SMC Networks AMK50 Series User manual

Doc. No. AMX-OMZ0095
PRODUCT NAME
Activated Carbon Filter
MODEL / Series / Product Number
AMK50-(F,N)06 ~ (F,N)10(B)(-R,Z)-D
AMK60-(F,N)10(B)(-R,Z)-D

Contents
Page
1. Safety Instructions
2 to 6
2. Application
7
3. Standard specifications
7
4. How to Order
8
5. Construction / Options / Replacement parts
9
6. Bowl assembly specifications
10
6-1. Bowl assembly for AMK50
10
6-2. Bowl assembly for AMK60
10
7. Assembly of Optional parts
11
8. Troubleshooting
12
9. How to Replace the Components
13 to 14
9-1. Bowl assembly Replacement
13
9-2. Element Replacement
14
10. Disassembly Drawing
15
11. Dimensions
16
-1-

Activated Carbon Filter
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition to International Standards
(ISO/IEC)*1) , and other safety regulations.
*1) ISO 4414: Pneumatic fluid power -- General rules relating to systems.
ISO 4413: Hydraulic fluid power -- General rules relating to systems.
IEC 60204-1: Safety of machinery -- Electrical equipment of machines .(Part 1: General requirements)
ISO 10218: Manipulating industrial robots -Safety.
etc.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
The expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is confirmed.
1.The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2.When the product is to be removed, confirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, medical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or
other applications unsuitable for the standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4.Use in an interlock circuit, which requires the provision of double interlock for possible failure by using a
mechanical protective function, and periodical checks to confirm proper operation.
-2-

Activated Carbon Filter
Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1.The warranty period of the product is 1 year in service or 1.5 years after the product is
delivered,whichever is first.2)
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility,
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
2) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum
pad or failure due to the deterioration of rubber material are not covered by the limited
warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by the
relevant security laws and regulation of the countries involved in the transaction. Prior to the
shipment of a SMC product to another country, assure that all local rules governing that export
are known and followed.
Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval tests
relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.
! Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval tests
relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.
-3-

- 4 -
Precautions for Design
Warning
1) Carefully consider the application, required specifications, and operating conditions (pressure, flow
rate, temperature, environment and power supply) in accordance with the latest catalog (SMC
website), making sure not to exceed the specification range.
2) Consult SMC if no leakage is allowed due to the environment, or if the operating fluid is not air.
3) This product cannot be used in the following environments.
- Atmosphere containing corrosive gas, organic solvent, or chemical agent solution is, or a location
where any of these substances is attached.
- Atmosphere containing with sea water or water or containing steam, or a location where any of
these substances is attached.
- Locations subject to direct sunlight (Block direct sunlight to the product to prevent deterioration due
to ultraviolet rays or temperature rise).
- Where the product is exposed to heat sources or in areas that the product is exposed to radiant
heat.
- Where impact or vibration is present.
- In a location with high humidity and a large quantity of dust.
- Outdoor.
- Mounting on vehicle or vessel (The product may be damaged due to excessive vibration).
4) For air blow applications, prevent airborne particles from the operating environment entering into the
compressed air stream, or foreign matter may adhere to the workpiece during the air blow.
5) If the air equipment is mounted on the outlet of the product, particles will be generated from the
equipment and required cleanliness may not be obtained. Instead, install the air equipment at the
inlet.
Caution
1) Applications in which the difference between the inlet and outlet pressure exceeds 0.1MPa must be
avoided. Or the element is broken.
2) The activated carbon filter (AMK series) adsorbs oil vapor contained in the compressed air and
removes the odors derived from it, but does not remove all odors.
Selection
Warning
1) Grease is used on the internal seal. If this is not acceptable, please consult SMC.
2) Select the model so that the maximum discharge value (instantaneous) of the flow rate will not
exceed the rated air capacity. If the flowrate exceeds the maximum air flow capacity, the activated
carbon will not be able to adsorb properly, it may cause deterioration in the performance.
Caution
1) Do not use the product with low air pressure (e.g. for blower). This product is dedicated for
compressed air whose minimum operating pressure is specified depending on the equipment. If the
product is operated at a pressure lower than the minimum operating pressure, it may cause
deterioration in the performance or malfunction.

- 5 -
Installation
Warning
1) Do not drop or apply impact during transportation or installation. It will cause damage to the product
and result in operation failure.
2) Do not install in areas of high humidity or high temperature. Operation outside of the product
specification range may cause damage to the product or operation failure, or shorten the product life.
3) Connect the product ensuring the direction of arrow or "1"(IN) and "2"(OUT) ports for air direction or
an arrow. Incorrect connections may cause malfunction.
4) Install with adequate space for maintenance beneath the product. Refer to [11. Dimensions] (page
16) for necessary space.
Piping
Warning
1) Before piping, perform flushing or cleaning of the piping, etc. to remove any cutting chips, cutting oil,
solid foreign matter, etc. from the piping. Contamination of piping may cause damage or malfunction.
2) When screwing together pipes and fittings, etc., be certain that chips from the pipe threads and
sealant do not get inside the pipe. When a sealant tape is used, leave 1.5 to 2 thread ridges exposed
at the end of the threads.
3) Connect piping/fittings using the recommended torque while holding the female thread side tightly.
Insufficient tightening torque can cause loose piping or sealing failure. Excess tightening torque may
cause damage to threads. If the female side is not held while tightening, excessive force will be
applied to the bracket directly, causing breakage.
Recommended tightening torque (Unit: N m)
Thread size 3/4 1
Torque 28 to 30 36 to 38
4) Before screwing-in an SMC fitting or S coupler, please refer to "Tightening the threaded portion of
the connection thread" section of the Fitting & Tubing Precautions.
5) Do not apply torsion or bending moment other than the weight of the product itself. External piping
needs to be supported separately as it may cause damage. Non-flexible piping like steel tube is
susceptible to excessive moment load or vibration. Insert flexible tubes to prevent this.

- 6 -
Air Source
Warning
1) Use clean air. Do not use compressed air containing chemicals, organic solvent, synthetic oil or
corrosive gas as it may be cause of breakage of components or operation failure.
2) Air containing too much moisture may deteriorate the performance. Install the refrigerated air dryer
or aftercooler before the activated carbon filter.
3) Make sure that the supply pressure is not below the minimum operating pressure. If it is used at the
minimum operating pressure or less, pressure resistance increases, leading to the decrease of
operation life or operation failure.
Caution
1) On the inlet side of the activated carbon filter, install a micro mist separator (AMD series) as a
pre-filter to eliminate oil droplets and oil aerosol.
Maintenance
Warning
1) Release the pressure in the product to the atmosphere when replacing parts or removing piping.
2) Maintenance and checks should be done by following the procedure in the operation manual.
Incorrect handling of the product may cause breakage or operation failure of the equipment or
device.
3) Do not touch the product when operating at high temperature (40 to 60oC). The operators may get
burnt. Be sure to confirm that the temperature of the container or operating part is reduced to 40 oC
or less to prevent burns.
4) Periodically check the bowl internal surface for dirt. If any dirt is observed, clean the bowl interior
with neutral detergent for household used to remove the foreign matters and oil content.
Accumulation of foreign matters and scale causes the performance to drop.
5) Replace the element before 1 year or 2000 operating hours passed from start of use as it may
deteriorate the performance.
The replacement period of the element varies depending on the operating conditions. Even before
the aforementioned replacement period is reached, replace the element if oil smell comes out from
the outlet side.
Caution
1) Check the element periodically and replace it with a new one if necessary. If it is found that outlet
pressure drops or the flow is restricted, check the condition of the element.

2. Application
This product aims at eliminating oil vapor in the air line.
3. Standard specifications
Note 1) Conditions in accordance with below and in addition to the conditions above.
- AMD is mounted on the inlet.
- Flow capacity, inlet pressure, and the amount of oil concentration at the filter inlet are stable.
- New element.
Note 2) Inlet pressure: 0.7 MPa. Flow at 20°C, atmospheric pressure, and 65% of relative humidity.
The compressed air quality class on the inlet side is [1:4:2].
Note 3) Based on ISO8573-1:2010 Compressed air - Part1: Contaminants and purity classes.
-7-
AMK50 AMK60
3/4，1 1
2200L/min(ANR) 3700L/min(ANR)
1.25kg 1.50kg
Stainless steel
Model No.
Port size
Fluid
Ambient and o fluid temperature
Air
-5 to 60
o
C (No freezing)
Max. 0.003mg/m
3
(≒0.0025ppm)
ISO8573-1:2010 [1:4:1]
Outlet side oil concentration
Note1)
Min. operating pressure 0.05MPa
Proof pressure
Max. operating pressure
1.5MPa
1.0MPa
Max. air flow capacity
Note2)
Compressed air purity class
Note3)
Bowl material
Weight

4. How to Order
AMK
- - - D
❶
❷
❸
❹
❺
50 06 B
-8-
Note1) ❹Option and ➎Semi-standard: Select one each for a to c.
Note2) ○: For NPT thread type only.
50 60
Nil ● ●
N● ●
F● ●
06 ●―
10 ● ●
Nil Without mounting option ● ●
B With bracket ● ●
Nil Flow direction: Left to right ● ●
R Flow direction: Right to left ● ●
Nil Pressure unit: MPa Temp. unit:
o
C● ●
Z Pressure unit: psi Temp. unit:
o
F○
Note2)
○
Note2)
❷Thread type
Rc
NPT
G
Symbol Description
❶
Body size
3/4
1
Port size
❸
Mounting
Semi-standard
❺
a
Options
❹
bFlow direction
cPressure unit
Temperature unit

5. Construction / Options / Replacement parts
-9-
Construction / Options / Replacement parts
AMK50 / AMK60
1
2
3
4
Replacement parts
AMK50 AMK60
①
Element AMK54P-060AS AMK64P-060AS
②
Bowl seal
③
Bowl assembly AMK54P-120AS AMK64P-120AS
Note1)
Options
AMK50 AMK60
④
Bracket assembly
Note2)
Note1)
Note2) Assembly of the mounting bracket (2 types) and set screw (2 pcs.).
Refer to the [7. Assembly of Optional parts](P12) for mounting the bracket assembly.
The numbers in the table and construction are consistent with the number in [9. How to Replace the Components]
(P13 and 14) and [10. Disassembly Drawing](P15).
AF54P-070AS
Part No.
Part No.
No. Parts description
No. Parts description
AM54P-160S

6. Bowl assembly specifications
6-1. Bowl assembly for AMK50
Option symbol
Semi-standard
symbol
6-2. Bowl assembly for AMK60
Option symbol
Semi-standard
symbol
-10-
Note1) Part No.③includes Bowl seal ②. Refer to [10. Disassembly Drawing](P15).
Appearance
and
Part No.
Note1) Part No.③includes Bowl seal ②. Refer to [10. Disassembly Drawing ](P15).
－
Appearance
and
Part No.
－
－
－
Semi-standard: "-" (Standard)
Rc
G
NPT
Port thread
type ③Part No.
AMK64P-120AS
Semi-standard: "-" (Standard)
Rc
G
NPT
Port thread
type ③Part No.
AMK54P-120AS

7. Assembly of Optional parts
Bracket
1)
2)
-11-
Mounting of bracket B
Fix the bracket B with the set screw (2 pcs.) included
in the package. Refer to the table below for the
tightening torque.
Insert bracket A from the front side of the product
so that the finger of the bracket A engages with the
groove and the bottom of the body.
Mounting of bracket A
(see drawing on the left)
Product
Bracket A
Bottom
of the body
Groove
Model No. Tools Tightening torque
AMK50
AMK60
Phillips
screwdriver(+) 1.5±0.2 N m
Set screw
(2 pcs.)
Bracket B
Finger

8. Troubleshooting
Refer to [9. How to Replace the Components](P13 and 14) and [10. Disassembly Drawing](P15).
Category Failure
Flow rate
As pressure drop
is large, fluid
does not flow.
1. The filter installed upstream is
clogged.
Replace the element of the filter on the
inlet side. -
Oil is smelled
from the outlet
side.
1. The activated carbon in the element
cannot normally absorb oil.
Replace the element.
P13 to 14
1. From the filter installed on the inlet
side, oil aerosol comes out.
Replace the element of the filter on the
inlet side and the element of the
activated carbon filter.
P13 to 14
2. The level of fluid accumulated in the
drain on the inlet side filter has
reached the bottom of the element
surface or higher.
Discharge the drain accumulated in the
container and wipe off the oil content in
the pipes. Then, replace the element of
the activated carbon filter.
P13 to 14
1. From the filter installed on the inlet
side, particles come out.
Replace the element of the filter on the
inlet side and the element of the
activated carbon filter. P13 to 14
2. The influence of the chemicals,
organic solvent, ozone and others
have deteriorated the activated
carbon filter causing particles to flow
from the outlet side.
Supply clean air.
-
1. Breakage of the bowl seal. Replace the bowl seal.
Apply grease to the bowl seal before
assembling it.
Note1)
P13
2. Bowl is damaged. Replace the bowl assembly. P13
Air leakage
Air leaks
between
the body and
bowl.
Note1) Fluorine grease is recommended when applying additional grease.
-12-
Problem
Possible causes Countermeasure Page for
reference
Performance
Oil aerosol
flows from the
outlet side.
Particles flow
from the outlet
side.

9. How to Replace the Components
！Warning
9-1. Bowl assembly Replacement
Model
No.
Work
classifi
cation
Tools Criteria
1) Remove the bowl assembly from the product.
Remove four mounting screws while supporting the flange
by hand, and lower the flange up to the stopper.
AMK50/AMK60
Hexagon wrench key
(Nominal size: 5)
－
2) Rotate bowl assembly by around 10° in the arrow direction,
then remove the bowl assembly from the body.
－ －
3) Remove the bowl seal and element.
－ －
4) Install the element and bowl seal in the bowl assembly.
－ －
5) Insert the fingers (two locations) of the bowl into the notches
(two locations) of the body by aligning them with each other,
and turn the bowl assembly by around 10° in the arrow
direction. Engage both fingers (two locations) of the bowl
with the body.
－ －
6) Install the flange to the body, temporarily tighten four
mounting screws, and then tighten them diagonally and
evenly to secure the flange.
AMK50/AMK60
Hexagon wrench key
(Nominal size: 5)
Before replacement, make sure that no pressure remains in the equipment.
After replacement, confirm that the product satisfies specific functions and no external leakage occurs before operating it.
Work step
AMK50
AMK60
DisassemblyAssembly
-13-
Tightening torque:
AMK50
AMK60 3.5±0.3N m
Mounting screws
(4 pieces)
Bowl seal
Element
Flange
Stopper
Bowl assembly
Pull downward
10 degrees
Rotation
Body
Assembly 5. Engagement condition of finger part of bowl
Notch groove
(Two locations)
Part A
Align the notch groove with the finger of the bowl (Part A).
Engage the fingers of the bowl with the body (Part A).
Bowl fingers
(Two locations)
Bowl fingers
(Two locations)
10 degrees Rotation

9-2. Element Replacement
Model
No.
Work
classifi
cation
Tools Criteria
Disassembly
1) Remove the bowl assembly by referring to the section [9-1.
Bowl assembly Replacement] (P13).
－ －
Assembly
2) Install the replacing element and bowl seal in the bowl
assembly. Mount the bowl assembly by referring to the
section [9-1. Bowl assembly Replacement] (P13).
－ －
Work step
AMK50
AMK60
-14-
Bowl seal
Element
Bowl assembly

10. Disassembly Drawing
-15-
Body
I N
OUT
AMK50 / AMK60
②Bowl seal
①Element
③Bowl assembly
Mounting screws (4 pieces)

11. Dimensions
-16-
IN OUT
P A B C D G J M N Q R S T U V
AMK50 3/4・1 90 222 32 45 30 45 70 66 40.5 11 13 113 3.2 52.5
AMK60 1 90 299.1 32 45 30 45 70 66 40.5 11 13 113 3.2 52.5
Model
No.
Option specifications
Bracket mount
Standard specifications
(Port size)
Maintenance
space

Revision history
4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN
Tel: + 81 3 5207 8249 Fax: [phone]
URL https://www.smcworld.com
Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
© 2022 SMC Corporation All Rights Reserved
