OVERVIEW
The SMC6110L2 provides wire speed 10/100 Fast Ethernet switching with features specifically designed for
smaller SMB workgroup environments. The switch has 2 built in Gigabit ports providing enhanced uplink
capabilities. An integrated part of this switch family is the IP Clustering function. The feature allows cus-
tomers to group together up to 32 switches into a single logical group which can be managed using a single
IP address. The switch features advanced Quality of Service features that can reduce the latency of packets
through the network, with specific traffic prioritization improving the delivery of converged data such as
voice and high quality video over IP. Overall this switch is part of flexible switch family which brings PoE and
non-PoE switches to the edge of the network.
www.smc.com
v.1
SMC6110L2
TigerSwitch 10/100 Standalone 8-port 10/100 Managed
Layer 2 Switch with 2 x Gigabit Combo ports
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
LEGEND
G:Ëj
JD:-(('C)
JD:9I)(MGE
JD:E8J'+
9iXeZ_F]]`Z\(
G:Ëj
JD:-(('C)
JD:9I)(MGE
JD:E8J'+
9iXeZ_F]]`Z\)
@ek\ie\k
JD:9I)(MGE
?\X[HlXik\ij
J\im\i J\im\i
APPLICATION DIAGRAM
KEY FEATURES
High port density in a small footprint Supports IP Clustering
Low density fully managed switch with 8 ports 10/100 plus 2
Gigabit combo ports for uplink bandwidth and redundancy
Clustering enables single IP address management for up to 32
devices from the SMC61xxL2 and SMC81xxL2 families
Enables local network management Fanless Design for edge deployment
Software includes LLDP and UPNP enable device discovery
for simple management for edge network systems
Low power consumption and highly integrated solution allows the
device to not need a fan so desktop or rack mount installation is
possible
SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS
JD:/(,'C)
G:ËjG:Ëj G:Ëj
:fi\
JD:-(('C)
JD:-(('C)
JD:-(('C)
Cfn;\ej`kp<[^\Jn`kZ_`e^

PORTS
• 8 10/100BASE-T ports
• 2 Gigabit combo ports (RJ-45/SFP)
NETWORK INTERFACE
• 10/100 BASE-T ports
• 10/100/1000 BASE-T ports
• SFP Transceiver slots supporting SX, LX
and ZX SFP
• Multimode fiber cable; 62.5/125 or
50/125 microns
• Singlemode fiber cable: 9/125 micron
SWITCHING FABRIC
• 6.5Gbps
• 6.1Mpps
BUFFER ARCHITECTURE
• 2Mbits
SWITCHING DATABASE
• 8K MAC address entries
LED
• System: Power, Diag
• Ports: Link/activity
TEMPERATURE
• Operating: 0 to 40 °C/32 to 104 °F
• Storage: -40 to 70 °C/-40 to 158 °F
HUMIDITY
• Operating: 10% to 90% (non-condensing)
WEIGHT
• 1.8 kg
• 3.97 lbs
DIMENSIONS
• 330 x 204 x 43 mm
• 12.99 x 8.03 x 1.73in
AC INPUT
• 100 to 240 V, 50-60 Hz, 0.4A
POWER SUPPLY
• Internal, auto-ranging transformer:
100 to 240 VAC, 50 to 60 Hz
POWER CONSUMPTION
• 13.2 Watts maximum
MAXIMUM CURRENT
• 0.4 A @ 100 VAC
• 0.2 A @ 240 VAC
MTBF
• 8 Years
SWITCH FEATURES
• Spanning Tree Protocol (802.1D, .1w)
• Forwarding Mode
• Store-and-forward
• VLAN Support
• Up to 255 groups; port-based or with
802.1Q
• VLAN tagging, GVRP for automatic VLAN
learning
• 802.1v (Protocol based Vlans)
• Private vlan support
• Quality of Service
• Supports 4 levels of priority with flexible
classification and prioritization
• Per port bandwidth management
• MultiLink Trunking (LACP)
• 8 groups of up to 8 ports
• Port Mirroring
• IEEE 802.1x
• L2/L3/L4 access control lists
• TACACS+ client authentication
• HTTPS and SSL
• SSH for Telnet sessions
• Static port security
• Jumbo Frame support (on gigabit ports)
• Dual firmware images
• Multiple configuration files support
• LLDP
• UPnP
MANAGEMENT FEATURES
• In-Band Management
• Telnet, SLIP, Web-based HTTP, or SNMP
manager
• Out-of-Band Management
• RS-232 DB-9 console port
• Software Loading
• TFTP in-band or Xmodem out-of-band
• MIB Support
• MIB II (RFC 1213), Bridging MIB (RFC 1493),
Ethernet-Like MIB (RFC 2665), Bridge MIB
Extensions (RFC 2764), RMON MIB (RFC
1757), RFC 2737, RFC 2742, RFC 2021, RFC
2863, RFC 2618, SMC’s private MIB
STANDARDS
• IEEE802.3 Ethernet, IEEE802.3u
Fast Ethernet
• IEEE802.1D Spanning Tree Protocol and
traffic priorities
• IEEE802.1p Priority tags
• IEEE802.1Q VLAN
• IEEE802.1ac VLAN tagging
• IEEE802.1ad Link aggregation
control protocol
• IEEE802.1w Rapid Spanning Tree
• IEEE802.1v Protocol Based Vlans
RMON SUPPORT
• Groups 1,2,3, 9 (Statistics, History,
Alarm, Event)
ISO
• IEC8802.3
COMPLIANCES
• CE Mark
EMISSIONS
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• EN 61000-3-2/3
• VCCI Class A
IMMUNITY
• EN 61000-4-2/3/4/5/6/8/11
• MIC Class A
SAFETY
• UL 60950-1 and CSA 60950-1
• IEC 60950-1 and EN 60950-1
WARRANTY
• Limited lifetime
SLIDE-IN TRANSCEIVERS FOR COMBO PORTS
SMC1GSFP-SX
• 1G SX SFP Transciever, 550M, Multimode fiber
SMC1GSFP-LX
• 1G LX SFP Transciever, 10Km,
Singlemode fiber
SMC1GSFP-ZX
• 1G LH SFP Transciever, 70Km
Singlemode fiber
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
©2008, SMC Networks. All rights reserved.
www.smc.com
v.1
TECH SPECS - SMC6110L2
