SIZZIX eclips 2 User manual

Lea el manual antes de
operar el producto.
Guarde el manual para
futuras referencias.
Veuillez lire ce Guide avant
d'utiliser le produit.
Conservez ce Guide pour le
consulter au besoin.
Read Guide Before
Operating Product.
Save Guide For Reference.
eCAL2 Software included!
Logiciel eCAL2 inclus!
¡Incluye el Software eCAL2!
USER’S GUIDE
GUIDE DE L'UTILISATEUR
MANUAL DE USO
®
Electronic Cutter Fabric Starter Kit w/Bluetooth®
Cutter Électronique Kit de Démarrage Pour Tissu avec Bluetooth
Guillotina Electrónica Kit Básico de Telas con Bluetooth

2IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ THESE IMPORTANT SAFETY INSTRUCTIONS
THIS DEVICE IS INTENDED FOR HOUSEHOLD USE ONLY
WARNING
To reduce the risk of fire, electrical shock or personal injury, it is important that you read and
understand all the instructions and warnings that come with your eclips®2 Electronic Cutter (“Product”).
ELECTRICAL SHOCK HAZARD
Product is an electrical device. Use with caution. Observe the following precautions:
• Do not operate Product on wet surfaces or near any water sources (tub, shower, sink, etc.).
• Keep liquids and beverages away from Product.
• Unplug Product from outlet when not in use or before cleaning.
• Unplug Product when removing or installing Blades or Blade Holder.
PINCH HAZARD
Cutting Carriage can pinch fingers or hand. Feed Rollers can catch hair or clothing.
• Keep fingers away from moving parts.
• Keep hair and clothing away from moving parts.
CUTTING HAZARD
Cutting Blades are sharp. Handle with care.
• Keep fingers away from exposed blade.
Keep away from Children
• Choking hazard. Small parts.
This Product has a Class 1 laser and complies with International Standards EN 60825-1;
a Class 1 laser product is safe under reasonably foreseeable conditions of operation.
Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
• DO NOT disassemble the device.
• DO NOT shine the laser on a reflective surface.
• DO dispose of the Product according to the local laws and regulations of your region.
• DO NOT look directly at laser at any time.
GENERAL SAFETY RULES:
• Read and understand all the instructions and warnings that come with the Product.
• Always operate Product on a dry, clean, level surface.
• Do not operate Product with wet hands.
• Keep area of operation well lit.
• Do not operate Product near flammable liquids or gases.
• Do not operate Product out of doors.
• Do not unplug Product by tugging or pulling the power cord.
SAVE THESE INSTRUCTIONS AND WARNINGS and keep them near your eclips®2 Electronic Cutter.
Please visit sizzix.com for more information.
NOTICE The device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

3
25
4
6
7
9
10
8
1
3
CONTENTS
CONTENTS
1. eclips®2 Electronic Cutter (26" x 6 1/2" x 7")
(Model # EC-C1400) Bluetooth®
2. Universal Power Supply
3. Power Cord
4. eclips®2 User's Guide and Bluetooth®Instructions
5. Blade Holder
6. Blades, Standard, 2 Pack
7. (2) 12" x 12" Cutting Mats**:
(1) for fabric (Coral); (1) Standard (Blue)
8. 6ft USB 2.0 Cable
9. Pen Holder
10. Scraper
CONTENTS
To install eCAL2 Software for your new eclips®2 Electronic Cutter:
1. Go to http://www.sizzix.com/eCAL2
2. Enter your Email Address and serial number below. Click the SUBMIT button.
3. Click the Windows®or Mac®link to download the eCAL2 software.
4. Open up the eCAL2 installer on your computer and follow the Setup Wizard instructions.
5. After successfully ACTIVATING eCAL2 software on your computer*, connect the eclips2 Electronic
Cutter to your computer using the enclosed Bluetooth instructions.
*If your software doesn’t activate, go to www.craftedge.com.
**12" x 24" Cutting Mats also available (sold separately). Visit sizzix.com to see a complete selection of available accessories.

4
Right Sideof Machine
Computer USB Port
Depth Selection
Arrow
1. Plug Power Cord into Universal Power Supply.
2. Plug Universal Power Supply into side of eclips®2 Machine.
3. See Bluetooth®Instructions or for USB connection:
1. Plug USB cable into back of eclips2 Machine.
2. Plug flat end of USB cable into USB port of computer.
CONNECTING
SET UP
DO NOT adjust blade depth while Machine is operating.
NOTICE
SET UP
SETTING THE BLADE DEPTH
Lower Number for Thinner Material
Higher Number for Thicker Material
Printed on a ring around the Blade Holder Top are Blade Depth Settings, ranging from 1
to 6. These numbers can be selected individually by setting the Depth Selection Arrow on the
number relative to the material you will be cutting.
As a general rule, thinner materials, such as cotton fabric, paper and vinyl, require
a lower number Blade Depth Setting, while thicker materials, such as fabric with iron-
on backing, light chipboard and heavy cardstock, require a higher number Blade Depth
Setting. For optimal results, try a test cut and make the necessary adjustments to the settings
before performing the final cut.

5
Lift open Machine Cover to
expose Carriage and Blade
Holder Clamp.
Loosen Clamp by turning
Clamp Screw counterclockwise,
approximately 1/4 of a
turn. IMPORTANT: Spring
on end of Clamp Screw
MUST be kept in place.
Place Blade Holder into Clamp,
making sure that Depth Selection
Arrow is facing out.
1 2 3
Clamp Screw
Top Edge of Clamp
Depth Selection
Arrow
White Ring
Angled
Cutting Edge
Safety Cap
Insert this end
into Blade Holder
Non-Cutting Side
Tighten Blade Holder by turning
the Clamp Screw clockwise, until
Blade Holder is secure.
4
Clamp Screw
Clamp
SET UP
CAUTION: CUTTING HAZARD Blade is sharp, handle with care.
WARNING: MOVING PARTS Keep fingers, hair and clothing away.
CAUTION: CUTTING HAZARD Keep fingers away from exposed blade.
CAUTION: Always unplug Machine before removing or installing Blade Holder.
INSTALLING THE CUTTING BLADE HOLDER
Carefully remove Safety Cap from
Blade, exposing Angled Cutting
Edge.
Carefully insert Non-Cutting Side
of Blade into hole at bottom of
Blade Holder. Blade is held in
place magnetically.
Note that Blade is exposed, but
barely visible, when inserted
properly.
1 2 3
INSERTING THE BLADE INTO THE BLADE HOLDER

6
1 2
Pressing Power button
again will turn the
Machine OFF.
1 2
1 2
Replace plastic cover
on Cutting Mat when
not in use.
Only use fabric on Coral
color fabric Cutting Mat.
SET UP
DO NOT unplug USB cable from computer while Machine is in use.
This will cause loss of data.
NOTICE
WARNING: MOVING PARTS Keep fingers, hair and clothing away.
3
Activate loading using
eCAL software on your
Computer.
STARTING THE MACHINE
CUTTING MATS
LOADING THE CUTTING MAT INTO THE MACHINE
Rollers
Guides
12" – 24"
12"
WORKSPACE
PLACEMENT
Leave 12 to 24 inches of clear space behind your eclips®2 Machine to allow full
Cutting Mat movement.
Place your eclips2 Machine at least 12 inches from the edge of your work surface
to prevent it from tipping over and causing possible injury.
ENVIRONMENT
Place eclips2 Machine on a clean, level, dry and sturdy surface.
PLACING MATERIAL
ON THE CUTTING MAT
Peel back and remove plastic cover
from Cutting Mat. Align material to be cut with top-left edge of Cutting Mat. Press evenly
into place.
Open cover (Cutting Mat can also
be loaded with Machine cover
closed.)
When removing more intricate
shapes from Cutting Mat, an eclips
Die Pick or Scraper is recommended.
Plug Power Cord into wall outlet. Plug
the other end into your eclips2 Machine. Press Power button (front of Machine shown). Unplug Machine when not in use.
Place Cutting Mat between Alignment
Guides and insert into Machine until the
leading edge touches the Rollers.

7
CUTTING BLADE MAINTENANCE
CLEANING THE CUTTING BLADE
MAINTENANCE
MAINTENANCE
Loosen Blade Holder Clamp
by turning Clamp Screw
counterclockwise. Remove
Blade Holder.
Push down on Blade Ejection Pin
to reveal Blade. Carefully remove
and discard used Blade.
Carefully insert new Blade into
hole at bottom of Blade Holder;
Blade is held in place magnetically.
Replace Blade Holder in Machine,
as shown on page 5.
2 3
4
BladeEjection Pin
Blade
CAUTION: CUTTING HAZARD Keep fingers away from exposed blade.
WARNING: CHOKING HAZARD Small parts. Keep away from children.
CAUTION: CUTTING HAZARD Blade is sharp, handle with care.
CAUTION: Always unplug Machine before removing or installing Blade Holder.
Non-Cutting Side
ADJUSTING THE CUTTING BLADE DEPTH
REPLACING THE CUTTING BLADE
Lift open Machine Cover to
expose Carriage and Blade
Holder Clamp.
1
Clamp Screw
After prolonged use, the Cutting Blade may not cut as precisely as it once did. To help prolong the life of the Cutting
Blade, remove it from the Blade Holder and clean it with Isopropyl Alcohol (rubbing alcohol) poured onto a clean
paper towel. Remove any material left inside the Cutting Blade Holder, using a Die Pick Tool.
Visit sizzix.com to see a complete selection of available accessories.
Printed on a ring around the Blade Holder Top are Blade Depth Settings, ranging from 1 to 6. These numbers can be
selected individually by turning the wheel to the number relative to the material you are using. Refer to page 4 for
more information about setting the Blade Depth.

TROUBLESHOOTING
 Problem: eclips®2 system will not turn on
• Unplug system from wall outlet before troubleshooting. Make sure all components and connectors are plugged in
properly (see pg. 4). When everything is connected, plug system into wall outlet and press power ON (see pg. 6).
 Problem: eclips2 Machine freezes up
• Turn off Machine and restart (see pg. 6).
 Problem: Machine is not cutting with its usual pristine quality
• Your Cutting Blade may be worn and need replacing (see pg. 7).
• Make sure material to be cut was correctly selected in the eCAL application's cut settings.
• If you are using a material not listed, manually change the Speed, Pressure and Blade Depth using the eCAL application.
Please note that not all materials will be compatible with the Machine.
 Problem: Cutting Blade does not cut all the way through my material
• Make sure Cutting Blade is installed properly (see pg. 5).
• Make sure material to be cut was correctly selected in the eCAL application's cut settings.
• Increase cutting pressure or decrease cutting speed manually using the eCAL application. If Blade still does not cut through the
chosen material, the Blade needs to be adjusted (see pg. 4) or replaced (see pg. 7).
 Problem: The corners of my cutouts are wrinkled
Make sure you are using recommended materials with the correct eCAL settings. If you have confirmed this:
• Blade may need to be replaced for a sharper cut.
• Pressure setting may be too high (change to a lower number for lesser pressure).
• Cutting Mat may have lost its adhesion.
• Speed setting may be too fast (change speed to a slower, lower number).
• Blade Depth Setting may be too high (change Blade Depth to a lower number).
 Problem: Machine is cutting outside of material
• Laser preview the image before you cut it to see how it will fit on the material. Make any necessary adjustments.
 Problem: Material keeps shifting from its original position during cutting
• Fabric must be starched, stabilized, or have an iron-on backing before cutting.
• If your material is no longer adhering to the Cutting Mat, it is time to replace the Cutting Mat* or re-coat it with eclips Spray
Adhesive (sold separately)*. Fabric mats will require 2 or 3 coats of Spray Adhesive.
• If you are using a material that has an adhesive side covered by a protective, slippery backing, turn the adhesive side face-up,
so that the material can better adhere to the Cutting Mat. Be sure to use the Mirror feature to reverse the artwork to its proper
orientation. Clean the cutting blade after use.
 Problem: Material does not stick to Cutting Mat
• Remove clear protective sheet from Cutting Mat (see pg. 6). Using the eclips Scraper Tool, make sure all debris has been
removed from the Cutting Mat. Align material to top-left corner of Cutting Mat and press evenly into place. If material will not
stick to Cutting Mat, replace it or re-coat it with eclips Spray Adhesive (sold separately)*.
 Problem: Cutout cannot be removed from Cutting Mat
• Use a tool, such as the eclips Scraper when removing cutouts from the Cutting Mat.
*For a complete selection of available accessories and replacement Cutting Mats, visit sizzix.com.
TROUBLESHOOTING
8
For latest updates to the User's Guide, please visit sizzix.com.

9
END USER LICENSE AGREEMENT
END USER LICENSE AGREEMENT
Revised: 013116/T15_0195
ECLIPS®2 ELECTRONIC CUTTER BY SIZZIX®
Ellison Educational Equipment, Inc., doing business as
Sizzix®(“Sizzix”) is willing to grant to you a license to
use the eclips®2 Electronic Cutter (the “Product”), subject
to your acceptance of the following terms and conditions.
Please read the terms of this Agreement carefully. Your use
of the Product or any components will constitute acceptance
of the terms of this Agreement. If you do not agree to these
terms, you may not use the Product and you should contact
Sizzix for instructions regarding the return of the Product.
1. License. Subject to the terms of this Agreement, Sizzix
hereby grants you a non-exclusive, non-transferable,
royalty-free, limited license to use the Product and
any associated components, software, firmware and
documentation for personal, non-commercial purposes
solely in connection with the use of the Product for
its intended purpose as described in the applicable
documentation. You may assign this license only as part of
a sale or transfer of the Product and all components, and
only if the recipient agrees to comply with the terms of this
Agreement. Your rights under this Agreement will terminate
upon such assignment.
2. Restrictions. Except to the extent expressly permitted
under applicable law, you may not reverse engineer,
decompile, or otherwise attempt to make a copy of,
or publish, the software, firmware or documentation
included with the Product. Sizzix retains ownership of
the Product design and associated software, firmware
and documentation, together with all related intellectual
property rights, subject only to the limited rights granted
to you in this Agreement. No right to use Sizzix, eclips2
or any other brand of Ellison Educational Equipment is
granted under this Agreement. You agree to comply with all
export laws and regulations applicable to the Product and
its components.
3. Warranty. The product is subject to the Limited
Warranties included in the Product documentation, which is
hereby incorporated into this Agreement.
4. General. This agreement is governed by the laws
of the State of California. All disputes relating to
the Product or this Agreement shall be subject to the
exclusive jurisdiction of the state and federal courts in
Orange County, California. This Agreement is the entire
agreement between you and Sizzix relating to the Product,
and it supersedes any prior communications and any
conflicting terms contained in any purchase order, quote or
acknowledgment. No amendment to this Agreement shall
be binding unless signed by Sizzix and you.
5. Contacting Sizzix. For Product inquiries, please contact:
North America:
sizzix.com
877-355-4766 toll-free in USA
949-598-8821 outside USA

10
WARRANTY
Revised: 013116/T15_0195
WARRANTY
ECLIPS®2 ELECTRONIC CUTTER BY SIZZIX®
90-DAYS LABOR, ONE-YEAR PARTS LIMITED WARRANTY
What Does This Warranty Cover?
This Limited Warranty covers only manufacturing defects in
material and workmanship in the hardware components of
your eclips®2 Electronic Cutter (the “Product”).
How Long Does The Warranty Last?
Labor: For a period of 90 days from the original date of
purchase of the Product (“Labor Warranty”).
Parts: For a period of 1 year from the original date of
purchase of Product (“Parts Warranty”). You should retain
your receipt as proof of purchase, which may be required
in connection with obtaining warranty service.
What Will Sizzix Do?
Labor Warranty: Sizzix will, at our option, repair or
replace with new or refurbished product or parts, product
determined to be defective. If Sizzix elects to replace the
product after this Labor Warranty has expired but while the
Parts Warranty below is still in effect, it will do so for the
applicable labor charge.
Parts Warranty: Sizzix will supply new or refurbished
replacement parts in exchange for parts determined to be
defective.
“Refurbished” means a product or part that has been
returned to its original specifications. In the event of a
defect, these are your exclusive remedies. Any product or
parts replaced under this Limited Warranty will become the
property of Ellison Educational Equipment, Inc. (“Sizzix”).
What Does This Warranty Not Cover?
It does not cover technical assistance for hardware,
firmware or software usage and it does not cover any
software products, whether or not contained in the Product.
Any such software is provided “AS IS”. Please refer to the
End User License Agreement included with the Product for
your rights and obligations with respect to the software.
Further, this Limited Warranty does not cover damages
or defects caused by misuse or abuse of the Product;
modification of or to any part of the Product; use of any
third-party software, firmware and/or hardware with
the Product; acts of God; limitations of technology; or use of
the Product for commercial, rather than personal, applications.
The cutting blades, blade housing, cutting mat and any
accessories are also excluded from this Limited Warranty.
Opening any of the Product housing or tampering with the
Notice label on the underside of the housing will automatically
void the warranty.
Disclaimers. SIZZIX SHALL NOT BE LIABLE FOR
CONSEQUENTIAL AND INCIDENTAL DAMAGES, DAMAGES
FOR BODILY INJURY (INCLUDING DEATH) AND DAMAGE TO
PROPERTY. THE DURATION OF
ANY IMPLIED WARRANTIES SHALL BE LIMITED TO THE
DURATION OF THE EXPRESS WARRANTY SET FORTH ABOVE.
SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGE, DAMAGES FOR PERSONAL INJURY OR
THE LENGTH OF IMPLIED WARRANTIES, SO THESE
LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
How Do You Get Warranty Service?
If you believe that there is a manufacturing defect in material
and workmanship in the hardware components packaged with
your Product during the Limited Warranty Period, please
contact Sizzix Customer Relations at the following telephone
number or website:
North America:
sizzix.com
877-355-4766 toll-free in USA
949-598-8821 outside USA
AReturn Authorization (RA), along with shipping information,
will be issued. Following a determination by Sizzix that a fault
covered by this Limited Warranty may have occurred, Sizzix
will: (a) ship you replacement parts or (b) ship you a
replacement Product. Product not covered by this Limited
Warranty will be returned at your expense.
The device has been evaluated to meet general RF exposure
requirement.
The device can be used in portable exposure condition without
restriction.
Changes or modifications not expressly approved by the party
responsible for compliance could void your authority to
operate the equipment.
