TY32S L-810 LED Single Low Intensity
Solar Powered Obstruction Light (Type B)
Description:
The solar panel comes with TY32S provides power supply to the light, which makes TY32S
a self-contained and care-free light unit. Also, with the solar function, the light is easy to
deploy to almost any condition and any emergency case. Robust body built and surface
coating provides good protection against hash environments. TY32S is equipped with an
8Ah NiMH rechargeable battery which could power the light up to 10 days when the weather
is cloudy & rainy. NiMH battery is also a clean power source with no pollution. The NiMH
battery is also easy to find almost anywhere. TY32S is also available with an optional on/off
switch for storing and protect battery from over-discharging.
Features& Benefits:
• High quality optics for excellent beam spread control
• Ultra-light LEDs, energy saving
• Self-contained without outside power supply
• Maximum visibility distance 7.6KM
• Once fully charged, it can work for up to 10 days for flashing mode and 4 days in flashing
mode
• Auto-off after being packed for 18 hours
• All hardware of obstruction lights are made of corrosion resistant metals.
• Use of quality components and sophisticated technology reduce chances of maintenance
and replacement.
• LED light source ensures long lifetime, maintenance free
• Shock and vibration resistant
• Corrosion resistant and UV stable polycarbonate housing
• Ease of mount, mount accessories available
• No wiring job, nice & easy installation
.Applications:
• High rise building marking • Telecom tower marking
• Road obstruction marking • Navigation aid
• Port, dock entrance&walkway • Buoy marking
• Offshore gas&oil platform

Shanghai Lansing Electronics Co., Ltd Tel : [phone] Fax：[phone] Web：www.lansinglight.com E-mail：[e-mail]
Add: No 609, Tahui Rd, Shihudang Town, Songjiang Dist Shanghai, China, 201612
All rights reserved by Lansing,without the written authorization of the Lansing, any part thereof shall not be reproduced or transmitted in any form.
TY32S L-810 LED Single Low Intensity
Solar Powered Obstruction Light (Type B)
Installation dimension（mm）
Specifications:
LIGHT OUT-PUT
SPECIFICATIONS
>32.5 cd
Nominal Night Range
>7.6 KM
LED Color Available
Red, White, Green, Blue or Yellow
Vertical Divergence
10 Degree
Horizontal Out-put
360 Degree
Illumination
Ultra-bright LEDs
LED Lifespan
100,000 Hours
OPERATION
Autonomy
Steady burning: 4 days, Flashing: 10 days
On & Off Level
70/100 Lux
Flash Pattern
20-60FPM（optional）
POWER SUPPLY
Power Source
Solar module, mono-crystalline silicon
Solar Efficiency
13.5%
Max. Power Out-put
4.8 Watts
Battery Type
High-efficiency NiMH rechargeable battery
Battery Capacity
8 AH
Battery Replacement
Yes, replaceable
MECHANICAL STRUCTURE
Lens
Polycarbonate, UV Stabilize
Body
Polycarbonate or Die-casting Aluminum
Water-proof
IP67
Weight
1.65 kg (Polycarbonate) or 2.5kg (Die-casting Aluminum)
Temperature Range
-40 ~ +55
Dimensions
215.5mm H, 226mm Diameter
Warranty
5 years for light
2 years for NiMH battery

Shanghai Lansing Electronics Co., Ltd Tel : [phone] Fax：[phone] Web：www.lansinglight.com E-mail：[e-mail]
Add: No 609, Tahui Rd, Shihudang Town, Songjiang Dist Shanghai, China, 201612
All rights reserved by Lansing,without the written authorization of the Lansing, any part thereof shall not be reproduced or transmitted in any form.
TY32S L-810 LED Single Low Intensity
Solar Powered Obstruction Light (Type B)
Compliance with
•ICAO Annex 14, Volume I,
Obstruction Light Low Intensity Type B
•FAA AC No. 150/5345-43, L-810
•DGAC Mexico
TY32A
TY32A is updated with a flash frequency adjustable switch, which can set 40, 50, 60, 70 and
90 FPM (Flash per minute). Additional, a Dry Contact Relay is built in the light to report light
failure to central monitoring devices, in case of working with junction box or control
box.Alarm report conditions:
• Lamp low current(when lamp current falls<50%)
• Solar panel failure
• Battery fail
TY32W
TY32W is further updated from TY32DA, which can realize both Flashing Frequency
Adjusting&Alarm
Reporting functions, through built in 2.4G wireless module.
In case of working with our wireless control box, TY32W can report failure status to central
monitoring in the BTS. Distance between TY10W& receiver should be <100meters
Alarm report conditions:
• Lamp low current(when lamp current falls<50%)
• Solar panel failure
• Battery fail
Ordering Code
TY32S
TY32A
TY32W
Basic functions
Flashing frequency adjustable
Synchronization
Light failure alarm report
Wireless
Note: Synchronization & alarm report functions need junction box or control box to be in the
system

Shanghai Lansing Electronics Co., Ltd Tel : [phone] Fax：[phone] Web：www.lansinglight.com E-mail：[e-mail]
Add: No 609, Tahui Rd, Shihudang Town, Songjiang Dist Shanghai, China, 201612
All rights reserved by Lansing,without the written authorization of the Lansing, any part thereof shall not be reproduced or transmitted in any form.
TY32S L-810 LED Single Low Intensity
Solar Powered Obstruction Light (Type B)

Shanghai Lansing Electronics Co., Ltd Tel : [phone] Fax：[phone] Web：www.lansinglight.com E-mail：[e-mail]
Add: No 609, Tahui Rd, Shihudang Town, Songjiang Dist Shanghai, China, 201612
All rights reserved by Lansing,without the written authorization of the Lansing, any part thereof shall not be reproduced or transmitted in any form.
TY32S L-810 LED Single Low Intensity
Solar Powered Obstruction Light (Type B)
Mounting bracket
Installation and operation:
Option 1
1. Secure the light on a smooth surface which has enough strength, if there is no mounting
surface, we can customize special mounting bracket as request
2. When installation, please stay away the nearby light source
3. Use 4XM8 screws to fix the light base on the smooth place
Option 2:
Use a MBP80 Mounting brackets below picture) to fix the light on the pole, pipe, telecom
tower or any other places required the light.
Notice:
• The part of material of products is PC( like lamp cover and lamp shell ), so it cannot direct
or indirect touch the organic solvent, such as industrial alcohol, banana oil, isopropyl alcohol,
carbon tetrachloride, cyclohexanone and so on, otherwise, the product will be corrosion.
• Please read the instruction manual carefully before operation.
• For protection of batteries during transport and storage, lights bottom installed sleep
switch, and is set to sleep mode, please check whether the lamp is in normal working
condition before installation or testing, turn on the switch according to the instruction.
• The bottom of the switch control: Press 3 to 5 seconds, the light starts to sleep (stopped
working); Press 1 to 2 seconds, the lights began to work); testing and operation of switches in
the dark environments, or covered with black shade cloth in order to operate correctly.
• Any question in operation please contact our company.

Shanghai Lansing Electronics Co., Ltd Tel : [phone] Fax：[phone] Web：www.lansinglight.com E-mail：[e-mail]
Add: No 609, Tahui Rd, Shihudang Town, Songjiang Dist Shanghai, China, 201612
All rights reserved by Lansing,without the written authorization of the Lansing, any part thereof shall not be reproduced or transmitted in any form.
TY32S L-810 LED Single Low Intensity
Solar Powered Obstruction Light (Type B)
BATTERY CHARGING IF NECESSARY:
FIRST WAY: Put the light under sunlight
SECOND WAY:Use a Charger( around 4.2v-5v) such as switching power supply etc
1.open the cover
2. Put the dip switch
to “ON” position
3. Close the cover,
and put the light
under sunlight
1.Open the back cover
(take care of the seal
ring)
2.Take off the
battery
3.Find a suitable charger
（4.2v-5V ）and connect
with the battery(note +/-),
and charge the battery for
2-3 hrs
4.After finishing the
charging, assemble the
light. Note the seal ring
to waterproof.
