1 GAS SHUT OFF VALVE 86 3803 000 86 3803 000
2 JACKET - LEFT TOP COVER 86 1101 000 86 1101 000
3 JACKET - RIGHT TOP COVER 86 1102 000 86 1102 000
4JACKET FRONT ASSEMBLY 86 0102 000 86 0152 000
5 1/4 TURN PAWL LATCH 00 5075 000 00 5075 000
6 1/4 LATCH PAWL LATCH SLOTTED STUD 00 5074 000 00 5074 000
7 JACKET VIEW WINDOW PLUG 86 3105 000 86 3105 000
8 JACKET LEFT - ASSEMBLY 86 0103 000 86 0153 000
9 JACKET RIGHT- ASSEMBLY 86 0104 000 86 0154 000
10 PROPANE CONVERSION KIT 86 0905 000 86 0955 000
11 AIR INTAKE & FLUE COLLAR ASSEMBLY 86 0106 000 86 0106 000
12 AIR INTAKE WELDED ASSEMBLY 86 0107 000 86 0157 000
13 TOP COVER 86 1115 000 86 1165 000
14 FRONT PANEL ASSEMBLY 86 0112 000 86 0162 000
15 TERMINAL BRACKET 86 1132 000 86 1132 000
16 REAR FRAME SUBASSEMBLY 86 0111 000 86 0161 000
17 REAR BOTTOM SUBASSEMBLY 86 0113 000 86 0163 000
18 BOILER LEGS PACKAGE (PACKAGE OF 4) 86 6915 000 86 6915 000
19 SNAP BUSHING 50 0385 000 50 0385 000
20 WALL BRACKET 86 1128 000 86 1178 000
21 BELLOWS 86 3202 000 86 3202 000
22 GAS PIPE GROMMET 86 3203 000 86 3203 000
23 BLOWER GASKET 86 3204 000 86 3254 000
24 WORM DRIVE CLAMPS 3 1/2" DIA 86 3205 000 86 3205 000
25 GAS VALVE (WITH FLANGE) 86 3208 000 86 3208 000
26 BLOWER 86 3215 000 86 3265 000
27 GAS PIPE ASSEMBLY 86 0211 000 86 0256 000
28 COMBUSTION CHAMBER 86 3301 000 86 3351 000
29 O-RING 1.102 x 0.177 - 70EP 86 3401 000 86 3401 000
31 DRAIN VALVE 1/2" 86 3495 000 86 3495 000
32 WATER HIGH LIMIT 86 3404 000 86 3404 000
33 WA
TER SENSOR 86 3406 000 86 3406 000
34 SPARK IGNITOR GASKET 86 3407 000 86 3407 000
35 SPARK IGNITOR 86 3408 000 86 3408 000
36 HELICAL BUNDLING WRAP (FOR SPARK CABLE) 86 3608 000 86 3608 000
38 OBSERVATION WINDOW (SIGHT GLASS) 86 3433 000 86 3433 000
39 RETURN PIPE- WELDED ASSEMBLY 86 3435 000 86 3485 000
40 SUPPLY PIPE - WELDED ASSEMBLY 86 3442 000 86 3492 000
41 HEA
TEXCHANGER ASSEMBLY 86 0406 000 86 0456 000
42 FLUE SENSOR 86 3501 000 86 3501 000
43 FLUE COLLECTOR CLEANING ACCESS DOOR SEALING 86 3503 000 86 3503 000
44 FLUE COLLECTOR CLEANING ACCESS DOOR 86 1501 000 86 1501 000
45 FLUE PIPE 86 3502 000 86 3552 000
46 CAP 86 3505 000 86 3505 000
47 FLUE COLLECTOR 86 3504 000 86 3554 000
48 CONDENSA
TION DRAIN PIPE - ASSEMBLY 86 0502 000 86 0552 000
49 HONEYWELL VENTURI 86 3209 000 86 3259 000
50 HEYCO -TITE LIQUID TIGHT STRAIGHT THRU CORDGRIPS, RLTCG 7 (SMALL SIZE) 86 3602 000 86 3602 000
51 3/8" STRAIGHT BX CONNECTOR 40 0309 000 40 0309 000
52 ON/OFF SWITCH 86 2601 000 86 2601 000
53 TERMINAL BLOCKS 8, 86 2603 000 86 2603 000
54 CONTROL BOARD WITH COVER 84 2609 000 84 2609 000
55 LED DISPLAY - ASSEMBLY 86 2606 000 86 2606 000
56 TRANSFORMER 24V
,HONEYWELL 140B1297 66 0528 000 66 0528 000
57 PRESSURE GAUGE ( INCL. CHECK VALVE) 86 3611 000 86 3611 000
58 J2 CONNECTOR HARNESS (FOR ON/OF SWITCH, GROUND TERMINAL) 86 2107 000 86 2107 000
59
J5 CONNECTOR HARNESS (FOR WATER AND FLUE SENSORS, THERMOSTATS AND L.W.C.O. CONNECTION
) 86 2103 000 86 2103 000
60 J6 CONNECTOR HARNESS (FOR BOILER LOOP AND DHW CIRCULATORS CONNECTION) 86 2105 000 86 2105 000
61 J9 CONNECTOR HARNESS (FOR COMBUSTION BLOWER CONNECTION - CONTROL SIDE) 86 2106 000 86 2106 000
62
J13 CONNECTOR HARNESS (FOR GAS VALVE TRANSFORMER AND GROUND, WATER HIGH LIMIT CONNECTION)
86 2108 000 86 2108 000
63 BLOWER CONNECTOR HARNESS 86 2109 000 86 2109 000
64 GAS VALVE CABLE 86 2104 000 86 2104 000
65 SPARK CABLE 86 2101 000 86 2101 000
66 GROUND WIRE 86 2100 000 86 2100 000
67 CIRCULATOR NEUTRAL JUMPER 86 2110 000 86 2110 000
68 AIR INTAKE PIPE 86 3106 000 86 3106 000
69 SCREW PACKAGE 86 6914 000 86 6914 000
70 VENT/AIR INTAKE TERMINATION KIT (FOR PVC VENTING) 86 0802 000 86 0802 000
71 CIRCULATOR TACO 86 3804 000 86 3806 000
72 SAFETY RELIEF VALVE 65 0550 000 65 0550 000
73 AIR CHAMBER REPLACEMENT ASSEMBLY 86 0910 000 86 0960 000
74 SEALING - EZ SEAL ( 70" LONG STRIP FOR AIR INTAKE AND FLUE PIPE) 86 6911 000 86 6911 000
76 AIRBOX GASKET 86 3409 000 86 3459 000
77 FLUE COLLECTOR GASKET 86 3424 000 86 3474 000
78 OUTDOOR SENSOR KIT (12 kOhm) 86 3805 000 86 3805 000
79
VENT/AIR INT
AKE TERMINATION HORIZ. MOUNTING ASSY (FOR STAINLESS STEEL VENTING)
45 1138 000 45 1138 000
80 NATURAL GAS CONVERSION KIT 86 0906 000 86 0956 000
BOBCAT Modulating Condensing Gas Boiler
Boiler Replacement Parts List
Item No. Description B-120 B-200
When ordering replacement parts: specify the model number, serial number and gas by name ( natural or propane).
For replacement parts, heating contractors should contact their Slant/Fin boiler distributor.
PUBLICATION: B-10PL REV. A
Printed in U.S.A. 208
Part No. 86 5738 000
This parts list must be left with owner, hung on or adjacent to
the boiler. Owner should retain parts list for fuure reference.
