Ski-Doo EXPEDITION V-1000 User manual

Date: August 25, 2005 Subject: Skandic/Expedition No. 2006-1
YEAR MODEL PACKAGE MODEL NUMBER SERIAL NUMBER
2006 EXPEDITION V-1000 TUV FA6A, FA6B All
2006 EXPEDITION 600 HO SDI TUV FB6A, FB6B All
2006 SKANDIC 440 (E) Fan LT FH6B All
2006 SKANDIC 550 (E) Fan SUV FD6B, FD6D All
2006 SKANDIC 550 (E) Fan SWT FE6B All
2006 SKANDIC 550 (E) Fan WT FG6B All
2006 SKANDIC 600 (E) SUV FC6B, FC6D All
2006 SKANDIC 600 (E) WT FF6B All
TABLE OF CONTENTS
P
PP
Pa
aa
ag
gg
ge
ee
eP
PP
Pa
aa
ag
gg
ge
ee
e2
22
2
IMPORTANT NOTICE .......................... 2
UNCRATING..................................... 3
Procedure .......................................... 3
SET-UP............................................ 4
Battery Preparation................................ 4
Battery Removal................................... 4
Battery Installation ................................ 5
Rear Suspension Rear Shock.................... 5
Front Suspension Shocks ........................ 6
Skis.................................................. 7
Instrument Panel .................................. 8
Handlebar........................................... 9
Steering Pad ....................................... 9
Holding Strap.......................................10
Windshield .........................................11
Aluminum Foil Heat Shield.......................13
Seat Belt............................................13
Backrest ............................................14
Drive Belt...........................................14
Air Intake Silencer.................................15
Snow Guard........................................16
FINAL PREPARATION..........................16
MPI (Connecting)..................................16
B.U.D.S. (Customer Name) ......................17
B.U.D.S. (Programing a DESS Key) .............18
Engine Oil Level ...................................18
Recommended Oil ................................18
Break-in Period.....................................19
Oil Injection Pump Bleeding .....................19
Brake Fluid Level ..................................20
Coolant Reservoir Level ..........................20
Track Adjustments ................................20
Brake Disk..........................................20
Driven Pulley.......................................20
DELIVERY TO CUSTOMER...................20
Predelivery Check List............................20
Speedometer ......................................21
Rear Suspension Adjustments ..................21
SPECIFICATIONS ...............................22
Printed in Canada. (mbl2006-002 AP) 1/24
©2005 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved.
®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates.
* Trademark of Bombardier Inc. used under license.

IMPORTANT NOTICE
IMPORTANT NOTICE
This bulletin must be used in conjunction with the check list enclosed in the bag with the OPERATOR’S
GUIDE. Make sure that PREDELIVERY CHECK LIST is completed and signed.
WARNING
To obtain limited warranty coverage, predelivery procedures must be performed by an authorized
Ski-Doo®snowmobile dealer/distributor. Apply all necessary torques as indicated.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:The information and components/system descriptions contained in this document are correct
at the time of publication. Bombardier Recreational Products Inc. (BRP) however, maintains a policy
of continuous improvement of its products without imposing upon itself any obligation to install
them on products previously manufactured. Due to late changes, there might be some differences
between the manufactured product and the descriptions and/or specifications in this document. BRP
reserves the right at any time to discontinue or change specifications, designs, features, models
or equipment without incurring obligation. The illustrations in this document show the typical
construction of the different assemblies and may not reproduce the full detail or exact shape of
the parts. However, they represent parts that have the same or similar function.
The content of this bulletin is designed as a guideline only. All mechanics performing predelivery
procedures should have attended the current model year service training. Further information
or inquiries should be directed to your distributor service representative and/or specific SHOP
MANUAL sections. Please complete the PREDELIVERY CHECK LIST for each snowmobile and
retain a customer signed copy. Make sure the customer receives the OPERATOR’S GUIDE,
PREDELIVERY CHECK LIST signed copy and SAFETY VIDEOCASSETTE.
There is a tag attached to the ignition key, only the customer must remove it. This label
will remind the customer to ask dealer/distributor to perform suspension adjustments
according to riding style and vehicle load.
2 / 24 2006-1 Predelivery

UNCRATING
UNCRATING
Procedure
3
2
1
A00A2F6
Carefully lay the crate on its bottom.
CAUTION: Allowing the crate to drop may
cause serious damage to the vehicle.
Using a drill or a screwdriver, remove all screws
[
[[
[1]
]]
] retaining crate cover to crate base.
Tilt [
[[
[3]
]]
] the crate cover toward the front
or the rear of the vehicle.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:There is a notch at the front of the crate
that indicates the front of the vehicle [
[[
[2]
]]
].
Lift the crate cover slowly to avoid
damaging the vehicle.
Remove the predelivery kit and parts to be
installed from part box or from under the seat
compartment according to the model.
Detach skis from crate base.
Discard screws and washers.
Remove polyethylene foam protective sheets.
If applicable, detach windshield from seat.
CAUTION: Make sure vehicle is properly
supported before removing ski legs and rear
suspension from crate brackets.
Detach the ski legs from the crate base.
Discard screws.
A29G12A
Model(s): TUV and SUV
Model(s): All Models except TUV and SUV
A29F166
Remove the rear retaining strap.
Predelivery 2006-1 3 / 24

UNCRATING
A06F2Q6
Cut locking tie retaining hook.
Lay on seat and ask another person to apply
pressure onto rear bumper.
Remove hook from suspension.
WARNING
Before removing hook always verify that
vehicle is properly supported and that
parking brake is applied.
WARNING
Hook must be removed to have snowmobile
suspension operational.
Remove the vehicle from the crate base.
SET-UP
Battery Preparation
Model(s): All except LT
All electric starting equipped vehicles using a
YTX20L-BS or YTX24L-BS type battery require
a specific charging procedure at predelivery.
Follow the appropriate procedure as
described below.
WARNING
Always wear safety glasses and charge in
a ventilated area. Never charge or boost
battery while installed on vehicle. Do not
open the sealed caps during charging. Do
not place battery near open flame.
CAUTION: If battery becomes hot, stop charging
and allow it to cool before continuing.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Sealed VRLA batteries have an internal
safety valve. If battery pressure increases due to
overcharging, the valve opens to release excess
pressure, preventing battery damage.
An automatic charger is the fastest and most
convenient way for error-proof charging.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:If battery cannot be recharged using the
following charging chart, replace battery.
Battery Voltage below 12.8 V
STANDARD CHARGING
(recommended)
BATTERY TYPE TIME CHARGE
YTX20L-BS 4–9 hours
YTX24HL-BS 5–10 hours 2A
QUICK CHARGING
BATTERY TYPE TIME CHARGE
YTX20L-BS 50 minutes
YTX24HL-BS 1 hour 10 A
Model(s): LT Only
During preparation, the battery can be
activated as described in last year appropriate
SKI-DOO SHOP MANUAL.
CAUTION: Prior to charging the battery,
always remove it from the vehicle to
prevent electrolyte spillage.
Battery Removal
A29E136
1
2
Model(s): TUV
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Battery is located under the seat.
Unhook battery cover strap [
[[
[1]
]]
] from its support.
Open battery cover [
[[
[2]
]]
].
Remove battery.
4 / 24 2006-1 Predelivery

SET-UP
Model(s): All Models except TUV
Remove air silencer.
Unhook the battery strap or undo steel strips
nut and screw holding battery.
Remove the battery.
Battery Installation
Properly position the battery on its rack.
WARNING
Always connect the battery cables exactly in
the specified order. Connect RED ( + ) cable
first, then BLACK ( –) ground cable.
Connect RED ( + ) cable to battery positive post.
Apply silicone dielectric grease (P/N 293 550 004)
on battery positive connection.
Cover the RED ( + ) connection with rubber boot.
Connect BLACK ( –) cable to battery negative post.
Apply silicone dielectric grease (P/N 293 550 004)
on battery negative connection.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Place the BLACK ( –) cable under
the battery strap.
Close battery cover (if applicable)
Secure battery with steel strips or rubber strap.
Reinstall previously removed parts if applicable.
Rear Suspension Rear Shock
1
2
A29F126
Model(s): TUV and SUV Only
Lift up rear side of snowmobile.
Install shock absorber bearing bushings
in place [
[[
[1]
]]
].
Install shock absorber in place (with
protector upward and adjustments handle
towards the rear) [
[[
[2]
]]
].
Secure shock to upper arm using:
–one hexagonal bolt M10 x 50
–one nut M10.
Secure shock to rear arm using:
–two hexagonal bolts M10 x 40
–two lock washers
–two shims
–two circlips
–one rear shock shaft.
Torque to 45 N•m(33 lbf•ft).
1
Model(s): SWT/WT Only
Secure front arm upper axle of rear suspension
usingtwoM10x30screws[
[[
[1]
]]
] in plastic
bag under the seat.
Apply Loctite 243 (blue) (P/N 293 800 060)
on threads.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Use a tie-down between the front
arm and spring axle to ease the installation
of the front arm screws.
Torque screws to 58 N•m(43 lbf•ft).
Predelivery 2006-1 5 / 24

SET-UP
Secure rear arm using previously removed screws.
Apply Loctite 243 (blue) (P/N 293 800 060)
on threads.
Torque screws to 58 N•m(43 lbf•ft).
Model(s): WT Only
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:For single driving condition use upper
hole and for two person driving condition or
load in rack, use lower hole.
Apply Loctite 243 (blue) (P/N 293 800 060)
on threads.
Torque screws to 58 N•m(43 lbf•ft).
Model(s): All except TUV and SUV
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Also in shrink pack are 4 horse shoe type
washers that are used to adjust rear suspension
for trail riding according to load (refer to the
appropriate SHOP MANUAL for proper procedure);
they are to be put in the tool box for further use.
Front Suspension Shocks
A29F176
1
23
23
Model(s): TUV and SUV Only
Lift front of vehicle and block safely.
Remove and discard shipping brackets
from suspension.
Discard spring clips, keep screws.
Remove air intake silencer.
Install shock absorbers to suspension with
their adjusting ring at bottom.
Secure with hexagonal bolts and nuts
provided in predelivery kit.
1
Model(s): WT/SWT Only
Remove long bolts [
[[
[1]
]]
] that compress front
suspension on both sides.
1
Install 2 plastic bushings [
[[
[1]
]]
]intoshock
absorber eyelets.
Stretch shock to its maximum.
Slide shock absorber into bottom of ski leg
until shock rod goes through cap hole.
Loosely install conical spring washer, concave
surface inside, and M10 nut on shock rods,
keeping at least 1/4 in (5 mm) of free play.
Install stop bounding on ski with its highest
portion toward front.
6 / 24 2006-1 Predelivery

SET-UP
Install skis on snowmobile using bolts,
nuts, washers and rubber bushings supplied
in the predelivery kit.
Skis
A29F186
4
56
1
3
2
7
7
Model(s): TUV and SUV Only
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Ensure the ski leg bushing [
[[
[5]
]]
]is
still on the ski leg [
[[
[6]
]]
].
Insert the ski stopper [
[[
[1]
]]
] from the predelivery
kit with the higher side toward the front
[
[[
[3]
]]
] into the ski.
Install the ski [
[[
[7]
]]
] to ski leg [
[[
[6]
]]
].
Secure the ski to ski leg with:
–the existing M10 hexagonal bolt [
[[
[2]
]]
].
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Make sure that the hexagonal bolt head
is toward the outside of the vehicle.
–M10 elastic flanged nut [
[[
[4]
]]
] from the
predelivery kit.
Torque to 45 N•m(33 lbf•ft).
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Repeat the same procedure on
the opposite ski.
Put the vehicle back on the ground.
1
A29G1GA
Model(s): All except TUV and SUV
Install stop bounding [
[[
[1]
]]
] on skis with its
highest portion toward front.
On some models, a support plate should
be installed as per photo.
Install a washer on both side of ski leg.
3
4
6
1
4
2
5
3
Install skis on vehicle using the following
parts from the predelivery kit:
–[
[[
[1]
]]
] stop bounding (already installed)
–[
[[
[2]
]]
]sleeve
–[
[[
[3]
]]
] rubber bushings
–[
[[
[4]
]]
] conical spring washers (concave surface
inside) (SWT only)
–[
[[
[5]
]]
]bolts
–[
[[
[6]
]]
]nuts.
Predelivery 2006-1 7 / 24

SET-UP
1
A29G1D6
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:[
[[
[1]
]]
] Front of the vehicle.
Torque ski leg nuts to 45 N•m(33 lbf•ft).
Torque shock rod top nuts to
30 N•m(22 lbf•ft).
Instrument Panel
Model(s): Expedition 600 HO SDI
mbl2006-002-100
Take the instrument panel out from front
compartment (under hood). Remove
protective plastic.
Remove both screws on the top of hood and
both screws on lower corner of instrument
panel. Keep them for installation.
mbl2006-002-101
Open hood and remove the inner cover.
mbl2006-002-102
Using 2 kept screws, install the lower
side of instrument panel to hood. Install
removed inner cover.
mbl2006-002-103
Install the top side of instrument panel
with the 2 last kept screws.
8 / 24 2006-1 Predelivery

SET-UP
Handlebar
A29G0Q6
Model(s): Already Installed on Steering Column
Adjust handlebar and set both clamps to
have equal gap on each side.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Use handlebar wire hole as a
guide to center.
Master cylinder brake fluid reservoir
must be levelled.
Torque nuts from 24 N•m(18 lbf•ft).
2
A29G1B6
3
1
4
Model(s): To be Installed on Steering Column
Assemble handlebar with extension [
[[
[1]
]]
]and
clamps [
[[
[2]
]]
] on steering column.
Secure temporarily with:
–[
[[
[3]
]]
] 2 hexagonal bolts (predelivery kit)
–[
[[
[4]
]]
] 2 elastic nuts (predelivery kit).
Adjust handlebar and set both clamps to
have equal gap on each side.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Use handlebar wire hole as a
guide to center.
Master cylinder brake fluid reservoir
must be levelled.
MODELS TORQUE
SKANDIC SUV 24 N•m(18lbf•ft)
EXPEDITION 29 N•m(21lbf•ft)
Torque nuts from 24 N•m(18 lbf•ft).
Steering Pad
3
1
2
4
A29G156
Model(s): Steering Pad with Keyway
Loosen throttle and brake handle housings.
Install steering pad.
Adjust both throttle and brake handle housings
to match steering pad.
Secure steering pad [
[[
[1]
]]
] to handlebar with:
–2 keyways [
[[
[2]
]]
]
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Useliquidsoaptoeaseinstallation
if necessary.
–2 screws M5 x 20 [
[[
[3]
]]
]
–2nutsM5[
[[
[4]
]]
].
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Item [
[[
[3]
]]
]and[
[[
[4]
]]
] seat tighten only,
no deformation of rubber.
Predelivery 2006-1 9 / 24

SET-UP
A29F156
Model(s): Steering Pad with Zipper
Properly position foam in place.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Steering foam can be secured in
place with a device such as filament tape
to ease the installation.
Fit steering padding and set in place with zippers.
mbl2006-002-001
Holding Strap
A29G146
Model(s): If so Equipped
Cut locking tie retaining right side strap end.
If applicable, insert strap through holes
provided in steering padding.
1
2
3
5
6
4
A03G0X6
Secure right side strap end with retaining clip [
[[
[3]
]]
].
Tighten firmly using:
–hexagonal bolts [
[[
[1]
]]
]
–nuts [
[[
[6]
]]
]
10 / 24 2006-1 Predelivery

SET-UP
–flat washers [
[[
[2]
]]
]and[
[[
[5]
]]
]
–flat washers (spacer) [
[[
[4]
]]
].
Torque to 11 N•m(97 lbf•in).
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:A wire route along handlebar. To
avoid pinching it, make sure to keep wire
outofretainingclip.
Windshield
12
A29H066
Model(s): All except TUV
Remove headlamp molding.
Install rubber expansion nut [
[[
[1]
]]
]inhole
above headlamp.
Line up hole in windshield [
[[
[2]
]]
] with rubber
expansion nut and install screw with cup.
Tighten slightly so that rubber expands
inside hood.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
: Skandic SUV model have two
rubber expansion nuts.
Model(s): WT/SWT Only
Remove plastic plate from hood.
Install air intake cover with filter and rubber
support assembly in predrilled holes on the hood.
Retain with 4 supplied push nuts, using
2 end pins on each side.
2
1
3
Pry out headlamp molding.
Install air intake cover with filter, rubber
support and push nuts [
[[
[1]
]]
].
Install windshield [
[[
[2]
]]
].
Install latches (10) [
[[
[3]
]]
].
A29H0X6
Model(s): All except TUV
Install windshield and secure with latches
inside hood.
Predelivery 2006-1 11 / 24

SET-UP
Reinstall plastic plate.
Secure with latches, clips and nuts (for
rubber expansion nuts).
Reinstall headlamp molding.
Make sure to properly position lower edge of
plastic molding under head lamp.
Model(s): WT/SWT/WT LT Only
Secure inside plastic hood with supplied green
clips (if not already secured).
A29H0Y6
Model(s): All except TUV
Addfoaminsidecover.
Take care to position foam correctly.
A29H1D6
Model(s): TUV 600 HO SDI Only
Install and secure air intake dashboard cover
using 4 screws from predelivery kit.
A32H2M6
1
3
2
Model(s): All TUV
Remove the headlamp protector [
[[
[1]
]]
] from hood.
Unclip the inner protector [
[[
[3]
]]
] from the
headlamp protector [
[[
[1]
]]
].
Remove protective films from the windshield [
[[
[2]
]]
].
Insert tabs of headlamp protector [
[[
[1]
]]
]in
windshield square holes.
Clip the inner protector [
[[
[3]
]]
] in place.
A29H1E6
Model(s): TUV 600 HO SDI Only
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Take care to slide the windshield support
underneath the air intake dashboard cover.
12 / 24 2006-1 Predelivery

SET-UP
A29H1F6
Add foam.
A32H2K6
1
Model(s): All TUV
Secure windshield assembly to hood using
latches from predelivery kit.
A29H1G6
Remove part between mirror housing and adaptor.
Aluminum Foil Heat Shield
1
Model(s): SWT Only
Found in seat compartment, an aluminum foil heat
shield has to be installed on hood inner surface [
[[
[1]
]]
].
Remove backing from heat shield.
Align inside hood above braking mechanism
(disc), and stick in place, see photo.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:This heat shield has to be installed
over the duct in order to protect both the duct
and the hood from heat. Do not remove duct
since this heat shield goes over it.
Seat Belt
Model(s): SWT/LT Only
A seat belt can be found in luggage compartment.
Install it on seat using belt lugs each
side of seat base.
Predelivery 2006-1 13 / 24

SET-UP
Backrest
A22H0L6
1
Model(s): All Models except Expedition
Install spacers [
[[
[1]
]]
] (included in shrink kit) in
rear seat holes for backrest.
Install backrest in its proper position.
Secure rear arms of backrest using 2 M8 x
30 screws found in shrink pack.
Align front arms of backrest and secure with M8
x 20 screws included in the shrink pack.
Model(s): Expedition Series
mbl2006-002-002
Install backrest in its proper position and
screwtheknobtosecureit.
Drive Belt
Model(s): All except 4-TEC
WARNING
Engine should be running only when belt
guard is secured in place.
Remove belt guard.
Clean pulleys and disk brake with a suitable
cleaner such as pulley flange cleaner
(P/N 413 711 809).
Install drive belt in its proper rotation direction,
arrow pointing at front.
14 / 24 2006-1 Predelivery

SET-UP
A29C306
4 3 1 2
Model(s): 4-TEC Only
WARNING
Engine should be running only when belt
guard is secured in place.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Belt guard is purposely made slightly
oversize to maintain tension on its pins
and retainers preventing undue noise and
vibration. It is important that this tension be
maintained when reinstalling.
Remove tether cord cap.
Open engine compartment.
Loosen collar screw [
[[
[1]
]]
] on air silencer grommet.
Disconnect engine vent hose [
[[
[2]
]]
]fromairsilencer.
Disconnect air temperature sensor [
[[
[3]
]]
].
Unhook latch [
[[
[4]
]]
] from air silencer.
Remove air intake silencer.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:At installation do not forget to
connect air temperature sensor otherwise
a trouble code will appear.
Remove belt guard.
Clean pulleys and disk brake with a suitable
cleaner such as pulley flange cleaner
(P/N 413 711 809).
Install drive belt in its proper rotation direction,
arrow pointing at front.
Air Intake Silencer
1
Model(s): All except TUV
This part consist of three separate pieces.
First fasten the bottom of air intake silencer.
Check that guide pins are in the provided holes.
Guidepinsmustbeintotheseholes[
[[
[1]
]]
].
1
Bottom part of air intake silencer installed [
[[
[1]
]]
].
Predelivery 2006-1 15 / 24

SET-UP
1
Install the middle part of air intake silencer [
[[
[1]
]]
].
Mount the upper part of the air intake silencer.
Install the back side first and check that
brackets are on right position.
Fasten air intake silencer pieces together
with provided clamps.
Make sure air intake silencer rubber extension
and carburetors fit well.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:While installing air intake silencer, take
care to route throttle cable the right way.
Snow Guard
1
2
Install snow guard [
[[
[1]
]]
] with extra plastic support
[
[[
[2]
]]
] (in luggage compartment if applicable) using
rivets supplied in its packaging.
FINAL PREPARATION
MPI (Connecting)
A32A1M6
Model(s): TUV Only
Start B.U.D.S.
Select the vehicle's Protocol (Kw2000) in
CHOOSE PROTOCOL from the MPI menu.
Wait a few seconds while B.U.D.S. loads
the protocol into the MPI.
16 / 24 2006-1 Predelivery

FINAL PREPARATION
A32A1N6
Connect power supply harness [
[[
[1]
]]
],
(P/N 529 035 869), to 6 pin connector [
[[
[2]
]]
].
Connect the 6 pin diagnostic cable [
[[
[3]
]]
]to
power supply harness [
[[
[1]
]]
].
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Injection vehicles already have a 12 V
battery; they do not need any external 9 V or 12 V
power to allow programming and troubleshooting.
A33E0YA
2
3
1
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:The use of the power supply harness [
[[
[1]
]]
]
will keep the vehicle's ECM ON. Not using it will
make the ECM shut off after a few seconds.
Select the vehicle’sprotocolinCHOOSE
PROTOCOL from the MPI menu. The
protocol is KW 2000.
Turntheengineshutdownswitchtothe
engine off position.
Insert the grey DESS cap (P/N 529 035 896)
onto the vehicle DESS post.
Press the start/stop button to wake up the ECM.
A32A1O6
Click on the READ DATA from the tool
bar to initiate communication and to read
the content of the ECM.
B.U.D.S. (Customer Name)
A32A1P6
Model(s): TUV Only
Click on the VEHICLE tabtoopenthe
vehicle information page.
Type the name of the customer in the
CUSTOMER zone.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:After you are finished typing the
name, B.U.D.S. automatically updates the
delivery date on the screen.
Predelivery 2006-1 17 / 24

FINAL PREPARATION
B.U.D.S. (Programing a DESS
Key)
A32A1Q6
Model(s): TUV Only
Read the content of the vehicle's MPEM by
clicking on READ DATA from the tool bar.
Click on the KEYS tabtoopentheDESSkeyspage.
Click on ERASE ALL KEYS.
Click on ADD KEY.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:A dialog box opens and asks you to
insert a key on the MPI DESS post.
IfthekeythatyouinsertedontheMPIDESS
post was successfully read and added to the
document, message box will appear.
Click on OK.
Repeat steps 3to 5for each DESS key you
want to program into the vehicle.
Write the document into the vehicle by clicking
on WRITE DATA from the tool bar.
Remove the GREY key from the vehicle DESS.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:If the B.U.D.S. system loses
communication while connected, press the
start/stop button or turn briefly the ignition switch
to the START position to reactivate communication.
Engine Oil Level
A29C2Y6
1 2
Model(s): TUV 4-TEC Only
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:These models are equipped with
4-stroke engine. Use XP-STM 0W40 synthetic
4-stroke oil (P/N 293 600 054).
CAUTION: Vehicle must be on a level surface
before checking any fluid level.
Make sure engine is at operating temperature
Leave engine running at idle for 30 seconds.
Stop the engine and wipe the dipstick.
N
NN
NO
OO
OT
TT
TE
EE
E:
::
:Dipstick must be completely screwed
in before checking oil level.
Oil level must be between minimum [
[[
[2]
]]
]and
maximum [
[[
[1]
]]
] marks on dipstick.
Recommended Oil
Model(s): All Models except 4-TEC
CAUTION: Use only oil that flows at
-40°C(-40°F).
Oil is contained in the injection oil reservoir.
Use only two-stroke engine
injection oil, sold by BRP.
MODEL OIL TYPE
2-TEC SDI [1]
XP-S synthetic 2-stroke oil
or XP-S 2-stroke synthetic
blend
All others
XP-S synthetic 2-stroke oil
or XP-S 2-stroke
synthetic blend
or XP-S mineral
injection oil
18 / 24 2006-1 Predelivery

FINAL PREPARATION
CAUTION: [1] XP-STM synthetic 2-stroke oil
and XP-S 2-stroke synthetic blend oil are
specially formulated and tested for the severe
requirements of these engines. Use of any
other brand two-stroke oil may void the limited
warranty. Use only XP-STM synthetic 2-stroke
oil or XP-S 2-stroke synthetic blend. There
is no known equivalent on the market for
the moment. If a high quality equivalent
were available, it could be used.
XP-STM mineral injection oil is a special blend
of basic oil and additives especially selected to
ensure unequalled lubrication, engine cleanliness
and minimum spark plug fouling.
The XP-STM 2-stroke synthetic blend and
XP-STM synthetic 2-stroke oil provides superior
lubrication, reduced engine component wear
and oil deposit, thus maintaining maximum-level
performance and antifriction properties. These
synthetic and synthetic blend injection oil meets
the latest ASTM and JASO standards by ensuring
high biodegradability and low exhaust smoke.
CAUTION: Never use four-stroke petroleum
or synthetic motor oil and never mix these
with outboard motor oil. Do not use NMMA
TC-W, TC-W2 or TC-W3 outboard two-stroke
engine oils or ashless two-stroke engine
oils. Avoid mixing different brands of API
TC oil as resulting chemical reactions may
cause severe engine damage.
WARNING
Wipe off any oil spills. Oil is highly flammable.
Model(s): 4-TEC Models
These models are equipped with a 4-stroke engine.
Use XP-S 0W40 synthetic 4-stroke oil
(P/N 293 600 054 )), or a high quality equivalent.
Break-in Period
Model(s): All Models except 4-TEC and 600 HO
SDI
To assure additional protection during the
initial engine break-in, 500 mL (17 U.S. oz) of
recommended injection oil should be added to fuel
for the first full filling of fuel tank. Always remove
and clean spark plugs after engine break-in.
Model(s): 4-TEC and 600 HO SDI
For fuel injection engines, no oil needs to
be added to the first fuel tank.
Oil Injection Pump Bleeding
Model(s): All except TUV
Remove muffler if needed.
Bleedmainoilline(betweentankandpump)
by loosening the bleeder screw [
[[
[2]
]]
]untilall
air has escaped from the line [
[[
[1]
]]
].
Add injection oil as required.
1
2
Model(s): WT/SWT Only
[
[[
[1]
]]
] No air in main line
[
[[
[2]
]]
] Bleeder screw
1
2
Model(s): LT Only
[
[[
[1]
]]
] No air in main line
[
[[
[2]
]]
] Bleeder screw
Check also for proper oil lever adjustment;
mark on lever must align with mark on pump
body when throttle lever is activated just
enough to take all cable free-play.
Predelivery 2006-1 19 / 24

FINAL PREPARATION
Bleed the small oil lines between pump and
intake manifold by running engine at idle while
holding the pump lever in fully open position.
Model(s): TUV 600 HO SDI Only
Oil injection pump is factory set. However, if
adjustment needs to be checked or modified,
refer to the SERVICE BULLETIN 2005–8.
Brake Fluid Level
1
A06G1O6
Model(s): All except LT
Check brake fluid in reservoir for proper level [
[[
[1]
]]
].
Add brake fluid as required.
Use brake fluid:
–SRF(DOT4)(P/N293600063)or
–GTLMA (DOT 4) (P/N 293 600 062).
CAUTION: To avoid serious damage to the
brake system, use only DOT 4 brake fluid from
a sealed container. Do not use brake fluid
taken from old or already opened containers,
nor mix different fluids for topping off.
Coolant Reservoir Level
Model(s): Liquid Cooled Only
CAUTION: Vehicle must be on a level surface
before checking any fluid level.
Check coolant level in the overflow coolant tank.
When the engine is cold, the level must be
between minimum [
[[
[2]
]]
]andmaximum[
[[
[1]
]]
] marks.
Use Bombardier premix coolant (P/N 219 700 362)
or a blend of 50/50 distilled water and
ethylene-glycol .
CAUTION: To prevent rust formation or
freezing conditions, always use ethylene glycol
antifreeze containing corrosion inhibitors
specially recommended for aluminum engines.
Always use 50% antifreeze and 50% water for
this particular type of snowmobile.
Track Adjustments
Refer to SHOP MANUAL and to TECHNICAL
DATA section at the end of this bulletin to
adjust track tension and alignment.
Brake Disk
Remove any rust built-up on braking surfaces.
Clean brake disk with pulley flange cleaner
(P/N 413 711 809).
Driven Pulley
Model(s): All except LT
It is usual to experience spring settings during
break-in period of a new spring.
The factory spring preload is slightly higher
to compensate for springs settings.
Specifications in TECHNICAL DATA are applicable
after break-in period (about 10 hours of use).
DELIVERY TO CUSTOMER
Predelivery Check List
Make sure to complete the “Predelivery Check
List”before delivering the vehicle.
20 / 24 2006-1 Predelivery
