Smart Technologies LightRaise 60wi Assembly instructions

Diagonal Y
(image height) Z (plate height)
67"
(170 cm) 35"–36" (89 cm–91.5 cm) 14 1/2" (37 cm)
68"
(173 cm) 36"–37" (91.5 cm–94 cm) 14 1/2" (37 cm)
70"
(178 cm) 37"–38" (94 cm–96.5 cm) 14 3/4" (37.5 cm)
72"
(183 cm) 38"–39" (96.5 cm–99 cm) 15" (38 cm)
74"
(188 cm) 39"–40" (99 cm–101.5 cm) 15 1/4" (39 cm)
76"
(193 cm) 40"–41" (101.5 cm–104 cm) 15 1/2" (39.5 cm)
78"
(198 cm) 41"–42" (104 cm–107 cm) 15 3/4" (40 cm)
80"
(203 cm) 42"–43" (107 cm–109 cm) 16" (40.5 cm)
82"
(208 cm) 43"–44" (109 cm–112 cm) 16 1/4" (41 cm)
84"
(213.5 cm) 44"–45" (112 cm–114 cm) 16 1/4" (41 cm)
86"
(218.5 cm) 45"–46" (114 cm–117 cm) 16 1/2" (42 cm)
88"
(223.5 cm) 46"–47" (117 cm–119.5 cm) 16 3/4" (42.5 cm)
90"
(228.5 cm) 47"–48" (119.5 cm–122 cm) 17" (43 cm)
92"
(234 cm) 48"–49" (122 cm–124.5 cm) 17 1/4" (44 cm)
94"
(239 cm) 49"–50" (124.5 cm–127 cm) 17 1/2" (44.5 cm)
96"
(244 cm) 50"–51" (127 cm–129.5 cm) 17 3/4" (45 cm)
98"
(249 cm) 51"–52" (129.5 cm–132 cm) 18"
(46 cm)
100"
(254 cm) 52"–53" (132 cm–134.5 cm) 18 1/4" (46.5 cm)
All dimensions +/- 1/4" (0.5 cm)
LightRaise™ interactive projector quick connect guide
3 mm
2 mm
3 mm
4 mm
max.
D max.
(mm) # of shims # of spacers Indicator setting
0–6 0 0 3
7–12 0 0 9
13–19 0 0 16
20–26 1 0 10
27–33 0 1 10
34–39 0 1 16
40–46 1 1 10
47–52 0 2 9
53–60 0 2 16
D
3
D
1
D
2
D
> 4"
(10 cm)
Diagonal
Y
Z
1023792 Rev 01
smarttech.com/support
smarttech.com/contactsupport
Gray area
represents
“No Fly Zone”
For more detailed instructions, see the LightRaise interactive projector textless installation guide included with
your projector or download it at smarttech.com/kb/170259.
<5 mm
<5 mm <5 mm
<5 mm
<5 mm
<5 mm
1. Surface selection
2. Projector mounting Table 1
Table 2
~
~
<10 mm
Tilt
Warp
120 min.
© 2014 SMART Technologies ULC. All rights reserved. LightRaise, smarttech and the SMART
logo are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/
or other countries.

1. Surface selection
Projection surface must meet the guidelines found in
the LightRaise interactive projector surface evaluation
guide (smarttech.com/kb/170402).
Ensure the image surface warp (horizontal,
vertical, diagonal) is less than 5 mm.
Ensure the top bezel or protrusions don’t extend
3 mm above the surface.
Ensure the projection surface is mounted accord-
ing to the LightRaise interactive projector textless
installation guide (smarttech.com/kb/170259).
Charge a pen for 120 minutes for use in the initial
setup and alignment.
2. Projector mounting
Image surface tilt (horizontal, vertical) is less than
10 mm.
Record “D” measurement: _________.
Ensure the correct number of shims and spacers
are selected based on the “D” measurement in
Table 1.
Ensure the mounting plate optical image center
line is aligned with the image center. Ensure one
set of holes on the mounting plate is secured to
at least one stud.
(Optical) C
L
(Optical)
C
L
1 3/4 " (4.5 cm)
SLR60wi
1 1/2" (3.8 cm)
SLR60wi2
SLR60wi2-SMP
AB
Secure the projector mounting plate at the posi-
tion determined by the “Z” measurement.
Ensure all cables or other obstructions don’t
cross the “No Fly Zone.”
Complete installation and image adjustment.
3. Initial setup and alignment
Install SMART software:
 SLR60wi – minimum SMART Notebook 11.1
 SLR60wi2 – minimum SMART Notebook 11.4
 SLR60wi2-SMP – minimum SMART Meeting
Pro 4.0
Click SMART BoardLFRQLQWKH:LQGRZVQRWL¿-
cation area or the Mac Menu bar, and then select
SMART Settings >Connection Wizard.
Watch the embedded videos throughout the initial
setup and follow the instructions.
When prompted by the Connection Wizard, enter
the number for the boom setting that’s located on
the right side of the projector boom.
With the pen turned on, complete the 36-point
pen orientation.
Set the indicator setting on the touch detection
module (TDM) (left and right) as determined by
Table 1.
Press the red button to turn the red laser ON.
Use the center dial to adjust the red laser 1 1/2"
(35 mm) away from the surface in the target area.
Press the red button to turn the red laser OFF.
With the alignment tool turned ON, trace the
projected alignment path. It turns green as you
complete each section. Ensure the alignment tool
is held correctly as illustrated in the LightRaise
interactive projector textless installation guide
(smarttech.com/kb/170259).
Adjust dials (left, center, right) according to the
prompts.
Repeat the alignment traces and adjustments
according to the prompts (possibly 3–5 times).
 &RPSOHWHWKHSRLQW¿QJHURULHQWDWLRQ
Record the star rating:
____________
Note: If you receive a one-star rating, the TDM turns
off, you can use only the pen, and touch is disabled. If
you receive a two-star rating, touch works but is highly
compromised.
60$57UHFRPPHQGVDVXUIDFHÀDWQHVVRIOHVVWKDQ
PP$ÀDWWHUVXUIDFHSURYLGHVDKLJKHUVWDUUDWLQJ
Table 3
Star rating Touch Pen Surface
ÀDWQHVV
1 None Excellent >15 mm
2 Poor Excellent 10–15 mm
3 Good Excellent 5–10 mm
4 Excellent Excellent <5 mm
LightRaise interactive projector installation checklist
' $&'
