Key Features and Benefits
Product Overview
SMCFS1601/SMCFS2401
EZ SwitchTM 10/100
16-/24-Port Unmanaged Fast Ethernet Switches
Green Ethernet
Environmentally friendly these switches allow
significant power saving compared to non-
Green switches.
Support for Quality of Service
When the switches receive a frame tagged
with an 802.1p priority tag, they will place it
into a priority queue. Priority queuing is useful
in implementations where time-sensitive data
such as voice and video are streamed across
the network.
Auto MDI/MDI-X on each port
Support from Auto-MDIX means that no
cross-over cables are required. Simply plug
and play.
Metal chassis, fan-less design
The compact, rack mountable metal chassis
is ideal for desktop or rack mounting
applications. In addition, the lack of fans
ensures silent operation.
The EZ Switches 10/100 (SMCFS1601/ SMCFS2401) are unmanaged,
rack-mountable 16-/24-port Fast Ethernet switches for workgroup and
small office environments. All 10BASE-T/ 100BASE-TX ports deliver
dedicated 10/100 Mbps links to each attached LAN segment – all with
conventional cabling and adapters. Auto-negotiation is used to select the
optimal communication mode for each connection, auto-sensing selects
the optimal transmission speed. With store-and-forward switching and flow
control, maximum data integrity is always maintained, even under heavy
loading. Environmentally friendly the switches consume less power than
non-Green Ethernet switches without reducing network performance. Easy
installation and reliability make these plug-and-play switches an ideal
choice for smooth Fast Ethernet integration in workgroup and small office
network environments.

PHYSICAL PORTS
SMCFS1601:
16 x 10/100 Mbps Auto-Negotiation RJ-45 ports
SMCFS2401:
24 x 10/100 Mbps Auto-Negotiation RJ-45 ports
NETWORK INTERFACE
10BASE-T (IEEE 802.3)
100BASE-TX (IEEE 802.3u)
FEATURES
IEEE 802.3x Flow Control
IEEE 802.1p QOS
Auto-MDI/ MDIX
Green Saving
Fan-less design
LEDS
System: Power
Ports: Link/ Activity
SWITCHING DATABASE
SMCFS1601: 8K MAC address entries
SMCFS2401: 8K MAC address entries
BUFFER MEMORY
SMCFS1601: 256 Kbytes/ device
SMCFS2401: 256 Kbytes/ device
SWITCHING CAPACITY
SMCFS1601: 3.2Gbps, non-blocking
SMCFS2401: 4.8Gbps. Non-blocking
INPUT VOLTAGE
100-240V~50/60Hz
FRAME FILTER RATE
10BASE-T: 14881pps/ port
100BASE-TX: 148810pps/ port
FRAME FORWARDING RATE
10BASE-T: 14881pps/ port
100BASE-TX: 148810pps/ port
THROUGHPUT
SMCFS1601: 2.4MPPS
SMCFS2401: 3.6MPPS
DIMENSIONS
294 x 180 x 44 mm (11.6 x 7.1 x 1.7 in)
WEIGHT
SMCFS1601: 1287g (2.83lbs)
SMCFS2401: 1321g (2.91lbs)
Features
Optional Accessories
Contact
ELECTROMAGNETIC COMPATIBILITY
CE Mark
FCC Class A
IMMUNITY
EN55024
IEC61000-4/2/3/4/5/6/8/11
EMISSIONS
FCC Class A, CISPR Class A, EN55022/EN61000-3-2
SAFETY
LVD (EN60950)
TEMPERATURE/ HUMIDITY
Operating Temperature: 0℃~40℃(32℉~104℉)
Operating Humidity:10%~90% non-condensing
Storage Temperature:-40℃~70℃(-40℉~158℉)
Storage Humidity:5%~90% non-condensing
WARRANTY
Please check www.smc.com for the warranty terms in
your country.
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despi
Barcelona, Spain
Check www.smc.com for your local country contact
information
Taiwan
No. 1 Creation Rd, lll,
Science-based Industrial Park,
Hsinchu 30077, Taiwan, R.O.C.
Tel: [phone] Fax: [phone]
Singapore
1 Coleman Street
#07-09, The Adelphi
Singapore 179803
Tel: [phone] Fax: [phone]
Check www.smc-asia.com for your local country contact
information
©2011 SMC Networks. EZ SwitchTM is a trademark of
SMC Networks. Other trademarks or registered
trademarks are the property of their respective owners.
Information is subject to change without notice. All rights
reserved.
