Wireless SMC8511WG
2.4GHz Outdoor Wireless Cable Extension
www.smc.com
The new SMC8511WG Outdoor Wireless CATV Extension is developed
to enable cable system operators to leverage the latest wireless
technology to extend the reach of their existing DOCSIS
networks and to increase service offerings within their current
infrastructure. This solution allows CATV operators to offer
commercial broadband data service to customers at unwired
premises utilizing standard WiFi CPE equipment.
The SMC8511WG provides cable operators a low-cost alternative
for delivering data service to businesses requesting access to a
high-speed network without a cable drop. The product is
designed for ease and speed of deployment leveraging 802.11b/g
wireless technologies. This is a perfect solution for Cable opera-
tors looking to generate new revenues by offering services in
rural areas or with a wireless hotspot.
SMC8511WG cable extension offers flexible configuration options
to meet specific needs for cable operators. As a point-to-multi-
point system, SMC8511WG is efficient and affordable to small
businesses and corporate applications. As a point-to-point
bridging applications, it is a powerful, dedicated wireless data
link for enterprise network.
The SMC8511WG is a self contained unit with internal DOCSIS
cable modem, Ethernet interface, wireless access point with a
high gain antenna and 60-90 VAC CATV power supply housed in
a weatherproof enclosure. Operating power is supplied from the
CATV plant through a power passing tap or through the Ethernet
connection. SMC8511WG mounts on the strand and is available
with mounting hardware for rooftop or tower or pole installations.
SMC8511WG allows for easy management through HTTP, SNMP,
SSH and Telnet. Web based network management tools make
configuration and remote management of the network simple.
SNMP allows for easy integration into your existing wired net-
work and management infrastructure. SMC8511WG supports the
principal access and security protocols on the DOCSIS network
side (BPI). Wireless security includes enterprise level advanced
authentication and encryption. Security features include 64/128
bit WEP, TKIP and Advanced Encryption Standard (AES), WiFi
Protected Access (WPA) and authentication using 802.11X.
SMC8511WG also supports Wireless Distribution System (WDS).
WDS enables wireless bridging between the SMC8511WG and
other wireless enable CPE's that support WDS.
Combine these features with SMC's service and support, you
have an ideal solution for broadband access.
FEATURES
Complies with DOCSIS 1.0 and 2.0
Enjoy wireless freedom with built in 802.11b/g and support WDS
Firewall Protection
VPN Pass-through via L2TP, PPTP, and IPSec
Built-in 15dBi antenna for increased wireless coverage
BENEFITS
OVERVIEW
Fully interoperable with all DOCSIS cable networks
Wireless support of up to 108Mbps and up to 4 WDS links
Firewall can monitor and analyze all the information entering
your network.
Wireless hotspot users or remote corporate users can have
VPN access to their corporate LANs
Instant wireless access is achieved with the integrated 15dBi
patch panel antenna.

TECHNICAL SPECIFICATIONS SMC8511WG
COMPATIBILITY
• DOCSIS 2.0/Cable Home 1.1 compliant
• 802.11b/g compliant
PORTS
• 1 IEEE 802.11b/g wireless
• Cable Interface F type female 75ohm
• Ethernet Craft Port
CABLE MODEM FEATURES
• DOCSIS 2.0 certified
• 64/256QAM auto detection
• Supports maximum DOCSIS transfer rates
• Independent resets for downstream and upstream blocks
• Quality of Service (QoS) features
• Supports 16 Service Identifiers (SIDs)
• Supports 64/128/256 bit RC4 authentication and encryption
NETWORKING
• IEEE 802.1d compliant bridging
• DHCP Client
• DHCP Server
• SNMP
• DDNS
• DMZ
• Telnet
• SSH
• Radius
• TACACS+
• QoS
• UPnP
WIRELESS
• 802.11b/g compliant
• Data rate up to 108Mbps in 802.11g
• WEP 64/128-bit, WPA-PSK, TKIP, AES
• MAC Filtering
• Disable SSID Broadcast
• 8VPA
SECURITY
• Password protected configuration access
• Stateful Packet Inspection (SPI) Firewall
• Network Address Translation (NAT)
• Application Level Gateways (ALG)
• Intrusion Detection
• Denial of Service (DoS) prevention
• Web based authentication
• Comprehensive Logging
• Remote Admin Access
• NAT 1-1 Mappings
• VPN Pass-through
• IPSec
• PPTP
• L2TP
ENCRYPTION
• 56-bit/128-bit DES
• 64-bit/128/256-bit WEP
CERTIFICATION
• FCC Part 15.247
• FCC Part 15 Class A
SIZE
• 14.5 x 7.5 x 4 in. (W x H x D) - without brackets
• 36.83 x 19 x 10 cm. (W x H x D) - without brackets
WEIGHT
• 20 lbs
• 9 kg
POWER
• CATV 60-90 VAC thru CATV connector or 18-28 VDC
via Ethernet connector
• Consumption: 25 Watts
ANTENNA
• Horizontal BW = 35 degrees
• Vertical BW = 60 degrees
• Polarization = Vertical
• Antenna Gain = 15dBi
• Max Output Power: 4 Watts EIRP
• External: Optional
ENVIRONMENTAL
• Operating Temp: -40 degree to +65 degree C
• Operating Humidity: 5%-95% non-condensing
WARRANTY
• Limited Lifetime
