SKOPE Deluxe Bathroom Fan Heater
Operating Instructions PRN0355 Rev. 2.0 March 2010

288E
SKOPE Deluxe Bathroom Fan Heater
Introduction
Designed for easy installation,your SKOPE 988E Deluxe Bathroom
Fan Heater incorporates a unique wall-mounting hinged chassis,
making installation faster and easier. The heater also featuresan
installeradjustablestep-downthermostat,whichcanbeadjustedorby-
passed during installation.
Safety Information
Whenusinganyelectricalappliance,safetyprecautionsshouldalways
be observed.Read these instructions carefully, and retain for future
reference. For service, contact your nearest authorised service agent.
•Under no circumstances should an unauthorised person open the
heater, in order to adjust the thermostat.
•When used by, or near, young children or infirm persons, close
supervision is necessary. Young children should be supervised to
ensure thatthey do not play with the appliance.
•Do NOTuse this appliance other than for its intended use.
•Use this appliance with the voltage specified on the rating label.
•Be very careful notto touch hot surfacesor moving parts.
•Do NOTcover the grilles or place any objector material up against
the unit, as this may block entry or exhaust of airflow.
•Do NOT probe any opening toremovefluff.To ensure trouble-free
performance itis recommended that on a regular basis the unit be
isolated from the power supply and a vacuum cleaner used to
remove dustand fluff from the inlet and outlet grilles.
•Regulations require that electrical work be carried out by
authorised persons. For your own safetyand that of others,ensure
this is done.
•Do NOTallow the supplycord to come into contact with heated
surfaces during operation.
•Ifthe supply cord becomes damaged, itmustbe replaced by a
SKOPE authorised service agent, or similarly qualified person,in
order to avoid a hazard.

3
88E
SKOPE Deluxe Bathroom Fan Heater
Safety Cutout
Your SKOPE 988E Deluxe Bathroom Fan Heater isfitted with an auto-
resetthermal cutout and a fusible link. Either of these devices will
automaticallyswitch offthe elementsand the motor, should the unit
reach an abnormal temperature. Should this occur:
1.Disconnect heater from power supply
2.Checkfor blockage of the air inletand outlet
3.Use a vacuum cleaner to clean if necessary
If the heater still failsto operate, contact your nearest authorised
service agent.
Operation
Air isdrawnthrough the slotsin the cover of the heater by atangential
fan, blown over heating elements, and then blown out through the
bottom louvred grille into the room. The heater is controlled by the pull-
cord switch.
The heat output is regulated by an internal, step-down,thermostat
which will reduce the output from 2200-2400 Watts to 1100-1200
Watts, when a comfortable room temperature is reached. The heat
output isshown by the two neon indicators on the frontgrille:
•One neon glowing:the heater isoperating at 1100-1200 Watts
•Two neons glowing:the heater is operating at 2200-2400 Watts
Alternatively the heater can be operated via external wall switches,
fitted during installation,which as well as turning the heater on and off
can also override the thermostat, acting as a ‘Boost’ switch.
Care
Theheaterisbestwipeddown, fromtimeto time,withadampcloth.Do
not use any abrasive cleaners.

488E
SKOPE Deluxe Bathroom Fan Heater
Specifications: model 88E
SKOPE Industries Limited reserve the right to alter specifications without notice.
Contact Addresses
Electrical
Supply: 230-240 Volts a.c. 50 Hz.
Wattage: 2200-2400 Watts, thermostatically reduced to 1100-1200 Watts
Wiring: 600mm flexiblecord fitted with3-pinplug
Ingress Protection Rating: IPX1
Dimensions
Height: 235mm
Width: 460mm
Depth: 112mm
Weight: 4.4 kg
New Zealand
SKOPEINDUSTRIES LIMITED
PO Box 1091, Christchurch
New Zealand
Freephone:0800947 5673
Fax: [phone]
Email: [e-mail]
Website: www.skope.co.nz
Australia
SKOPE AUSTRALIA PTY LTD
A.C.N. 000 384 270
PO Box 7543, BaulkhamHills
NSW 2153, Australia
Freephone:1800121 535
Freefax: 1800 121 533
Email: [e-mail]
Website: www.skope.com.au
