Unmanaged Switch SMC8516T / SMC8524T
EZ SwitchTM 10/100/1000 16/24- Port Unmanaged Gigabit Switches
www.smc.com
SMC introduces the latest gigabit to the desktop
products, EZ Switch 10/100/1000 – 8516T and 8524T.
These switches provide gigabit Ethernet connectivity
from the network backbone all the way to the edge of the
network and to individual desktops.
Up to 10 times the speed of 100Mbit networks, these
switches reduces transfer times of large data files or
bandwidth intensive applications and enhancing overall
network significantly, making these switches worthy
investment in the long run.
The SMC EZ Switches are easy to install and an ideal
solution for network migration, as they are equipped with
10/100/1000 auto-MDIX ports. Not only is each port
tri-speed, all ports can be either connected to a workstation
or another switch. Both SMC8516T/SMC8524T support
up to 9K of jumbo frame, so that all packets and frames
remains in its highest fidelity and heightens the performance
of the switches.
Providing non-blocking wire-speed throughput, the EZ
Switches can handle the growing performance needs in
imaging, animation, CAD, film production and many more
current and emerging application. They deliver scalable
solutions for increased performance and productivity.
FEATURES
Auto MDI/MDI-X on each port to simplify integration
into a network
Support to handle Jumbo Packets up to 9K bytes packet
Complies with the IEEE802.3, IEEE802.3u, and IEEE802.3ab/
Gigabit Ethernet standard
Features Store-and-Forward mode with wire-speed filtering
and forwarding rates
IEEE802.3x compliant full-duplex flow control
Features Store-and-Forward with wirespeed filtering and
forwarding rates to ensure data integrity
Ports can be configured to 10/100Mbps half or full-duplex, or to
1000Mbps full-duplex mode to maintain network stability
Automatic Source Address Learning and Aging to ensure
superior delivery of data.
BENEFITS
OVERVIEW

TECHNICAL SPECIFICATIONS SMC8516T / SMC8524T
PORTS
• 16-port auto-MDIX 10/100/1000Mbps
RJ-45 auto-sensing ports
• 24-port auto-MDIX 10/100/1000Mbps
RJ-45 auto-sensing ports
NETWORK MEDIA
• 10Base-T, UTP/STP category 3 or 5 cable
• 100Base-T, UTP/STP category 3 or 5 cable
• 1000BASE-TX, UTP/STP category 5 cable, 4 pairs
LEDs
• System – Power
• Link/Activity
• 100/1000Mbps
FRAME SIZE
• Jumbo packets up to 9K bytes
DIMENSIONS
• 12.99 x 9.06 x 1.73 in
• 33 x 22.8 x 4.4 cm
WEIGHT
• SMC8516T: 5.05lbs / 2.29kg
• SMC8524T: 5.17lbs / 2.35kg
HUMIDITY
• Operating- 10% to 90%
• Storage- 5% to 90%
TEMPERATURE
• Operating- 320to 1040F / 00C to 400C
• Storage- -400to -940F / - 400C to -700C
WARRANTY
• Limited Lifetime
MAC ADDRESS
•8K
MEMORY BUFFER
• 400Kb
FORWARDING METHOD
• Store and Forward
POWER CONSUMPTION
• SMC8516T: 38 Watts
• SMC8524T: 54 Watts
POWER DISSIPATION
• SMC8516T: 130BTU/hr
• SMC8524T: 154BTU/hr
INPUT POWER REQUIREMENT
• 100-240VAC@50 -60Hz
SAFETY & EMI
• FCC Class A
• CISPR Class A
• EN 61000-3-2/3
•CE
• CSA (UL1950, CSA22.2.950),
TUV/GS (EN60950)
• TUV/GS (EN60950)
STANDARDS
• IEEE802.3
• IEEE802.3u
• IEEE802.3ab
• IEEE802.3x
CERTIFICATION
• CE Mark
IMMUNITY
• IEC 1000-4-2,3,4,6
EMI
• FCC Class B
