Skytech Smart Stat-IV User manual

REV. 3-26-19 Page 1
Skytech: Smart Stat-IV
Model: Smart Stat-IV
INSTALLATION AND OPERATION INSTRUCTIONS
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOT ATTEMPT TO INSTALL OR OPERATE
INTRODUCTION
This remote control system was developed to provide safe, reliable, user-friendly operation for gas heating appliances. This is a dry
contact, thermostat controlled system with built-in timer that can be operated from the transmitter.
The transmitter operates on (2) AAA 1.5V batteries that are included. Install the AAA
batteries supplied with the unit into the battery compartment. It is recommended
that ALKALINE batteries always be used for this product. Be sure the batteries are
installed with the (+) and (-) ends facing the correct direction.
If the transmitter does not illuminate when you press any buttons, or you see nothing
on the LCD screen, check the position of the batteries.
TRANSMITTER
MODE
TIME
TIMER
SET
DOWN
UP
+
+
-
-
LIQUID CRYSTAL DISPLAY - LCD
ON
OFF
THERMO
X
ROOM
SET
AM
PM TIMER
FLAME
EE
1
2
3
4
5
6
7
8
1. Low Battery Indicator - Battery power is low, replace batteries within two weeks.
2. Timer - Time remaining before the system shuts off.
3. Mode - Indicates whether the system is ON, OFF, or in THERMO mode.
4. Set - Indicates the desired SET temperature when in THERMO mode.
5. Flame - Indicates appliance is on.
6. Clock - Indicates current time.
7. Room - Indicates current ROOM temperature.
8. ºF - Indicates degrees Fahrenheit (ºC indicates degrees Celsius).
MODE FUNCTION
To select an operational mode, press the MODE button on the transmitter.
ON - Turns the appliance ON, the ame icon will appear on the LCD screen.
THERMO - Remote is in THERMO mode.
OFF - Turns the appliance OFF, the ame will disappear from the LCD screen.
The factory setting for temperature is degrees Fahrenheit (ºF). To change this
setting to degrees Celsius (ºC):
• Remove battery cover on the back of the transmitter and locate the setting
button in the top center of the battery compartment.
• Push the button once to enter temperature scale setting mode.
• Use the up and down buttons to switch between the ºF and ºC.
• Push the setting button again once again to set the displayed temperature
scale.
• Repeat this procedure to switch back to ºF.
SETTING ºFAHRENHEIT / ºCELSIUS SCALE
+
+
-
-
SETTING
BUTTON
E474962

REV. 3-26-19 Page 2
Skytech: Smart Stat-IV
THERMOSTAT FUNCTION
• Press the MODE key until the LCD screen shows the word “THERMO” at the top of the screen.
• To adjust set temperature, press the UP and DOWN buttons until the desired temperature is reached. The temperature range is
99ºF (32ºC) to 45ºF (6ºC).
• If no button is pressed, the set temperature will automatically be accepted.
• The ame icon will appear when the control calls for heat. The ame icon will disappear when the appliance reaches its set
• temperature.
• Press the MODE key to disengage the Thermo Mode.
SETTING THE CLOCK
• Hold the TIMER/TIME button for 3 seconds. The hour section of the time will begin ashing.
• Select the hour by pressing the UP and DOWN buttons. If you go past 12 o’clock the AM and PM will change.
• Once the hour is selected, press and release the TIMER/TIME button again, and the minute section of the time should be ashing.
• Use the UP and DOWN buttons to scroll through the minutes.
• Once the minutes are correct, press the set button or press and hold the TIMER/TIME button for 3 seconds. The time will lock.
SETTING THE COUNTDOWN TIMER
This remote control system can operate with a built-in countdown timer when the transmitter is in the ON or THERMO modes
(THERMO or ON must be displayed on the screen).
When plugged into a standard 110-120 VAC receptacle, the remote
receiver operates on commands from the transmitter or from the slide
switch on the face of the receiver (This switch is to be used during a
power outage to operate the appliance manually).
• ON: will manually turn on the appliance.
• REMOTE: will allow use of handheld transmitter. If the system
does not respond to the transmitter on initial use, check the battery
positions in the remote. If that does not work, see the LEARNING
TRANSMITTER TO RECEIVER section.
• OFF: will disable the remote receiver.
• It is suggested that the slide switch be placed in the OFF
position if you will be away from your home for an extended
period of time.
The remote receiver is manufactured with a “dry contact” relay in its
circuitry that operates like an on/off switch. However, no power or
current passes from the 110-120 VAC input side to the wires leading
from the output side of the remote receiver.
RECEIVER
• Press and release the TIMER button. The minimum 0:15 minute setting on the LCD Screen will begin to ash.
• Press the UP or DOWN button on the transmitter to chose your countdown time. Available countdown times are 15 min, 30
min, 45 min, and 1 hour to 9 hours (alternating every 30 min).
• To initiate the countdown, press the SET button. If no button is pressed within 15 seconds, the setting will automatically be
accepted. The system will return to OFF mode when the countdown time expires. If the system is in THERMO mode, it will
cycle on and off based on the set temperature until the timer expires.
THERMO UPDATING FEATURE
This remote control has a temperature updating feature built into its software. The transmitter reads the room temperature every
2 minutes, then updates the room temperature on the LCD screen.
NOTE: The thermo feature operates the appliance whenever the room temperature varies a certain number of degrees from the set
temperature. This variation is called the “swing” or temperature differential. This feature lets the appliance turn off and on 2 ºF (1 ºC)
above or below the set temperature of the room. This is to cushion the number of times the appliance is turned on and off.
NOTE: This product is designed for use with an attended hearth appliance or re feature. Adults must be present when
the Control System is operating. DO NOT program or thermostatically set this Control to operate a hearth appliance
or re feature when Adults are not physically present. Furthermore, DO NOT leave the hearth appliance or re feature
burning unattended; it may cause damage or serious injury. If an Adult is going to be away from the hearth appliance or
re feature for any length of time, then the handheld/wall mount, receiver/control module and application should be in the
“OFF” position.
LEARN

REV. 3-26-19 Page 3
Skytech: Smart Stat-IV
WARNING
This remote control system must be installed exactly as outlined in these instructions. Read all instructions completely before
attempting installation. Follow instructions carefully during installation. Any modications of this remote control or any of its
components will void the warranty and may pose a re hazard.
Consult gas appliance manufacturer’s instructions and wiring schematics for proper placement of all wires. All electronic modules
are to be wired to manufacturer’s specications.
The following wiring diagrams are for illustration purpose only. Follow instructions from manufacturer of gas valve and/or electronic
module for correct wiring procedures. Improper installation of electric components can cause damage to electronic module, gas
valve and remote receiver.
WIRING INSTRUCTIONS
A qualied electrician should install the remote control system.
MILLIVOLT VALVES
MILLIVOLT SYSTEM CHECK
• Ensure that the pilot ame is lit.
• Slide the 3-position button on the remote receiver to the ON position. The
main gas ame (i.e., the re) should ignite.
• Slide the button to OFF. The main ame should extinguish (the pilot ame
will remain on).
• Slide the button to REMOTE, then press the ON button on the transmitter to
change the system to on. The main gas ame should ignite.
• Connect one wire from the remote receiver to the TH terminal on the gas
valve.
• Connect the other wire from the remote receiver to the TH/TP terminal on
the gas valve.
The remote control receiver can be connected, in series, to a 24VAC transformer to
the TR (transformer) terminal on the ELECTRONIC MODULE. Connect the hot wire
from the 24VAC transformer to either of the wires on the remote receiver. Connect
the other wire from the receiver to the TH (thermostat) terminal on the ELECTRONIC
MODULE.
ELECTRONIC SPARK IGNITION 24 VAC INPUT
• Before installation, make sure you turn the slide switch to OFF. After installation, make sure you turn the slide switch to REMOTE.
• The remote receiver can be placed on the replace hearth or under the replace behind the control access panel.
• Use the wires attached to the remote receiver to connect to the gas valve or the electric module (piggyback connectors have both
male & female terminals for exibility).
• Be sure that the connectors do not touch each other or other bare metal surfaces; this will cause the appliance to turn on. The
connectors may be wrapped with electrical tape to prevent this.
INSTALLATION
Protection from extreme heat is very important. The remote receiver should be kept away from temperatures exceeding 170ºF. Extreme
heat can cause damage, which is not covered under warranty.
REMOTE RECEIVER
TERMINAL BLOCK
ON MILLIVOLT
GAS VALVES
TH
TP TP TH
THERMOPILE/
PILOT LIGHT
ELECTRONIC MODULE
TR TH
neutral wire
24VAC
hot wire
110/24VAC
Transformer
REMOTE RECEIVER
To 110 Power
To 110 Power

REV. 3-26-19 Page 4
Skytech: Smart Stat-IV
COMMUNICATION - SAFETY - TRANSMITTER - (C/S - T/X)
This remote control has a COMMUNICATION –SAFETY function built into its software to ensure the transmitter and receiver are
communicating normally.
In all operating modes, the transmitter sends an RF signal every fteen minutes to the receiver indicating that the transmitter is within
the normal operating range of 20 feet. Should the receiver NOT receive this signal, the receiver will begin a 2 hour countdown. If the
receiver does not receive a signal from the transmitter in 2 hours, the receiver will shut off the appliance. The receiver will then emit a
series of rapid “beeps” for a period of 10 seconds. Then after 10 seconds of rapid beeping, the receiver will continue to emit a single
“beep” every 2 seconds until a transmitter MODE Button is pressed to reset the receiver.
AUTO SHUT DOWN
This remote control has an auto shut down feature incorporated into its system. When the transmitter mode is in the ON position, the
appliance will only run for 9 hours. After that it will shut down. To reactivate the appliance, press the MODE button.
CP (CHILDPROOF) FEATURE
This remote control includes a childproof feature that allows the user to “lock-out” operations from the transmitter.
• To activate and de-activate the childproof feature, press and hold the SETTING button behind the battery cover for 5 seconds (The
letters “CP” will briey appear on the LCD screen when childproof mode is activated).
• “CP” will appear on the LCD screen if any button is pressed while childproof mode is engaged.
• When this mode is engaged, all auto settings go on without interruption (like thermostat). Only manual functions are prevented.
BATTERY LIFE
Life expectancy of the alkaline batteries in the transmitter should be at least 12 months. Check and replace all batteries:
• Annually.
• When operating range becomes reduced.
• When transmissions are not received by the remote receiver.
• If the hand held transmitter batteries measure less than 2.5 volts (Both batteries in combination).
ELECTRONIC SPARK SYSTEM CHECK
• Slide the 3-position button on the remote receiver to the ON position. The spark electrode should begin sparking to ignite the pilot.
After the pilot ame is lit, the main gas valve should open and the main gas ame should ignite.
• Slide the button to OFF. The main gas ame and pilot ame should both extinguish.
• Slide the button to REMOTE, then press the ON button on the transmitter to change the system to on. The spark electrode should
begin sparking to ignite the pilot. After the pilot is lit, the main gas valve should open and the main gas ame should ignite.
ELECTRONIC SPARK IGNITION DRY CONTACT INPUT
IS
Electronic
Module
Piggyback
Connectors
Switch
Wires
LEARN
LEARNING TRANSMITTER TO RECEIVER
This transmitter has one of 1,048,576 unique security codes. It may be necessary to program the remote receiver to “learn” the security
code of the transmitter upon initial use, if batteries are replaced, or if using a replacement transmitter.
• Make sure the receiver’s slide switch is in the REMOTE position.
• Press and release the LEARN button on the receiver.
• When you hear the “Beep”, press and hold the MODE button for about 2 seconds on the transmitter.
• You will then hear a series of beeps that indicate that your new transmitter has been accepted by the receiver.

REV. 3-26-19 Page 5
Skytech: Smart Stat-IV
TRANSMITTER WALL BRACKET
Slide Transmitter
down into holder
The transmitter can be hung on a wall using the clip provided.
• Wood - Drill 1/8’’ pilot holes and install with screws provided.
• Plaster/Wallboard - Drill 1/4’’ holes. Use a hammer to tap in the two
plastic anchors. Then install the screws provided.
TROUBLE SHOOTING
If you encounter problems with your replace system, the problem may be with either the replace itself or with the remote. Review
the replace manufacturer’s operation manual to make sure all connections are properly made. Then check the operation of the
remote in the following manner:
• Make sure all batteries are correctly installed in the transmitter. Also check that the batteries are fully charged.
• Check batteries in transmitter to make sure contacts are touching (+) and (-) ends of battery. Bend metal contacts in for tighter t.
• Be sure receiver and transmitter are within 20’-25’ operating range.
• If receiver is installed in a tightly enclosed metal surrounding, the operating distance will be shortened.
• Make sure the hand-held transmitter and remote receiver are communicating properly (see LEARNING TRANSMITTER TO
RECEIVER section).
FCC REQUIREMENTS
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODI-
FICATIONS TO THE EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT
For Technical Service, call:
U.S. INQUIRIES
[phone] or [phone]
For Sales: [phone]
Web site: www.skytechpg.com
CANADIAN INQUIRIES
[phone]
MANUFACTURED EXCLUSIVELY FOR SKYTECH II, INC
FCC Notication
Note: This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in ac-
cordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that inference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experience radio/TV technician for help

LIMITED WARRANTY
1. Limited Warranty. Skytech II, Inc. (“Skytech”) warrants that each new Skytech Control System, including all
hardware, parts and components (the “System”), when used in accordance with the instructions furnished by Skytech
provided with each System, shall be free in all material respects, of defects in materials and any workmanship under
normal use, subject to proper installation (“Limited Warranty”). This Limited Warranty is non-transferrable and sets
forth our sole and exclusive liability and the sole and exclusive remedies available in relationship to any non-
conformity, defect or similar claim. This Limited Warranty only extends to the original retail purchaser of the System
(the “Customer”) and expires upon any sale or transfer of the home where the System is installed by the Customer.
2. System Sold As Is. Subject to this Warranty and any applicable state law, each System is sold by Skytech to a
Customer on an “as is” basis. In addition, each System and Skytech’s obligations are and remain subject to all
additional disclaimers, limitations, reservations of rights, exclusions, and qualifications set forth on Skytech’s website,
www.skytechpg.com, all of which are considered part of the Warranty and are incorporated herein (collectively, the
“Additional Terms”). Each Customer, by purchasing and/or using any System or any portion thereof, does so subject
to the Warranty and the Additional Terms.
3. Installation and Use of System. Improper Installation, adjustment, alteration, service, or maintenance can cause
property damage, personal injury, or loss of life. Thoroughly read the installation and operating instructions of this
Control as well as the appliance it will be used in conjunction with as a system. If applicable, read the maintenance
instructions before installing this control. This product is designed for use with an attended hearth appliance or fire
feature. Adults must be present when the Control System is operating. DO NOT program or thermostatically set this
Control to operate a hearth appliance or fire feature when Adults are not physically present. Furthermore, DO NOT
leave the hearth appliance or fire feature burning unattended; it may cause damage or serious injury. If an Adult is
going to be away from the hearth appliance or fire feature for any length of time, then the handheld/wall mount,
receiver/control module and application should be in the “OFF” position.
4. Repair or Replacement of System or Parts. Should any System, or any hardware, components and/or parts
contained therein fail due to a defect in workmanship or material provided by Skytech after the purchase of a System
by a Customer, Skytech shall repair or, at its option, replace the defective System or part, hardware or component,
subject to the Customer’s compliance with all terms and conditions contained herein governing service and claims
under the Warranty. Skytech shall provide replacement parts at no charge for the first (5) five years of this warranty, and at
market cost for the Lifetime of the product to the original Customer. Gas valve and gas valve components will be available
at no charge for one (1) year. If Skytech does not have the parts for an individual model, then a comparable replacement
System will be provided at no charge within the first (5) five years after purchase, and then at market cost for the Lifetime of
that product to the Customer.
5. Warranty Claims; Skytech Service. To submit a valid claim under the Warranty (each, a “Valid Claim”), a Customer
must comply with the following:
a) Obtain a Return Material Authorization (“RMA”) number from Skytech by calling [phone]; and
b) Provide written notice to a Skytech or an Authorized Dealer (“Dealer”) and provide the Name, House Address, Email
Address and Telephone Number of the Customer;
c) Describe the System model number and nature of the defect, nonconformity, or other problem with the System;
d) Provide such notice within thirty (30) days of discovery of such defect, nonconformity, or problem;
e) securely pack and ship the defective Skytech Product to Skytech II, Inc. ATTN: Warranty Department at 9230 Conservation
Way, Fort Wayne, IN 46809. Customer assumes all costs and risks associated with transportation to Skytech (i) the RMA
number is only valid for thirty (30) days from the date the RMA was issued, (ii) the RMA number should be clearly marked
on the outside of each box being returned. Skytech may refuse shipments that DO NOT meet all of the Valid Claim
requirements. Skytech is not responsible for any refused shipments or any damage caused due to shipping, whether or not
it was a Valid Claim. Skytech shall be responsible for return shipment charges. Compliance with these requirements is a
condition to coverage under this Limited Warranty.
Skytech may refuse any shipment(s) that does not meet all of the Valid Claim requirements. Skytech is not responsible for
any refused shipments or any damage caused due to shipping, whether or not it was a Valid Claim. Skytech shall be
responsible for reasonable return shipment charges for any Skytech System returned whether or not Skytech
determines there is no defect with the System, reject for failure of the Customer to submit a Valid Claim, or otherwise
determine is not eligible for service under the Warranty.
Upon receipt of a Valid Claim and the properly-returned System, Skytech shall, at its option, either (a) repair the System,
at no charge to the Customer, or (b) replace the returned System with a new comparable System, at no charge to the
Customer, or (c) provide the Customer with a refund in an amount equal to the price paid by the Customer for the
defective System not including any service or labor cost associated with the installation or otherwise. Any System or

hardware, component or part repaired by Skytech hereunder, or any replacement System, hardware, component or
part shall be shipped to the Customer by Skytech at Skytech’s cost and the Warranty, the Additional Terms, and all
other terms and conditions set forth herein shall extend to such repaired or replacement System, hardware,
component or part. Skytech shall pay no refund before Skytech from the Customer receives the defective System,
hardware, component and/or parts. Any obligation of Skytech under this Section 4 shall be and remain subject to
Skytech’s right to physically inspect the defective System, hardware, component and/or part returned to Skytech by
the Customer. Some States do not allow the exclusion or limitation of incidental and consequential damages or limitation
on how long an implied warranty lasts, so the above limitation may not apply to you. This warranty gives you specific rights
and you may have other rights, which vary from state, province, or nation. To the extent allowable under any law, the liability
of Skytech is limited to the express terms of this warranty, and Skytech expressly disclaims any and all implied warranties,
including any warranties of fitness for a particular purpose or merchantability
REV. 2-24-17
Print information and detach at dotted line for return to: Skytech, ATTN WARRANTY DEPT., 9230 Conservation Way, Fort Wayne, IN 46809
Telephone: [phone]
Warranty Information
Purchase Date: Model: Date Code:
Purchased From:
Customer Name: Phone:
Back of remote Date Code Sample
16’
17’
1-12 is Month remote was produced 15-
16 is Year remote was produced
Sample date code above is 1611
Address:
Email Address: ____________________________________________________________________
City: State/Prov. Zip/Postal Code:
Please send a Proof of Purchase (original receipt) copy along with your Warranty form.
1
2
3
4
5
6
7
8
9
10
11
12
