Smart Electronic MX Flat HD User manual

HDTV Satellite Receiver
MX Flat HD
User Manual
Version: 12.12.2012 - English

Introduction
2 smart MX Flat HD
Introduction
Dear customer,
Thank you for buying a smart HDTV satellite receiver.
This user manual provides information on
•placement
•installation,
•adjustment
•operation,
•cleaning and disposal of the receiver.
Please carefully read the user manual before operating the receiver.
We hope you enjoy your smart receiver.
Your
smart electronic GmbH
Industriestraße 29
78112 St. Georgen
Germany
Service hotline: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.smart-electronic.de
© smart electronic GmbH 2012
All rights, technical changes, errors as well as printing mistakes reserved. Any reproducing or
copying of the contents requires prior written permission from smart.

Table of Contents
smart MX Flat HD 3
Table of Contents
1User Information .................................................................................8
1.1 Use of this Manual ...................................................................8
1.2 Signs, Symbols, Layout ...........................................................8
2Product Description............................................................................9
2.1 Scope of Delivery.....................................................................9
2.2 Receiver .................................................................................10
2.3 Remote Control......................................................................11
2.4 Save Energy ...........................................................................13
2.5 Guarantee...............................................................................13
3General Safety Instructions .............................................................13
3.1 Intended Use..........................................................................13
3.2 Risks in Case of Intended Use...............................................13
3.3 Location..................................................................................14
3.4 Grounding ..............................................................................15
3.5 Handling of Batteries..............................................................15
3.6 Notes on Product Liability......................................................15
4Installation of smart MX Flat HD .....................................................15
4.1 Connection Scheme...............................................................16
4.2 Connect Satellite Antenna .....................................................16
4.3 Connect TV Set ......................................................................16
4.4 Connect IR Eye ......................................................................16
4.5 Connect Home Cinema System (Optional)............................17
4.6 Connect Data Storage (Optional)...........................................17
4.7 Connect External Power Supply............................................18
4.8 Insert Batteries of Remote Control ........................................18
5Basic Operation.................................................................................18
5.1 Switch on Receiver ................................................................18
5.2 Installation ..............................................................................18

Table of Contents
4 smart MX Flat HD
5.2.1 Language............................................................................... 19
5.2.2 RAPS Start............................................................................. 19
5.2.3 RAPS Parameters.................................................................. 21
5.2.4 Satellite List ........................................................................... 22
5.2.5 Country .................................................................................. 22
5.2.6 Regional Channel................................................................... 23
5.2.7 Channel-Filter ........................................................................ 23
5.3 Select Operation Mode.......................................................... 23
5.4 Call/Leave Menu.................................................................... 24
5.5 Menu Navigation.................................................................... 24
5.6 Parental Lock......................................................................... 25
5.7 Set Time................................................................................. 26
5.8 TV........................................................................................... 27
5.8.1 Direct Channel Selection ....................................................... 27
5.8.2 Channel Selection via Selection Window.............................. 28
5.8.3 Channel Selection via Search Function................................. 29
5.8.3.1 HDTV Filter............................................................................. 29
5.8.3.2 Genre Filter ............................................................................ 29
5.8.3.3 Find Channels (by Alphabet) ................................................. 30
5.8.3.4 Sort Channel List (by Alphabet)............................................. 31
5.8.4 Channel Information .............................................................. 32
5.8.5 EPG........................................................................................ 32
5.8.5.1 Single EPG............................................................................. 33
5.8.5.2 Multi EPG............................................................................... 34
5.8.6 Audio Settings ....................................................................... 35
5.8.7 Teletext .................................................................................. 36
5.8.8 Subtitles................................................................................. 36
5.8.9 Aspect Mode ......................................................................... 37
5.8.9.1 Setting the Aspect Mode with the V-MODE key ................... 37
5.8.9.2 Setting the Aspect Mode via the Menu................................. 37
5.8.10 Video Resolution.................................................................... 37
5.8.11 Recall ..................................................................................... 38
5.8.12 Sleep Timer............................................................................ 38

Table of Contents
smart MX Flat HD 5
6Media Player ......................................................................................38
6.1 Music......................................................................................39
6.1.1 Playback.................................................................................39
6.1.2 Playlist ....................................................................................40
6.1.2.1 Creating a Playlist ..................................................................40
6.1.2.2 Moving files within the Playlist...............................................40
6.1.2.3 Delete files from the Playlist...................................................40
6.1.2.4 Delete all files from the Playlist: .............................................40
6.1.3 Edit Audio Files ......................................................................41
6.1.4 Sort Audio Files......................................................................41
6.1.5 Playback Mode ......................................................................41
6.2 Images....................................................................................42
6.2.1 Configure a Slide Show..........................................................42
6.2.2 Showing all Images in the Current Directory .........................42
6.3 Video ......................................................................................42
6.3.1 Playback Video.......................................................................42
6.3.2 Edit Video Files.......................................................................43
6.3.3 Sorting Videos........................................................................43
7Extended Settings and Functions ...................................................44
7.1 Installation ..............................................................................44
7.1.1 Antenna Connection ..............................................................44
7.1.2 Satellite List............................................................................44
7.1.3 Antenna Setup........................................................................46
7.1.3.1 Fixed Antenna ........................................................................46
7.1.3.2 Motor Antenna .......................................................................48
7.1.4 Single Satellite........................................................................50
7.1.5 Multi Satellite..........................................................................51
7.2 TV Channel List / Radio Channel List ....................................51
7.2.1 Add Channel to Favorites ......................................................52
7.2.2 Provide Channels with Password Protection (Lock
Against Unauthorized Access)...............................................52
7.2.3 Skip Channels when Switching from Channel to Channel
(Zapping) ................................................................................52

Table of Contents
6 smart MX Flat HD
7.2.4 Move Channels to Another Channel Position ....................... 53
7.2.5 Rename Channels ................................................................. 53
7.2.6 Delete Individual Channels from Channel List....................... 54
7.2.7 Delete All................................................................................ 54
7.3 Rename Favorite Lists........................................................... 55
7.4Timer...................................................................................... 55
7.5 OSD Setting........................................................................... 57
7.5.1 Hide OSD............................................................................... 57
7.5.2 OSD Transparency ................................................................ 57
7.6 LNB Supply Voltage .............................................................. 57
7.7 Automatic Standby Function................................................. 57
7.8 Display Setting....................................................................... 57
7.9 Digital Audio Out.................................................................... 58
7.10 Simultaneous Playback of Picture and Sound...................... 58
7.11 SmartLink (CEC) .................................................................... 59
7.12 RAPS System ........................................................................ 59
7.12.1 Show the Date of the RAPS File on the Receiver ................. 59
7.12.2 Setting RAPS Mode............................................................... 59
7.12.3 Enabling Automatic RAPS Updates ...................................... 60
7.13 Software Version.................................................................... 60
7.14 Factory Settings..................................................................... 60
7.15 Update of the Receiver Software .......................................... 60
7.15.1 Software Update via Satellite ................................................ 60
7.15.2 Update via USB ..................................................................... 61
8Operation in a Unicable System...................................................... 63
8.1 About Unicable ...................................................................... 63
8.2 Allocation of IF channels and frequencies ............................ 63
8.3 Installation.............................................................................. 64

Table of Contents
smart MX Flat HD 7
9Cleaning .............................................................................................66
10 Transport and Decommissioning....................................................66
11 Troubleshooting ................................................................................67
12 Disposal .............................................................................................69
13 Technical Data...................................................................................70
13.1 General Information................................................................70
13.2 Remote Control......................................................................70
13.3 Mains Adapter........................................................................70
13.4 Connections ...........................................................................70
13.5 Temperature...........................................................................70
13.6 Dimensions and Weight .........................................................71
14 Declaration of Conformity................................................................71

User Information
8 smart MX Flat HD
1User Information
1.1 Use of this Manual
•This manual is intended for the HDTV cable receiver smart MX Flat HD.
•Please carefully read this user manual before operating the device for
the first time.
•Please note all warnings and notes included in this user manual.
•Consider this user manual to be an integral part of the product, and
store it at a well accessible location.
•This user manual should also be enclosed when handing over the de-
vice to a third party.
•In case of loss, the current version of the user manual can be down-
loaded at the support center on our website www.smart-electronic.de.
•The software is still being further developed even after your purchase
of the device. Thus, it may be possible that certain operation steps do
not fully correspond to the user manual.
1.2 Signs, Symbols, Layout
Symbol/layout
Meaning
WARNING
Danger due to electric shock with possible severe bodi-
ly injury
CAUTION
Warning of possible physical damage
 NOTE
Useful information and hints

You are requested to perform an action.
1.
2. Perform these steps in the stated order.

List

Product Description
smart MX Flat HD 9
Symbol/layout
Meaning
Italics
The various possibilities of settings as well as image
captions are stated in Italics .
bold
Menu windows and menu items (that often include further
hidden menu items or direct settings) as well as the des-
ignations of keys are printed in bold letters.
2Product Description
2.1 Scope of Delivery
•HDTV satellite receiver smart MX Flat HD.
•Remote control
•2 batteries (AAA) for remote control
•User manual
•External power supply (12 V)
•External infrared receiver (IR eye) for the remote control
•Fastening material

Product Descripti
on
10 smart MX Flat HD
2.2 Receiver
No.
Description
View no. 1
1 Switch standby / operating
mode.
2 HDMI0F
1
HDMI breakout cable, digital
audio and video output.
3
OPT.
AUDIO
Digital optical output
(SPDIF).
View no. 2
4 IR
3.5 mm jack to connect the
IR remote eye (see section
4.4, page 16).
5 POWER
Socket for barrel jack to
connect the external power
supply.
View no. 3
6
LNB IN
F socket to connect the LNB
7
SERVICE
3.5 mm jack
8 USB
Connection for USB storage
device
1High Definition Multimedia Interface (engl.), Schnittstelle für die volldigitale Übertragung von
Audio- und Video-Daten.

Product Description
smart MX Flat HD 11
2.3 Remote Control
No.
Key
Description
1
Switch between operational and standby mode
2
1 - 9
Direct channel selection
3
FIND
Call of channel search function
4
MENU
Call main menu
5
PR+
Channel + or up-navigation in menu
PR-
Channel - or down-navigation in menu
Volume + or menu navigation to the right
Volume -or menu navigation to the left
OK/LIST
Display channel list / confirm menu item

Product Description
12 smart MX Flat HD
No.
Key
Description
6
INFO
Display information on current channel
7
TXT
Display / hide teletext
8
Red function key
9

PR
Switch of previously selected channels
10
Yellow function key
11
AUDIO
Selection of audio format
12
TV/RADIO
Switch between TV and radio mode
13
Not used
14
Play (media player)
15
Fast rewinding
16
Fast forwarding
17
Mute
18
0
Select playback format of media player
19
FAV
Call list of favorites
20
EPG
Call of EPG (Electronic Program Guide)
21
EXIT
Exit menu or menu item
22
Green function key
23
Blue function key
24
V-MODE
Switch aspect mode
25
PAGE+
10 entries up in menu / channel list
26
PAGE-
10 entries down in menu / channel list
27
Stop playback
28
Pause playback
29
Slow forwarding – slow motion
30
Slow rewinding

General Safety Instructions
smart MX Flat HD 13
2.4 Save Energy
The receiver smart MX Flat HD is equipped with particularly energy-saving
electric and electronic components. Furthermore, a sophisticated energy
management helps to save energy:
Thus, energy consumption during Save Energy Standby Mode is reduced
to less than 0.5 Watt!
2.5 Guarantee
The warranty of the HDTV satellite receiver smart MX Flat HD of smart
electronic GmbH corresponds to the legal regulations at the time of pur-
chase.
3General Safety Instructions
3.1 Intended Use
The HDTV satellite receiver smart MX Flat HD is intended for private re-
ceiving of digital satellite television (DVB-S). It is exclusively intended for
such purpose and must be used exclusively for such purpose.
Any other use is deemed to be unintended use.
3.2 Risks in Case of Intended Use
CAUTION!
Humidity, wrong mains voltage and/or wrong
mains frequency, lightning stroke or mechani-
cal overload may cause malfunction of or dam-
age to the device.
Ensure that the receiver (in particular the mains plug)
and the remote control are not exposed to any humidi-
ty. Example: Do not place filled flower vases or similar
onto the receiver.
Only connect the receiver to 175…250 V ~, 50/60 Hz.
Disconnect mains plug in case of thunderstorms or mal-
function.
Do not place heavy items onto the receiver.
Do not bend or squeeze the cable.

General Safety Instructions
14 smart MX Flat HD
WARNING!
Risk of electric shock when contacting mains
voltage.
Damage to housing, mains cable or improper repair
may result in contact to mains voltage.
Do not place heavy items onto the receiver.
Do not bend or squeeze the cable.
Repairs of plug, cable or receiver should only be per-
formed by qualified specialists.
3.3 Location
Place the receiver onto a solid and level surface.
Protect the receiver from humidity, heat, dust and dirt.
Do not place items filled with liquid, e.g. flower vases, onto the receiv-
er.
Protect the receiver from dripping and splash water.
Do not place burning items, e.g. burning candles, onto the receiver.
Ensure sufficient ventilation (ventilation slots must not be blocked): the
receiver should have a distance of at least five centimeters to its sur-
rounding elements on all sides.
Ensure that the ventilation openings are not covered by objects such
as newspapers, table cloths, curtains etc.
Only operate the receiver in moderate climate (not in tropical climate).
Place the receiver so that the mains plug can be disconnected at any
time, correspondingly disconnecting the device from the mains.

If the device is transported from cold to hot environ-
ment, then condensing humidity may build up in the de-
vice.
Do not connect the device, but leave it switched-off for
some hours.

Installation of sm
art MX Flat HD
smart MX Flat HD 15
3.4 Grounding
The satellite antenna must be grounded properly. Note the relevant VDE1F
2
regulations2F
3.

smart recommends that the outdoor unit of the satellite
system should be installed by a professional!
3.5 Handling of Batteries
•Batteries should always be out of children's reach.
•Leaking batteries cause damage to the environment and the remote
control.
•Batteries should not be exposed to extreme heat, e.g. sunlight, fire etc.
Dispose of the batteries in accordance with the applicable legal regula-
tions (see chapter Disposal, page 69).
3.6 Notes on Product Liability
In the following cases, the intended protection of the device may be lim-
ited. Then, liability regarding function of the device correspondingly pass-
es over to the operator:
•The device is not used in accordance with the user manual.
•The device is used out of the field of application as described above.
•The operator performs unauthorized changes of the device.
4Installation of smart MX Flat HD
CAUTION!
First connect the receiver to the satellite antenna and
any other devices before connecting the mains plug to
the power outlet.
Please also note the user manuals of the other devic-
es.
2VDE = Verband der Elektrotechnik, Elektronik, Informationstechnik (German) = Association
for Electrical, Electronic & Information Technologies
3DIN EN 60728-11 VDE 0855-1:2011-06: Cable networks for television signals, sound sig-
nals and interactive services, Part 11: Safety

Installation of smart MX Flat HD
16 smart MX Flat HD
4.1 Connection Scheme
default connection
optional connection
4.2 Connect Satellite Antenna
Connect the antenna cable to the receiver connection LNB IN.
4.3 Connect TV Set
As shown in the connection scheme, connect the HDMI breakout cable of
the smart MX Flat HD to your TV set.
4.4 Connect IR Eye
Um den Receiver mit der Fernbedienung bedienen zu können, müssen Sie
an der IR-Buchse das so genannte IR-Auge (im Lieferumfang enthalten)

Installation of smart MX Flat HD
smart MX Flat HD 17
anschließen. Dies muss so positioniert werden, dass es die Signale der
Fernbedienung empfangen kann.

Die Benutzung des IR-Auges ist zwingend notwendig.
Ohne korrekt angeschlossenes IR-
Auge ist der Betrieb
des MX Flat HD nicht möglich.
4.5 Connect Home Cinema System (Optional)
To improve audio playback, you can connect to the smart MX Flat HD -
additionally to the TV set - also a multichannel home cinema system or a
hi-fi system. There are various possibilities for connection. Your type of
connection depends on the connection possibilities of your home cinema
system.
a.
Your home cinema system is able to loop
through an HDMI signal, i.e. HDMI connec-
tion for receiver and HDMI connection for
TV set.
Receiver
TV set
Connect the home cinema system and the
receiver by using an HDMI cable as well as
home cinema system and TV set by using
an HDMI cable.
b.
Your home cinema system can process
digital audio data – connection for digital
data is pre-sent. OPT. AUDIO

Connect your home theater system and your
receiver with an optical cable.
4.6 Connect Data Storage (Optional)
Connect a data storage (USB stick or hard drive with USB connection)
at the USB connector to be able to access MPEG, MP3, JPG or other
media data files.

Basic Operation
18 smart MX Flat HD
4.7 Connect External Power Supply
Connect the cable of the power plug with the 12 V receiver socket.
4.8 Insert Batteries of Remote Control
This describes the steps for inserting new batteries of the remote
control or for replacing empty batteries:
1. Open the battery compartment on the bottom side of the remote con-
trol. Remove the cover of the battery compartment.
2. Place the two batteries 1.5 V (type: AAA).
Ensure correct polarity!
3. Close the battery compartment

Replace the batteries if certain remote control func-
tions are not performed any more or are performed
incorrectly.
When replacing batteries, always ensure that all bat-
teries are replaced.
5Basic Operation
This chapter describes the required steps to be able to use the offer of
radio and TV channels provided via satellite.
5.1 Switch on Receiver
1. Switch on all connected devices.
2. Ensure that the correct AV input is selected at the TV set (i.e. that the
signals from the receiver are displayed).
3. Ensure that the correct audio input is selected at the connected home
cinema or hi-fi system.
4. Connect the mains plug to the power outlet, to switch on the receiver.
5.2 Installation
After first switching-on or after resetting the receivers, various windows
will open:

Basic Operation
smart MX Flat HD 19
5.2.1 Language
By default, the smart MX Flat HD
language is preset to
Deutsch
[German].
Please ensure that the setting is
correct; you may change your set-
tings by correspondingly pressing
the keys PR+ and PR-.
Confirm by pressing OK to go
to the next window.

The submenu Language can be accessed anytime via
the menu Language.
5.2.2 RAPS Start
Your receiver is equipped with RAPS. RAPS means Receiver Automatic
Programming System. RAPS can automatically update the channel lists of
your receiver.
What is RAPS?
Currently, the satellites Astra 19.2° and 23.5°, Eutelsat Hot Bird 13° East,
Eurobird 9° and Turksat 42° offer a four-digit number of digital TV and
radio channels.
At delivery, state-of-the-art satellite receivers have all important channels
already stored. But what happens after that? New and interesting chan-
nels are added almost weekly, and there are channel changes time and
again.
Updating the channel list with a present receiver is not quite easy for most
users. When performing a channel search, invalid data are not deleted,
and usually the new channels are just added at the end of the list; this
requires time-consuming reprogramming of the channel list.
The RAPS system of your MX Flat HD automatically performs such pro-
gramming work.
The window RAPS Automatic Installation is the second window of the
installation process.

Basic Operation
20 smart MX Flat HD
Every time you switch off your receiver, RAPS checks whether there are
any changes with the channel lists (RAPS scan). This only takes a few
seconds.
In case of changes, the new data are automatically included into the new
channel list (RAPS download) and displayed in a table. If a channel
changes the receive parameters, then this is automatically updated by
RAPS. In case of new channels, such channels are added. If channels are
permanently discontinued, then the corresponding channel number is
deleted.
However, new channels are not only added, but allocated to logic blocks,
correspondingly enabling easier finding. That is why certain areas may
remain free. Example: For Germany, there is the basic list as well as the
areas Third Channels, Info+Sports, Special Interest, Local TV, as well as
News starting at channel number 100 and many Music Channels starting
at channel number 123.
You can cancel RAPS installation by
pressing the key EXIT
whilst the
countdown of RAPS installation is
running (and also at a later point in
time during installation).
The then displayed channel list is a preprogrammed factory list. However,
such list is not updated via satellite due to cancelled RAPS installation!
The respective up-to-date RAPS lists are available via the satellite Astra
19.2°. Correspondingly, RAPS can only be used within the footprint of the
satellite Astra 19.2°; furthermore, your system should be suitable for digital
Astra receiving.
