SMC Networks FH100 Series User manual

1 / 17
FGX-OM-F001-A
PRODUCT NAME
Return Filter
MODEL / Series / Product Number
FH100 Series
FH100 X0 Series

2 / 17
FGX-OM-F001-A
Contents
●Safety Instructions 1
1.How to Order 9
2.Construction and names of individual parts 10
3.Specifications 11
4.Installation and Piping 12
5.Maintenance 13
6.Maintenance parts 14

These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for
(ISO/IEC)*
1)
*1) ISO 4414: Pneumatic fluid power
ISO 4413: Hydraulic fluid power
IEC 60204
requirements) General requirements)
ISO 10218
etc
Caution
Warning
Danger
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
The
expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may beco
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and ma
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2. When the product is to be removed, c
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted,
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, me
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications describ
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for
1)
, and other safety regulations.
*1) ISO 4414: Pneumatic fluid power
ISO 4413: Hydraulic fluid power
IEC 60204
-
1: Safety of machinery
requirements) General requirements)
ISO 10218
-
1992: Manipulating industrial robots
Caution
Warning
Danger
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may beco
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and ma
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2. When the product is to be removed, c
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted,
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, me
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications describ
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
Safety
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for
, and other safety regulations.
*1) ISO 4414: Pneumatic fluid power
--
General rules relating to systems
ISO 4413: Hydraulic fluid power
--
General rules relating to systems
1: Safety of machinery
requirements) General requirements)
1992: Manipulating industrial robots
Caution
Caution
in minor or moderate injury.
Warning
Warning
result in death or serious injury.
Danger
death or serious injury.
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may beco
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and ma
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2. When the product is to be removed, c
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted,
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, me
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications describ
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
Return Filter
Safety
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for
safety and must be followed in addition to International Standards
, and other safety regulations.
General rules relating to systems
General rules relating to systems
1: Safety of machinery
--
Electrical equipment of machines (Part 1: General requirements) General
1992: Manipulating industrial robots
-
Safety
indicates a hazard with a lo
in minor or moderate injury.
Warning
indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
indicates a hazard with a high level of risk which, if not avoided, will resultin
death or serious injury.
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may beco
me unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and ma
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2. When the product is to be removed, c
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted,
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications describ
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
Return Filter
Safety
Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
safety and must be followed in addition to International Standards
General rules relating to systems
General rules relating to systems
Electrical equipment of machines (Part 1: General requirements) General
Safety
indicates a hazard with a lo
in minor or moderate injury.
indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
indicates a hazard with a high level of risk which, if not avoided, will resultin
death or serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
me unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and ma
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications describ
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
Return Filter
Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
safety and must be followed in addition to International Standards
General rules relating to systems
General rules relating to systems
Electrical equipment of machines (Part 1: General requirements) General
indicates a hazard with a lo
w level of risk which, if not avoided, could result
indicates a hazard with a medium level of risk which, if not avoided, could
indicates a hazard with a high level of risk which, if not avoided, will resultin
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
expected performance and safety assurance of the equipment will be the responsibility of the person who
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
me unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and ma
chinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications describ
ed in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
safety and must be followed in addition to International Standards
Electrical equipment of machines (Part 1: General requirements) General
w level of risk which, if not avoided, could result
indicates a hazard with a medium level of risk which, if not avoided, could
indicates a hazard with a high level of risk which, if not avoided, will resultin
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
expected performance and safety assurance of the equipment will be the responsibility of the person who
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
me unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
chinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
ed in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
FGX
Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
safety and must be followed in addition to International Standards
Electrical equipment of machines (Part 1: General requirements) General
w level of risk which, if not avoided, could result
indicates a hazard with a medium level of risk which, if not avoided, could
indicates a hazard with a high level of risk which, if not avoided, will resultin
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
expected performance and safety assurance of the equipment will be the responsibility of the person who
This person should also continuously review all specifications of the product referring to its lates
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
The assembly, operation and maintenance of machines or equipment including our products must be
chinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
ed in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
mechanical protective function, and periodical checks to confirm proper operation.
3
/
FGX
-OM-
F001
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
safety and must be followed in addition to International Standards
Electrical equipment of machines (Part 1: General requirements) General
w level of risk which, if not avoided, could result
indicates a hazard with a medium level of risk which, if not avoided, could
indicates a hazard with a high level of risk which, if not avoided, will resultin
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
expected performance and safety assurance of the equipment will be the responsibility of the person who
This person should also continuously review all specifications of the product referring to its lates
t catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
2. Only personnel with appropriate training should operate machinery and equipment.
The assembly, operation and maintenance of machines or equipment including our products must be
chinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
3. An application which could have negative effects on people, property, or animals requiring special safety
4. Use in an interlock circuit, which requires the provision of double interlock for possible failure by usi
ng a
/
17
F001
-A
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
safety and must be followed in addition to International Standards
Electrical equipment of machines (Part 1: General requirements) General
w level of risk which, if not avoided, could result
indicates a hazard with a medium level of risk which, if not avoided, could
indicates a hazard with a high level of risk which, if not avoided, will resultin
1. The compatibility of the product is the responsibility of the person who designs the equipment or
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
expected performance and safety assurance of the equipment will be the responsibility of the person who
t catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
The assembly, operation and maintenance of machines or equipment including our products must be
chinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
onfirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
dical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
3. An application which could have negative effects on people, property, or animals requiring special safety
ng a

The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries,
or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
『
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or
whichever is first.
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to u
noted in the specified catalog for the particular products.
*2)
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
『
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
2. Check the law for pressure vessels or opera
determine whether or not the product can be used.
3. This product does not correspond to regulations or standards for pressure vessel of any country or
region.
Safety Instructions
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries,
or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or
whichever is first.
*2)
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to u
sing SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
2. Check the law for pressure vessels or opera
determine whether or not the product can be used.
3. This product does not correspond to regulations or standards for pressure vessel of any country or
Safety Instructions
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries,
or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or
*2)
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
sing SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
2. Check the law for pressure vessels or opera
determine whether or not the product can be used.
3. This product does not correspond to regulations or standards for pressure vessel of any country or
Return Filter
Safety Instructions
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries,
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
sing SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
Compliance Requirements
』
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
2. Check the law for pressure vessels or opera
determine whether or not the product can be used.
3. This product does not correspond to regulations or standards for pressure vessel of any country or
Return Filter
Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries,
consult SMC beforehand and exchange specifications
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Read and accept them before using the product.
Limited warranty and Disclaimer
』
1. The warranty period of the product is 1 year in service or
Also, the product may have specified durability, running distance or replacement parts. Please
2. For any failure or damage reported within the warranty
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
sing SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
2. Check the law for pressure vessels or opera
ting fluids specified in each country in advance and
determine whether or not the product can be used.
3. This product does not correspond to regulations or standards for pressure vessel of any country or
Return Filter
Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
consult SMC beforehand and exchange specifications
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
1. The warranty period of the product is 1 year in service or
1.5 years after the product is delivered,
Also, the product may have specified durability, running distance or replacement parts. Please
2. For any failure or damage reported within the warranty
period which is clearly our responsibility,
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
sing SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted
for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
ting fluids specified in each country in advance and
3. This product does not correspond to regulations or standards for pressure vessel of any country or
Safety Instructions
The product herein described is basically provided for peaceful use in manufacturing industries.
consult SMC beforehand and exchange specifications
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
1.5 years after the product is delivered,
Also, the product may have specified durability, running distance or replacement parts. Please
period which is clearly our responsibility,
This limited warranty applies only to our product independently, and not to any other damage
sing SMC products, please read and understand the warranty terms and disclaimers
for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
ting fluids specified in each country in advance and
3. This product does not correspond to regulations or standards for pressure vessel of any country or
FGX
The product herein described is basically provided for peaceful use in manufacturing industries.
consult SMC beforehand and exchange specifications
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
1.5 years after the product is delivered,
Also, the product may have specified durability, running distance or replacement parts. Please
period which is clearly our responsibility,
This limited warranty applies only to our product independently, and not to any other damage
sing SMC products, please read and understand the warranty terms and disclaimers
for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
technology from one country to another are governed by the relevant
security laws and
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
ting fluids specified in each country in advance and
3. This product does not correspond to regulations or standards for pressure vessel of any country or
4
/
FGX
-OM-
F001
The product herein described is basically provided for peaceful use in manufacturing industries.
consult SMC beforehand and exchange specifications
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
1.5 years after the product is delivered,
Also, the product may have specified durability, running distance or replacement parts. Please
period which is clearly our responsibility,
This limited warranty applies only to our product independently, and not to any other damage
sing SMC products, please read and understand the warranty terms and disclaimers
for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due to the deterioration of rubber material are not covered by the limited warranty.
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
security laws and
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.
ting fluids specified in each country in advance and
3. This product does not correspond to regulations or standards for pressure vessel of any country or
/
17
F001
-A
consult SMC beforehand and exchange specifications
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
1.5 years after the product is delivered,
Also, the product may have specified durability, running distance or replacement parts. Please
period which is clearly our responsibility,
This limited warranty applies only to our product independently, and not to any other damage
sing SMC products, please read and understand the warranty terms and disclaimers
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or any other weapon is strictly prohibited. 2. The export of SMC products or
security laws and
regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
ting fluids specified in each country in advance and
3. This product does not correspond to regulations or standards for pressure vessel of any country or

5 / 17
FGX-OM-F001-A
Caution
SMC products are not intended for use as instruments for legal metrology.
For products that SMC manufactures or sells are not measurement instruments that are qualified by pattern
approval tests relating to the measurement laws of each country. Therefore, SMC products cannot be used
for business or certification ordained by the measurement laws of each country.

These safety instructions are intended to prevent hazardous situations and/or
Make sure to follow every instruction since they are for safety.
Caution
Warning
result in death or serious injury.
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
determined by a knowledgeable and experienced
Warning
1. Operating pressure
Do not use the product beyond the operating pressure range.
Do
not use in locations where peak pressure exceeds the operating pressure range due to water
hammer, surge pressure, etc.
2. Operating temperature
Do not use the product beyond the operating temperature range.
Do not use at temperatures at or above the bo
3. Fluid
-
Do not use fluids other those indicated in the drawings and catalog.
-
Do not use the product for toxic, corrosive or flammable fluids.
-
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
-
Never use the product with gases.
-
Do not use any fluid which will cause the seal, O
may deteriorat
4. Operating environment
-
Do not use in operating conditions or environments where changes in color or deterioration of
material due to corrosion occur.
-
Do not use this product in a place where shock or vibrations occur.
-Do no
t use the hydraulic filter outdoors.
Caution
5.
Rated flow rate
-
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
Caution
Check the O
replace it with a new O
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
Return Filter
Be sure to read this before handling the products.
These safety instructions are intended to prevent hazardous situations and/or
Make sure to follow every instruction since they are for safety.
Caution
:
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
minor or moderate injury.
Warning
:
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
determined by a knowledgeable and experienced
Warning
1. Operating pressure
Do not use the product beyond the operating pressure range.
not use in locations where peak pressure exceeds the operating pressure range due to water
hammer, surge pressure, etc.
2. Operating temperature
Do not use the product beyond the operating temperature range.
Do not use at temperatures at or above the bo
Do not use fluids other those indicated in the drawings and catalog.
Do not use the product for toxic, corrosive or flammable fluids.
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
Never use the product with gases.
Do not use any fluid which will cause the seal, O
may deteriorat
e these causing leakage.
4. Operating environment
Do not use in operating conditions or environments where changes in color or deterioration of
material due to corrosion occur.
Do not use this product in a place where shock or vibrations occur.
t use the hydraulic filter outdoors.
Caution
Rated flow rate
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
Caution
Check the O
-
ring of each part when replacing the element. If it
replace it with a new O
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
Return Filter
Be sure to read this before handling the products.
These safety instructions are intended to prevent hazardous situations and/or
Make sure to follow every instruction since they are for safety.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
minor or moderate injury.
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
determined by a knowledgeable and experienced
Warning
1. Operating pressure
Do not use the product beyond the operating pressure range.
not use in locations where peak pressure exceeds the operating pressure range due to water
hammer, surge pressure, etc.
2. Operating temperature
Do not use the product beyond the operating temperature range.
Do not use at temperatures at or above the bo
Do not use fluids other those indicated in the drawings and catalog.
Do not use the product for toxic, corrosive or flammable fluids.
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
Never use the product with gases.
Do not use any fluid which will cause the seal, O
e these causing leakage.
4. Operating environment
Do not use in operating conditions or environments where changes in color or deterioration of
material due to corrosion occur.
Do not use this product in a place where shock or vibrations occur.
t use the hydraulic filter outdoors.
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
ring of each part when replacing the element. If it
replace it with a new O
-ring.
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
Return Filter
/
Be sure to read this before handling the products.
These safety instructions are intended to prevent hazardous situations and/or
Make sure to follow every instruction since they are for safety.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
minor or moderate injury.
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
determined by a knowledgeable and experienced
Range of Operating Conditions
Do not use the product beyond the operating pressure range.
not use in locations where peak pressure exceeds the operating pressure range due to water
hammer, surge pressure, etc.
Do not use the product beyond the operating temperature range.
Do not use at temperatures at or above the bo
Do not use fluids other those indicated in the drawings and catalog.
Do not use the product for toxic, corrosive or flammable fluids.
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
Never use the product with gases.
Do not use any fluid which will cause the seal, O
e these causing leakage.
Do not use in operating conditions or environments where changes in color or deterioration of
material due to corrosion occur.
Do not use this product in a place where shock or vibrations occur.
t use the hydraulic filter outdoors.
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
Replacement of O
ring of each part when replacing the element. If it
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
/
Safety Instructions
Be sure to read this before handling the products.
These safety instructions are intended to prevent hazardous situations and/or
Make sure to follow every instruction since they are for safety.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
Warning indicates a hazard with a medium level of risk which, if not avoided, could
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
determined by a knowledgeable and experienced
Range of Operating Conditions
Do not use the product beyond the operating pressure range.
not use in locations where peak pressure exceeds the operating pressure range due to water
Do not use the product beyond the operating temperature range.
Do not use at temperatures at or above the bo
iling point of the fluid.
Do not use fluids other those indicated in the drawings and catalog.
Do not use the product for toxic, corrosive or flammable fluids.
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
Do not use any fluid which will cause the seal, O
-
ring or element to swell or deteriorate. The fluid
e these causing leakage.
Do not use in operating conditions or environments where changes in color or deterioration of
Do not use this product in a place where shock or vibrations occur.
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
Replacement of O
ring of each part when replacing the element. If it
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
Safety Instructions
Be sure to read this before handling the products.
These safety instructions are intended to prevent hazardous situations and/or
Make sure to follow every instruction since they are for safety.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
Warning indicates a hazard with a medium level of risk which, if not avoided, could
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
designer of the system.
Range of Operating Conditions
Do not use the product beyond the operating pressure range.
not use in locations where peak pressure exceeds the operating pressure range due to water
Do not use the product beyond the operating temperature range.
iling point of the fluid.
Do not use fluids other those indicated in the drawings and catalog.
Do not use the product for toxic, corrosive or flammable fluids.
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
ring or element to swell or deteriorate. The fluid
Do not use in operating conditions or environments where changes in color or deterioration of
Do not use this product in a place where shock or vibrations occur.
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
Replacement of O
-ring
ring of each part when replacing the element. If it
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
Warning indicates a hazard with a medium level of risk which, if not avoided, could
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
designer of the system.
not use in locations where peak pressure exceeds the operating pressure range due to water
Do not use the product beyond the operating temperature range.
iling point of the fluid.
Do not use fluids other those indicated in the drawings and catalog.
Do not use the product for toxic, corrosive or flammable fluids.
。
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
ring or element to swell or deteriorate. The fluid
Do not use in operating conditions or environments where changes in color or deterioration of
Do not use this product in a place where shock or vibrations occur.
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
ring of each part when replacing the element. If it
is swollen or damaged,
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
FGX
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or
equipment damage.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
Warning indicates a hazard with a medium level of risk which, if not avoided, could
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
designer of the system.
not use in locations where peak pressure exceeds the operating pressure range due to water
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
ring or element to swell or deteriorate. The fluid
Do not use in operating conditions or environments where changes in color or deterioration of
Do not use flow rates beyond the rated flow rate indicated in the drawings and catalog.
is swollen or damaged,
Be sure to follow the instructions shown below, considering prevention of damage to the
element, maintaining performance and efficiency of the maintenance check.
6
/
FGX
-OM-
F001
equipment damage.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
Warning indicates a hazard with a medium level of risk which, if not avoided, could
Incorrect handling can result in unexpected accidents. Equipment compatibility should be
not use in locations where peak pressure exceeds the operating pressure range due to water
Do not use fluids which cause corrosion or swelling of the material used for each part of the filter.
ring or element to swell or deteriorate. The fluid
Do not use in operating conditions or environments where changes in color or deterioration of
is swollen or damaged,
Be sure to follow the instructions shown below, considering prevention of damage to the
/
17
F001
-A
equipment damage.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in
Warning indicates a hazard with a medium level of risk which, if not avoided, could

7 / 17
FGX-OM-F001-A
Design and Installation
Caution
【Design】
1. Design the system with operating conditions, including operating pressure, operating temperature,
operating fluid, and operating environment appropriate for safe operation.
2. Install the mist separator and micro-mist separator in a place where pulsation seldom occurs.
3. Prevent back pressure and backflow from occurring.
The element may be damaged by back pressure and backflow.
4. Prevent the propagation of an excess moment load and vibration from the piping side.
5. If a relief function of the hydraulic filter which controls the pressure is not used in the hydraulic
circuit, design a circuit safe for the customer’s system.
6. Provide sufficient space for maintenance.
[Mounting]
1. Mount the product vertically so that the cover faces upwards.
If the product is mounted horizontally, foreign matters will accumulate on the element and the
product will be damaged by the load.
【Piping】
1. Connect it with IN and OUT ports in proper location.
It does not work with the connection reversed.
2. Connect the valves or fittings suited to the operating conditions by checking the size of each
connection port.
During connection work, make sure that powder from the piping screws or seal material does not
get into the interior of the piping.
Prior to operating, flush the piping line and check for abnormalities, such as fluid leakage.
3. Firmly fix the piping to the mounting frame using a saddle, etc., to avoid vibration or force caused
by the weight.
4. During element replacement, it is necessary to release fluid from the vessel.
Be sure to connect the pipe so that fluid releasing work can be absolutely performed.
5. Make sure that air releasing work can be absolutely performed.
If the pump is in a high position, idling sometimes occurs during re-start.
Take measures such as releasing the air in a high position, etc.
[Low temperature operation]
The hydraulic fluid used becomes high viscosity when the temperature is low during the winter, etc.,
and the differential pressure indicator or the switch may activate. If this occurs, wait until the oil
temperature rises by a warm-up operation, and confirm if the differential pressure indicator and switch
can be reset, then start the operation. (20 oC or more is the guide.) In the case of the differential
pressure indication switch, design the system in combination with the temperature sensor, so that the
output signal is not accepted until the oil temperature reaches the set value or more.

8 / 17
FGX-OM-F001-A
Return Filter/Safety Instructions
Be sure to read this before handling the products.
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
Make sure to follow every instruction since they are for safety.
Replacement of element
Caution
1.Timing of element replacement
Replace the element when differential pressure reaches 0.13MPa (red part appears in the view
port of the differential pressure indicator or when the differential pressure indicator switch is
actuated).
If the element is not replaced, the element can be damaged.
2.Cleaning each component
- When replacing the element, make sure to wear protective gloves, protective glasses, etc.
Trapped substances may cause injury.
Fluid, which is stuck to your fingers may make your hand slip and drop the element, etc.
For proper sealing during the replacement of the element, clean off any paint etc which is stuck to
the threads of the O-ring seat surface and the cover connecting part.
3.Temperature
Using this product at a high temperature (40 to 80 oC) may cause burns.
Be sure to confirm that the temperature of the filter surface and operating part is reduced to 40
degrees or less to prevent burns.
4.Drainage discharge
Be sure to exhaust the drainage that has accumulated in the filter when performing maintenance.

9 / 17
FGX-OM-F001-A
1. How to Order
FH100 - 06 - 0 0 0 －P 005
Symbol
Port size
Threaded
connection
06 3/4
08 1
10 1
1
/
4
12 1
1
/
2
16 2
20 2
1
/
2
24 3
Symbol
Differential
pressure indication
0 None
4 Differential
pressure indicator
5 Differential pressure indication
switch
Symbol Relief valve
0 With relief
valve
1 None
Symbol Hydraulic fluid
0 Petroleum
1 Water-glycol,
Emulsion
2 Phosphoric ester
Symbol Element
P Paper
M Micromesh
Symbol
Nominal
filtration
005 5µm
010 10µm
020 20µm
Symbol Nominal
filtration
standard
074 74µm
105 105µm
Non-standard
003 3µm
005 5µm
010 10µm
020 20µm
040 40µm
149 149µm
270 270µm
Table1-1 Port size (Rc)
Table1-2 Differential
pressure indication
Table1-3 Relief valve
Table1-4 Hydraulic fluid
Table1-5 Element
Table1
-
6 Nominal filtration
Note) The paper elements for
water-glycol or emulsion is 10
µm only.
Note) The non-standard
filtration is for micromesh
elements only.
Symbol Made to Order
Nil None (Standard)
X0 Non-standard
filtration equipped
Table1-7 Made to Order

10 / 17
FGX-OM-F001-A
2. Construction and names of individual parts
No.
Description
Part No. Material quantity
(1) Case - See 3.
Specifications 1
(2) Cover - See 3.
Specifications 1
(3) Element Refer to 6. Maintenance parts (1) Replacement Element
See 3.
Specifications 1
(4) Hexagon bolt - Carbon steel 1
(5)
Differential
pressure
indicator
Refer to 6. Maintenance parts (2) Replacement
Differential pressure indicator Aluminum alloy Nylon 1
(6) O-ring Refer to 6. Maintenance parts (3) Replacement O-ring
and seal bracket. See 3. Specifications 1
(7) O-ring Refer to 6. Maintenance parts (3) Replacement O-ring
and seal bracket. See 3. Specifications 1
(8)
Seal washer
Refer to 6. Maintenance parts (3) Replacement O-ring
and seal bracket. See 3. Specifications 1
Figure2-1 Name of individual parts and dimensions
Figure 2-2 (5) Differential pressure indicator
(1)
2)
(3)
(4)
(6)
(7)
(8)
IN OUT
port
DRAIN
【Differential pressure indicator】
1. When the differential pressure increases to
0.13Mpa (guideline for replacement) due to
clogging, a red ring floats and becomes visible in
the view port.
2. Once it is visible, it stays floating even when the
pump is stopped unless it is reset.
【Differential pressure indication switch】
1. When the differential pressure increases to
0.13Mpa (guideline for replacement) due to
clogging, a red ring floats and becomes visible in
the view port. At the same time, the micro switch in
the switch box is actuated.
2. Automatically recovers when the pump stops.
Reset button
View port View port
Width across flats
Blanking cap
Differential
pressure
indicator
Differential
pressure
indication switch
Table2-1 Parts

11 / 17
FGX-OM-F001-A
3. Specifications
Table3-1 Specifications
Item Specifications
Fluid Hydraulic fluid: Oils below are applicable. (Note1)
(Petroleum,Water-glycol, Emulsion,Phosphoric ester)
Applicable model
FH100-06 FH100-08 FH100-10 FH100-12 FH100-16 FH100-20 FH100-24
IN・OUT Port size
(Rc) 3/4B1B1 1/4B1 1/2B2B2 1/2B
3B
Drain port size M16×2
Rated flow
rate
(L/min)
Paper 50 80 120 160 260 450 600
Micromesh 60 100 150 200 300 550 700
Operating pressure 1.0MPa
Operating temperature 80oC
Nominal filtration 1. How to Order Table1-6 reference
Element size ø 64×L96 ø 74×L117 ø 88×L158 ø 119×L208
Number of element 1
Element replacement
differential pressure 0.13MPa
Relief valve open
pressure 0.15MPa (relief valve type)
Differential pressure
resistance 0.6MPa
Weight (kg) 2.5 4.3 6.8 17.5
Material
Case Aluminum casting
Cover Cast iron
O-ring Petroleum, water-glycol fluid or emulsion hydraulic fluid: NBR
Phosphate ester hydraulic oil: FKM
Element Paper: Paper, Epoxy resin, Carbon steel
Micromesh: Stainless steel, rolled steel, Epoxy resin
Seal washer Petroleum, water-glycol fluid or emulsion hydraulic fluid: SUS304,NBR
Phosphate ester hydraulic oil: SUS304,FKM
Surface Treatment Cover: Phosphate conversion coating, baking finish (Metallic blue)
Case: Trivalent chromate, baking finish (Metallic blue)
Micro switch for
differential pressure
switch
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure
indication switch.
Note1. Do not use the product for toxic, corrosive or flammable fluids. Do not use the product with fluid which is harmful
for the filter.

4. Installation and Piping
1)
Installation
-
When installing, allow sufficient space for maintenance.
space)
2)
Piping
-
Check each port size for selecting valves and fittings suitable for operating conditions.
Please check Safety Instruction before use.
3) When the differential pressure indication switch
(See Figure 4
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
specifications of the micro switch inside.
(1)
(2) Remove the cover.
(3) Remove the rubber plug.
(4) Hold the cord using the cable clamp
micro switch.
(5) After wiring, secure the cover by tightening the screws.
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
the element.
(
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
tightening the screw.
(8) The output signal is reset when the operation of the differential pressure indication switch is
stopped, and the inlet and outle
Design an electric circuit with a holding mechanism is necessary.
Figure 4
indication switch
Screw for holding the box position
(
Tightening torque:
4. Installation and Piping
Installation
When installing, allow sufficient space for maintenance.
space)
Piping
Check each port size for selecting valves and fittings suitable for operating conditions.
Please check Safety Instruction before use.
3) When the differential pressure indication switch
(See Figure 4
-
1,Figure 4
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
specifications of the micro switch inside.
Loosen the 4 screws that tighten the cover and remove it.
Loosen the screw for holding the box position.
(2) Remove the cover.
(3) Remove the rubber plug.
(4) Hold the cord using the cable clamp
micro switch.
(5) After wiring, secure the cover by tightening the screws.
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
the element.
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
tightening the screw.
(8) The output signal is reset when the operation of the differential pressure indication switch is
stopped, and the inlet and outle
Design an electric circuit with a holding mechanism is necessary.
Figure 4
-
1 Differential pressure
indication switch
Screw for holding the box position
Tightening torque:
0.315N
View port
4. Installation and Piping
When installing, allow sufficient space for maintenance.
Check each port size for selecting valves and fittings suitable for operating conditions.
Please check Safety Instruction before use.
3) When the differential pressure indication switch
1,Figure 4
-
2)
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
specifications of the micro switch inside.
Loosen the 4 screws that tighten the cover and remove it.
Loosen the screw for holding the box position.
(2) Remove the cover.
(3) Remove the rubber plug.
(4) Hold the cord using the cable clamp
micro switch.
(5) After wiring, secure the cover by tightening the screws.
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
tightening the screw.
(8) The output signal is reset when the operation of the differential pressure indication switch is
stopped, and the inlet and outle
Design an electric circuit with a holding mechanism is necessary.
1 Differential pressure
indication switch
Screw for holding the box position
0.315N
・m)
Cover
View port
4. Installation and Piping
When installing, allow sufficient space for maintenance.
Check each port size for selecting valves and fittings suitable for operating conditions.
Please check Safety Instruction before use.
3) When the differential pressure indication switch
2)
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
specifications of the micro switch inside.
Loosen the 4 screws that tighten the cover and remove it.
Loosen the screw for holding the box position.
(3) Remove the rubber plug.
(4) Hold the cord using the cable clamp
(5) After wiring, secure the cover by tightening the screws.
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
(8) The output signal is reset when the operation of the differential pressure indication switch is
stopped, and the inlet and outle
t pressures of the filter become equal.
Design an electric circuit with a holding mechanism is necessary.
1 Differential pressure
Cover
screw
Rubber plug
(
with grommet)
When installing, allow sufficient space for maintenance.
(Refer to 6. Maintenance parts (5) Maintenance
Check each port size for selecting valves and fittings suitable for operating conditions.
3) When the differential pressure indication switch
is mounted, refer to Steps (1) to (8) below for wiring.
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
specifications of the micro switch inside.
Loosen the 4 screws that tighten the cover and remove it.
Loosen the screw for holding the box position.
(4) Hold the cord using the cable clamp
as in Figure 4
(5) After wiring, secure the cover by tightening the screws.
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
(8) The output signal is reset when the operation of the differential pressure indication switch is
t pressures of the filter become equal.
Design an electric circuit with a holding mechanism is necessary.
Rubber plug
with grommet)
(Refer to 6. Maintenance parts (5) Maintenance
Check each port size for selecting valves and fittings suitable for operating conditions.
is mounted, refer to Steps (1) to (8) below for wiring.
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
Loosen the 4 screws that tighten the cover and remove it.
Loosen the screw for holding the box position.
as in Figure 4
-
2 and solder the cord to the terminal of the
(5) After wiring, secure the cover by tightening the screws.
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
(8) The output signal is reset when the operation of the differential pressure indication switch is
t pressures of the filter become equal.
Design an electric circuit with a holding mechanism is necessary.
Figure 4
indication switch wiring
Micro switch terminal
(prepared by customer)
(Refer to 6. Maintenance parts (5) Maintenance
Check each port size for selecting valves and fittings suitable for operating conditions.
is mounted, refer to Steps (1) to (8) below for wiring.
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
Loosen the 4 screws that tighten the cover and remove it.
2 and solder the cord to the terminal of the
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
(8) The output signal is reset when the operation of the differential pressure indication switch is
t pressures of the filter become equal.
Design an electric circuit with a holding mechanism is necessary.
Figure 4
-2
Differential pressure
indication switch wiring
Micro switch terminal
(prepared by customer)
FGX
(Refer to 6. Maintenance parts (5) Maintenance
is mounted, refer to Steps (1) to (8) below for wiring.
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
2 and solder the cord to the terminal of the
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
(8) The output signal is reset when the operation of the differential pressure indication switch is
t pressures of the filter become equal.
Differential pressure
indication switch wiring
Cable clamp
(prepared by customer)
Micro switch terminal
(prepared by customer)
12
/
FGX
-OM-
F001
(Refer to 6. Maintenance parts (5) Maintenance
is mounted, refer to Steps (1) to (8) below for wiring.
Refer to 6. Maintenance parts (4) Micro switch for Differential pressure indication switch for
2 and solder the cord to the terminal of the
(6) Keep the length of the connected cord so that it does not interfere with the replacement of
7) Adjust the switch box position by pushing from the top. Hold the position of the switch box by
(8) The output signal is reset when the operation of the differential pressure indication switch is
Differential pressure
(prepared by customer)
/
17
F001
-A
is mounted, refer to Steps (1) to (8) below for wiring.
2 and solder the cord to the terminal of the

13 / 17
FGX-OM-F001-A
5. Maintenance
Replace the element when differential pressure reaches 0.13MPa (red part appears in the view port of the
differential pressure indicator or when the differential pressure indicator switch is actuated). Replacement
of element should be performed according to the procedure below.
1) Removal of the bowl
1. Stop operation.
2. Confirm that the pressure of the system in which the filter is installed is zero.
3. Close the valve in order of IN, then, OUT.
4. Hold the width across flats at the bottom of the bowl with a wrench and remove the hexagon socket
head bolt (width across flats 24) of the drain port. Discharge all the fluid in the bowl from the drain
port. (Fluid in the bowl may not be completely discharged if air does not enter the bowl. In this case,
loosen the differential pressure indicator to discharge the fluid)
(5) Hold the cover. Loosen the bowl and remove it. (Fluid in the bowl may not be completely
discharged if air does not enter the bowl. In this case, loosen the differential pressure indicator to
discharge the fluid)
Warning Confirm that the internal pressure of the filter is zero before removing the bowl.
Caution
When using the product at a high temperature, be sure to check that the surface
temperature of the filter container is not more than 40 oC before starting operation in
order to prevent burns.
2) Removal of the element
1. Pull down the element out of the cover, and replace it with a new element.(Refer to 6.
Maintenance parts (1) Replacement Element) Clean the sealing surface for sealing properly.
3) Mounting of element
1. Mount the element by the reversed procedure for the Removal of the element in 2).
4) Mounting of the bowl
1. Check the O-ring of each part. If it is swollen or damaged, replace it with a new O-ring. (Refer to 6.
Maintenance parts (3) Replacement O-ring and seal bracket.
2. Mount the element by the reversed procedure for the Removal of the bowl. Hold the cover and screw
in the bowl to the cover. (Tightening torque: 70N・m)
3. Mount the seal bracket to the hexagon socket head bolt (width across flats 24) of the drain port. Fix
the width across flats (36) at the bottom of the bowl with a wrench and tighten it to the bowl.
(Tightening torque: 20N・m)
5) Restart the operation
1. After the replacement of the element, check the parts are assembled correctly before restarting
operation. In case of fluid leakage, stop the operation immediately. Check the sealing condition
and take corrective actions.

14 / 17
FGX-OM-F001-A
6. Maintenance parts
[1]Replacement Element
Port size
Symbol
Element type Element Size
(mm)
Paper Micromesh
06,08 EP420-□□ EM810-□□ ø64×L95
10,12 EP020-□□ EM910-□□ ø 74×L117
16 EP520-□□ EM020-□□ ø 88×L158
20,24 EP620-□□ EM120-□□ ø 119×L208
Note) Refer to the Figure 2-1 for the assembly position.
How to Order - Element
●Paper element
EP420－□□
●Micro mesh element
EM810－□□
Table6-1 3)
E ement number
Symbol
Nominal filtration
(Note)
005 5µm
010 10µm
020 20µm
Symbol Hydraulic fluid type
[N] Petroleum
W Water-glycol,Emulsion
V Phosphoric ester
Table 6-2 Nominal filtration
Table 6-3 Hydraulic operating fluid type
Note) The paper elements for water-glycol or emulsion is 10 µm only.
Table 6-4 Nominal filtration
Symbol
Nominal
filtration
003 3µm
005 5µm
010 10µm
020 20µm
040 40µm
074 74µm
105 105µm
149 149µm
270 270µm
Hydraulic fluid type (See Table 6-3)
Note) Refer to the Table 6-7 for the product
number of the O-ring for the element.

15 / 17
FGX-OM-F001-A
[2] Replacement Differential pressure indicator
Table 6-5 5. Replacement Differential pressure indicator
Name Hydraulic fluid type
Petroleum Water-glycol, Emulsion Phosphoric ester
Differential pressure indication CB-50H CB-50H-V
Differential pressure indication
switch CB-51H CB-51H-V
Blanking cap AG-12H AG-12H-W AG-12H-V
Note 1) Refer to the Figure 2-1 for the assembly position.
Note2) Tightening torque for cover: 15N・m
(3) Replacement O-ring and seal bracket
Table 6-7 Replacement O-ring and seal bracket
Hydraulic fluid type Port size O-ring for the
cover and bowl (6)
Element
O-ring (7)
Seal bracket
for drain port
(8)
Petroleum
Water-glycol,
Emulsion
(O-ring material:
NBR)
06,08 KA00466
(G90)
KA00800
(P35)
NB00006
10,12 KA00082
(P44)
16 KA00788
(G130)
KA00806
(P50)
20,24
KA00756
(AS568-
259,Hs70)
KA00809
(P85)
Phosphoric ester
(O-ring material:
FKM)
06,08 KA00704
(G90)
KA00721
(4D-P35)
NB00074
10,12 KA00107
(4D-P44)
16 KA00690
(G130)
KA00636
(4D-P50)
20,24
KA00676
(AS568-
259,Hs70)
KA00725
(4D-P85)
Note) Refer to the Figure 2-1 for the assembly position. Value in ( ) indicates nominal value.

16 / 17
FGX-OM-F001-A
[4] Microswitch for Differential Pressure Indication Switch
(1) Contact specifications (4) Electric circuit
(2) Rating (5) Terminal type
(3) Other performance
[5] Maintenance space
Item Specifications
Inrush
current Normally closed Max. 15A
Normally open -
Minimum applicable load DC5V 160mA
Table 6-8 Contact specifications
Rated voltage Resistance load
250 VAC 5A
Table 6-9 Rating
Item Specifications
Insulation resistance 100 MΩor more (Measured by 500 VDC, insulation resistance
tester. )
Contact resistance 30mΩor less
Withstand
voltage
Between terminals with
the same pole
AC1000V 50/60Hz 1min
Between charged metal
part and ground
AC1500V 50/60Hz 1min
Between each terminal
and non-charged metal
part
AC1500V 50/60Hz 1min
Table 6-10 Other specifications
Soldering terminal
(N. C. and N. O. common)
NC
NO
COM
Table 6-11 Maintenance space
Port size Dimension to draw the element Drain flushing dimension
06,08 290mm from the lower end of the bowl 100mm from the lower end
of the bowl
10,12 380mm from the lower end of the bowl
16 430mm from the lower end of the bowl
20,24 540mm from the lower end of the bowl
Precautions
1. Connect desired wiring to the micro switch
indication symbols 1 (COM. ) , 2 (N. C. ) ,and 3 (N.
O. ) . 2. When a protection mechanism is required,
take appropriate considerations on the electric circuit
since the micro switch is a type of non-reset.

17 / 17
FGX-OM-F001-A
