1 Product Introduction
The SMCSM10-Z works with the Touchscreen. The
device has an optical sensor capable of detecting
smoke particles in the event of fire. It also
contains an integrated heat sensor that is
triggered if a room experiences a sharp rise in
temperature. When triggered, the SMCSM10-Z
emits an audible alarm.
The SMCSM10-Z meets NFPA 72 field sensitivity
testing requirements without the need for
external meters. Built-in drift compensation
allows the SMCSM10-Z to adjust sensitivity
automatically as it becomes dirty over time. The
drift-compensation feature dramatically
increases the time between cleanings, as well as
reducing the chance of a nuisance alarm.
2 Parts List
Your SMCSM10-Z package includes:
(1) SMCSM10-Z Smoke Alarm
(2) CR123A lithium batteries
(1) Mounting plate
(1) Mounting screws and anchors
(1) This User Guide
3 Tools Required
Flat-Tipped Screw Driver
4 Finding a Suitable Location
Review the information in this section to ensure
you get the most out of the SMCSM10-Z. The
information in this User Guide is in accordance
with NFPA 72 and/or CAN/ULC-S529, depending
on country of installation.
Pre-installation Considerations
Install the SMCSM10-Z in accordance with the
National Fire Protection Association’s (NFPA)
Standard 72, Chapters 2 and 8. Depending on the
application, you may need to reference other
chapters of NFPA 72 or NFPA 101.
Choosing an Installation Location
When choosing an installation location, consider:
Use of structure and type of construction
Contents you want to protect and their
burning characteristics
Human occupancy
Total area to be monitored
Ceiling height and surface condition
Air movement and vent locations
Obstructions
Deflections
Recommended Locations
After considering these factors, choose a
location:
Where the temperature range is between 32°
and 104° F (0° and 40° C).
Where the humidity is between 0 and 95%
non-condensing.
Away from ventilation sources that can
prevent smoke from reaching the smoke
alarm.
At least 5 feet (1.5 m) from bathrooms.
When placing the SMCSM10-Z on a ceiling, mount
it in the center of the room or hallway at least 4
inches (10cm) away from any walls or partitions.
SMCSM10-Z Smoke Alarm Guide
Congratulations on purchasing your SMCSM10-Z Smoke Alarm with Heat Detection Sensor.
The SMCSM10-Z Smoke Alarm provides triple protection against fire. It combines a photoelectric smoke detector with an integrated heat detector
that senses both fixed temperature and temperature rate-of-rise within a room. It contains an integrated siren to signal alarms.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 2
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
When mounting the SMCSM10-Z on a wall, place
it so the top is 4 to 12 inches (10 to 31cm) below
the ceiling.
In rooms with sloped, peaked, or gabled ceilings,
place the SMCSM10-Z 3 feet (.9 m) down or away
from the highest point of the ceiling.
If mounting to suspended ceiling tile, secure the
tile with the appropriate fastener to prevent tile
removal.
Smoke alarms are not to be used with alarm
guards unless the combination has been
evaluated and found suitable for that purpose.
Note: A smoke alarm does not provide warnings
for fires resulting from explosions, smoking in bed
or other furniture; ignition of flammable liquids,
vapors and gasses; and children playing with
matches or lighters.
Locations to Avoid
Areas where normal ambient temperature is
less than 32°F (0°C), or exceeds 104°F
(40°C).
Dirty, dusty, insect infested areas.
In or near areas with combustion particles
(kitchens, garages, furnaces, hot-water
heaters, gas space heaters).
On the ceiling in rooms next to kitchens,
where there is no transom between the
kitchen and such rooms.
Damp or humid areas, or near bathrooms
with showers.
Near fresh-air inlets or returns or very drafty
areas.
Near heating/air conditioning vents, fans,
and fresh air intakes, which can drive smoke
away from the smoke alarm.
In dead-air spaces at the top of peaked
ceilings or in corners where walls and ceiling
meet. Dead air can prevent smoke from
reaching a smoke alarm.
Within 10 feet (3 m) of fluorescent light
fixtures.
Not suitable for outdoor use.
WARNING! LIMITATIONS OF SMOKE
DECTECTORS
Wireless smoke alarms are very reliable, but may
not work under all conditions. No fire alarm
product provides total protection of life or
property. Smoke alarms are not a substitute for
life insurance.
Smoke alarms require a source of power to work.
This smoke alarm does not operate and the
alarm will not sound if batteries are dead or not
installed properly.
Alarms may not be heard. A sound sleeper or
someone who has taken drugs or alcohol may not
awaken if Touchscreen or Smoke Alarm is
installed outside a bedroom. Closed or partially
closed doors and distance can block sound. This
product is not designed for the hearing impaired.
Smoke alarms may not always activate and
provide warning early enough. Smoke alarms
only activate when enough smoke reaches the
product’s smoke chamber. If a fire starts in a
chimney, wall, roof, on the other side of closed
doors, or on a different level of the property,
enough smoke may not reach the product for it
to alarm.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 3
All Rights Reserved
I/M SMCSD10-Z rev. 1.0
6/18/13
Smoke alarms are a significant help in reducing
loss, injury and even death. However, no matter
how good a detection device is, nothing works
perfectly under every circumstance and we must
warn you that you cannot expect a smoke alarm
to ensure that you will never suffer any damage
or injury.
Current studies have shown smoke alarms may
not awaken all sleeping individuals. It is the
responsibility of individuals in the household that
are capable of assisting others to provide aid to
those who may not be awakened by the alarm,
or to those who may be incapable of safely
evacuating the area unassisted.
5 Installing / Replacing Battery
The SMCSM10-Z comes with two 3V Lithium
CR123A batteries preinstalled. When you need to
replace them use the following procedure. Use
batteries specified in this document
specifications or as listed on the battery
compartment cover. Use of a different battery
can have a detrimental effect on the alarm
operation. Constant exposures to high or low
humidity can reduce battery life.
A. Remove the SMCSM10-Z from the mounting
base (see “Mounting the Sensor” on page 4).
B. Slide the battery compartment cover away
from the SMCSM10-Z to unsnap it and lift it
off.
C. If you are replacing batteries, remove and
dispose of the batteries appropriately. Wait
30 seconds after removal before continuing
to the next instruction.
D. Observing proper polarity as indicated in the
battery compartment, insert two new 3V
lithium batteries into the SMCSM10-Z battery
compartment and replace the battery
compartment cover.
Note: Use two new batteries when replacing old
batteries. Do not replace with batteries that were
used previously.
E. Reattach the SMCSM10-Z to the mounting
base and test the system.
F. The SMCSM10-Z ships with a dust cover for
protection on construction sites with dusty
environments. If your product is new, remove
the red plastic dust cover from the SMCSM10-
Z.
6 Pairing with Touchscreen
Each SMCSM10-Z is programmed with a unique ID
when manufactured. The unique ID is enrolled
into the Touchscreen at the time of installation,
allowing the SMCSM10-Z to communicate with
that specific Touchscreen.
A. From the Home screen, touch the Settings
widget.
B. When the Keypad screen appears, touch the
numbers to enter your keypad code.
C. When the Settings menu appears, use the
keypad to enter the Installer Code (this code
is the same for all Touchscreen installed by
your company).
D. When the Technician keyboard pad appears,
enter your Technician ID and touch Done.
E. When the Technician Settings menu appears,
select Sensors & Zones > Add a
Sensor/Zone. The Locating Sensors screen
appears.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 4
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
F. Click Next. The system scans the premise for
wireless sensors that can be added, which
must meet the following requirements:
- Not currently paired with another
Touchscreen
- Is active. New sensors must be activated as
follows; Turn the back cover counter-
clockwise to remove. Open the battery
compartment. Removing the battery
activation tab to power on the unit.
- Defaulted if previously paired. To default
the sensor, refer to section 9 defaulting
the alarm.
Follow the system prompts to complete the
add process. Trip the sensor by pressing and
holding down the Test Button on the front
cover of the alarm for 10 seconds.
G. When all the sensors are found and paired,
tap Done. Any located sensors that were not
paired are released by the Touchscreen and
can be added later. The Wireless Sensors
Located screen shows the number of wireless
sensors found and paired.
H. Tap Next. The Configure Wireless Sensors
screen shows icons of the sensors that were
found and paired.
I. Tap Next. The Add Sensor/Zone Modify
screen appears.
J. To modify a field on the Touchscreen, tap
the field. Use the onscreen keyboard to
enter changes. Tap Next to save changes.
K. When all sensors are configured properly, tap
Return to Menu in the Configure Wireless
Sensors screen.
L. If all sensors have not been configured, the
Modify screen appears for each sensor to let
you review its details. Change the details as
needed or tap Next to cycle through all the
sensors. The sensors are marked as
configured.
7 Mounting the Sensor
The following procedure describes how to mount
the SMCSM10-Z. Add the SMCSM10-Z to the
Touchscreen before physically mounting it in the
desired location.
A. Test communications between the
Touchscreen and the SMCSM10-Z before
permanently mounting the SMCSM10-Z as
follows:
- Hold the SMCSM10-Z where you plan to
install it.
- Press the SMCSM10-Z Test button for 10-
to-15 seconds. The SMCSM10-Z sends a
signal to the Touchscreen.
- At the Touchscreen, verify the signal was
received. A message will appear in the
upper right corner of the Touchscreen for
5 seconds. If no signal is received relocate
the SMCSM10-Z and retest.
B. Using two supplied screws and anchors,
mount the base.
C. Attach the SMCSM10-Z to the mounting base
as follows:
- Line up the raised alignment tab on the lip
of the SMCSM10-Z with the arrow on the
mounting base.
- Insert the SMCSM10-Z into the base and
turn clockwise about 15 degrees until it
snaps into place.
Note: The SMCSM10-Z cannot be attached to the
mounting base if no batteries are installed.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 5
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
D. Test communications between the
Touchscreen and SMCSM10-Z again:
- Press the Test button on the alarm for 10-
to-15 seconds. The SMCSM10-Z sends a
signal to the Touchscreen.
- Verify that the signal at the Touchscreen
was received.
E. Test the SMCSM10-Z (see “Testing the
SMCSM10-Z”on page 5).
8 Basic Operation
The SMCSM10-Z is equipped with an intuitive
normal mode.
Normal Mode
In normal operating mode, the Status LED
flashes once every 8 seconds.
In alarm mode, the red Status LED is ON.
In trouble or maintenance mode, the Status
LED is OFF.
In battery replacement mode, the SMCSM10-
Z turns OFF the Status LED and chirps every
45 seconds until the batteries are replaced.
Note: You can view modes from the Touchscreen.
Silence the Alarm
Press the Test button to silence the sounder
during an alarm. After a few minutes, the
sounder and alarm resume if smoke is still
present.
9 Testing the SMCSM10-Z
This section provides general guidelines for
testing the SMCSM10-Z with the Touchscreen. For
detailed instructions on how to put your
Touchscreen into test mode refer to the
Touchscreen documentation.
Using Test Button
A. Press the SMCSM10-Z Test button for 10-to-
15 seconds. The SMCSM10-Z sends a signal to
the Touchscreen.
B. At the Touchscreen, verify the signal was
received. A message will appear in the upper
right corner of the Touchscreen for 5
seconds.
Using Alarm Test Mode
A. Be sure the SMCSM10-Z is operating normally.
B. Set the Touchscreen to sensor test mode to
prevent an alarm signal from being sent to
the central-monitoring station if you have a
monitored system.
- From the Home screen, touch the Settings
widget.
-At the keypad, enter the Customer’s master
keypad code
-At the Settings Menu, touch Security >
Alarm Tests
-Follow the Touchscreen’s provided
directions to place it into Test Mode.
C. To generate a test alarm, press and hold
Test Button for 15 seconds. An alarm
message is sent to the Touchscreen. The
Touchscreen alarm will sound as each sensor
is tested.
D. Once completed, exit Test Mode from the
Touchscreen.
Using Smoke
The SMCSM10-Z can be tested during install or at
any time. It is recommended the SMCSM10-Z be
tested in place annually.
A. Use Smoke! in a Can® and follow the
directions on the can.
B. Hold a smoldering punk or cotton wick close
to the SMCSM10-Z and gently direct the
smoke into the smoke entry openings for 20
seconds or until an alarm is indicated.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 6
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
C. The LED should stay ON, the sounder should
emit a temporal 3 pattern, and an alarm
should be indicated at the Touchscreen.
Extinguish the smoke source after testing.
Wireless Signal Strength Test
Note: This step should only be performed by a
qualified service technician.
A. From the Home screen, touch the Settings
widget.
B. At the keypad, enter the Installer’s keypad
code (not the customer’s Master keypad
code).
C. At the keyboard screen, enter your
Technician Code and touch Done.
D. At the Installer Settings Menu, touch Sensors
& Zones > Sensor Diagnostics
E. At the next screen, choose the security zone
containing the smoke alarm.
F. At the Sensor Diagnostic screen, verify the RF
signal strength and other parameters.
10 Defaulting the Alarm
This step should only be performed by a qualified
service technician.
A. Remove the SMCSM10-Z from the mounting
plate.
B. Remove the two batteries.
C. Remove the smoke alarm’s top cover by
releasing the plastic clips starting with the
one in the battery well.
D. Press the enrollment switch in the RF circuit
inside the SMCSM10-Z and hold until you
replace the batteries.
E. Replace the batteries while still pressing the
enrollment switch then release the switch.
The RF Module LED flashes three times to
signal the SMCSM10-Z is not paired with a
Touchscreen.
F. Reinstall the top cover.
11 Viewing Zone Event History
To view event history:
A. Tap the Security widget on the Home screen.
B. Tap the History tab. The Zone Event History
shows the event history.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 7
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
12 Disabling Zones
The system can bypass a zone, so the zone is not
monitored when the system is armed. This is
useful when a sensor is being repaired. You can
only change the Bypass state of a zone when the
system is disarmed.
The system continues to log the activity of
bypassed zones in the Event History (see
"Viewing Zone Event History" on this page).
To bypass a zone:
A. With the system disarmed, tap the Security
app on the Home screen.
B. Tap the Turn Zone Off button for the smoke
alarm. The Turn Zone Off button changes to
Turn Zone On.
C. When the system is disarmed, the Security
Status header shows that some zones have
been bypassed.
13 Deleting a Sensor
Deleting a sensor from the premise removes it as
a monitored within the customer’s system. This
is not the same as disabling (bypassing) a sensor.
You should delete a sensor only:
If the SMCSM10-Z is being removed from the
premises.
To reset the SMCSM10-Z to factory default
settings by deleting the SMCSM10-Z and
adding it immediately.
To delete a SMCSM10-Z from the system:
A. Contact Customer Care to obtain the Premise
Passphrase for the current customer account.
B. Perform steps 6A through 6D under “Pairing
with Touchscreen” on page 3.
C. At the Technician Settings menu, select
Sensors & Zones > Delete a Sensor/Zone.
The Premise Passphrase keyboard appears.
D. Enter the Premise Passphrase and click
Done. The currently installed
sensors/security zones appear.
E. Tap the zone you want to delete and follow
the instructions on the Touchscreen to delete
the SMCSM10-Z and security zone from the
current system.
14 Maintenance
The SMCSM10-Z is designed for a long service life
of 10-years. Although the Touchscreen might
indicate when to service the SMCSM10-Z, several
checks are recommended.
Annual –Smoke Alarm Test.
Random - visual check for LED flashing every
8 seconds, sensitivity test, and wireless
signal strength.
Touchscreen indications are Trouble, Clean Me,
and Low Battery.
Trouble - SMCSM10-Z has an internal fault
requiring technical service.
Clean Me - the SMCSM10-Z sensitivity is out
of range and requires chamber cleaning. This
can occur due to dust build up or bug
intrusion.
Low Battery - batteries must be replaced for
proper operation.
Smoke Alarm Test
Test the SMCSM10-Z in place annually using
Smoke! in a can®, a canned aerosol simulated
smoke. Follow the directions on the can and in
section 9 of this guide.
Sensitivity Test
The SMCSM10-Z is equipped with an internal
diagnostic checking function. The diagnostic
indication via flashing LED counts and provides
an overall operational status. After the LED
flashes:
If the sensitivity is within limits and all other
tests pass, the SMCSM10-Z enters alarm mode
and resets after 7 seconds.
If the sensitivity is not within limits, or an
unserviceable hardware fault has been
detected, the LED is OFF until the SMCSM10-
Z is serviced.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 8
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
To place the SMCSM10-Z in diagnostic mode:
A. Press the Test Button on the smoke alarm for
5 seconds. When the test starts, the smoke
alarm LED flashes 1 to 9 times.
B. Count the LED flashes and see the table
below to determine the status of the smoke
alarm sensitivity and any action to take.
Flash
Meaning
Steps to Take
1
Unserviceable
hardware
fault
Reset unit and rerun the
sensitivity test. If error persists,
replace smoke alarm.
2 –3
Smoke alarm
is becoming
insensitive
Clean smoke chamber, reset it,
and rerun the sensitivity test. If
error persists, replace smoke
alarm.
4 –7
Smoke alarm
is within
normal
sensitivity
range.
None
8 - 9
Smoke alarm
is becoming
too sensitive.
Verify smoke chamber is
snapped down securely. Clean
smoke alarm and replace the
smoke chamber.
Alarm/Wireless Testing
Follow instructions in section 9 of this guide to
test the communication link between the
SMCSM10-Z and the Touchscreen.
Clean Me
Clean the SMCSM10-Z chamber cover with a dry
or damp (water) cloth as needed to keep it free
from dust and dirt. When necessary, use the
following procedure to clean the interior of the
smoke chamber and replace the smoke chamber.
A. Notify the Central Monitoring Station that the
SMCSM10-Z is being tested. Be sure the
system is in Test mode with the Central
Monitoring Station.
B. Remove the SMCSM10-Z from its mounting
base.
C. Remove batteries.
D. Slide a flat-blade screwdriver in the alarm
cap slot. Gently push the handle down to pry
the cap up and off.
E. Squeeze the smoke chamber where indicated
by the alignment arrows, and pull it up and
away from the SMCSM10-Z and discard. See
the following figure.
F. Blow out or use a soft-bristled brush to
remove dust and dirt from the smoke
chamber base.
G. Line up the new smoke chamber with the
optical base by aligning the arrows on the
smoke chamber to the latches on the optical
base and snap down into place.
H. Replace the alarm cap by lining up the cap
with the smoke alarm.
I. Insert the cap into the smoke alarm and turn
clockwise approximately 15 degrees. The cap
snaps firmly into place when secure.
J. Insert the batteries into the smoke alarm
using the proper polarity, and replace the
battery compartment cover.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 9
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
K. Reattach the SMCSM10-Z to its mounting
base.
L. Test the smoke alarm sensitivity and contact
the Central Monitoring Station to place the
system back online (remove from Test
mode).
M. Verify all auxiliary functions for a complete
test of the system.
Low Battery
Replace the batteries using the directions in
“Installing / Replacing Battery” in section 5.
15 Troubleshooting
The SMCSM10-Z does not power up properly or
reports low battery.
Be sure the batteries are fully seated within
the battery compartment and the polarity is
correct.
Check the battery voltage (3.0 VDC nominal).
Touchscreen does not respond.
Follow the instructions in Section 9 to test
the SMCSM10-Z link with the Touchscreen.
Be sure the SMCSM10-Z is enrolled into the
Touchscreen properly.
Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
Tamper condition does not restore.
Be sure the SMCSM10-Z is installed properly
onto the mounting plate and the mounting
plate has a magnet.
Be sure there are no trouble indications at
the alarm.
Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
If a tamper alarm occurs.
Remove the SMCSM10-Z from its mounting
base and reinstall.
Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
Alarm/open condition does not restore.
Be sure the smoke or heat has cleared at the
SMCSM10-Z.
Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 10
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
16 Specifications
Compatible panel
OpenHomeTM Touchscreen panels
Power
Two CR123 battery
Battery type
3.0 VDC lithium
Panasonic® CR123A, Sanyo®123A, Duracell DL123A
Standby Current
35 A (typically)
Battery Life
5 years (typically)
Sensor
Photoelectric
Sensitivity
2.2% +/- 1.3% / ft.
Drift Compensation Adj.
0.5% / ft. max.
Heat Detection –Fixed
135°F ± 5°F (57.2°C ± 2.8°C)
Heat Rate of Rise
15°F/min>105°F (8.3°C/min>
40.6°C)
Audible Alarm
85 dBa @ 10’ (3M) temporal 3
Low Battery Beep
1 every 45 seconds.
RF Wireless Frequency
2.4 GHz
Weight w/battery
0.20 lbs / 0.09 kg
Dimensions
5.6" x 2.4" (14.2cm x 6.1cm)
Storage temperature
-4 to 140°F (-20 to 60°C)
Operating environment
32 to 104°F (0 to 40°C)
Relative Humidity
0 to 95% non-condensing
Dimensions
5.6" x 2.4" (14.2cm x 6.1cm)

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 11
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/2013
NFPA Guidelines
NFPA 72, 2-1.4.2.1 Total (Complete) Coverage
If required, total coverage shall include all rooms, halls,
storage areas, basements, attics, lofts, spaces above
suspended ceilings, and other subdivisions and accessible
spaces; and the inside of all closets, elevator shafts,
enclosed stairways, dumbwaiter shafts, and chutes.
Inaccessible areas shall not be required to be protected by
alarms. (For exceptions, see NFPA 72.)
NFPA 72, 2-1.4.2.2 Partial Coverage
If required, partial detection systems shall be provided in
all common areas and work spaces, such as corridors,
lobbies, storage rooms, equipment rooms, and other
tenantless spaces in those environments suitable for
proper alarm operation in accordance with this code.
NFPA 72, 2-1.4.2.3 Selective Coverage
Where codes, standards, laws, or authorities having
jurisdiction require the protection of selected areas only,
the specified areas shall be protected in accordance with
this code.
NFPA 72, 2-1.4.2.4 Supplementary (Non required)
Coverage
Where installed, detection that is not required by an
applicable law, code, or standard, whether total
(complete), partial, or selective coverage, shall conform to
the requirements of this code. (For exceptions, refer to
NFPA 72 Chapter 2 Spacing Requirements.)
NFPA 72, 2-1.4.3
Where non-required detection devices are installed for a
specific hazard, additional non-required detection devices
shall not be required to be installed throughout an entire
room or building.
NFPA 72, 2-2 Heat-Sensing Fire Alarms
Heat-sensing fire alarms shall be installed in all areas
where required by the NFPA codes and standards or by
the authority having jurisdiction.
NFPA 72, 8-1.4.1.3.2 Detection in New Apartment
Buildings
Approved, single-station smoke alarms shall be installed in
accordance with 7-6.2.10 of NFPA 101 outside every
sleeping area in the immediate vicinity of the bedrooms
and on all levels of the dwelling unit including basements.
(101: 18-3.4.4.2) (For exceptions, refer to this section of
NFPA 72.)
NFPA 72, 8-1.4.1.4.2 Detection in Existing Apartment
Buildings
Approved, single-station smoke alarms shall be in-stalled
in accordance with 7-6.2.10 of NFPA 101 outside every
sleeping area in the immediate vicinity of the bedrooms
and on all levels of the dwelling unit including basements.
(101: 19-3.4.4.1) (For exceptions, refer to this section of
NFPA 72.)
Regulatory Information
2002/96/EC (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste in
the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new
equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info.
RoHs Directive
2002/95/EC RoHS Compliant. Hereby, SMC Networks declares
that this product does not contain lead, mercury, cadmium,
hexavalent chromium, polybrominated biphenyls (PBB) or
polybrominated depheny ethers (PBDE) in more than the
percentage specified by EU directive 2002/95/EC, except
exemptions stated in EU directive 2002/95/EC annex.
UL Rating
ANSI/UL 268 and CAN/ULC-S529, CSFM
FCC ID: QPY-5XXNTT-Z
IC: 8303B-5XXNTT-Z
The device complies with part 15 of the FCC Rules as well
as Industry Canada Rules and Regulations license-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may
cause undesired operation.
Conformité Réglementaire
Ce dispositif est conforme à la réglementation de la IC et
(Partie 15) de la FCC. Son fonctionnement est soumis à
deux conditions: (1) ce dispositif ne doit pas causer
d’interférences nuisibles, et (2) ce dispositif doit accepter

SMCSM10-Z Smoke Alarm Guide
Copyright ©2013 SMC Networks Page 12
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/2013
toute interférence reçue, y compris les interférences
pouvant entraîner des conditions de fonctionnement
indésirables.
Fire Prevention and Escape
The purpose of an early warning smoke alarm is to sense
the presence of fire in its early stages and sound an alarm
through the Touchscreen giving the occupant(s) time to
exit the premises safely.
Avoid Fire Hazards
No detection device can protect life in all situations.
Therefore, safeguards should be taken to avoid potentially
dangerous situations as follows:
Do not smoke in bed.
Do not leave children home alone.
Never clean with flammable liquids such as gasoline.
Properly store materials. Use general good
housekeeping techniques to keep your home neat
and tidy. A cluttered basement, attic, or other storage
area is an open invitation to fire.
Use combustible materials and electrical appliances
carefully and only for their intended uses. Do not
overload electrical outlets
Do not store explosive and/or fast burning materials in
your home.
Even after proper precautions have been taken, fires
can start. Be prepared.
In Case of Fire
In the event of a fire:
Leave immediately. Don’t stop to pack or search for
valuables.
In heavy smoke, hold your breath and stay low, crawl
if necessary. The clearest air is usually near the floor.
If you have to go through a closed door, carefully feel
the door and door knob to see if undue heat is
present. If they seem cool, brace your foot against the
bottom of the door with your hip against the door and
one hand against the top edge. Open it slightly. If a
rush of hot air is felt, slam the door quickly and latch
it. Unvented fire tends to build up considerable
pressure. Be sure all members of the household
realize and understand this danger.
Use your neighbor’s phone or a street fire alarm box
to call the fire department. The job of extinguishing
the fire should be left to the professionals.
Be Prepared
Practice the following steps to prepare you and your family
in the event of a fire:
Perform fire drills regularly. Use them to assure
recognition of an alarm signal.
Draw a floor plan and show two exits from each room.
It is important that children be instructed carefully,
because they tend to hide in times of crisis.
Establish one meeting place outside the home. Insist
that everyone meet there during an alarm. This will
eliminate the tragedy of someone reentering the
house for a missing member who is actually safe.
If you have children and/or physically challenged
people residing in your household, use window decals
to help emergency personnel identify the sleeping
quarters of these individuals.
WARNING
Smoke alarms CANNOT provide warnings for fires
resulting from explosions, smoking in bed or other
furniture, ignition of flammable liquids, vapors and gases,
children playing with matches or lighters.
