koda Auto pursues a policy of constant product and model development. We trust that you will understand that changes to models in
terms of shape, equipment and engineering, may be introduced at any time. It is therefore not possible for legal claims to be made
based on the data, illustrations and descriptions contained in this wners Manual.
Reprint, reproduction or translation, either in whole or in part, is not permitted without the written consent from koda Auto.
koda Auto expressly reserves all rights relating to copyright laws.
We reserve the right to make changes to this document.
Published by K DA AUT a. s.
Swing.indd 2Swing.indd 2 9.9.2008 11:08:159.9.2008 11:08:15
© ŠKODA AUTO a.s. 2008

Contents 1
Contents
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio - Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important information . . . . . . . . . . . . . . . . . . . . . . . .
Anti-theft protection . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
2
2
3
3
5
7
7
s334.7.book Page 1 Tuesday, August 12, 2008 9:23 AM

Radio2
Radio
Radio - Overview
Rotary/push knob
−switching on and off (press for a long period of time)
−Reducing the volume (briefly press)
−Volume control (rotate)
−other function settings in various menus
Rotary/push knob to call up the menu settings of the parameter for
radio or CD player
Button to activate the audio source
Button to activate the radio mode
Buttons
−manual station finding, fast station finding
−Select the track in the CD mode, fast forward/backward search in the CD
mode
Button
−Display of radio text information
−Display of additional information of MP3-CDs
Button for adjusting the sound
Button automatically stores the station
Button to activate the reception of traffic reports
CD-case
CD - eject button
Station keys
−store and select the RDS station
−CD selection
−Enter code
Characters in the text
*Parts of the equipment which are marked in such a way are only installed as
standard on certain models or are available as special equipment.
End of the paragraph.
The paragraph continues on the following page.
Important information
Warranty
The equipment warranty terms and conditions also apply for new vehicles.
After the expiration of the warranty, a piece of equipment in need of repair will be
replaced with a reconditioned, original item with spare part warranty. It is, however,
a precondition that the housing has not been damaged and no unauthorised
attempts have been made to carry out repairs.
Note
Damage within the meaning of the warranty must not be the result of improper
handling of the system or from unprofessional repair attempts. It is also essential
that there is no external damage.
Operation of radio
The radio should only be used, if the traffic situation permits it.
The volume settings must be selected in such a way that audible signals from the
outside, e.g. a Martins horn from utility vehicles (police cars, ambulances and fire
brigade), can be heard at all times.
Power output
4x20 W
A
1VOL
A
2MENU
A
3MEDIA
A
4RADIO
A
5 
A
6INFO
A
7
A
8AS
A
9TP
A
10
A
11
A
12
s334.7.book Page 2 Tuesday, August 12, 2008 9:23 AM

Radio 3
WARNING
Please concentrate fully at all times on your driving! As the driver you are
fully responsible for road safety. Only use the functions of the radio in such
a way that you are always in full control of your vehicle in all traffic
situations!
Using the display
Carefully handle the display because dents and scratches can occur through pres-
sure of the finger or contact with sharp objects.
The display can be cleaned with a soft cloth and finger marks can be wiped away
with pure alcohol.
Note
Do not use solvent such as turpentine or petrol as they will corrode the display
surface.
Anti-theft protection
Anti-theft coding
Your radio is equipped with a convenience coding. If the radio is being operated for
the first time, the safety code is not only stored in the radio but also in the vehicle.
After disconnecting and reconnecting the battery, first of all switch on the ignition
and then the radio.
If you wish to install the radio in another vehicle, the safety code must be entered.
In this case, please do not hesitate to contact a Škoda Service Partner or a Škoda
importer.
As the unit only functions after entering the safety code, this practically excludes its
use after a theft - a contribution to increased anti-theft safety.
Note
The code is stored in the instrument cluster. This ensures that it is automatically
decoded (convenience coding). Manual input of the code is normally not
necessary.
Enter code
– Switch on the radio if the ignition is on.
– Enter the safety code using the station keys - .
– Confirm the safety code by pressing the station key .
If you have confirmed a wrongly entered code, you can repeat onceagain the entire
process.
If the code number is entered incorrectly for the second time, the unit will be
blocked for approx. one hour. It is possible to enter again the safety code after one
hour has expired, when the unit and the ignition have been switched on.
The cycle - two attempts, blocked for an hour - will continue to apply.
Basic setting
Switching the unit on and off
– The system is switched on or off by pressing the rotary/push knob
for a long period of time.
If the key is pulled out of the ignition lock with the unit switched on, the unit wil
switch off automatically. You can switch on again the unit by pressing the
rotary/push knob . When the ignition is switched off, the unit switches off auto-
matically after approx. one hour (discharge protection of the vehicle battery).
If you have switched off the radio by withdrawing the ignition key, the radio
switches on again once the ignition is on.
1 4
6
A
1
A
1
s334.7.book Page 3 Tuesday, August 12, 2008 9:23 AM

Radio4
Audio settings
– Press the button and then the station key and select the desired
parameter.
– Set the desired value by turning the rotary/push knob .
You can select between the following parameters:
•BASS - bass setting;
•MIDDLE - midtone setting;
•TREBLE - treble setting;
•BALANCE - setting of the volume ratio between the left and right side;
•FADER - setting of the volume ratio between the front and the rear;
•ON VOL
•PDC VOL
•GALA
•LOUD - in case of low volume level, this function reinforces the range of bass
and treble frequencies;
ON VOL
Your radio stores the last volume set before switching off. If the value is higher, the
volume is reduced to the value of the parameter ON VOL after switching on the
radio again.
GALA
Your radio increases automatically its volume with the increasing vehicle speed. A
higher setting value results in a stronger volume increase.
PDC VOL*
If your vehicle is equipped with “parking aid”, the volume is automatically
decreased to a pre-defined value, when the “parking aid” is active.
Setting the special functions
– Press the button longer.
– Select theindividual functions of the menu with the help of the station
keys.
– Set the desired value using the rotary/push knob or with the help
of the station keys.
AUX*
Switching on or off the functions of the external audio source.
Setting of the input sensitivity AUX LEV:
•AUX LEV 1 - high level, used in particular for notebooks;
•AUX LEV 2 - middle level, used for cassettes or CD player;
•AUX LEV 3 - low level, used for MP3 player;
PHONE*
If your vehicle is equipped with a handsfree system, you can switch on or off the
monophone play function of the mobile phone calls via the loudspeakers of the
vehicle.
BEEP
Switching on or off the tone signal when storing the radio stations.
ILLUM
Switch on (value 2) or switch off (value 1) the rear lighting of the control buttons for
the radio.
AF
The function alternative frequency (AF) ensures that the best receivable frequency
of the selected station is automatically and precisely set. The replay of the broad-
cast can be muted briefly during the search process according to the best receiv-
able frequency. If no alternative frequency of the set station can be found and the
station no longer offers a satisfactory quality, then please select another station.

A
12
A
2
MENU
A
2
A
2
s334.7.book Page 4 Tuesday, August 12, 2008 9:23 AM

Radio 5
REG
Certain programs of the broadcasting companies are divided into regional
programs at specific times. That is why in individual regions the regional programs
of a station can broadcast different contents.
First of all the unit attempts to set only alternative frequencies of the selected
station.
If the quality is however so low, that there is a risk of a “program loss”, the unit also
accepts “related” frequencies.
•FIX - the receiver switches to a regional “related” station, if the reception of the
current station could be interrupted;
•AUTO - the receiver can access the regional “related” station unlimited.
BT-AUDIO*
Enables a wireless transfer of MP3 data to the telephone preinstallation.
Radio mode
Waveband switch-over
– Press the button for a long period of time.
Your radio is equipped with FM and AM wavebands. They are divided in 6 memory
levels, i.e. 3 levels for the FM waveband and 3 levels for the AM waveband. There
are each 6 memory spaces available on these levels.
Activation of the FM waveband
The FM waveband is activated when pressing the station key FM. By briefly
pressing the button , you can select between the memory levels FM1, FM2
and FM-AS.
Activation of the AM waveband
The AM waveband is activated when pressing the station key AM. By briefly
pressing the button , you can select between the memory levels FM1, FM2
and FM-AS.
The process of searching for and storing the radio stations
Manual search
– Set the frequency of the desired radio station by pressing the button
or or by turning the rotary/push knob .
Store station
– After selecting the radio station, hold the station key , on which it
should be stored until it briefly switches to mute and a brief signal
sounds.
Automatic station finding with storing the radio stations
– Press the button . An automatic station finding is started during
which the 6 stations with the strongest signal in the memory level FM2
and/or AM2 are stored. This applies only to the wavebands FM2 and
AM2.
When storing the radio stations on the station keys is finished, you can call up
the desired radio station by pressing a station key .
Note
The stored radio stations of the current waveband are updated and stored once
again by repetitively pressing the button .
Radio text
Certain radio stations transmit additional text information - designated as
radio text.
– The information of the radio text is displayed by pressing the button
.
RADIO
A
12
RADIO
A
12
RADIO
 
A
2
A
12
AS
A
12
A
12
AS
INFO
s334.7.book Page 5 Tuesday, August 12, 2008 9:23 AM

Radio6
Note
•The text information must not be available to all radio stations.
•Depending upon the quality of the received signal, the radio needs a specific
time, in order to correctly read all the illustrated characters.
Traffic reports
Activating and deactivating the traffic reports
Press the button , TP appears in the display. If a set radio station does not
transmit a traffic report, the radio searches for a station which transmits the traffic
report.
An incoming traffic report automatically interrupts the CD play function or listening
to a radio station, which at that moment is not transmitting a traffic report. At the
end of the traffic report, the radio automatically returns to the original play func-
tion.
If you wish to deactivate the traffic information, press once again the button , TP
goes out on the display.
Function SCAN
The stations of a waveband can be played briefly one after the other (for
ten seconds).
– Press the set button , the radio searches automatically all available
stations of the current waveband.
– In order to call up the original radio station, press the station key
CANCEL.
– End the automatic finding by pressing the button OK. The current
radio station remains selected.
– If you wish to select other radio stations, press the button SKIP.
TP
TP
A
2
A
12
A
12
A
12
s334.7.book Page 6 Tuesday, August 12, 2008 9:23 AM

CD player 7
CD player
Using the system
Inserting the CD
– Press the button , in order to select the audio source: CD
(internal CD drive), CDC (external CD changer), AUX (external input)
and BT-AUDIO (wireless transfer of MP3 data to the telephone prein-
stallation).
– Carefully insert a CD into the CD case until it is automatically
drawn in. The play function begins automatically.
Operating the CD player
Select track
– Briefly press the rocker switch or during the play function of
the CD or turn the rotary/push knob , in order to select the previous
and/or the next title.
– Press the button or longer for fast replay of the track (reverse
or forward). The play function is continued after releasing the button.
Function SCAN
– Briefly press the control button , in order to scroll through the CD.
The first 10 seconds of each title are played.
– In order to call up the original replayed title, press the station key
CANCEL.
– End the automatic finding by pressing the button OK. The already
replayed title remains selected.
– If you wish to select another title, press the button SKIP.
End the play function of the CD
– In order to end the play function of the CD, press the desired station
key.
Ejecting CD
– Press the button , the Cd is ejected.
Note
•If the ejected CD is not removed, it is drawn in again for safety reasons.
•If the radio is functioning in the TP mode before changing to the CD mode, the
play function of the CD is interrupted during the traffic reports and the unit switches
over to the radio mode. After the traffic reports have ended, the unit switches back
once again to the CD mode.
Play function of MP3 data
Display of additional information
– Press the button , the additional information for the current title
is displayed on the display.
– You can select the additional information with the station buttons ,
which is displayed on the display.
Selective functions in CD mode
During the CD play function the following functions are displayed on the display:
RPT
Selection of the mode for repeating the title.
•OFF - Play function in continuous order;
MEDIA
A
10
 
A
2
 
A
2
A
12
A
12
A
12
A
11
INFO
A
12
s334.7.book Page 7 Tuesday, August 12, 2008 9:23 AM

CD player8
•TRACK - repeated play function of the selected title;
•FOLDER - is a CD inserted with MP3 data, the titles are repeated from the folder,
which was active when starting the repeat mode.
MIX
Play function of titles in random order.
•OFF - Play function in continuous order;
•ON - Play function of titles in random order in a certain folder (folder);
FLD DOWN (PREV PL - for the play function of the play list)
Scroll downwards in the folders.
FLD UP (NEXT PL - for the play function of the play list)
Scroll upwards in the folders.
PLAYLIST
Play function of the playlist (folder of selected titles from individual folders, which
is stored on the CD).
General information for MP3 operation
Requirements for the MP3 data and data carrier
•650 MB and 700 MB CD-ROM, CD-R, CD-RW.
•The CDs must correspond to the ISO 9660 Level 2 standard as well as the Joliet
data system (single and multi-session).
•Data names must be no longer than 64 characters.
•The list structure is restricted to a depth of 8 list levels.
•The name of the artist, the album and the title of the reproduced MP3 data can
be shown as ID3 tag, providing this information is available. The list and data name
will be displayed if there is no ID3 tag.
•Play lists are not supported.
•WMA data (Windows Media Audio) can also be played even if the copyright is
additionally protected by the DRM procedure (Digital Rights Management). Such
WMA data is not supported by the unit.
Bit rate (data flow per time unit)
•The system supports MP3 data with bit rates of 32 to 320 KB/s as well as MP3
data with variable bit rates.
•The indicated playing time data with variable bit rates is not reliable.
Playing sequence of MP3 data and folders
Fig. 1 Playing sequence of
MP3 data and folders
s334.7.book Page 8 Tuesday, August 12, 2008 9:23 AM
