Fantec QB-35US3R+AES User manual

SERIAL
internal
ATA
Technical changes reserved.
FANTEC GmbH • Billwerder Billdeich 605B • 21033 Hamburg Deutschland
Tel. +49 (0) - 73 09 2 83 • Fax +49 (0) - 72 69 28 98
http://www.fantec.de • www.fantec-forum.de • [e-mail]
FANTEC QB-35US3R+AES
256bit AES USB dongle
Power supply
eSATA connector
SUPERSPEED USB 3.0 connector
80mm thermal controlled fan
Power button
Status LED for interface selection
Status LED for fan speed
Status LED for RAID mode
Status LED for AES encryption
Button for interface selection
Button for fan speed selection
Backup your data with the FANTEC QB-35US3R+AES with space for up to
four SATA hard drives in one case. Protect your data from unauthorized ac-
cess with 256bit AES encryption and the included 256bit AES USB dongles.
No access to your data without these 256bit AES USB dongles. The flexible
interfaces SUPERSPEED USB 3.0 and eSATA provide ultra-fast data transfer.
Easy Plug & Play with hot swap. The built-in temperature sensor automati-
cally controls the 80mm fan and ensures optimum cooling of the hard drives.
FANTEC QB-35US3R+AES
6
5
1
7 96 8
2
4
3
7
8
9
10
11
12
10 11 12
1
2
3
4
5
4x 8.89cm (3.5") eSATA & USB 3.0 RAID+AES CASE
Manufacturer Item-No.: 1525

Specifications
Technical changes reserved.
FANTEC QB-35US3R+AES
FANTEC GmbH • Billwerder Billdeich 605B • 21033 Hamburg Deutschland
Tel. +49 (0) - 73 09 2 83 • Fax +49 (0) - 72 69 28 98
http://www.fantec.de • www.fantec-forum.de • [e-mail]
Dimensions (device)
• 126 x 215 x 166mm (W x D x H)
• Netto weight 1.8kg apiece
Logistical data
• Dimensions retailbox
(293 x 155 x 270mm - W x D x H)
• Dimensions carton
(606 x 503 x 290mm - W x D x H)
• Gross weight with retailbox
~2.9kg per retailbox
• Carton
6 pieces per carton
• Total weight carton
18kg
• EAN
4250273415254
Equipment
• Hard disk case
• Suitable for 4x 8.89cm (3.5") SATA HDDs
• 256bit AES encryption
• RAID controller
RAID modes 0, 1, 3, 5, 10, BIG
• SUPERSPEED USB 3.0 connector
Data transfer up to 5Gbps
• eSATA connector
Data transfer up to 3Gbps
• Internal 80mm fan
• Automatic fan speed control via built-in
temperature sensor
• Manual fan speed selection (3-levels)
• Power off in synchronization with PC
• Blue status LED (front)
interface selection, fan speed, RAID mode
and AES encryption
Connectors
• 4x SATA (internal)
• 1x SUPERSPEED USB 3.0 connector (rear)
• 1x eSATA connector (rear)
• 1x power supply (side)
• 1x 256bit AES encryption (side)
Power supply
• AC in 100~240V
• DC out 12V/5A
Operating system
• Microsoft Windows 2000 SP3, XP
SP2, Vista, 7
• MacOS 10.3 and above
• Linux
Package contents
• 1x USB 3.0 cable
(compatible to USB 2.0, 1.1)
• 1x eSATA cable
• 4x HDD handles
• 1x external power supply
• 1x srewdriver
• 2x USB dongles for 256bit AES
encryption
• AES Key Management Software
• Manual
4x 8.89cm (3.5") eSATA & USB 3.0 RAID+AES CASE
Manufacturer Item-No.: 1525
