Sliger SV590 User manual

SV590
Manual V1.0

SCREWS
The SV590 comes with a total of 5 different screws types. For the purposes of
this guide we will assign a unique color and type number to each of the screw
to signify their locations in this guide.
GREEN- M3 x 6mm PAN HEAD
Securing PCIe Cards
PINK - M3 x 8mm FLAT HEAD
Power Cord
RED - M3 x 5mm FLAT HEAD
Radiator Mount Bracket
Power Cord Mount Bracket
SSD / HDD bracket
VIOLET –632 x ¼” TRUSS HEAD
Motherboard
Power Supplies
Orange –632 x ¼” FLAT HEAD
Side Panels
Base Plate
Radiators
HDDs

EASY OFF TOP
The top cover features tool-less removal via ball-stud mounting points,
this allows for convenient access to your motherboard and PCIe card IO
ports in place of traditional front panel IO ports. The top panel may be very
tight on the first few times on/off.

SIDE PANELS
GPU SIDE REAR CORNER
CPU SIDE FRONT CORNER
Side panels of the SV590 are held on via 8x 632 x ¼” FLAT HEAD screws.
Four per side, two at top and two at bottom.
Please pay attention to the correct size screw driver as to not strip the screw
heads.

SLIDE OFF PANELS
Once the screws are removed, the front/GPU side panel slides of the front,
and the rear/CPU side panel slides off the back of the case.
Panels may scratch the case frame, please handle with care.

CASE FRAME
The rear radiator bracket of the SV590 frame is held on by 6x M3 x 5mm
FLAT HEAD screws; 3x per side, 2x at top and one at bottom.
You will also need to unscrew the SSD mount bracket which is held on by
additional 2x M3 x 5mm FLAT HEAD screws.

FRAME SEPARATION

POWER CORD
The SV590 includes an internal
power cord extension, and a
mount bracket for easy access to
the extension plug.
There is also a pass-through
grommet to get the extension
into the case. Clip this grommet
over the cord, then run the cord
through the cutout, and slide the
grommet into position as shown
left.
The power cord extension is then installed into the mount bracket with two
M3 x 8mm FLAT HEAD screws.
Once the power cord is installed both into the bracket and into the
grommet, the bracket then can be attached to the case via 2x M3 x 5mm
FLAT HEAD screws.
Note that the SV590 power cord
mount is adjustable to four
different positions in order to
allow the user to position it where
it obstructs the motherboard IO
ports the least.
It is critical you install the
power cord before installing
the IO shield for your
motherboard!

POWER SUPPLY
The fan on the power supply is recommended to be positioned with the fan
side of the power supply towards the center spine of the case. This
orientation will result in better overall system temperatures and lower noise.
Once positioned, the SFX PSU can be attached to the PSU Mounting Bracket
with up to 6x of the included 632 x ¼” TRUSS HEAD screws.
Note that not all SFX Power Supplies have all 6x screw holes as shown.

MOTHERBOARD
Don’t forget to install the power
cord and your IO shield first!
Some CPU coolers may require a
back plate installed before
installing the motherboard into
the case.
It is advised to also check that any
back of motherboard M.2 drives
are installed before mounting the
motherboard.
Once the IO shield and power
cord / power cord grommet are
properly installed the
motherboard can now be
mounted using 4x 632 x ¼”
TRUSS HEAD screws.
A Phillips #2 screw driver with a
minimum 7-8cm shaft length is
recommended for installing these
screws. Both of the screws on the
PCIe slot side of the motherboard
have pass-through holes in the
case frame to allow the screw
driver and screw to pass through
and be screwed in straight
Additional installation instructions
for your CPU, CPU cooler, RAM,
etc. are covered by your
motherboard or coolers
respective user manual

CABLE MANAGEMENT
Once the motherboard and
power supply are mounted it is
recommended to do some cable
management before you install
any radiators or PCIe cards.
Note the CPU and cooler mount
back plate / standoffs are
installed.
The power switch / LED is routed
and plugged into the
motherboard.
The power cord is mounted at
top (two screws in counter sinks)
and properly passed through the
grommet, and routed to the inlet
on the power supply.
Make sure the PSU switch is on.
Motherboard power cables are
plugged in, and GPU power
cables are loosely positioned.
Power cables are loosely
managed and zip tied.
The PCIe riser is plugged into
the PCIe slot on the
motherboard.

240mm / 120mm AIO
The compact design of the case
SV590 limits the ways in which dual
AIO setups can be installed.
The 240mm AIO at left (orange)
must be mounted above the 120mm
AIO with the radiator hoses facing
downwards.
The 120mm AIO must be mounted
below the 240mm AIO, with the
120mm AIO hoses able to be
oriented to the top or bottom of the
case.
If the 240mm AIO hoses are
mounted to the top, you will not be
able to screw the case together –as
the hoses will hit the motherboard
and/or GPU.
Conversely if the hoses are mounted
as shown, the hoses will come out
where there is additional free space
next to the power supply / below the
GPU/PCIe cards.
If your AIOs do not include
mounting screws, please use the 632
x ¼” TRUSS HEAD screws provided
with the case.
ALL FANS MUST BE SET TO EXHAUST OUT THE REAR OF THE CASE
If installed as intake you will cause your power supply and GPU to run at
high temperatures which can cause part failures.

360mm AIO
If the 360mm radiator
hoses are mounted to
the top, you will not be
able to screw the case
closed as the hoses will
collide with the
motherboard and/or
GPU PCIe riser bracket.
Conversely if the hoses
are mounted as shown,
to the bottom of the
case, the hoses will not
have interference
issues due to free
space provided around
the power supply and
below the GPU/PCIe
cards.
If your AIOs do not
include mounting
screws, please use the
632 x ¼” TRUSS
HEAD screws provided
with the case.
ALL FANS MUST BE SET TO EXHAUST OUT THE REAR OF THE CASE
If installed as intake you will cause your power supply and GPU to run at
high temperatures which can cause part failures.
NOTE: All 360mm AIOs or radiators in
the SV590 must be mounted with the
radiator hoses/ports at bottom.

REASSEMBLE CASE
With the radiator/AIO in position
your case should look like the
example to the right, less your GPU
and any 2.5” SSD / 3.5” HDDs.
Mounting the AIO-radiator is the reverse order of page 5 in this guide.
The rear radiator mount bracket of the SV590 frame is held on by 2x M3 x
5mm FLAT HEAD screws; 3x per side, 2x at top and one at bottom.
We recommend plugging in your
fan headers / fan splitters before
screwing the rear radiator bracket
back onto the case frame.
It is also recommended to do try
various positions with the AIO
CPU pump block to best fit your
AIO hoses as lengths can vary.

GPU MOUNTING
Process of installing the GPU is same
it would be on a standard PC case,
just on a PCIe riser. Slide the card
into position, push down into the
slot, and then secure the PCIe card
bracket with the M3 PAN HEAD
screws.
If your GPU only has a 2-slot wide
PCIe bracket the SV590 includes
a single-color matched slot cover.
We recommend installing the
GPU after installing the radiator as
the case will be slightly more
rigid.
Additionally, this method allows
access to the fan screws for ease
of installing fan guards, reversing
fan airflow, etc.

SSD and HDDs
Two placement examples are shown.
Motherboard side example at top,
and GPU side example at left.
The SSD bracket is mounted via 2x
M3 x 5mm FLAT HEAD screws.
SSDs are mounted to this bracket
with up to 4x M3 x 5mm FLAT
HEAD screws each.
The SV590 3x SSD bracket can be
mounted in one of a few positions
on either side of the case.
The SSD bracket itself is
symmetrical on mounting, but
asymmetrical on SSD position to
allow SSDs to be offset for better
cable management and AIO tube
routing

SSD and HDDs
All SSDs in this position should be
mounted with 2x M3 x 5mm FLAT
HEAD screws per SSD.
3.5” Hard Drive Disks should be
mounted with two 632 X 1/4” FLAT
HEAD screws.
The SV590 also has a section of
standard obround venting at the
bottom of the case for attachment
of 3.5” Hard Drive Disks and 2.5”
SSD directly to the frame when
stood on end.
Two configurations are show, at
right with 2x 3.5” HDDs, and 1x
2.5” SSD, and below with 5x 2.5”
SSD.

BASE PLATE
The SV590 removable base plate is attached via 4x 632 X 1/4” FLAT
HEAD screws.
Alignment of the rectangular cutout in the base plate to the obround
vent pattern of the chassis frame before attachment is critical.
This cutout in the base plate is here so that screws for mounting SSD,
HDDs, or custom loop pumps and/or reservoirs do not cause the case to
sit uneven

Technical Specifications
Motherboard
Mini-ITX (170 x 170mm)
CPU Air Coolers
Maximum of 55mm tall CPU coolers
Liquid Cooler
1x 360mm radiator
OR
1x 240mm radiator + 1x 120mm radiator
Maximum Length: 430mm (or up to 450mm with very little room for cables out rear of top)
Maximum Width: 149mm
Maximum Thickness: 66mm (including fan and radiator thickness)
Maximum of 55mm tall CPU pump blocks
Space in bottom of case or between CPU and PSU for short pump/res combos. Custom mounting
may be required.
Fan Mounting
Up to 3 120mm fans, or 3 140mm fans with 120mm mounting screw positions
PCIe Cards
Supports one three (3) slot wide card, or with PCIe bifurcation riser 1x 2-slot card and 1x single slot
card
Maximum card height: 160mm
Maximum card length: 390mm (290mm with 3.5" HDD or 324mm with 2.5" SSDs in case
bottom)
Maximum card width: 68mm
Note that the PCIe card is mounted behind motherboard on a PCIe 3.0 16x flexible ribbon riser
Bifurcation riser limits the outer PCIe 16x 2.0 card to 2 slots wide, and inner slot to a single slot card.
Bifurcation outer slot maximum card width: 47mm
Storage
(3x) 2.5" SSD/HDD mounting points on bracket between CPU and PSU
Optional (4x) 2.5" SSD/HDD mounting in bottom of case [restricts GPU length to 324mm]
Optional (2x) 3.5" HDD mounting in bottom of case [restricts GPU length to 290mm]
Front connection
Currently not available
Security
1x Kensington Lock Cutout
Power Supply
SFX
SFX PSU are available up to 750W, with 1000W units available Q1 2020
SFX-L is supported; however, it is a very tight fit and not recommended.
Material
Chassis: Galvanized Steel
Side Panels: Cold Rolled Steel
Base Plate: Cold Rolled Steel with black adhesive SBR feet
Finish
Powder coating
Outside Dimensions
Case Body: 154mm x 247mm x 472mm (WxDxH)
Base Plate: 218,8mm x 284,8mm x 2,64mm (WxDxH)
Weight
6,33 kg (Base configuration)
Volume
17,95 Liters
Rev Control
Check Data Sheet

Info
Manufacturer
Importer
Sliger Designs Inc.
1575 Linda Way, Suite 107
Sparks, NV 89431, USA
+1 775 356 5595a
www.sliger.com
DENSITY LABS s.r.o.
Veterná ulica 759/37
SK-90067 Láb, Slovakia
www.DENSITY.sk
Sliger Designs Inc. and Density Labs s.r.o. declare that this equipment is in compliance with Low Voltage Directive 2014/34/EU
according to the standard EN 62368-1:2014. Copy of the original declaration may be obtained at [email protected].
© 2019 Density Labs s.r.o. and Sliger Designs Inc. All rights reserved. DENSITY logo is a property of Density Labs s.r.o. in Slovakia
and/or in other countries. All other trademarks are the property of their respective owners. Product may vary slightly from pictures
in this document. Specifications and/or features may be subject to change without prior notice.
Other manuals for SV590
2
Table of contents
