FR Select - LED Selectable Round Flood Lights INSTALLATION GUIDE
FRSelect.Installation.V23.01
Due to continuous product improvements, specication and/or equipment updates may change without notice.
Page 1/3
June 21, 2023 10:47 AMLast updated:
11325 Cash Rd, Suite #100
Houston, Texas 77477 | 713-389-5680 |[email protected] |www.slgus.com
WARNING: PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
ONLY LICENSED ELECTRICIANS SHOULD PERFORM ANY INSTALLATION SERVICES TO AVOID PERSONAL INJURY
AND PRODUCT DAMAGE.
DISCONNECT POWER BEFORE ATTEMPTING INSTALLATION OR SERVICING TO AVOID ELECTRIC SHOCK
ORCOMPONENT DAMAGE.
FOLLOW THE NATIONAL ELECTRIC CODE (NEC) AND ALL APPLICABLE FEDERAL, STATE AND LOCAL ELECTRIC CODES
AND SAFETY STANDARDS IN ACCORDANCE TO INSTALLING THIS PRODUCT.
ONLY UL (OR OTHER NTRL) APPROVED WIRE FOR INPUT/OUTPUT CONNECTIONS SHOULD BE USED WITH MINIMUM SIZE
OF 18 AWG OR 14 AWG FOR CONTINUOUS RUNS.
ONLY INSTALL WHERE AMBIENT TEMPERATURE DOES NOT EXCEED RATED OPERATING TEMPERATURE OF THE FIXTURE.
HANDLE THIS PRODUCT WITH CAUTION DURING OR AFTER OPERATION TO AVOID BURNS FOR IT MAY BECOME HOT.
DISCONNECT PRODUCT TO ALLOW COOLING BEFORE SERVICING.
DO NOT ALTER OR MODIFY THIS PRODUCT TO AVOID SERIOUS PERSONAL INJURY, DEATH, PROPERTY DAMAGE
AND/OR PRODUCT MALFUNCTION.
THIS PRODUCT MUST BE GROUNDED TO AVOID MALFUNCTIONING AND ELECTRICAL SHOCK.
THIS PRODUCT IS DESIGNED TO OPERATE IN AMBIENT TEMPERATURES RANGING FROM -40˚F TO 104˚F (-40˚C TO +40˚C)
CAUTION - RISK OF FIRE.
SAFETY PRECAUTIONS:
IMPORTANT: READ AND FOLLOW INSTRUCTIONS CAREFULLY BEFORE INSTALLING THE FIXTURE.
GENERAL: INSPECT THE FIXTURE THOROUGHLY UPON RECEIVING FOR ANY FREIGHT DAMAGE
. USE A PHILIPS SCREWDRIVER TO OPEN THE KNOCKOUT ON THE BACK OF THE FIXTURE TO ADJUST THE DESIRED WATTAGE
AND LIGHT COLOR.
. TIGHTEN THE KNOCKOUT AFTER EVERY SETTING.
WATTAGE & CCT SETTINGS
CCT ADJUSTABLE
(3000K, 4000K, 5000K)
ADJUSTABLE SWITCH
WATTAGE ADJUSTABLE
(LOW, MEDIUM, HIGH)

FR Select - LED Selectable Round Flood Lights INSTALLATION GUIDE
FRSelect.Installation.V23.01
Due to continuous product improvements, specication and/or equipment updates may change without notice.
Page 2/3
June 21, 2023 10:47 AMLast updated:
11325 Cash Rd, Suite #100
Houston, Texas 77477 | 713-389-5680 |[email protected] |www.slgus.com
.KNUCKLE MOUNTING
MAKE WIRING CONNECTIONAND SCREW IN
THREADS TO MOUNTING BOX.
.LONG VISOR
ALIGN AND SECURE VISOR WITH FOUR SCREWS
PROVIDED ON THE FACE OF THE FIXTURE.
.ADJUSTING BEAM ANGLE ±90˚
LOOSEN SET SCREW TO ADJUST FIXTURE
ANGLE AND TIGHTEN ONCE DONE.
.GROUND STAKE MOUNTING
MAKE WIRING CONNECTIONS AND THREAD
STAKE INTO FIXTURE. PICK A DESIRED LOCATION
AND DRIVE THE STAKE INTO THE GROUND.
.TENON MOUNTING
MAKE WIRE CONNECTION AND THREAD FIXTURE
INTO THE TENON. SELECT A DESIRED LOCATION
TO MOUNT THE TENON.
MOUNTINGS & VISOR INSTALLATION

FR Select - LED Selectable Round Flood Lights INSTALLATION GUIDE
FRSelect.Installation.V23.01
Due to continuous product improvements, specication and/or equipment updates may change without notice.
Page 3/3
June 21, 2023 10:47 AMLast updated:
11325 Cash Rd, Suite #100
Houston, Texas 77477 | 713-389-5680 |[email protected] |www.slgus.com
WIRING DIAGRAM
TROUBLE SHOOTING
. CHECK POWER SOURCE
. CHECK WIRE CONNECTIONS
SUPPLY WIRE
0-10 VDC
AC LINE (BLACK/BROWN)
AC NEUTRAL (WHITE/BLUE)
GROUND (GREEN/YELLOW)
DIM - (GREY)
DIM + (PURPLE)
L
N
G
(IF APPLICABLE) DIM -
DIM +
LED DRIVER
FIXTURE
