Sliger SM5X0 Series User manual

SM5X0 SERIES
ASETEK 92mm AIO MOUNT
ASSEMBLY GUIDE

ASSEMBLE THE AIO
Pictured below is the recommend fan mounting and tube configuration
for the ASETEK 92mm AIO for our SM5X0 series cases.
Note the orientation of the tubes, fan, and fan wire.
NOTE: Sliger does NOT include the screws for attaching the
fan to the radiator. We recommend 4x .750” long 6-32
Phillips #2 flat head screws.

“INSTALL” REAR FAN
Your secondary fan (or 4x SSD / 3.5” HDD bracket) must be positioned
before installing the AIO. DO NOT SCREW IT INTO POSITION. (yet)

ATTACH AIO BRACKET
Attach the AIO bracket to the radiator so the hoses are towards the GPU
side of the case, and the two mount hardware are towards the rear of case.
NOTE: the 4x screws used for bottom of AIO are 1/4” 6-32 PFH #2 black.

INSERT ASSEMBLY
From the motherboard side insert the assembly at an approximate 45 degree
angle to tuck radiator right angle hose connectors under the center spine.
The rest of the assembly should then be able to slide straight in.

CHECK CLEARANCE
The below image illustrates where the tubes should be resting once the
radiator is succefully placed. This position prevents any kinks in AIO hoses.

TIME TO SCREW
Install the AIO bracket with the 2x M3 Flat Head screws provided with
the AIO bracket. Your 120mm fan can then be screwed into position.
