smart things sdock mini User manual

smart things solutions GmbH
Schulstraße 29
82234 Weßling, Germany
www.smart-things.com
AirPlay, iPad, iPhone, iPod classic, iPod nano and iPod touch are trademarks of Apple Inc., registered in the
U.S. and other countries. Lightning is a trademark of Apple Inc.
“Made for iPod,”“Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been
designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer
to meet Apple performance standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone,
or iPad may affect wireless performance.
Designed in Germany.
Made in China.
Wallmount.
Photoframe.
Docking Station.

Congratulations!
You have purchased the smart things sDock mini wall mount.
We put a lot of eort into the development and have selected only
materials of the highest quality. The production of our products is
subject to strict quality controls. However, in case you should detect
material or manufacturing defects, please contact the retailer where
you have purchased the product.
We hope that you will thoroughly enjoy our product.
Safety Instructions
Handling the sDock mini is very easy. However, we would like to ask
you to take a moment to read the mounting and operating
instructions carefully to avoid mistakes.
Mounting
Make sure that the wall has sucient bearing capacity for mounting
the product. Please note that the wall xing has to carry a multiple
of the wall mount's weight. Depending on the wall materials it could
be necessary to use special xing items (e.g. cavity xing, etc.). The
supplied screws and rawl plugs are suitable for mounting the
product on walls made of solid timber, stone, concrete, or timber
posts only. Take extra caution not to damage gas or water pipes or
electric wiring in the wall!
Attention!
The transparent screen covering the clip-on screen is only held by
clamping in the frame. Please be aware, that the transparent screen
can fall oif you mount it on slanted surfaces (e.g. slanting ceilings
in the attic). Risk of injury!
Correct Use
Please use this product only with these Apple products together
with the cables and chargers approved by Apple.
The sDock mini wall mount was developed for the use in
environmental conditions normally found in private homes and
oce buildings. Please avoid positioning the product in areas with
high exposure to sun radiation, extremely warm or cold
temperatures, high humidity or moisture.
The sDock mini wall mount was developed for the use with Apple
products and has been approved for the following products:
1
2
3
5
4
iPad Positioning Guide
Mounting holes
Transparent pane
Apple Lightning
Locking for iPhone/iPod
sLock
Pivoting base
Lever to remove the pane
Sockets for charging cables
VESA 75 xing option
iPad mini On/OSwitch
See bigger drawing
in the picture manual.
6
7
8
9
10
11
Instructions for use EN
Power supply out of the
wall
sDock mini allows a power supply
out of the wall. Only a professional
electrician is allowed to make such
an installation.
Take care that the power supply in
any case has enough air supply.
Overheating may cause re!
Attention!
The Apple power supply delivered
with the iPad is not approved for
use in a wall box.
Fire danger!
USB micro ports
Attention!
The USB micro ports are
not designed as a USB Hub.
Do only connect a single charger!
Maintenance
Clean your sDock mini with a micro ber cloth or a soft, damp cloth.
Never use aggressive cleaning substances.
Attention! Please detach all cables before you clean it.
Proper Disposal
Once nished using, please dispose of the sDock in an
environmentally responsible manner.
According to EU regulation 2001/96/EC and 2006/ 66/EC it does not
belong in the household garbage! Bring it to a respective collection
point or return it to the place of purchase.
297
16
5
11 28
10
14
3

smart things solutions GmbH
Schulstraße 29
82234 Weßling, Germany
www.smart-things.com
A
B
C
297
16
5
11 28
10
14
3
AB
4x
1.
4.
C
2.
3.
5.
1.
4.
2.
3.
6.5.
4x
90°
D
E
F
AirPlay, iPad, iPhone, iPod classic, iPod nano and iPod touch are trademarks of Apple Inc., registered in the
U.S. and other countries. Lightning is a trademark of Apple Inc.
“Made for iPod,”“Made for iPhone,” and “Made for iPad”mean that an electronic accessory has been
designed to connect specifically to iPod, iPhone, or iPad, respectively,and has been certified by the developer
to meet Apple performance standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone,
or iPad may affect wireless performance.
Designed in Germany.
Made in China.

Wallmount.
Photoframe.
Docking Station.
3.
1.
2.
3.
1.
2.
1. 1.
2.
3.
2.
3.
4a.
4b.
5.
90°
