Sirio Antenne HA077 User manual

ATTENTION
IF YOU HAVE ANY PROBLEMS OR QUESTIONS, EMAIL OR CALL
CUSTOMER SERVICE BEFORE YOU RETURN THIS PRODUCT TO THE
STORE WHERE IT WAS PURCHASED.
For Customer Service:
USA: Email: [e-mail] /Call: 1-877-897-1222
CANADA: Email: [e-mail] /Call: 1-866-666-0421
**When emailing Customer Service, please include your Order Number and platform of
purchase in the email subject for quicker assistance.
HA077
INSTRUCTION MANUAL ENCLOSED
INSTRUCTION MANUEL ENCLOSED

ALU SLIDING GAZEBO 3X4M ASSEMBLY INSTRUCTION
PARTS LIST
Part Description Quantity
PARTS
A1 leg tube( lower) 4
A2 leg tube( upper) 2
B2 leg tube( upper) 2
C1 Side tube 1
C2 Side tube 1
DMiddle top tube 2
E1 Side tube 1
E2 Side tube 1
F1 Side tube 2
F2 Side tube 2
S1 Top tube 2
S2 Top tube 2
GRoof tube 1
H Roof tube 5
H1 lower leg connect tube 2
H 2Curtain tube 4
I Hanger for middle top tube 1
I1 Hanger for side tube 2
J Screw M5X12 16
K Screw M4X12 16
L Middle top tube hanger 4
M Side tube hanger 8
N Plastic fastener for middle top tube 1
O Screw M6X75 6
P Screw M6X45 32
R Screw M6X10 20
T Leg connect 4
URoof
1
V Plastic cap for side /top tube 14
W Plastic cap for leg tube 4
X Screw M6X30 2
Y Leg plate 4
Z Tent peg 8
Z1 Anchoring 8
AA Socket head wrench 1
AB Cross screwdriver 1
AC Top tube middle connect 2
AE Side tube middle connect 3

For Customer Service:
Email: [email protected]
[email protected]
Call:1-877-897-1222 / 1-866-666-0421

Remark :
We recommend two people to finish the installation together.
1.Part C1 and C2 is connected fixed with K screws .
Part D are connected with part AE and fixed with part K screws.
Part E1 and E2 is connected fixed with part K screws.
Part S1 and S2 is connected with part AC and fixed with part R screws.
Part F1 and F2 is connected with part AE and fixed with part K screws.
GETTING STARTED
1. Before assembly, CAREFULLY use scissors or utility knife to cut and unwrap all
parts. Make sure you do not discard the hardware.
2. Make sure that you have all the parts listed. If you are missing any parts, please email
Customer Service: USA: [e-mail] or call 1-877-897-1222. Canada:
[e-mail] or call 1-866-666-0421. Please identify the parts you need and model
number. Make sure to include your name and address.
3.
Please include your Order Number and platform of purchase
in the email subject,
and one of our customer service representative will get back to you.
Warm Tips:
1. The plastic covers on some metal parts are just for product protection. Please remove
it before assembly.
2. Please follow the sequence of AI during assembly.
3. Do not tighten the screws until all of them are in right positions.
PLEASE READ AND FOLLOW ALL SAFETY TIPS

2.Part I、L、N installed on Part D in sequence, and final assembly Part V.
Part I1、M installed on Part F in sequence, and final assembly Part V.
3. A1+A2 is connected by part T into tube A ,then the plastic cap part W
is placed on the A tube.
A1+B2 is connected by part T into tube B ,then the plastic cap part W
is placed on the B tube.

4. Attached the tube C to the tube A+B using screw P, then the plastic
cap part V is placed on the C tube.
Attached the tube E to the tube A+B using screw P, then the plastic
cap part V is placed on the E tube.
5. Attached the tube F to the tube A+B using screw P, then place the part

Y on the tube A+B tube and fix it with screw R.
6. Both ends of tube S are fixed on tube C and tube E respectively with
part O , after the H1 part is connected, fix it under the A+B tube with screw J.
7. The curtain tube G passes through the part N and connects the two ends
when the cloth jacking is installed, then install curtain tube H through the

part I and connect the two ends.
8. Both ends of tube D are fixed on tube C and tube E respectively with part O,
Both ends of the tube G are fixed on the tube C with part X,
The part H2 is fixed on the tube C and the tube E respectively,
Then pull down the curtains and connect it to the tubes H1 by plastic clips.

9. Rotate out the adjusting screw on the tube H, pass through the part M and
rotate back again. open the roof and tighten the knob of the part I1 and part I
to fix the roof.
The part Y is fixed with the part Z.

10.Tighten all screws securely before use.
Till now you have finished the whole assembly and enjoy your furniture!
