Skotero FORCE XR User manual

CONGRATULATIONS
TO YOUR SKOTERO FORCE XR
With the purchase of your SKOTERO FORCE XR
e-scooter you have acquired a quality product. The
Skotero Force XR consists of high quality components
and is manufactured under strict quality control.
Before using the Skotero Force XR, please read all
instructions for safe operation.This user manual
will guide you through the functions and use of
this e-scooter. Before using this e-scooter, please
familiarize yourself with its operation so that you can
keep it in the best possible condition.
This e-scooter is not suitable for children under
14 years of age. Check the rules that apply in your
country or place of residence.
We wish you a lot of fun and many safe kilometers
with your Skotero Force XR!
What’s in the box?
Battery charger Manual

CONTENTS
GENERAL INFORMATION
KEY COMPONENTS
HOW TO USE THIS E-SCOOTER
SAFELY PARKING YOUR E-SCOOTER
TRANSPORTING THE E-SCOOTER
WARNINGS
CLEANING
POSSIBLE MALFUNCTIONS AND SOLUTIONS
SPECIFICATIONS
WARRANTY CONDITIONS
WARRANTY CARD
1
2
3
4
5
6
7
8
9
10
11
1. GENERAL INFORMATION
This manual introduces you to the proper use, functions, safety tips and features of the Skotero Force XR. This manual
contains important information, read it carefully for the safety of yourself and others. It is your responsibility to follow this
manual and the instructions it contains carefully and to make them known to others who use this electric scooter. Make
sure that others understand all instructions and safety tips. We advise you to regularly go over the instructions with any
other riders of the scooter. You can then also check the scooter for any defects.
When using the Skotero Force XR for the first time, make sure to practice in a place where there are no obstacles and to
get to know all the possibilities of the Skotero Force XR.
Enjoy riding your new electric scooter!
Check the legislation regarding electric scooters in your country and take
out a vehicle- and/or liability insurance.
Our company is not liable for any damage or consequential damage cau-
sed directly or indirectly by the use of the electric scooter.

2. KEY COMPONENTS 3. HOW TO USE THIS E-SCOOTER
3.1 UNFOLD
1: Pull the lever at the bottom of the steering rod towards you.
2: Pull the steering rod up until you hear a click and the folding mechanism is locked. Attention: Put your foot on the running
board while pulling up the handlebars. A firm push will lock the folding mechanism. In the beginning this is hard to do!
3: Pull up the handlebars left and right until you hear a click.
3.2 FOLD
1: Pull the lever at the bottom of the steering rod towards you. This requires a certain amount of force at the beginning
because the locking mechanism is fixed tightly. Later it will move more smoothly.
2: Slide out the rings next to the handles and fold the handles in.
3: Pull the steering rod down until you hear a click.
3.3 START RIDING
1: Insert the key into the keyhole at the right below the display.
2: Turn the key to the 1st position on the right below the display to start the scooter.
3: Turn the key to the 2nd position on the right below the display to turn on the lights.
4: When the Skotero Force XR is switched on and you are ready to ride, stand with one foot on the running board and put your
other foot on the ground to push yourself off.
5: Turn the handle towards you to accelerate, stand on the e-scooter with your second foot and keep your balance.
6: When you want to brake, use the hand brake levers which are located on both the left and right side of the handlebar. Press
both to come to a halt.
7: Make sure you push up the stand before riding.
8: Make sure you turn on the lights while riding.
9: Make sure you do not step on the rear fender while driving. This may lead to malfunction.
10: On the right side of the handlebar is the bell, use it when necessary.
1 2 3
12 3
1. Handle
2. Gas handle
3. Handbrake
4. Display
5. Light
6. Suspension
7. Folding hinge
8. Tail light
9. Suspension
10. Side stand
11. Reflectors
12. Front wheel
13. Steering rod
14. Loading port
15. Rear wheel
1
2
8
10
9
6
5
7
11
12
13
14
54
3
15

Speed in km/h
Battery status
Trip distance
3.4 STOPPING AND BRAKING
1: Braking is done by gradually pressing the left brake lever (this is the rear brake) and the right brake lever (this is the front
brake) simultaneously.
2: Always use the front and rear brakes simultaneously to brake safely. Practice braking safely several times. If you apply too
much braking force suddenly and, for example, only on the front wheel, you run the risk of tipping over. Always lean back a
little during braking.
3: For safety reasons, always check your brakes before every ride. If the brake force decreases significantly during use, you
should have it repaired. The scooter may only be used again after repair.
4: By turning the key under the display to the left, you switch off the electric scooter.
3.5 CHARGING YOUR E-SCOOTER
1: First switch off the electric scooter!
2: Make sure the charging port is clean and dry.
3: Plug the supplied charger into the charging port on your e-scooter. Never use another charger!
4: Connect the adapter of the power supply unit to an electrical outlet.
The power supply LED indicator will now turn red, indicating that the battery is being charged. When charging is complete, the
LED indicator will change colour from red to green. Charging time is 7 hours on average.
Red: not fully charged
Green: fully charged
5: Disconnect the charger from the electric scooter and from the wall socket.
6: When the plug is connected to the charging port, sparks may occur due to the voltage difference, this is normal.
7: Make sure you only use the original charger. Any other charger may cause electrical problems and serious damage to the
battery.
8: Always charge your e-scooter in a safe area, preferably not overnight. While charging, check regularly that no extreme heat
is generated in the footboard or charger.
3
The use of non-standard chargers or the use of different voltage chargers
may cause insufficient charging or fatal damage to the battery or the
electrical system.
4. SAFELY PARKING YOUR
E-SCOOTER
After stopping the scooter, get off and push the side stand down with your foot to support the scooter. The side stand is located
on the left side of the e-scooter under the running board. Before you ride again, fold the side stand back up so that it is parallel
to the running board.
5.TRANSPORTING YOUR E-SCOOTER
Fold up the e-scooter. Do not drop it during transport; do not place it near fire; do not place it near explosive materials. Secure
the e-scooter in your vehicle.
3
1 2 3 4
7 8
8
65
910
3.6 OPERATION AND EXPLANATION OF THE DISPLAY
1: Turn on the display by turning the key to the right.
2: The display shows the battery status, the speed and the trip distance.
1 2 3
57
4
41
Hard impacts against the e-scooter, dropping it, etc. can cause serious risks.
Damaged batteries pose a great danger of self-ignition!

6.WARNINGS
6.1 LEARN HOW TO DRIVE SAFELY BEFORE TAKING THE ELECTRIC SCOOTER ON THE ROAD
If service/repair is required, please send a message to [email protected]. A ticket will be made for you immediately and your
question will be taken into consideration.
6.2 PREPARATION
Claims under this guarantee must then be submitted under offering the scooter etc. and at the direction of Orange Ventures
BV.
6.3 WEIGHT LIMITATION
Reason for weight limitation:
Ensuring the safety of the rider
Avoiding overload damage
Do not try to turn too fast.
Use the device only at temperatures between 0 °C and +45 °C.
6.4 RANGE PER CHARGING CYCLE
The range depends on several factors:
Road surface conditions: on flat paths you have a wider range than on uneven ground.
Weight: the range depends on the weight of the load.
Temperature: extreme temperatures reduce the range.
Tyre pressure: if the tyres are not inflated to the required pressure, the range is reduced.
Maintenance: if the electric scooter is properly charged and the battery is kept in good condition, the range is increased.
Driving fast results in progressively higher power consumption and a sharp reduction in range.
As the battery ages, its range will also decrease. Remember that with older batteries, your flash light will also shine less
brightly.
Speed and driving style: at a constant speed, the range is greater than with frequent stopping, accelerating and braking.
6.5 SAFE DRIVING
To keep the electric scooter in good condition, read all installation and operating instructions carefully before using the vehicle.
Observe all safety instructions when riding the scooter.
This electric scooter is designed for individual use only.
Riding a scooter is not recommended for children (please check local laws for age limits), the elderly and pregnant women.
People with a limited sense of balance are not allowed to ride the scooter.
Avoid riding the scooter under the influence of alcohol or other intoxicating substances.
Do not carry any objects in your hands while riding.
Make sure you have a clear view.
Your feet should always be on the running board when riding.
The scooter is suitable for one person only.
Do not start or stop abruptly.
Avoid riding on steep slopes.
Stop riding the scooter if you hit an object (such as a wall or other structure).
Do not ride in poorly lit or dark places.
Ride the scooter at your own risk, we accept no liability for accidents or damage.
Ride at a safe speed that allows you to stop at any time.
Keep the scooter at a sufficient distance from other people and avoid collisions.
Steer by means of shifting balance. Quick movements can lead to falls.
Do not ride in rain or other wet conditions. Only ride in dry weather.
If possible, avoid driving over obstacles and avoid snow, ice and slippery surfaces.
Avoid driving over textiles, small branches and stones, if possible.
If possible, avoid driving in narrow places or surfaces with obstacles.
If getting on and off the vehicle causes damage, this is not covered by the warranty. There is danger of injury.
6.6 CHARGING
Make sure that the electric scooter, charger and DC power supply of the device are always dry.
Note: for charging this e-scooter, only use the charger supplied. another charger may cause damage to the device and other
potential risks.
Use the mains adapter to plug the DC input of the unit into a conventional power outlet.
Make sure that the green indicator on the mains adapter is lit.
The red light is lit when the unit is not properly charged; if this is the case, check the connections.
If the indicator on the charger changes from red to green, the battery is fully charged.
Now you can stop the charging cycle. Overcharging shortens battery life.
Charging takes approx. 7 hours. Do not charge the battery longer than 7 hours. After 7 hours, you should disconnect.
6.7 BATTERY WARNINGS
Do not attempt to replace or modify the battery.
Never use your Skotero Force XR when the battery smells strange, overheats or leaks.
Do not touch leaking materials or inhale the emitted fumes.
Do not allow children or animals to touch the battery.
The battery contains dangerous substances, do not open it, do not insert anything.
Use only the charger supplied by Skotero Force XR.
Do not attempt to charge the Skotero Force XR if the battery is deeply discharged or has emitted dust. In that case you
should contact your dealer.
Follow all local, state and federal laws regarding recycling, handling and disposal of Lithium Ion batteries.
The electric scooter may only be shipped in its original packaging.
7. CLEANING
7.1 CLEANING AND STORAGE OF YOUR ELECTRIC SCOOTER
1. Clean the scooter with a damp cloth, do not immerse it in water.
2. Do not use alcohol, petrol or washing powder to clean the scooter, because the paint or other parts of the scooter may be
damaged.
3. Do not use a water jet or high-pressure cleaner. Make sure the electric scooter is switched off and the charging cable is
disconnected during cleaning. Always make sure that no water can get into the inside of the scooter.
4. When the scooter is not in use, try to store it in a dry and cool place indoors. Try to avoid outside storage. Prolonged
exposure to sunlight and/or overheating will accelerate the ageing process of the scooter’s appearance, tyres and battery.
7.2 MAINTENANCE OF THE BATTERY OF AN ELECTRIC SCOOTER
1. Do not use other models or brands of batteries, otherwise there is a safety risk. Use the original charger only.
2. Do not touch the battery poles. Do not disassemble the battery pack. Prevent contact of the battery poles with metal;
damage and/or short circuit may occur.
3. Incorrect disposal of used batteries can cause serious pollution of the environment. Therefore, comply with local laws and
regulations when disposing of this battery pack.
4. Do not store the battery pack where the temperature is above 50°C or below -20°C (for example, by leaving the scooter or
battery pack in a car exposed to the sun).

Driving range decreases
1. Insufficient battery charge
2. Tyre pressure is not sufficient
3. Frequent braking, starting or overloading
4. Battery ageing or normal decrease in capacity
5. Low ambient temperature and therefore
reduction of battery capacity
1. Check whether the charger is damaged
2. Check tyre pressure before use
3. Develop good driving habits
4. Replace the battery
5. Normal phenomenon
The battery cannot be
recharged
Display does not turn on
1. The charger is not connected
2. The battery temperature is too low
3. The battery is too hot
1. Check whether the plug is loose
2. Wait until the battery has reached the
correct charging temperature
1. There is no power supply
2. The power converter is damaged
3. The dashboard is defective
1. Check that the battery is connected
2. The battery is defective
3. Contact after-sales service to have the
fault rectified
4. Check the fuse
8. POSSIBLE MALFUNCTIONS AND
SOLUTIONS
POSSIBLE MALFUNCTIONS CAUSE SOLUTION
No power after power on There is no power supply
1. Check that the battery is installed
and connected with the plug
2. Battery voltage is insufficient, charge
the battery
MODEL
INPUT
OUTPUT
MAX SNELHEID
WEIGHT
YEAR OF PRODUCTION
WEIGHT LOAD
BATTERY
POWER CONSUMPTION
The maximum speed and
maximum accessible
distance is determined by
the weight of the rider, the
speed being ridden, the
weather conditions, the
tyre pressure and the age
of the battery. A full charge
is also necessary for best
performance. Bear in mind
that a lot of acceleration,
driving against the wind,
going uphill, a lot of weight
or driving at maximum
speed increases the power
consumption enormously
and decreases the range.
9. LIST OF PARAMETERS
PARAMETERS
Folded
DIMENSIONS
QUALITY
E-SCOOTER
BATTERY
TYPE: LI-ION BATTERY
ENGINE
Unfolded
Maximum weight load
Weight of e-scooter
Ground
Battery pack
Engine power
Flat, dry ground
Skotero Force XR
2020
100 kg
48 V 13 Ah
500 W
500 W
115 x 16 x 38 cm
BATTERY CHARGER
Charging time ca. 7 h
Rated voltage
Rated input voltage
Rated output voltage
20 km/h
18,6 kg
54,6V 2A
100 kg
18,6 kg
48V 13Ah
48V
54,6V 2A
100-240V, 50-60Hz
100-240V, 50-60Hz
121 x 54 x 122,5 cm
Max. speed 20 km/h

LIGHTING
Stop light
Direction indicators
FEATURES
Range
Suspension
Display
Bell
10. WARRANTY TERMS
SKOTERO IS A REGISTERED TRADEMARK OF ORANGE VENTURES B.V.
ARTICLE 1 WARRANTY
1.1 Orange Ventures B.V. guarantees that the Skotero scooters are free of construction and/or material errors, in as far as this
follows from these guarantee conditions.
1.2 In case the product proves to be defective due to defects in material or finish during the guarantee period, Orange
Ventures B.V. or a Skotero dealer in the guarantee area will, at its own discretion, repair or replace the product or the
defective parts under the conditions mentioned below, without charging any costs for labour or parts. Orange Ventures B.V.
and the Skotero dealers can replace defective products or parts with new or reconditioned products or parts. All replaced
parts and products become property of Orange Ventures B.V.
1.3 This warranty will only be granted within the warranty period and on presentation of the original invoice or receipt
(mentioning date of purchase, model name and dealer) together with the defective product. Orange Ventures B.V. and the
Skotero dealers may refuse free warranty service if these documents are not submitted or are incomplete or illegible. This
warranty is void if the model name or serial number has been changed, deleted, removed or made illegible or if it is visible
that unauthorized repairs or changes have been carried out.
1.4 The warranty can only be invoked by the first owner of the Skotero product in question.
1.5 This guarantee does not cover transport costs nor risks related to the transport of your product to and from Orange
Ventures B.V. or your Skotero dealer.
1.6 The guarantee expires according to the provisions of articles 3.1 and 3.2. As far as batteries and some electronic parts are
concerned, restrictions apply as mentioned in article 5.2.
1.7 The guarantee provided by Orange Ventures B.V. on the basis of these terms and conditions does not affect the possibility
to appeal to the seller on the basis of the ordinary, legal provisions.
ARTICLE 2 WARRANTY PERIOD
2.1 You can only claim under the guarantee if you have filled in the guarantee card and submitted the original proof of
purchase. The warranty card can be found in your manual or can be filled in online at https://www.skotero.co.uk/warranty-
card/. The warranty period begins on the day of purchase.
2.2 Skotero aluminium frames are guaranteed for 2 years on construction and/or material faults; for Skotero steel frames the
guarantee period is also 2 years.
2.3 Suspension forks, shock absorbers and all other parts, except for the parts mentioned in the following subsection (2.4) of
this section, are guaranteed for a period of 1 year.
2.4 No warranty is given on parts that are subject to wear and tear, such as tyres, chain, sprockets, freewheel, rear sprockets,
cables and brake pads, unless there are design and/or material defects.
2.5 Other parts, provided they are properly maintained, are covered by a warranty of 1 year. For additional provisions, see
article 5.
ARTICLE 3 WARRANTY EXCLUSIONS
3.1 IN THE FOLLOWING CASES, THE WARRANTY BECOMES NULL AND VOID:
1: Incorrect and/or careless use of the Skotero product and use that is not in accordance with its intended use;
2: The Skotero product has not been maintained in accordance with the instructions;
3: Technical repairs have been carried out without the authorization of Orange Ventures B.V. and/or have not been carried out
professionally;
4: Subsequently mounted parts do not comply with the technical specification of the electric scooter in question or have been
assembled incorrectly;
5: If the proof of ownership or proof of repair stating that the electric scooter has been properly assembled and checked
before delivery to the customer is not available or not signed by the seller;
6: If the Skotero product has been sprayed with pressurized water as with garden hose and/or high-pressure cleaner;
3.2 FURTHERMORE, THE LIABILITY OF ORANGE VENTURES, E.G. FOR DAMAGE TO (PARTS OF) THE ELECTRIC
SCOOTER AS A RESULT OF THE ABOVE IS EXPLICITLY EXCLUDED:
1: Incorrect adjustment / tension of handlebar, stem, brakes, quick release of the wheels and spoke tension if applicable;
2: Failure to replace parts such as brake, brake pads, tyres, chain and sprockets on time;
3: Incorrect or insufficient lubrication of rotating parts and/or parts for which this has been specified.
4: Climatic influences such as normal weathering of paint, rust or chrome rust.
5: Wrong use of the scooter. Incorrect use includes jumping with the scooter, use in places other than the normal road (read
the regulations of your country), including half-pipes, springboards, etc.; overloading the scooter ( max. weight is stated on the
packaging and scooter) by weight or otherwise.
Yes
No
40 km under ideal conditions
Yes
front & back
Yes
Headlight
Tail light
Yes
Yes

3.3 THE ELECTRIC SCOOTER IS INTENDED FOR PRIVATE USE ONLY.
Professional use such as rental or other intensive commercial use is excluded from warranty.
ARTICLE 4 WARRANTY PARTS
4.1 During the guarantee period, all parts identified by Orange Ventures B.V. as having a material and/or construction fault
shall, at Orange Ventures B.V.’s discretion, be repaired, sent free of charge or reimbursed. Any costs of (dis)assembly shall be
borne by Orange Ventures B.V.
4.2 Costs of transport of the Skotero product and/or parts from and to Orange Ventures B.V. shall be at the expense of the
owner, unless the part in question qualifies for warranty; prior consultation shall take place regarding the manner of transport
to the service centre (Orange Ventures B.V. or the local dealer).
4.3 If a certain part qualifies for warranty and the original is no longer available, Orange Ventures B.V. will provide a minimum
equivalent alternative.
ARTICLE 5 ADDITIONAL WARRANTY CONDITIONS
5.1 Consult the manual of your Skotero Force XR product for additional warranty conditions.
5.2 Warranty period electronics parts:
Skotero electric scooters: electric motor, controller and charger: 2 years.
EXTRA PROVISIONS BATTERY:
1: Skotero battery warranty period; Li-ion battery: 1 year.
2: If batteries, chargers or electronic parts show fall damage, the warranty will be void.
3: Normal wear and tear/reduction of battery capacity is not covered by the warranty. Batteries lose capacity over time.
Li-ion batteries lose capacity even when not in use. Batteries that are not used for more than one month can self-discharge
(self-discharge, or deep discharge is not covered by this warranty). Batteries that are less than 10 % charged must be
recharged immediately otherwise they will be irreparably damaged and are not covered by the warranty! Orange Ventures
B.V. guarantees that within 1 year after purchase the battery retains at least 70 % of its specified capacity, provided that the
charging and maintenance requirements of the battery are met.
ARTICLE 6 SUBMISSION OF CLAIM
6.1 Claims under this warranty must be submitted for inspection via the Skotero dealer from whom the electric scooter was
purchased or a Skotero service centre (see the website for addresses). At the same time, the proof of purchase as well as the
proof of ownership delivered with the electric scooter must be handed over to the dealer.
6.2 In case the owner has moved or the dealer is no longer available, Orange Ventures B.V. will, upon request, give the name
of the nearest Skotero dealer.
ARTICLE 7 WARRANTY AREA
7.1 The warranty area is limited to the European countries in which Orange Ventures supplies itself.
ARTICLE 8 LIABILITY
8.1 A guarantee claim honoured by Orange Ventures B.V. does not automatically mean that Orange Ventures B.V. also accepts
liability for any consequential damage, whether material or immaterial. The liability of Orange Ventures B.V. shall never extend
beyond that described in these guarantee conditions.
Any liability of Orange Ventures B.V. for consequential damage is expressly excluded. The provisions of these terms and
conditions shall not apply if and insofar as this results from a provision of mandatory law.
ARTICLE 9 EXCLUSIONS AND LIMITATIONS
9.1 Except as stated above, Orange Ventures B.V. does not give any warranties (whether explicit, implicit, legal or any other)
with regard to the quality, performance, accuracy, reliability, suitability for a particular purpose or any other quality of the
product or part thereof. If this exclusion is not or not fully permitted by the applicable legislation, the exclusion or limitation
of the guarantee of Orange Ventures B.V. shall only apply to the maximum extent permitted by the applicable legislation.
Any guarantee that cannot be fully excluded shall (to the extent permitted by applicable law) be limited to the duration of this
guarantee. This guarantee obliges Orange Ventures B.V. exclusively to repair or replace the products covered by the terms
and conditions of this guarantee. Orange Ventures B.V. is not responsible for any loss or damage relating to products, service,
this guarantee or other, including - economic or tangible losses - the price paid for the product - loss of profit or income,
loss of data, enjoyment of the product or other related products - indirect, secondary or consequential damage or loss. This
applies regardless of whether this damage or loss is related to fault or non-functioning of the product or related products due
to defects or because the product is unavailable while at Orange Ventures B.V. or at a Skotero dealer, resulting in downtime,
loss of operating time or interruption of work. This applies to loss and damages according to any legal interpretation, including
negligence and other illegalities, breach of contract, explicit and implicit guarantee, and civil liability (even if Orange Ventures
B.V. or a Skotero dealer has been informed of the possibility of such damages). If the applicable legislation prohibits or limits
such exclusions of liability, Orange Ventures B.V. shall exclude or limit its liability to only the maximum extent permitted by
the applicable legislation. For example, in certain countries it is forbidden to exclude or limit damages for negligence, gross
negligence, wilful misconduct, fraud and similar acts. Orange Ventures B.V.’s liability under this guarantee shall under no
circumstances exceed the price paid for the product, but if the applicable legislation only permits higher limitations of liability,
the higher limitations shall apply.
9.2 Consumers have legal rights under applicable national laws relating to the sale of products to end users. This warranty
does not affect any legal rights that you may have, nor any rights that cannot be excluded or limited, nor any rights against
the person from whom you purchased the product. You may exercise any rights you may have in your sole discretion.

Mr/Ms
First name
Name
Street
Postcode
Place
Country
Telephone number
Email address
Please enter the following information on our website
VIN-NUMBER
(FRAME NUMBER)
Date of purchase
Purchased at (name of dealer)
https://www.skotero.uk/warranty card/
WARRANTY CARD SKOTERO FORCE XR
