Wireless SMCHMANT-6
EZ Connect™ 2.4 GHz Directional Home Antenna
www.smc.com
The EZ Connect™ 2.4 GHz Directional Home Antenna
(SMCHMANT-6) provides an extended range solution for
your wireless networking hardware. Providing 3x the output
power over standard dipole antennas (2dBi) this new 6dBi
directional antenna will significantly extend your wireless
network coverage area up to 50%. With support for all 2.4
GHz Wi Fi standards, including IEEE 802.11b, 802.11b+, and
the new high speed 802.11g standard – this antenna will work
on any wireless device that has the popular reverse SMA
antenna connector.
The EZ Connect™ 2.4 GHz Directional Home Antenna works
with all Barricade™ g Broadband Routers to boost your high-
speed wireless signal in a specific direction. Supporting a
total plug-and-play installation, this new directional antenna
can be installed in 2 simple steps. Simply remove one of the
default antennas from your Router, Access Point, or PCI card
and connect the new SMCHMANT-6. To optimize your signal,
place or mount this new antenna in a location to maximize
your new boosted wireless signal.
OVERVIEW
FEATURES
Works with 2.4 GHz 802.11 technology to extend your wireless network
Efficient antenna design provides focused wireless signal for direct
impact
Flexible installation options – place on a desktop or mount to a wall
Simple and Quick Installation – connects to any 2.4 GHz device in 3
steps
Higher output power
Antenna Extension Cable – 100cm cable included
BENEFITS
Significantly extends your 802.11b, 802.11b+, or 802.11g wireless net-
work coverage up to 50%.
Directional Antenna design provides a focused wireless signal with 80
degree spread.
Innovative Design with mounting kit included so you can hang this
antenna on a wall or use the stand and place it on your desktop.
No configuration required, works with any 2.4 GHz network device
that has a removable antenna with SMA connector including wireless
Routers, Access Points, and wireless PCI Adapters.
With 6dBi of output power, you can extend your wireless signal into
hard to reach places, such as backyards, other floors and basements.
Provides a 100cm cable so you can connect the antenna to your
Router, Access Point, or Adapter card and still have enough cable
length to place the antenna in an optimized location.

TECHNICAL SPECIFICATIONS SMCHMANT-6
COMPATIBILITY
• 802.11b
• 802.11b+
• 802.11g
• Most 2.4 GHz Wireless Devices with a Detachable Antenna
• Operating System Independent works with any OS.
Frequency Range
• 2400-2500MHz
Gain:
• 6dBi
Voltage Standing Wave Ratio (VSWR)
• 2.0:1 Max
Polarization
• Linear Vertical
Horizontal Plane
• 80°
Vertical Plane
• 80°
Impedance
•50
Connector
• Reverse SMA Plug
Cable Type
• ULA, 100cm
• Extension cable#1 : ULA316, 100cm
• Extension cable connector#1 : RP SMA JACK,RP TNC PLUG
• Extension cable#2: ULA316, 100cm
• Extension cable connector#2 : RP SMA JACK, RP MMCX R/A
PLUG
Cable Length
• 100cm
Operating Temperature
• -10°C to 55°C
Humidity
• 95% at 25°C
Weight
•125g
• 4.40oz
Dimensions:
• 75 x 72 x 12 mm
• 2.95 x 2.83 x .47 in
Warranty
• Limited Lifetime
Tech Support
• Free 24x7 Support via a Toll-free number
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local country contact information
