Skyworth LCD-26L8E User manual

Instruction Manual
LCD-26L8ELCD-26L8E
26" LCD TV/MONITOR
SIZE:A5

WARNING AND PRECAUTION
Read all of the instructions before operating the set. Keep these instructions well
for later use.
PRODUCT
The ventilation shouldnot be impedeby covering theventilation
openings with items,such as newspaper, table-cloths, curtains,etc.
Do not push any objects of any kind into this unit through the cabinet slots
as they could touch the current carrying parts or short-circuit parts, resulting
in fire, electric shock, or damage to the unit.
Unplug the set when it is not used for a long period of time.
Do not dismantle this product by yourself as this may cause damage.
Do not touch the screen surface with fingers as this may scratch or mar the
LCD screen.
Do not impact the LCD screen with hard pressure as this may damage the
LCD screen severely.
POWER
Please use the core plug as required.
PLUG
Unplug the set under the following conditions:
If the set will not be used for a long period of time.
If the power cord or the power outlet/plug is damaged.
Follow the instructions to install and adjust the product. Adjust those
controls that are covered in this operating instructions as improper
adjustment of other controls may result in damage. If this happens, unplug
the set and refer to the service personnel.
If the set is subject to impact or has been dropped to have the cabinet
damaged.
POWER CORD & SIGNAL CABLE
Do not allow anything to rest on or roll over the power cord & signal cable.
Protect the power cord & signal cable from being trampled.
Do not overload the power cord or power outlet.
Do not expose the power cord & signal cable to moisture.
The battery (batteryor batteries orbattery pack) shallnot be exposed
to excessive heatsuch as sunshine,fire or thelike.
The mains plugis used asthe disconnect deviceand shall remain
readily operable.

WARNING AND PRECAUTION
CLEANING
Dust the set by wiping the screen and cabinet with a soft, clean cloth or
some special liquid cleaner.
Do not apply excessive force to the screen when cleaning.
Do not use water or other chemical cleaner to clean the screen as this
may damage the surface of the LCD screen.
USE ENVIRONMENT
Do not installthis equipment ina confined spacesuch as abook
case or similarunit. Toprevent injury, this apparatusmust be securely
attached to thewall mount fastenedon the wall.
Place the set on a place that allows good ventilation.
Do not use the set near damp, and cold areas, protect the set from
overheating.
Keep away from direct sunlight.
The apparatus shallnot be exposedto dripping orsplashing and
that no objectsfilled with liquids,such as vases,shall be placed
on the apparatus.
Do not use the set near dust place.
Toreduce the risk offire or electric shock,do not expose thisappliance
to rain or moisture.
No naked flamesources, such aslighted candles, shouldbe placed on
the apparatus.

-1-
Precautions when usingbatteries
Do not useold and newbatteries together.
Do not usedifferent types ofbatteries (for example,Manganese and
Alkaline batteries) together.
Note that there are chargeableand non-chargeable batteries. Do not
attempt tocharge non-chargeablebatteries.
Remove thebatteries fromthe remotecontrol unitif you donot intendto use
the unit fora long time.Precautions when usingthe remote controlunit
Do not dropthe remote controlunit.
Do not subject theremote controlunit tophysical shocks.
Keep theremote control unitdry. May cause theunit to malfunction.
Replace thebatteries withnew oneswhen operationof the unit deteriorates.
SETUPSETUP
Insert TheBatteries
Remove the batterycover by pressingit and slidingit down.
Insert the two1.5V (AAA size)batteries making surethe polarity (+
or -)of thebatteries matches thepolarity marks Insidethe unit.
Replace the batterycover by slidingit in untilyou hear aclick sound.
1
2
3
TV Installation

Locate the receiver in the room where direct light does not strike the screen.
Total darkness or a reflection on the picture screen can cause eyestrain. Soft and indirect
lighting is recommended for comfortable viewing.
Allow enough space between the receiver and the wall to permit ventilation.
Avoid excessively warm locations to prevent possible damage to the cabinet or premature
component failure.
This TV operates on AC supply directly, connect the AC plug to the socket at the back of the TV.
Insert the mains plug in the socket having a mains voltage of 100-240V AC.
Do not install the receiver in a location near heat sources such as radiator, air ducts, direct
sunlight, or in a place somewhere like close compartment and close area. Do not cover the
ventilation openings when using the set.
Features
Up to 200 programme memory.
Sleep timer.
picture modes.
When no TV signal isdectected, after 15
minutes the TV switches itself automatically
to stand-bymode.
CYS: PAL /SECAM / NTSC
SYS: BG/DK /I / M
HDMI Input (support up to 1080P)
PC Input (support up to 1080i)
NICAM Stereo / AV Stereo
Program Organiser .
4:3 format , 16:9 format,14:9 zoom,
16:9 ZOOM1,16:9 ZOOM2
Panel Features
High resolution (1366x768), 26"TFT LCD
display.
2
Brightness: 450cd/m
High-speed response time <8msec.
8-bit color depth, display 16.2M colors.
High contrast ratio (800:1 Typital)
00
Viewing angle:160 (H)/150 (V)(CR>10).
InThe Box
Television
User Guide
Youshould have:
Remote control
Warranty Card
2 xAAA battery
Stand
Wall mount
SETUPSETUP
-2-

FUNCTIONAL PARTS
-3-
3. VOLUME UP/DOWN BUTTON
4. PROGRAM UP/DOWN BUTTON 5. MENU BUTTON
7. ON/OFF BUTTON
2. REMOTE SENSOR
1. POWER INDICATOR
6. TV/AV BUTTON
9. Av3 INPUT8. S-VIDEO INPUT
10. EARPHONE OUTPUT
Note: The graphics are for representation only.
FRONT PANEL
12. SPEAKERS
2
3
4
5
6
7
+ PROG -+ VOL - MENU TV/AV ON/OFF
8
81
8
9
-AUDIO- LRVIDEO S-VIDEO
ERAPHONE 3
10

-4-
FUNCTIONAL PARTS
BACK PANEL
1. HDMI1\HDMI2: Connect HDMI input signal from signal source such as DVD.
2. VGA: Connect a PC via a VGA cable.
3. VGA AUDIO: Connect audio signal from PC.
4. Y Pb Pr(HDTV): Connect
5. AV2: Connect AUDIO and VIDEO input signal from signal source such as DVD.
6. S/PDIF : Connect digital AUDIO output signal.
7. AV OUT : Connect AUDIO and VIDEO output signal.
8. AV1 : Connect AUDIO and VIDEO input signal .
9. ANTENNA IN: Connect a coaxial cable to receive signal from the antenna or cable.
RCA cable to connect DVD player or other video device's YPbPr output.
VGA
75 ANT
HDMI2 VGA AUDIO Pb PrY
L - AUDIO - R VIDEO
S/PDIF
HDMI1
AV2
R - AUDIO - L VIDEO
R - AUDIO - L VIDEO
AV1
AV OUT
14
12356789

PROGRAM SELECTION BUTTONS(0-9)
You could select program you want with 0-9
button. For program up to 100-199, you need
press three digitnumber quickly, then TVwill go
to the program directly. For program between
10-99, you need press two digit number
according program quickly and wait, then TV
will go tothe program. For program between0-9 ,
just press onedigit and wait.
Remote ControlUnit
4
6
8
7
5
MUTE BUTTON ( )
Press once to mute the sound, press again to
return to presetsound level.
POWER (STANDBY) BUTTON ( )
Press this buttonto turn theTV on/off.
1
2
3
-5-
OPERATIONINSTRUCTIONS
AV/TV BUTTON
Press this buttonto display externalvideo signal
Such as TV/AV IN/HDTV/ VGA/HDMI1/HDMI2.
Press up/down arrowkey to selectitem and
press left/right arrowkey to enterselected item.
SLEEP BUTTON(SLEEP)
Press this buttonto set the sleep timer. When
the preset length of time has passed, the TV
set Enters standby mode. The time
change(minutes):10,20,30,40,50,60,90,120, off.
INFO BUTTON
Press this buttonto display thesettings on the
screen.(e.g. Channel numberfor TV input,
channel name, coloursystem).
PROGRAM UP/DOWN BUTTONS(PROG.+/-)
Press the PROG.+button to selectthe program
Forwards. Pressthe PROG.- buttonto select the
program backwards.
VOLUME UP/DOWNBUTTONS (VOL.+/-)
Press VOL+/- buttonsto adjust soundlevel. Or
adjust the volumeof each itemin the menu
status.
QUICK VIEW BUTTON(RECALL)
Press this button to return to the previously
viewed program.
9
SLEEP
CANCEL
REVEAL
Sub-page
INDEX
SIZEHOLD
MIXTEXT
PIPON/OFF PIPSOURCE PIP SOUND PIPSIZE
PICTURE SOUND FAV. NICAM
EXIT
MENU
VOL INFO PROG
RECALL
AV/TV
MUTE
POWER

MENU BUTTON (MENU)
Press this button to enter the menu screens for
various Optional adjustablesettings.
SOUND MODE BUTTON(NICAM)
Press this button,you can selectdifferent sound
mode when the source is different.
TV SOURCE
The NICAM
selection is commonfor all TVchannels .
1. MONO: MONO
2. STEREO: MONO, STEREO
3. DUAL: MONO,DUAL1, DUAL2
11
12
13
14
OPERATIONINSTRUCTIONS
Remote ControlUnit
-6-
CURSOR button( / )
Left/Right/Up/Down direction keys for selecting
menu itemsor signalsources.
EXIT BUTTON
Press to exit MENU directly.
OK BUTTON (OK)
Press to enterselected item.
Left Right arrow/Zoom-/+ (Z- / Z+)
Press to change the screen format: 4:3 format, 16:9
format, 14:9 ZOOM, 16:9 ZOOM1, 16:9 ZOOM2.
PICTURE Button
Press to change the picture setting :Normal , soft ,
personal, bright .
Fav. BUTTON
Press Fav. button to switch favourite channel which
you had set in Favourite channel MENU. If there is
no channel in Favourite channel list, there is no
response for this Fav. Button.
SOUND Button
Press to change the sound setting :standard, Music,
Film, Voice, Personal .
10
15
16
17
18
PIP ON/OFF
Press this buttonto switch onor off PIPfunction .
PIP function isavailable in HDTV, VGA, HDMI
mode only.
PIP SOURCE
Press this buttonto select PIPsource from TV,
AV whenPIP is active.
19
20
SLEEP
CANCEL
REVEAL
Sub-page
INDEX
SIZEHOLD
MIXTEXT
PIPON/OFF PIPSOURCE PIP SOUND PIPSIZE
PICTURE SOUND FAV. NICAM
EXIT
MENU
VOL INFO PROG
RECALL
AV/TV
MUTE
POWER

-7-
SLEEP
CANCEL
REVEAL
Sub-page
INDEX
SIZEHOLD
MIXTEXT
PIPON/OFF PIPSOURCE PIP SOUND PIPSIZE
PICTURE SOUND FAV. NICAM
EXIT
MENU
VOL INFO PROG
RECALL
AV/TV
MUTE
POWER
OPERATIONINSTRUCTIONS
21
CANCEL BUTTON (OPTION)
Press this buttonto appear theTV signal onthe
background.
REVEAL BUTTON (OPTION)
Press this button to reveal the hidden
information for some Teletext pages pressagain
to hide theinformation.
INDEX BUTTON (OPTION)
Press this button to enter the Teletext's index
MENU.
SUB.PAGE BUTTON(OPTION)
Subcode mode, gives, the possibility to select
certain subcode pagesof a teletextpage.
SIZE BUTTON
Press this buttonyou can select different image
sizes: Normal, double high top, double high
bottom.
MIX BUTTON(OPTION)
the button is used as closing /opening the
teletext Background.
HOLD BUTTON
Press this buttonto hold theTeletextpage
without update to prevent the pagefrom
changing. Press again torelease the hold state.
TEXT BUTTON
This button is usedfor entering the teletextMENU.
F1-F4 (OPTION)
These four colorkey are forrelative fast teletext
function in thebottom of teletextpage and
organizer function relativeoperation .
22
23
24
25
26
27
PIP SOUND
Press this buttonto select currentsound output
from main orPIP source whenPIP is active.
PIP SIZE
Press this buttonto change PIPpicture size ,
Normal or Zoomwhen PIP isactive .
28
29
30
31
Remote ControlUnit
