Product Overview
SMCFS8
EZ Switch 10/100
8-port Fast Ethernet Desktop Switch
The EZ Switch™ 10/100 (SMCFS8) is a Fast Ethernet desktop
switch that is easy to install and improves network performance
by offering speeds up to 200Mbps per port. Designed for easy
integration with any home or small office network, the SMCFS8
contains added features like Store-and-Forward Switching and
Flow Control to ensure data delivery and network integrity. The
Green Saving feature automatically powers down ports that are
not in use to help saving on energy costs and to make the
network more eco-friendly.
Key Features and Benefits
Store-and-forward Technology
Flow Control and Store-and-Forward Switching with
wire-speed filtering and forwarding rates
ensure data delivery and network integrity.
Easy-to-read LED Indicators
At-a-glance LED indicators per port simplify network
troubleshooting.
Auto MDI/MDI-X on each port to simplify
integration into a network
The switch automatically detects the cable and port
configuration of the opposite connection. No cross-
over cables required, pure plug-and-play.
Green Saving
Green Saving technology allows home and
business users to save on energy costs, conserve
energy and protect our environment.

Features
PHYSICAL PORTS
8 x 10/100Mbps Nway ports (RJ-45)
DC power socket
COMPATIBILITY
10Base-T (IEEE802.3)
100Base-TX (IEEE802.3u)
Full Duplex Flow Control (IEEE802.3x)
SWITCHING DATABASE
2K MAC address entries
BUFFER MEMORY
768Kb per device
PERFORMANCE
Aggregated Bandwidth: 1.6Gbps
Throughput: 1.2Mpps
FEATURES
Supports NWay protocol for speed (10/100Mbps) and
duplex mode (Half/Full) auto-detection
Wire-speed packet filtering and forwarding rate
Store-and-forward architecture filters fragment & CRC
error packets
Green Saving technology to reduce power consumption
LEDS
System: Power
Port: Link/Activity
POWER REQUIREMENTS
Input : 100~240V, 50/60Hz 0.2A
Output : 5V/600mA
WEIGHT & DIMENSIONS
158g
150 x 80 x 30 mm
EMISSIONS
FCC Class B
CE
VCCI Class B
TEMPERATURE
Operating: 0~400C (32~980F)
WARRANTY
Please check
Contact
North America
20 Mason, Irvine,
CA 92618, U.S.A
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despi
Barcelona, Spain
Check www.smc.com for your local country contact information
©2010 SMC Networks. EZ SwitchTM is a trademark of SMC
Networks. Other trademarks or registered trademarks are the
property of their respective owners. Information is subject to
change without notice. All rights reserved.
www.smc.com for the warranty terms in your
country.
