Sky Detective SD30 User manual

1
SD30 user manual

2
Introduction
Sky Detective’s SD30 Tracker uses Qualcomm’s CDMA
gpsOne technology. The SD30 provides tracking, security
and recovery of high-value packages/assets in real time or
on demand. Sky Detective’s SD30 provides accurate
location capability, even in impaired environments such as
inside trailers and closed packages without the use of
external antennas.
The device can set to follow up the enwrap, baggage or cars,
custody the special crowd.
Install the Battery
You must install and charge the battery to use your device.
Insert the ridge at the side of the battery into the base of the
device, then push the battery down and snap it into place.
Remove the battery
Shove the button as the direction of the arrowhead, slide the
battery down as the other arrowhead.

3
SD30 Software ApplicationFeatures
1 Power key Turn on or off the device，and do
some different function according to
the pressing time.
2 Accessory
Connector
Port
Insert charger, data cable and other
accessories.
3 Indicate light Indicate the currently state.
The SD30 has a single programmable button located on the
bottom left hand corner of the device.
zTurn the SD30 ON or OFF. The SD30 can be
programmed to have the button turn the device ON or
OFF. The device could accidentally be turned off while
being used. This would fundamentally render the
device inoperable. Extreme caution should be used.
zCheck the Status of the Battery. The SD30 can be
programmed to have the button provide the status of
the battery. A low battery notification could be
displayed on the LED or sent over the air. Battery
usage would increase and drain the battery at a
potentially much faster rate until the battery is fully
discharged. This would fundamentally render the
device inoperable. Extreme caution should be used.
zRequest a location fix. The SD30 can be
programmed to have the button request a location.
A valid location fix request could be displayed on the

4
LED or sent over the air. Battery usage would
increase and drain the battery at a potentially much
faster rate until the battery is fully discharged. This
would fundamentally render the device inoperable.
Extreme caution should be used.
zCheck the Status of CDMAcoverage. The SD30 can
be programmed to have the button check the status of
CDMA coverage. A status of the CDMA coverage
could be displayed on the LED. Battery usage would
increase and drain the battery at a potentially much
faster rate until the battery is fully discharged. This
would fundamentally render the device inoperable.
Extreme caution should be used.
The connector port can use to test GPS net. It has two
faction: Test the GPS electric capability connecting the cable;
The other, connecting the outside GPS antenna in the poor
net can boost up the take over much more GPS signal.
Tri-Colour LED
The SD30 has a tri-colour LED located on the bottom right
hand corner of the device. The Red and Green colours will
be very clear. The third colour will be a blend of Red and
Green (both lights on).
Pressing the power key 1second can tests the currently net,
the Green indicate in the CDMA coverage, the Red means
out of the service.

5
Pressing 3 seconds can tests the currently battery level, the
Green indicate the full charge, the twinkling red light
indicates the low charge, the constant red light indicate the
extremely low charge.
Pressing 5 seconds make once orientation.
Pressing 7seconds turns off the device.
In the off state, pressing more 0.5 seconds turn on the
device,
When charging the device, the Red indicates charging the
battery, the Green indicates the full battery.
SD30 Location Determining Mode
MS-Assisted: The SD30 will support MS-Assisted location
fixes. In this mode, the device’s location is calculated by the
PDE.
MS-Based: The SD30 will support MS-Based location fixes.
In this mode, the device’s location is calculated by the SD30
using assistance data provided by the PDE. The assistance
data is provided by the PDE to the device on request and the
assistance data will remain valid for approximately one half
hour. Autonomous The SD30 does not support autonomous
GPS fixes.
SD30 Network Features
Control Plane: The SD30 will support control plane.
User Plane: The SD30 will support user plane.
You can choose to use on control plane or user plane.

6
Human Explosure to RF:
1. This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. To maintain
compliance with FCC RF exposure compliance requirements,
please avoid direct contact to the transmitting antenna
during transmitting, the minimum distance should be at least
20 cm from the antenna
2. Modification not approved & performed by manufacturer
may void the user’s authority to operate the device
