condition concerning technical security.

Operating Instruction and Documentation
UNI-LIFT 2500
- 4 -
Organising requirements
- The instructions for use are constantly to be kept at the place of operation being at hand
at any time.
- In addition to the instructions for use rules pertaining to other regulations i.e. accident
prevention and environmental rules are to be observed and directed.
- Safety- and danger alert operation of personal is occasionally and by observing the
instructions for use to be controlled.
- As far as required and ordered by regulations personal protective equipment is to be
used
- All safety- and danger-hints at the lift are to be observed!
- Spare parts must comply with technical requirements laid down by the manufacturer.
This is only warranted with original parts.
Consider time intervals given or fixed in instructions for use for repeated
tests/inspections.
Maintenance works, remedy of faults and disposal
- Fixed Adjusting-, maintenance- and inspection works and time intervals including
Details for exchange of parts/part components as mentioned in the instructions for use are to be
adhered.
These works must only be carried out by expert personal.
- After maintenance- and repair works loose screw connections must always be firmly
tightened!
Guarantee and liability
- Our „General conditions of selling and delivering“ are in force.
There will be no guarantee or liability for injuries of persons or things if these injuries are caused
by one or by some of the following reasons.
- Inappropriate use of the lift
- Inappropriate installation, initiation, operation and maintenance of the lift.
- Use of the lift while one or several security devices do not work or do not work correctly or are
not installed correctly.
- Not to follow the regulations of the operating instruction concerning transport, storing,
installation, initiation, operation and maintenance of the lift.
- Changes of the construction of the lift without asking the producer.
- Changes of important adjustments of the lift (e.g. driving elements, power rating, motor speed,
etc)
- Wrong or incorrect maintenance.
- Catastrophes, acts of God or external reasons.

Operating Instruction and Documentation
UNI-LIFT 2500
- 5 -
Fill out, undersign and copy this sheet and send the original to the lift manufacturer.
The copy remains in the manual.
Otto Nußbaum Hebetechnik GmbH & Co. KG
Korker Straße 24
D-77694 Kehl-Bodersweier
Record of installation
The automotive lift UNI-LIFT 2500 with the
serial number:............................................ was installed on:...............................................
at the firm:................................................. at:.....................................................................
the safety was checked and the lift was started.
The installation was effected from the operating authority/competent (please delete as applicable).
The safety of the automotive lift was checked from the competent before the initial operation.
The operating authority attest the installation of the automotive lift, the competent attest the correct
initial operation.
............................................ ..................................................... ............................................
date name of the operating authority signature of the operating authority
............................................ ..................................................... ............................................
date name of the competent person signature of the competent person
Your customer service:.................................................................................................................
Automotive Lift date: 04/2006 Manual date: 24.04.2006

Operating Instruction and Documentation
UNI-LIFT 2500
- 6 -
Record of handing over
The automotive lift UNI-LIFT 2500 with the
serial number:............................................ was installed on:...............................................
at the firm:................................................. at:.....................................................................
the safety was checked and the lift was started.
The persons below were introduced after the installation of the automotive lift. The introduction was
carried out from an erector of the lift-manufacturer or from a franchised dealer (competent person).
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name of competent signature of the competent
Your customer service:.................................................................................................................

Operating Instruction and Documentation
UNI-LIFT 2500
- 7 -
1.Introduction
The document ”Operating Instruction and Documentation” contains important information about
installation, operation and maintenance of the lift.
To furnish proof of the installation of the automotive lift the form ”Record of Installation” must be
signed and returned to the manufacturer.
To furnish proof of the singular, regular and extraordinary check this documentation contains forms.
The forms should be used to document the checks. They should not be removed from this
documentation.
Every change of the construction and displacement of the automotive lift has to be registered in
the ”Master document” of the lift.
1.1 Installation and check of the automotive lift
Only specialist staff is allowed to do work concerning safety and to do the safety checks of the lift.
They are called experts and competent persons in this document.
Experts are persons (for example self-employed engineers, experts) which have received
instruction and have experience to check and to test automotive lifts. They know the
relevant regulations concerning both labour and accidents prevention.
Competent persons are persons who have acquired adequate knowledge and experience with
automotive lifts. They took part in training from the lift-manufacturer (servicing
technicians of the manufacturer or dealer are competent)
1.2 Information of Warning
To show danger and to show important information the three symbols below are used. Pay
attention to those passages, which are marked with these symbols.
Danger! This sign indicates danger to life. Inexpert handling of the described
operation may be dangerous to life.
Caution! This sign cautions against possible damage to the automotive lift or other
material defects in case of inexpert handling .
Attention! This sign indicates an important function or another important
note.

Operating Instruction and Documentation
UNI-LIFT 2500
- 8 -
2.Master document of the automotive lift
2.1 Lift–manufacturer
Otto Nußbaum Hebetechnik GmbH & Co. KG
Korker Straße 24
D-77694 Kehl-Bodersweier
2.2 Application
The automotive lift UNI-LIFT 2500 is a lifting mechanism for lifting motor vehicles with a laden
weight of up to 2500 kg. The max. load distribution is 2:3 in or against drive-on direction.
The automotive lift is only designed for servicing vehicles. It is not allowed to carry persons with the
lift. It is not allowed to climb on the lift or on the vehicle. It’s not allowed to install the standard-
automotive lift in a hazardous location or washing bays.
After changes of the construction after essential maintenance work on carrying parts and after
changing the installation place, an expert has to check the lift and to confirm its correctness and
security.
2.3 Changes at the construction
Changes at the construction, expert checking, resumption of work
(date, kind of change, signature of the expert)
..............................................................................................................................................................
..............................................................................................................................................................
........................................................................................................................…………………………..
name, address of the expert
........................................................... ............................................................
place, date signature of the expert
2.4 Displacement of the automotive-lift
Displacement of the automotive-lift, expert checking, resumption of work
(date, kind of change, signature of the expert)
..............................................................................................................................................................
..............................................................................................................................................................
........................................................................................................................…………………………..
name, address of the expert
........................................................... ............................................................
place, date signature of the expert

Operating Instruction and Documentation
UNI-LIFT 2500
- 9 -
2.5 Page for notice

Operating Instruction and Documentation
UNI-LIFT 2500
- 10 -
3. Technical information
3.1 Technical ratings
Capacity 2500 kg
Load distribution max. 2:3 in or against drive-on direction
Lifting time approx. 31 sec. with 1200 kg
Lowering time approx. 26 sec. with 1200 kg
Lifting height 1790 mm
Line Volthage 3 x 400 Volt , 50Hz
Powerrating 3kW
Motor speed 2800 rot./min.
Pump capacity 3 cm³
Hydraulic pressure ca. 240 bar with 2500 kg
Pressure relief valve ca. 255 bar with 2500 kg
Oil tank approx. 11 Litre
Sound level ≤75 dBA
Connection by customer 3~/N+PE, 400V, 50 Hz (standard version)
with fuse T16A
(Pay attention to the voltage of your state)
3.2 Safety devices
1. Click and pawl arrangement
safety device of the load against unintentional lowering.
2. Overprint valve
Overprint-safety of the hydraulic system.
3. Roll-off safety at the rails
Safety device of the vehicle against falling.
4. Lockable main switch
Safety device against unauthorised using.
5. Stop valves at the hydraulic cylinders
Safety device against lowering and pipe-breaking.
6. Optional: CE-STOP
security equipment against squash.

Operating Instruction and Documentation
UNI-LIFT 2500
- 11 -
3.3 Data sheet

Operating Instruction and Documentation
UNI-LIFT 2500
- 12 -
4. Safety regulations
Observe during working with the automotive-lift the following regulation:
(BGG945: Examination of automotive-lifts; BGR260 Working with automotive-lifts; Regulation for
accident prevention (VBG14) .
Especially the following regulations are very important:
• The laden weight of the lifted vehicle mustn’t be more than 2500 kg. The max. load sharing
is 2:3 in or against the drive-on direction.
• The automotive lift must be sunk completely, before the vehicle is driving, in the provided
direction, on the lift.
• During working with the lift the operating instructions must be followed.
• At vehicles with low sub-ground clearance or with optional equipment’s is to be tested
previously whether damages can appear.
• Only trained personnel over the age of 18 years old are to operate this lift.
• It’s not allowed to stay under the lifted or lowered vehicle (except for the operator).
• It’s not allowed to transport passengers on the lift or in the vehicle.
• It’s not allowed to climb onto the lift or onto a lifted vehicle.
• The automotive lift must be checked from an expert after changes in construction or after
repairing carrying pads.
• It’s not allowed to start with repair operations at the lift before the main switch is switched off.
• During lifting or lowering the vehicle it must be observed from the operator.
• It’s not allowed to install the standard-automotive lift in hazardous location and wash halls.
5. Operating instructions
The Safety Regulations must be observed during working with the automotive lift.
Read the safety regulations in chapter 4 carefully before working with the lift!
5.1 Lifting the vehicle
• Drive vehicle over the lift, longitudinal axes on line of the lift.
• Block the vehicle against rolling, put into gear.
• Check the dangerous places of the lift and be sure that there are no objects or people in the
immediate area of the lift or on the lift.
• Switch on the control system; main switch on position ”1”
• Raise the lift. Push the lever ”lifting”.
• Raise the lift on working height; push the lever "lifting".
• Do not raise the lift until the limit stop.
fig: 1 operating unit

Operating Instruction and Documentation
UNI-LIFT 2500
- 13 -
5.2 Lowering the vehicle
• Lower the vehicle at the height for working or until the rails reach the lowest
point; push the lever “lowering“.
• If the lift is on the limit stop. Push the lever slowly on position “lowering“,
otherwise the hose burst check valve can be closed and the lift does not lowered.
• Control the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift.
• If the lift is in the ratchet - push the lever “lifting“ until the ratchets are free and
than lower the lift again.
• (Optional): CE-STOP. Before the lift reaches its lowest position, the lift stops automatically
After the lift has stopped, check the danger areas around the lift. Push the lever “lowering”
again. A acoustic warning signal will sound as the lift is further lowered. This is to warn
against the risk of crushing as the lift is lowered to its lowest (fully collapsed) position.
5.3 Equalisation of the rails
Continuous duty of the lift without reaching the lowest position there might be an
un equalisation of the two rails functionally. Normally equalisation of the lift returns
after a few minutes (cooling time of hydraulic oil).
In case the un equalisation of the two rails remains you should perform as follows to
regain the lift’s function:
Equalisation must be performed without vehicle, otherwise the vehicle might fall down.
• Lower the lift in the lowest position.
• Drive off the vehicle from the lift.
• Remove the cover of the operating unit.
• Raise the lift on approx. 400mm;
• Turn equalisation lever 90° upside and hold it in this position.
• Push the lever “lifting or lowering“ until the rails have the same height.
Pic. 2 back side of the operating unit
1 lever: “lifting“/“lowering“
2 switch “motor on“
3 pressure control valve
4 filling plug
5 equalisation lever (ball valve)
6 hydraulic pressure switch
SL - tube “return in the tank“
H1 - tube “lifting“
KL - tube “ratchet“
D1 - tube “equalisation“
• Let go off the levers (it goes to start position without help)
• The lift has the normal function mode.

Operating Instruction and Documentation
UNI-LIFT 2500
- 14 -
6. Troubleshooting
If the lift does not work properly, the reason for this might be quite simple. Please check
the lift for the potential reasons mentioned on the following pages. If the cause of
trouble cannot be found, please call the technical service.
Problem: Motor does not start!
Possible causes:
No power supply
main switch is not engaged or defective
fuse faulty
feed line is cut
thermal switch in the motor is active
Optional: Top-limit switch is faulty
Motor faulty
Solution:
check the power supply
check the main switch
check the fuse
check and repair it
let it cool down
Check the top-limit switch
Call the service partner
Problem: Motor starts, the lift does not raise!
Possible causes:
The vehicle is too heavy
The oil level is too low
Emergency lowering screw is not closed
Defective hydraulic valve
Gear pump is defective
Coupling from the motor is faulty
Solution:
unload the vehicle
refills
check the screws
Call the service partner
Call the service partner
Call the service partner
Problem: The automotive-lift does not lowered
Possible causes:
automotive-lift is on a obstacle
Hydraulic valve is faulty
Main fuse is faulty
The safety ratchet is locked
The lever or the valve is faulty
Optional CE-Stop limit switch is faulty
Solution:
(read chapter 6.1)
Kundendienst benachrichtigen
Sicherungen prüfen lassen
Raise the lift and lower again
Check the limit switch
6.1 Driving on an obstacle
If the slave side of the lift is running onto an obstacle during lowering and the hydraulic
tube has no more pressure, the pressure switch is activated and the lift stops self-instructed.
Raise the lift, push lever “lifting“ until the obstacle can be removed.
If the master side of the lift is running onto an obstacle during the lowering the lift stops
mechanically. Raise the lift, push lever “lifting“ until the obstacle can be removed.

Operating Instruction and Documentation
UNI-LIFT 2500
- 15 -
6.2 Emergency lowering
A emergency lowering is an intervention into the control of the lift and can be planned
only by experienced expert.
The emergency lowering must be carried in this order. Otherwise a malfunction can
lead it to damages or lead to danger for body and lives.
The emergency lowering can only be performed when the ratchets are not engaged.
The emergency lowering must only be performed by persons instructed to use the lift.
Please refer to the regulation ”Lowering”.
• Raise the safety ratchet with a device and put an object (wood, height 30 mm) between the
hydraulic cylinder and the safety ratchet so the teeth of the ratchets can not engaged in the
ratchet strip (see Pic). Make these process on both cylinder.
Pic 3:
1 safety ratchet
2 hydraulic cylinder of the ratchet
3 block (height 30 mm)
4 hydraulic cylinder
5 ratchet strip
• Control the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift.
• Loose the red lockout.
• Open the emergency lowering screw slowly. The lowering process starts. Observe the
emergency lowering. Close the screw with danger .
• Lower the lift in the lowest position.
• After the emergency lowering, the lift must shut down until the defective parts has been
changed.
Pic 4: Position of the emergency lowering screw.

Operating Instruction and Documentation
UNI-LIFT 2500
- 16 -
7. Inspection and Maintenance
Before conducting maintenance work, preparations must be made to ensure that
during maintenance and repair work there is no risk to the safety of people working on
or around the lift and also that there is no risk of damage to equipment being used on
or around the lift.
To guarantee the utmost availability and to ensure that the lift remains functional, maintenance
work contracts are organised between our clients and their local retailers.
A service must be performed at regular intervals of 3 months through the operator in
accordance with following service manual. If the lift is in continuous operation or in a dirty
environment, the maintenance rate must be increased.
During daily operation the lift must be closely observed to ensure that it is functioning correctly.
In the case of malfunction or leakage the technical service must be informed.
7.1 Maintenance plan of the lift
• Before beginning any maintenance work isolate the power supply. Secure the main switch
(lock it). Secure the danger area around the automotive lift and secure the lift against
unintentional lowering.
• Clean the piston-rod using compressed air.
Grease the piston rods with a high capacity lipid (approx. 5 g of S2 DIN51503 KE2G
available from the Renolit Company.
• Check the function of the ramps and the roll-over safety device.
• Check the stripper of the cylinder.
• Clean and lubricate the moving parts of the lift (hinge bolts, sliding pieces, sliding surfaces)
grease with a multipurpose lipid (example: Auto Top 2000 LTD. Agip).
• Grease the lubricate nipples with a multipurpose lipid. (example: Auto Top 2000 LTD. Agip).
• Check all the safety devices of the lift.
Execution of the lubrication:
• The bolts of the automotive-lift must be are checked by an expert. (We recommend the
execution of the examination by a person which during a work training participated.)
After the examination the hinge bolts and bearings are to be lubricated. In the case of strong
contamination the bearings are to clean at least outwardly.
• Lubricate the movable parts. (bolts, sliding blocks, sliding surfaces)
The assigned sliding bearings are appropriate for the unlubricated operation. In case of
normal operating conditions no lubrication is necessary.
With intensified operating conditions, e.g. with the work with corrosion-aggressive media,
with strong dirt and dusty condition, with painting fog, etc. exists the danger of the corrosion
and/or the penetration of foreign matter into the bearings. An improved protection of the
bearings can be achieved by lubrication.
Therefore we recommend the precautionary lubricating of all hinge bolt bearings.
• Use a lubrication spray with good creep characteristics in case by using hinge bolts without
lubrication nipples. Inject the surfaces of the bolts.
Before spraying clean the bearings carefully at least outwardly.
During the lubrication procedure the bearing must be relieved. The relevant safety regulations
are to be considered
After the lubrication, raise and lower the automotive-lift several times without load.

Operating Instruction and Documentation
UNI-LIFT 2500
- 17 -
It is necessary to lubricate in regular intervals. In the case of usual use of the automotive-lift we
recommend monthly lubrication intervals. In the case of strong demand of the automotive-lift
the lubrication intervals must be shortened accordingly.
Recommended lubricants:
Grease: each commercial grease e.g..
! Attention: Do not use greases with fixed lubricants (e.g. graphite, Mos2) use.
Lubrication spray: trade-usual lubrication sprays
! Attention: Do not use lubrication spray with silicon parts.
• Check the electrical parts, electric cables and channels for Damage.
• Check all welded joints for cracks on the automotive-lift.
If any cracks are found on the lift cease use immediately. Switch-off and secure the main
switch (lock) and call the service partner.
• Check the function and condition of the safety ratchets. Grease the sliding surfaces.
• Damage to external surfaces, must be immediately repaired.
If theses repairs are not made immediately, permanent damage to the powder-coated
surface may result.
Repair and clean damaged areas with an abrasive paper (grain 120). After this is complete,
use a suitable paint (observe the RAL Number).
• Check the zinc surface and repair it with a suitable tool. Use abrasive paper (grain 280).
White rust can result from moisture laying in certain areas for long periods of time. Poor
aerating can also result in rust formation.
Rust may result from mechanical damage, wear, aggressive sediments (de-icing salt, liquids)
or insufficient cleaning.
Repair and clean these areas with abrasive paper (grain 280).
After this is complete, use a suitable paint (observe the RAL Number).
• Examine the hydraulic lines for leakage (visual check).
Life time of hydraulic hoses:
The use duration of the hose lines should not exceed six years, including a storage time of
two years.
• The hydraulic oil has to be changed at least once a year. To change the oil, lower the lift into
its lowest position. Empty all tanks and refill with clean oil, approx. 11 litres per hydraulic unit
are needed.
Use an ATF-Suffix hydraulic-oil (OEST Company) if the ambient temperature is under 5
degrees centigrade. After filling, the hydraulic oil must be between the upper and lower
markings of the oil level gauge.
Remove the old oil according to the appropriate regulations.
• Check that all screws and bolts are correctly torque (turning moments, see the list Pic. 6)
Pic 5:
7.2 How often must the lift be cleaned?

Operating Instruction and Documentation
UNI-LIFT 2500
- 18 -
A regular and appropriate maintenance practice will aid the preservation of the lift.
No guarantees can be given when damage (egg rust or fading colour) is the direct result of poor
maintenance and cleaning practice.
Regular cleaning of all kinds of dirt is the best protection against wear and the formation of rust
and will prolong the life of the lift
- Dirty deposits that can cause rust include:
• de-icing salt
• sand, pebble stone, natural soil
• all types of industrial dust
• water; also in connection with other environmental influences
• all types of aggressive deposits
• constant humidity caused by insufficient ventilation
Obviously this is dependent on the type of work being done with the lift, the degree of
cleanliness of the workshop and location of the lift. The degree and amount of dirt is dependent
on the season, on the weather conditions and the ventilation of the workshop.
During poor conditions it may be necessary to clean the lift once week, but cleaning once a
month will suffice.
Clean the lift and the floor with a non-aggressive and non-abrasive detergent. Use a gentle
detergent to clean the parts. Use an standard washing-up liquid and lukewarm water.
- Do not use steam jet cleaners.
- Remove all dirt carefully with a sponge or if necessary with a brush.
- Ensure that no washing-up liquid is left on the lift after cleaning.
- Do not use aggressive means for cleaning the workshop floor and the automotive lift.
- A permanent contact with any kind of liquid is not allowed. Do not use high
pressure devices for cleaning the lift.
8. Security check
The security check is necessary to guarantee the safety of the lifting during use. It has to be
performed in the following cases:
1. Before the initial operation, after the first installation
Use the form “First security check before initiation”
2. In regular intervals after the initial operation, at least annually.
Use the form “Regular security check at least annually”
3. Every time the construction of that particular lift has been changed.
Use the form “Extraordinary security check”
The first and the regular security check must be performed by a competent person. It
is recommended to service the lift at this occasion.
After the construction of the lift has been changed (changing the lifting height or
capacity for example) and after serious maintenance works (welding on carrying
parts) an extraordinary security check must be performed by an expert.
This manual contains form with a schedule for the security checks. Please us the adequate form
for the security checks. The form should remain in this manual after they have been filled out. In
the following there is a short description about special safety devices.

Operating Instruction and Documentation
UNI-LIFT 2500
- 19 -
9. Installation and Initiation
Pic 6:
9.1 Regulations for the installation
• The installation of the lift is performed by trained technicians of the manufacturer or its
distribution partner. If the operator can provide trained mechanics, he can install the lift by
himself. The installation has to be done according to this regulation.
• The standard lift must not be installed in hazardous locations or washing areas.
• Before installation a sufficient foundation must be proved or constructed. (foundation
drawing)
An even installation place has to be provided. The foundations must be based in a frost
resistance depth, both outside and indoors, where you must reckon with frost.
• An electrical supply 3~/N+PE, 400 V, 50 Hz has to be provided. The supply line must be
protected with T16A (VDE0100 German regulation). The minimum diameter amounts to 2,5
mm².
• All cable ducts have to be equipped with protective coverings to prevent accidents.
• After the installation of the automotive-lift, it is necessary to examine by customer the
Protective grounding after IEC regulation (60364-6-61). An insulation resistance examination
is also recommended.
• Plug-type connection bay customer: If the plug-type connection is on a height of about 2
meter and only approachable with devices. In this case it is necessary to fasten a separate,
lockable main switch in approachable height.
9.2 Erection and doweling of the lift
• Install the lift according to the data sheet and the foundation plan.
• Install the operating unit at its designed place. Connect the power supply.
• Connect the hydraulic. All hoses are marked.
• Fill in the hydraulic oil, approx. 11 litres are needed. A high quality hydraulic oil is
recommended, it should be 32 cst. (e.g. HLP 32 LTD. OEST Company) After the fill up, the
hydraulic oil must be between the upper and low marking of the oil level gauge.
• Push lever ”up” of the lift until the vent screw at the top of master cylinder is
accessible.
• Open the vent screw (cylinder screw with copper ring), located at upper side in guide
bush of master cylinder. (Do not turn vent screw out completely) until oil comes out
of the bore-hole. Shut vent screw immediately and fasten it.
• If the ratchets of the lift engage before oil comes out of the vent screw, shut the vent
screw and lift the lift with lever ”up” until the ratchet is not engaged any more.
• Afterwards repeat deaerating as described until oil comes out of the ventilating
screw.
• Carry out equalisation of the rails as described in chapter ”operating instructions”

Operating Instruction and Documentation
UNI-LIFT 2500
- 20 -
• Raise the UNI-LIFT to a height of 1500 mm.
• Adjust the lift: first one base plate, than the second base plate. If there is an uneven floor
even it with metal sheets. A continuous contact between the floor and the base plate must be
guaranteed to avoid hollow spaces. Dowel the lift:
Nußbaum Company demands LIEBIG safety dowels (German dowel manufacturer) or
equivalent dowels of other manufacturer but: observe their regulations.
Before doweling check the concrete floor (with quality B25!) if the concrete floor goes to the
top edge of the floor. For an existing concrete floor the dowels have to be chosen according
to Pic. 7. If floor tiles are on the concrete floor, the dowels have to be chosen according Pic.
8. Its important for the trouble-free working that the base plate are clean and the guides of
the sliding block are clean and greased.
Check the adjustment of the base plates and dowel the lift: Bore the holes to fix the dowels
through the borings of the base plates. Clean the holes with pressure air. Put in the safety
dowels.
• If necessary dowel the operating unit at the floor.
• Tighten the Liebig-dowels with the dynamometric key (M = 80Nm).
Each Liebig dowel must be tightened with the demanded torque. Otherwise the normal
and secure function of the lift can not guaranteed. Observe the regulations of the
other dowel-manufacturer.
• Raise and lower the lift several times with load. Check the torque of the dowels and check
the hydraulic hoses tightness.
• Equalize the lift, if this is necessary.
• Mount the covers: Do not damage the cables.
9.3 Initiation
Before the initiation a security check must be performed. Therefore use form: First
security check.
If the lift is installed by a competent person, he will perform this security check. If the
operator installs the lift by himself, he has to instruct a competent person to perform the
security check.
The competent confirms the faultless function of the lift in the installation record and form for
the security check and allows the lift to be used.
Please send the filled installation record to the manufacturer after the installation.
9.4 Changing the installation place
If the place of installation shall be changed, the new place has to be prepared in according to
the regulations of the first installation. The changing should be performed in accordance with
the following points:
• Raise the lift on approx. 1000 mm.
• Remove the cover of the hydraulic tubes.
• Loose the dowels.
• Lower the lift in the lowest position.
