SMC Networks HMANT-4 User manual

1
2
Thank you for choosing the SMC EZ ConnectTM Home Antenna.
This EZ Quick Installation Guide provides simple install instructions.
Note: Performance may depend on where you will attach the EZ ConnectTM Home
Antenna. For best results, test both antennas to compare the range and
coverage area.
EZ ConnectTM Home
Antenna Hardware installation
Quick installation Guide
SMCHMANT-4
Take the wireless
device.
Remove either
antenna.
Connect
the SMCHMANT-4.
Installation
is completed.
FOR TECHNICAL SUPPORT, CALL:
From U.S.A. and Canada
(24 hours a day, 7 days a week)
(800) SMC-4-YOU;
Phn: [phone];
Fax: [phone]
From Europe: Contact details can be found
on www.smc-europe.com or www.smc.com.
INTERNET
E-mail addresses:
[email protected]
[e-mail]
World Wide Web:
http://www.smc.com/
http://www.smc-europe.com/
If you are looking for further contact
information, please visit www.smc.com
or www.smc-europe.com.
Model Number: SMCHMANT-4
Driver updates:
http://www.smc.com/index.cfm?action=tech_support_drivers_downloads
Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable.
However, no responsibility is assumed by SMC for its use, nor for any infringements of
patents or other rights of third parties, which may result from its use. No license is
granted by implication or otherwise under any patent or patent rights of SMC.
SMC reserves the right to change specifications at any time without notice.
Copyright© SMC Networks, Inc., 2004. All rights reserved.
SMC is a registered trademark; and EZ ConnectTM is a trademark of SMC Networks, Inc.
Other product and company names are trademarks or registered trademarks of their
respective holders.
3
4

ANTENNA
HOME
4d
Bi Booster Antenna
R
everse SMA Fema
l
e
Connector
Package Contents
Hardware Description
Verify you have the following items included in the EZ Connect™ Home Antenna package.
• 1 EZ ConnectTM Home Antenna.
• 1 EZ Wall Mounting Kit.
•Quick Installation Guide.
Immediately inform your dealer in the event of any incorrect, missing or damaged parts.
If possible, please retain the carton and original packing materials in case there is a need
to return the product.
Please register this product and upgrade the product warranty at the SMC's Web site
www.smc.com or www.smc-europe.com.
Antenna Mounting Options
The EZ ConnectTM Home Antenna is mounted on a support for desktop use or it can be fixed
to the wall if you use the EZ Wall Mounting Kit. With these two mounting options you can
make sure the antenna is placed in an ideal location to maximize the performance.
Using the wall-mount option:
1. Locate a position on the wall where you want to place the antenna. Depending on the
wall you may need to use the plastic anchor that is included in the wall mounting kit.
2. Once you have drilled a hole for the mounting screw, hold the antenna against the wall,
insert the screw in the base of the antenna and tighten the screw to the wall.
The EZ Connect™ Home Antenna line can be used with any 2.4GHz Wireless device with a
SMA antenna connector, such as Barricade™ g Routers and EZ Connect™ Wireless PCI
Adapters. By adding this antenna to your 2.4GHz wireless router or 2.4GHz wireless PCI
adapter you can boost the wireless signal up to 50% and increase the range of your
wireless network.
Disclaimer: Distance thresholds can be drastically reduced by environmental interference.
For questions regarding likely-case wireless ranges, please visit us on the web
at www.smc.com or www.smc-europe.com.
Technical Specifications
Frequency Range: 2400-2500 MHz
Gain: 4dBi
Voltage Standing Wave Ratio (VSWR): 2.0:1 Max
Polarization: Linear Vertical
Horizontal Plane: 360°
Vertical Plane: 40°
Impedance: 50 ohms
Connector: Reverse SMA Plug
Cable Type: ULA-316
Cable Length: 100 cm
Operating Temperature: -10°C to 55°C
Humidity: 95% at 25°C
Weight: 180 g
Dimensions: 145 x 54.5 x 48 mm
