Tracer ®VMA with AutoReg™

Flowmeter with Automatic Flow Regulation

Operating Instructions

General

The TracerVMA Flowmeter with AutoReg provides:

•Analog Flow Output (Selectable 0 to 3.5V, 0 to 5V or 0 to 10V)

•Analog Temperature Output (Selectable 0 to 4.1V, 0 to 5V or 0 to 10V)

(Lowest Voltage Output settings match TracerVM Base Units for ease

of direct replacement if needed.)

•Programmable Alarm Switch for High or Low Temperature and/or

Flow. Switch can be set for Turbulent Flow instead of programmed

settings. 1A, 30VAC/30VDC

•Flow Rate Display (GPM or LPM)

•Fluid Temperature Display (°F or °C)

•Reynolds Number Display

•BTU’s per Minute Display

•FCI Display (Turbulent Flow or “TF” on display)

•Volume Totalizer Display

•Automatic Shuto Timer

•Glycol Scale Options, 0%, 10%, 20% or 30% (for FCI Calculation)

Automatic Regulation Control Features

•Regulation via Flow Rate or Reynolds Number

•Actuator Alarm noties user via switch when the AutoReg is unable to

achieve the desired set point (15 seconds - 999 seconds).

Temperature

Operating Range .....................0 to 120°C (32 to 248°F)

Accuracy ............................................................. ±0.5°C

Component Materials

Sensing Element...............Silicon-Based MEMS Sensor

Seal (sensor to housing)..........................EPDM Rubber

Flow Path Insert ............................................PPA 40 GF

3/8" & 1/2" Body Sizes........... Glass-Filled Nylon Flow

Body with Brass or Nylon End Caps

3/4" & 1" Body Sizes.................... Anodized Aluminum

or Stainless Steel (optional)

Electronics Cover..................................................Nylon

Cable .........................9-Conductor, 24AWG, 4.8M long

Operating

Internal Relay................................. 1A, 30VAC/30VDC

Min. Power Required............................... 1.5A, 24VDC

Power Usage ..................................................3.0A Max.

200 to 300mA Typical

Maximum Pressure ............................. 10.3bar (150 psi)

Output Signals..............................................Ratiometric

Available Flow Ranges and Accuracy

Body

Size

Range

(LPM)

Range

(GPM)

Flow

Accuracy

(Full Scale)

Reynolds

Number

Deadband

Flow Rate

Deadband

3/8" &

1/2" 1 to 15 .3 to 4 ±1.5% 300 0.1

3/8" &

1/2" 2 to 40 .5 to 10.6 ±1.5% 300 0.1

3/4" &

1" 5 to 100 1.3 to 26.4 ±1.5% 1000 1.0

1" 10 to 200 2.6 to 52.8 ±1.5% 1000 2.0

RoHS Compliant

TracerVMA Interface and Sensor are calibrated as a

matched pair. Separating the pair voids the calibration.

Flow and

Temperature

Sensor

AutoReg Module with 3/8” Delta-Q

(Control Cable disconnected)

TracerVMA User Interface with

1”NPT Flow Body

Tracer®

VMA with AutoReg™Instruction

Power supply other than 24VDC may damage the electronics! Ensure

that power supply provides Earth Ground (0V) and not a reference.

Earth Ground is required for reliable ow and temperature outputs.

“TF” notication appears on the display when Turbulent Flow is likely

inside the cooling circuit of the selected size.

Turbulent ow is the mixing and swirling of water inside a cooling line

that provides optimum heat transfer. Water ow rate greater than the point

of Turbulent Flow provides diminishing benets with increased pumping.

Turbulent ow tracking allows technicians to apply mathematical cool-

ing principles to all machines in a water system. Visit the Technical

Documents section of www.smartow-usa.com for a detailed discussion of

Turbulent Flow.

Input the percentage of glycol (0, 10, 20 or 30% only) in cooling water for

accurate Turbulent Flow Indication (default value is 0). See Setup Mode

option on page 5. Antifreeze compounds of ethylene glycol are sometimes

added to cooling water. Glycol compounds have much higher viscosity

than water. As a result, higher ow rates are required to reach Turbulent Flow

when glycol is used.

Pipe Conguration

For best performance, install a straight run of pipe equal to 10 pipe

diameters on the inlet side of the TracerVMA owmeter and a straight run of

pipe equal to 5 pipe diameters on the outlet side of the owmeter.

Use appropriate pipe sealant to prevent leakage on inlet and outlet sides of

the owmeter.

Power

Attach the power and switching connections to the bare wires of the cable

according to the chart at right. Individual wires are 24AWG stranded

copper. Attach 24VDC power to the unit for correct operation.

In normal operation, the internal relay is energized. If power to the unit is

lost, or if unit is turned o, relay state changes to signal an alarm.

EMI/RFI Interference

Care should be taken to route power and signal cables away from motors

and pumps. Signal integrity may be adversely aected by close proximity

of the wiring to machinery producing high frequency emissions.

BTU Basics

To obtain the most accurate BTU/m calculation, use the

Tracer VMA to measure the supply side water temperature (in °F)

before installing in a cooling water return line.

BTU’s per minute calculation is based on the increase in water temperature

multiplied by the ow rate. The TracerVMA calculates this information

based on supply side temperature entered manually. Due to inherent dier-

ences in most thermometers, the most accurate BTU calculation will result

from using the same thermometer (inside the TracerVMA) to measure supply

and return line temperatures. Record the supply side temperature and enter

it using the “Set BTU/m Input Temperature” instructions on page 5.

Turbulent Flow

Cable

Maximum eective signal cable length is 4.8M (16ft)

as supplied. Splicing extra length to the cable is not

recommended.

Flow and Mounting Direction

Orient the TracerVMA User Interface so the ow

direction of the process uid matches the directional

arrow on the body of the meter. Flow in the opposite

direction of the arrow will yield inaccurate voltage

output. The presence of air bubbles in the process uid

will also create an inaccurate voltage output.

Install AutoReg module downstream from the User

Interface at least 5 pipe diameters from the sensor

outlet. Flow regulator response time will increase in

relation to distance between AutoReg module and

TracerVMA User Interface.

Maintenance Instructions

Copper Plumbing Alert

DO NOT connect an aluminum body owmeter

directly to copper plumbing. Galvanic corrosion is very

likely to occur. Stainless steel body material is strongly

recommended for this application.

9-Conductor Cable Color Chart

Wire Color Function

Black DC Ground (Earth)

(Ground for Analog Output)

Yellow +DC Input (24VDC)

Red not used

Blue not used

Orange Flow Analog Voltage Output (+)

Violet Temp. Analog Voltage Output (+)

Green Relay Common

Brown Relay Normally Open

Gray Relay Normally Closed

Tracer®

VMA with AutoReg™Instruction

Operating Instructions

Modes of Operation

There are three modes of operation for the TracerVMA Flowmeter:

User Mode, Setup Mode and Calibration Mode.

User Mode displays all available process information:

•Flow rate

•Te mp er at u r e

•Reynolds Number

•Turbulent Flow Indication “TF”

•Alarm Indication (when congured in Setup Mode)

•BTU’s per minute (when input temperature is provided in Setup

Mode)

•Total volume (when congured in Setup Mode)

Setup Mode congures the owmeter for:

•Volume totalizer on/o

•Unit selection (English or Metric)

•Switching set points (alarm)

•BTU/m temperature input

•Automatic shut o time

•Pipe diameter (factory set to match body size)

•Glycol scale options (0%, 10%, 20% or 30%)

•Analog Output: Temperature (4.1V, 5V, 10V, o)

•Analog Output: Flow (3.5V, 5V, 10V, o)

•Relay settings (alarm or turbulent ow)

•Flow Rate Setpoint

•Actuator Alarm

•Reynolds Number Setpoint

•Regulation Method (Flow, Reynolds Number, o)

Calibration Mode congures the owmeter for:

•Flow sensor selection

•Temperature and Flow Calibration

•Available Battery Voltage (disregard for TracerVMA User Interface)

•Firmware information and updates

•Factory default settings

Users should not make changes within Calibration Mode.

Accidental loss of factory calibration may occur.

User Mode

Press to enter User Mode. User Mode is display only.

Press r or s buttons to scroll through displays of Flow Rate, Temperature and Reynolds

Number. Totalizer and BTU/m display are available when enabled.

BTU/m is automatically disabled until input temperature is entered within User Mode.

Totalizer function is o when shipped. See Setup Mode instruction to enable and zero Total

Volume display. When totalizer is enabled, total ow volume will be visible on all User Mode

screens. When the display is o, totalizer does not add to the total volume.

Battery Life Indicator in upper right corner of the display may ash on this model but will turn

o automatically. It has no function on this model.

To exit User Mode, press to power down the meter.

Tracer®

VMA with AutoReg™Instruction

Setup Mode

The display must be o to enter Setup Mode. Press and hold s button,

then hold down . “Setup Mode” appears in the upper left corner of

the display. Press r or s buttons to scroll through the list of selectable

options.

Volume Totalizer calculates total ow volume from “on” point. For best

results, disable “Automatic Display Shut-o” (page 5) when using

the Volume Totalizer. Total volume updates only when the display

is on. (Maximum value is approximately 42,949,000 liters or

11,338,000 gallons. Display will reset to zero and restart.)

Press to select. Press r or s to enable or disable then press

to select. If enabled, Press then r or s buttons to

select On, O or Reset. At ON/OFF/RST screen, press r or s to

move through next menu options.

Flow Units select LPM (liters per minute) or GPM (gallons per minute).

Press to change units. Press r or s buttons to select LPM or

GPM unit. Press to select.

Temperature Units select °F or °C.

Press to change units. Press r or s buttons to select °F or °C

unit. Press to select.

Relay Set Point Programming (Alarm)

Note: If no relay switching is desired, set all alarms to “OFF” and set

“Relay Settings” function to “ALARM” (see page 5).

Alarm Temperature High causes relay to change state when the set point

temperature is exceeded.

Press to view or change. Press r or s buttons to select de-

sired high temperature point between 32°F - 248°F (0°C - 120°C).

Press to select. To disable, set temperature setting to “OFF”.

Alarm Temperature Low causes relay to change state when the process

temperature falls below the set point.

Press to view or change. Press r or s buttons to select de-

sired low temperature point between 32°F - 248°F (0°C - 120°C).

Press to select. To disable, set temperature setting to “OFF”.

Alarm Flow High causes relay to change state when the set point ow rate

is exceeded.

Press to view or change. Press r or s buttons to select de-

sired high flow point from 1 - 66 GPM (2 - 250 LPM). Press

to select. To disable, set ow rate setting to “OFF”.

Alarm Flow Low causes relay to change state when the process ow rate

falls below the set point.

Press to view or change. Press r or s buttons to select de-

sired low flow rate from 1 - 66 GPM (2 - 250 LPM). Press to

select. To disable, set flow rate setting to “OFF”.

Setup Mode

VOLUME

TOTALIZER

Setup Mode

FLOW

UNITS

Setup Mode

ALARM

TEMP HIGH

Setup Mode

ALARM

FLOW HIGH

Tracer®

VMA with AutoReg™Instruction

Setup Mode (continued)

Set BTU/m Input Temperature

Press to view or change. Press r or s buttons to select input

temperature point between 40°F - 181°F. Press to select. To

disable, select “OFF”. (For the most accurate calculation, measure

the input temperature using TracerVM owmeter. Then move the

owmeter to the output side of the circuit using the measured

temperature input.)

Automatic Display Shut-o

Press to view or change. Press r or s buttons to select shut-

off time between 15 and 240 seconds, or select “DISABLE” for

continuous display. Press to select.

Pipe Diameter is used to calculate Turbulent Flow.

Press to view or change. Press r or s buttons to select

correct pipe size. This is pre-set at the factory during calibration to

match meter input size. It is not usually necessary to change this.

Press to select.

Percentage of Glycol is used to calculate Turbulent Flow.

Press to view or change. Press r or s buttons to select

appropriate percentage of glycol present in the process water.

Options are: 0%, 10%, 20% and 30%. This is pre-set at the factory

to 0%. Higher ow rate is required to achieve Turbulent Flow

when glycol is present. Press to select.

Analog Temperature Output

Press to view or change. Press r or s buttons to select:

•0.5V - 4.1V (matches TracerVM Base Output)

•5V FS (5Volts Full Scale)

•10V FS (10Volts Full Scale)

•DISABLED

Press to select.

Analog Flow Output

Press to view or change. Press r or s buttons to select:

•0.5V - 3.5V (matches TracerVM Base Output)

•5V FS (5Volts Full Scale)

•10V FS (10Volts Full Scale)

•DISABLED

Press to select.

Relay Settings

Note: If no relay switching is desired, set all Relay Set Point alarms to

“OFF” (see page 3) and set “Relay Settings” function to “ALARM” .

Press to view or change. Press r or s buttons to select:

•TFLOW (change state when Turbulent Flow is not present)

•ALARM (change state using programmed temp. and flow

settings)

Press to select.

Flow Setpoint

Press to view or change. Press r or s buttons to select

desired setpoint within the flow range. Press to select.

Setup Mode

BTU/m

INPUT TEMP

Setup Mode

PIPE

DIAMETER

Setup Mode

GLYCOL

Setup Mode

ANALOG

FLOW

Setup Mode

RELAY

SETTINGS

Tracer®

VMA with AutoReg™Instruction

Actuator Alarm

Press to view or change. Press r or s buttons to select alarm

between 15 and 999 seconds. The actuator Alarm changes relay

state when the regulator is unable to meet the programmed ow

rate or reynolds number. This alarm does not have a “DISABLED”

option. Press to select.

Reynolds Setpoint

Press to view or change. Press r or s buttons to select target

Reynolds Number. Reynolds Number between 4000 and 8000 is

generally assumed to be turbulent. See Value Curve Chart at right.

Press to select.

Note: in the 200LPM range, Reynolds Number should be set

>10,000. Refer to the on-line Scientic Cooling Calculator for

help selecting the appropriate Reynolds Number or Flow Rate:

www.smartow-usa.com/scientic-cooling-calculator/.

Regulation Method

Press to view or change. Regulation Method selects control

of the ow regulator between Flow Rate and Reynolds Number

values as entered in the menu items above (Flow Setpoint and

Reynolds Setpoint). Press r or s buttons to select:

•FLOW

•REYNOLDS

•DISABLED

Press to select.

EXIT/OFF

Press to power down.

Steel Temp, ºF

Unstable

Steel Temp.

Cooling Flow Rate, GPM

0.00 0.50 1.00 1.50

100

105

110

115

120

125

130

Stable &

Efficient

Wasted

Capacity

Reynolds Number

4000 8000

Steel Temperature vs. Coolant Flow

Water 70°F, .44" ID Coolant Circuit

Value Curve

For valuable Mold Cooling Articles and

Turbulent Flow Calculation Tools, visit

the Technical Documents page of the

SMARTFLOW-USA web site:

http://www.smartow-usa.com/

documents.htm

Tracer®

VMA with AutoReg™Instruction

Calibration Mode

Users should not make changes in Calibration Mode

unless directed by Burger & Brown Engineering.

Loss of Factory Calibration May Result.

The display must be o to enter Calibration Mode. Press and hold r

button, then press to enter Calibration Mode. “Calibration Mode”

appears in the upper left corner of the display. Press r or s buttons to

scroll through the list of selectable options.

Flow Sensor

Press r or s buttons to change the value. Press to select.

This value is set at the factory to match ow range of the sensor.

Temperature Calibration

Calibration Value appears in this screen. Do not change it unless

you have calibrated the TracerVM according to the temperature

calibration procedure. Press r or s buttons to change the value.

Press to select.

Flow Calibration

Calibration Value appears in this screen. Do not change it unless

directed by the factory. Press r or s buttons to change the value.

Press to select.

Analog Temperature Calibration

Calibration Value appears in this screen. Do not change it unless

directed by the factory. Press r or s buttons to change the value.

Press to select.

Analog Flow Calibration

Calibration Value appears in this screen. Do not change it unless

directed by the factory. Press r or s buttons to change the value.

Press to select.

Battery

Disregard for this model.

Firmware Info

Press to display program version.

Factory Default

Factory use only.

Factory Default

WARNING! This function returns the meter to factory

settings before calibration. A password is needed to change

this setting, it is not user-serviceable.

EXIT/OFF

Press to power down.

Calibration Mode

FIRMWARE

INFO

Tracer®

VMA with AutoReg™Instruction

Limited Warranty

Seller warrants that this product supplied will conform to the description herein stated and that the product will be of standard quality. This is the sole warranty

made by Seller with respect to this product. Seller expressly disclaims any other express or implied warranties, including, but not limited to, the implied warranty

of merchantability and the implied warranty of tness for a particular purpose. Seller shall not be liable for any cost or damages, whether direct, incidental or

consequential, including, but not limited to, any injury, loss or damage resulting from the use of this product, regardless of whether any claim for such cost or

damages is based on warranty, contract, negligence, tort or strict liability. The sole liability of Seller is limited to repairing or replacing this product. This warranty

shall not apply to any products that have been repaired or altered by anyone other than Seller. The warranty shall not apply to any products subject to misuse due to

common negligence or accident, nor to any products manufactured by Seller which are not installed or operated in accordance with the printed instructions of Seller

or which have been operated beyond the rated capacity of the goods. Seller states that the product’s useful safe life is 5 years. Actual life may vary widely depending

on operating environment such as temperature, pressure, and chemical exposure. Users are cautioned to refer to instructions for operating limits and a partial list of

incompatible chemicals.

Troubleshooting

Display Resolution

ERR Memory Error, Contact the Factory, not user serviceable.

Flow and

Temperature

readings are 0.00

Check cable between sensor and electronics housing is plugged in both

places. Re-seat connections.

Flow and

Temperature

readings are
