For Water, Solid/Oil Separation and Deodorization
Height and mass reduced by up to
40
%
New
∗The C type is only suitable for modular connection.
Spacer Note)
Differential pressure switch
Uses the same spacer as the F.R.L. combination AC series.
Possible to make a modular connection with products such as AR series regulator.
AMH + AME
AMH + AME + AMF
Modular connection example
Note) Spacer with bracket cannot be mounted.
Use the attached bracket.
Addition:
5
types
Compact, Lightweight (AME쏔C, AMF쏔C)
Modular connection, Space-saving design, Labor-saving in piping!
AMG쏔C, AFF쏔C, AM쏔C, AMD쏔C
AMH쏔C, AME쏔C, AMF쏔C
Options added AMG쏔C, AFF쏔C, AM쏔C, AMD쏔C
AMH쏔C, AME쏔C, AMF쏔C
1.6 MPa specifications
Fluororubber specifications
With differential pressure
switch
(125 VAC, 30 VDC)
With differential pressure
switch
(30 VDC)
Degreasing wash, white
vaseline specifications
Conventional
Water Separation
Water Separator/AMG
Solid/Oil Separation
Main Line Filter/AFF
Mist Separator/AM
Micro Mist Separator/AMD
Micro Mist Separator with Pre-filter/ AMH
Super Mist Separator/AME
Deodorization
Odor Removal Filter/AMF
Series AM 첸
/AFF
Compressed Air Cleaning Filter Series
141
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD쏔
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 141

Water droplet removalWater droplet removal
Water Separator
Water droplet
separation rate: 99%
Nominal filtration rating: 3 μm
[Filtration efficiency:
99%]
Main Line Filter
Mist Separator
Micro Mist Separator
Nominal filtration rating: 0.3 μm
[Filtration efficiency: 99.9%]
Oil mist density at outlet:
Max. 1.0 mg/m3(ANR)
[≈0.8 ppm]
Nominal filtration rating: 0.01 μm
[Filtration efficiency: 99.9%]
Oil mist density at outlet:
Max. 0.1 mg/m3(ANR)
[≈0.08 ppm]
Large dust particle filtration, Oil droplet separationLarge dust particle filtration, Oil droplet separation
Dust filtration, Oil mist separationDust filtration, Oil mist separation
Dust filtration, Oil mist separationDust filtration, Oil mist separation
Model
AMG
AFF
AM
AMD
300
750
1,500
2,200
3,700
6,000
12,000
300
750
1,500
2,200
3,700
6,000
12,000
22,000
28,000
42,000
300
750
1,500
2,200
3,700
6,000
12,000
200
500
1,000
2,000
3,700
6,000
12,000
8,000
24,000
8,000
24,000
40,000
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
50(2B) flange
80(3B) flange
100(4B) flange
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
50(2B) flange
50(2B), 80(3B), 100(4B) flange
50(2B) flange
50(2B), 80(3B), 100(4B) flange
100(4B), 150(6B) flange
Flow capacity
l/min (ANR)
Max. flow
capacity at
0.7 MPa
inlet pressure
Port size Note
Piping
support
type
Piping
support
type
Free
standing
type
Free
standing
type
Piping
support
type
Piping
support
type
150C
250C
350C
450C
550C
650
850
2C
4C
8C
11C
22C
37B
75B
75A
125A
150A
220A
150C
250C
350C
450C
550C
650
850
150C
250C
350C
450C
550C
650
850
801
901
800
900
1000
AMG150C to 550C
AFF2C to 22C
AM150C to 550C
AMD150C to 550C AMD650 to 1000
AM650/850
AFF75A to 220AAFF37B/75B
AMG650/850
142
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 142

Micro Mist Separator
with Pre-filter
Super Mist Separator
Odor Removal Filter
Built-in 0.3 μm pre-filter
The AM + AMD element have been integrated to
achieve a space-saving design.
Nominal filtration rating: 0.01 μm
[Filtration efficiency: 99.9%]
Oil mist density at outlet:
Max. 0.1 mg/m3(ANR)
[≈0.08 ppm]
Color change indicates when element is saturated.
Nominal filtration rating: 0.01 μm
[Filtration efficiency: 99.9%]
Oil mist density at outlet:
Max. 0.01 mg/m3(ANR)
[≈0.008 ppm]
Cleanliness at outlet:
Not more than 35
particles of size
0.3 μm or larger/10 l
(100 particles or less/ft
3
)
Nominal filtration rating: 0.01 μm
[Filtration efficiency: 99.9%]
Oil mist density at outlet:
Max. 0.004 mg/m3(ANR)
[≈0.0032 ppm]
Dust filtration, Oil mist separationDust filtration, Oil mist separationDust filtration, Oil mist separation
Dust filtration, Oil mist adsorptionDust filtration, Oil mist adsorption
DeodorizationDeodorization
Model
AMH
AME
AMF
200
500
1,000
2,000
3,700
6,000
12,000
200
500
1,000
2,000
3,700
6,000
12,000
200
500
1,000
2,000
3,700
6,000
12,000
8,000
24,000
8,000
24,000
40,000
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
1, 1 1/2
1 1/2, 2
50(2B) flange
50(2B), 80(3B)
100(4B) flange
50(2B) flange
50(2B), 80(3B)
100(4B) flange
100(4B), 150(6B)
flange
Flow capacity
l/min (ANR)
Max. flow
capacity at
0.7 MPa
inlet pressure
Port size Note
Piping
support
type
Piping
support
type
Piping
support
type
Free
standing
type
150C
250C
350C
450C
550C
650
850
150C
250C
350C
450C
550C
650
850
150C
250C
350C
450C
550C
650
850
801
901
800
900
1000
AMH150C to 550C AMH650/850
AME150C to 550C AME650/850
AMF150C to 550C AMF650 to 1000
143
Series AM 쏔 /AFF
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD쏔
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 143

Series AM 쏔 /AFF
Compressed Air Cleaning Filter Series
Series
AMG
Series
—
Nominal
filtration rating
—
Smell
—
Oil mist density
at outlet
99%
Water
removal
rate Page
P.145
쎲Water Separator
Eliminates water droplets in the
compressed air.
Series
AFF
3 μm
(Filtration
efficiency:
99%)
—
—
—
P.153
쎲Main Line Filter
Eliminates impurities such as
oil and foreign matter, etc. in
compressed air.
Series
AM
0.3 μm
(Filtration
efficiency:
99.9%)
1 mg/m3(ANR)
(≈0.8 ppm)
(after oil saturation)
P.161
쎲Mist Separator
Eliminates oil mist in
compressed air or rust sized
0.3 μm or more, and foreign
matter such as carbon.
Series
AMD
0.01 μm
(Filtration
efficiency:
99.9%) 0.1 mg/m3(ANR)
(≈0.08 ppm)
(after oil saturation)
P.169
쎲Micro Mist Separator
Eliminates foreign matter
sized 0.01 μm or more, or oil
particles in an aerosol state.
Series
AMH
0.3 + 0.01 μm
(Filtration
efficiency:
99.9%)
P.179
쎲Micro Mist Separator with
Pre-filter
Oil separator, which incorporates
pre-filter (equivalent to the AM
series) into micro mist separator.
Series
AME
0.01 μm
(Filtration
efficiency:
99.9%)
Reduces
oil smell.
0.01 mg/m3(ANR)
(≈0.008 ppm) P.187
쎲Super Mist Separator
Captures foreign matter sized
0.01 μm or more and adsorbs
oil particles in an aerosol state.
Series
AMF
Deodorizes
oil smell.
0.004 mg/m3 (ANR)
(≈0.0032 ppm) P.195
쎲Odor Removal Filter
Eliminates odor from
compressed air.
∗Applicable only to the AFF37B, 75B, AM쏔650 and 850.
P.210
Special Specifications
Clean Series
Usable inside a clean room.
Cotter-free, Fluorine-free Series
Eliminates the effects on a color CRT by copper ion or
fluoric resin, etc.
P.204
Modular Connection Examples
P.206
How to Order Bowl Assembly
Specific Product Precautions
Discontinued Model and Equivalent Model
P.276
P.216
P.220
Related Products
Auto Drain Valve, Motor Operated Auto Drain, Heavy Duty Auto Drain, Differential Pressure Gauge
P.210
Made to Order
쎲With differential pressure gauge
Possible to control product,s service life
by monitoring the clogged element.
쎲Auto drain type, drain guide
specifications
Drain piping is possible by auto drain type.
쎲With IN-OUT flange
Flange piping connection is possible.
쎲White vaseline specifications∗
Using white vaseline for lubricant.
쎲With differential pressure gauge,
IN-OUT flange
Flange piping connection and clogged
element confirmation are possible.
쎲With differential pressure switch
(with indicator)∗
Allows visual confirmation of differential
pressure which indicates the element life.
The built-in contact enables remote control.
Options
쎲Seal material: Fluororubber 쎲IN-OUT reversal direction 쎲Degreasing wash,
white vaseline
쎲For medium air pressure 쎲Drain guide 1/4 female threaded
쎲With element service indicator
쎲
With differential pressure switch (with indicator)
(125 VAC, 30 VDC) 쎲
With differential pressure switch (with indicator)
(30 VDC)
Water Separator
Deodorizer Solid/Oil Separator
Refer to
“How to
Order” of
respective
models.
144
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 144

Water Separator
Series AMG
Made to Order
(For details, refer to page 210.)
AMG
Symbol
AMG150C to 550C AMG650/850
Can remove water droplets in com-
pressed air. Use this product in
cases where “water must be avoided,
but not so dry as when an air dryer is
used”.
Through the adoption of an element
that is exclusively used for removing
water droplets and the ample hous-
ing interior space, a 99%∗water re-
moval rate∗∗ has been achieved.
Caution
Water separator can remove water droplets, but
it cannot remove moisture.
∗ Condition of inlet air
Pressure: 0.7 MPa
Temperature: 25°C
Relative humidity: 100%
Liquid water content (Water droplet
content): 15 g/m3(ANR)
Compressed air flow: Rated flow of each
model
∗∗ Water removal rate (%) =
Removed water (Water droplet) (g)
Inflowed water (Water droplet) (g)
Caution
Be sure to read before handling.
Refer to front matters 42 and 43 for Safety Instructions and pages 6 to
8 for Air Preparation Equipment Precautions.
Rated flow (l/min (ANR))
Note)
Port size
Mass (kg)
Model
300
AMG150C
750
AMG250C
1500
AMG350C
2200
AMG450C
3700
AMG550C
6000
AMG650
12000
0.38 0.55 0.9 1.4 2.1 4.2 10.5
AMG850
Note) Max. flow at 0.7 MPa.
Max. flow varies depending on the operating pressure. Refer to “Flow Characteristics” (page 148)
and “Maximum Air flow” (page 149).
18,1414,3838,1212,341 34,11,1212 12,
Model
0.05 MPa
1.5 MPa
Fluid
Max. operating pressure
Min. operating pressure∗
Proof pressure
Ambient and fluid temperature
Water removal rate
Element life
Compressed air
1.0 MPa
5 to 60°C
99%
2 years or when pressure drop reached 0.1 MPa
∗With auto drain: 0.1 MPa (N.O. type) or 0.15 MPa (N.C. type)
Specifications
AMG150C AMG250C AMG350C AMG450C AMG550C AMG650 AMG850
AM-BM101 AM-BM102 AM-BM103 AM-BM104 AM-BM105 BM56 BM57
Applicable model
Accessory
Bracket assembly
(with 2 mounting screws)
Modular connection is possible
with AMG150C to 550C.
(For details, refer to page 204.)
x 100
145
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD쏔
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 145

How to Order
AMG150C to 550C
AMG 550C 10
Body size
150C
250C
350C
450C
550C
Options
Symbol F: Rubber material: Fluororubber
Fluororubber is used for the parts
such as O-ring and gasket.
Symbol H: For medium air pressure
(1.6 MPa)
Can be used up to 1.6 MPa at
maximum.
Symbol J: Drain guide 1/4 female threaded
1/4 female threaded
Can be pipied to the
drain exhaust port.
Symbol R: IN-OUT reversal direction
Air flow in the separator is changed to
right to left.
(Air flow direction of the standard: Left
to right.)
Symbol V: Degreasing wash,
white vaseline
Body/housing is degreasing washed. The
lubrication grease for O-ring and gasket is
changed to white vaseline.
∗3 Refer to “Auto Drain Specifications/
Option Combinations”.
Auto drain ∗3
C
D
Drain cock (Without auto drain)
N.C. auto drain
N.O. auto drain
Symbol
Nil
Description
Thread type
F
N
Rc
G∗1
NPT
Symbol
Nil
Type
∗1 Conforms to
ISO1179-1.
Port size
01
02
03
04
06
10
Symbol
1/8
1/4
3/8
1/2
3/4
1
Size 150C
Applicable body size
250C 350C 450C 550C
X15
X26
—
With IN-OUT flange
N.C., N.O. auto drain, drain piping type
Symbol
Nil
Description Page for details
—
P.212
P.213
Made to Order
(“How to Order” and the applicable models are different from those
shown on this page. Be sure to refer to “Made to Order”.)
Option ∗3
F
H
J
R
V
Rubber material: Fluororubber
For medium air pressure (1.6 MPa)
Drain guide 1/4 female threaded ∗4
IN-OUT reversal direction
Degreasing wash,∗5white vaseline
Symbol
Nil
Description
—
∗4 Drain piping and piping for a stop valve such
as ball valve are required.
∗5 Only body/housing is degreasing washed.
C
D
J
Symbol
Auto drain specifications
Nil
F H R V
Auto Drain Specifications/Option Combinations
Accessory
Description
—
Bracket ∗2
Symbol
B
Nil
∗2 Bracket is included,
(but not assembled). : Available
: Plural options cannot be selected.
(i.e. Combinations such as C-FV, D-FHV are not possible.)
: Not available
146
Series AMG
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 146

How to Order
AMG650/850
AMG 650 10
10
14
20
Port size
1
112
2
650 850
Symbol Size
Applicable body size
Nil
Thread type
F
N
Rc
G
NPT
Symbol Type
Description
—
With IN-OUT flange
N.C., N.O. auto drain, drain piping type
White vaseline
Page for details
—
P.212
P.213
P.213
X15
X26
X12
Symbol
Nil
Made to Order
(“How to Order” and the applicable models are different from those
shown on this page. Be sure to refer to “Made to Order”.)
Auto drain ∗2
D
∗2 Refer to “Auto Drain Specifications/Option
Combinations”.
∗3 Body size 850 is equipped with a ball valve
(Rc 3/8 female threaded). Mount a piping
adapter IDF-AP609 (page 205) to the ball valve
if NPT 3/8 female threaded is required.
Description
Drain cock (Without auto drain) ∗3
N.O. auto drain
Symbol
Nil
Body size
650
850
Auto drain specifications/Option
Auto drain specifications
Option
Auto drain specifications Option
D
J
R
DJR
Applicable model
AMG650 AMG850
N.O. auto drain
Drain guide 14
IN-OUT reversal
direction
Auto Drain Specifications/Option Combinations
Note) Refer to “How to Order Bowl Assembly” on page 206.
Accessory
Description
—
Bracket ∗1
Symbol
B
Nil
∗1 Bracket is included,
(but not assembled).
Option ∗2
JDrain guide female threaded ∗4
IN-OUT reversal direction
R
Description
—
Symbol
Nil
∗4 Drain piping and piping for a stop valve such
as ball valve are required.
Note) Element service indicator (symbol: T) is not
available as an option because water
deposits inside the indicator could lead to
malfunctions.
: Available : Not available
14
147
Water Separator Series AMG
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD쏔
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 147

AMG250C AMG550C
AMG350C AMG650
Note) Compressed air over max. flow line in the table below may not meet the specifications of the product.
It may cause damage to the element.
AMG150C AMG450C AMG850
Flow Characteristics
Pressure drop (MPa)
Pressure drop (MPa)
Pressure drop (MPa)
Pressure drop (MPa) Pressure drop (MPa)
Pressure drop (MPa)Pressure drop (MPa)
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Series AMG
Air flow rate (l/min (ANR)) Air flow rate (l/min (ANR))
Air flow rate (l/min (ANR)) Air flow rate (l/min (ANR))
Air flow rate (l/min (ANR)) Air flow rate (l/min (ANR))
Air flow rate (m3/min (ANR))
148
Series AMG
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 148

Construction
AMG150C to 550C, AMG650 AMG850
OUT OUT IN IN
q
r
w
e
Note) Refer to “How to Order Bowl Assembly” on page 206.
Note) Sight glass is indicated in the figure for easy understanding
of component parts. However, it differs from the actual
construction. Refer to dimensions on pages 150 to 152 for
details.
Maximum Air Flow Model Selection
No.
4
Description Applicable
model
Except option F
For option F
Material
Resin,
others
Element
assembly
AMG150C
AMG-EL150
AMG-EL150-F
AMG250C
AMG-EL250
AMG-EL250-F
AMG350C
AMG-EL350
AMG-EL350-F
AMG450C
Model
AMG-EL450
AMG-EL450-F
AMG550C
AMG-EL550
AMG-EL550-F
AMG650
AMG-EL650
—
AMG850
AMG-EL850
—
∗Element assembly: With gasket (1 pc.) and O-ring (1 pc.)
∗Refer to back page 219 for replacement of auto drain.
∗Element assemblies for Made to Order (X12, X15, X20, X26) are same as those for standard (see the above table).
Replacement Parts
Select a model in accordance with the following procedure taking the
inlet pressure and the max. air flow rate into consideration.
(Example) Inlet pressure: 0.6 MPa
Max. air flow rate: 5 m3/min (ANR)
1. Obtain the intersecting point A of inlet pressure and max. air flow
rate in the graph.
2. The AMG650 is obtained when the max. flow line is above the in-
terecting point A in the graph.
No.
2
3
1
Description Material Note
Aluminum die-casted∗
Aluminum die-casted
Tempered glass
Chrome treated
Epoxy coating on
inner surface
—
Housing
Body
Sight glass
Component Parts
∗The AMG850 is aluminum casted.
Note) Make sure to select a model that has the max. flow line above
the obtained intersecting point. With a model that has the max.
flow line below the obtained intersecting point, the flow rate will
be exceeded, thus leading to a problem such as being unable to
satisfy the specifications.
Max. air flow rate (m3/min (ANR))
Inlet pressure (MPa)
149
Water Separator Series AMG
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD쏔
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 149

Dimensions
M
øV
Drain
IN OUT
(Accessory)
Bracket
G
U
D
I
L
T
K
J
C
H
Maintenance
space
R
S
P
Q
O
F
M5
A
EB
N
ø10 One-touch fitting
34
Drain cock
Gray: N.C.
Black: N.O.
20
1/4 female threaded
20
1/4 female threaded
AMG150C to 550C
(mm)
AMG150C
AMG250C
AMG350C
AMG450C
AMG550C
A
Model Port size Bracket related dimensions
158
172
204
225
259
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
B
10
14
18
20
24
C
99
113
145
166
200
D
63
76
90
106
122
E
20
20
20
20
20
F
63
76
90
106
122
G
10
10
10
10
15
H
173
190
222
246
278
I
56
66
80
90
100
J
20
24
28
31
33
K
5
8
8
10
10
T
6
6
7
9
9
U
6
6
7
9
9
L
12
12
14
18
18
M
6
6
7
9
9
V
10
10
12
15
15
N
35
40
50
55
65
O
54
66
80
88
102
P
70
80
95
111
126
Q
26
28
34
50
60
R
4.5
5
5
9
10
S
1.6
2
2.3
3.2
3.2
Auto drain
C: With auto drain (N.C.)
D: With auto drain (N.O.)
Option
J: Drain guide 1/4 female threaded
Combination of D: With auto drain (N.O.)
and H: For medium air pressure
150
Series AMG
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 150

180
76
4.5
12
136 160
160
150
20
11
15
40
253
334
10
85
32
311
20
Maintenance
space
Drain M5
(Accessory)
Bracket
IN OUT
Auto drain
D: With auto drain (N.O.)
Option
J: Drain guide 1/4 female threaded
AMG650
20
1/4 female threaded
34
Drain cock: Black
ø10 One-touch fitting
Dimensions
151
Water Separator Series AMG
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD쏔
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 151

220
110
6
18
184
220
220
180
120
13
15
30
348
464
10
42
461
58
Rc 3/8 female threaded
24
Maintenance
space
Drain
IN OUT
(Accessory)
Bracket
Auto drain
D: With auto drain (N.O.)
for AMG850
AMG850
23
3/8 female threaded
Dimensions
152
Series AMG
P0141-P0220-E.qxd 08.11.6 1:48 PM Page 152

Main Line Filter
Series AFF
AFF
JIS Symbol
Model Selection Maximum Air Flow
Max. flow line
Can remove impurities such as oil,
water and foreign matter in com-
pressed air and can improve the
function of a dryer in the down-
stream, extend the life of precision
filter, and prevent trouble with the
equipment.
Select a model in accordance with the
following procedure taking the inlet pressure
and the max. air flow rate into consideration.
(Example) Inlet pressure: 0.6 MPa
Max. air flow rate: 5 m3/min
(ANR)
1. Obtain the intersecting point A of inlet
pressure and max. air flow rate in the
graph.
2. The AFF37B is obtained when the max.
flow line is above the intersecting point A
in the graph.
AFF75A AFF125A
AD402-03-2
G46-15-02
AI-2S
50(2B)JIS 10K FF flange 80(3B)JIS 10K FF flange 100(4B)JIS 10K FF flange
AFF150A AFF220A
Applicable model
Auto drain (2 pcs. each)
Pressure gauge (2 pcs. each)
Companion flange (2 pcs. each)
Anchor bolt (3 pcs. each)
Accessory/For AFF75A to 220A
AFF2C AFF4C AFF8C AFF11C AFF22C AFF37B AFF75B
AM-BM101 AM-BM102 AM-BM103 AM-BM104 AM-BM105 BM56 BM57
Applicable model
Accessory/For AFF2C to 22C, AFF37B/75B
Bracket assembly
(with 2 mounting screws)
Rated flow
(l/min (ANR))
Port size
Mass (kg)
Model
300
AFF2C AFF4C AFF8C AFF11C AFF22C AFF37B AFF75B AFF75A AFF125A AFF150A AFF220A
0.38
Note) Max. flow at 0.7 MPa.
Max. flow varies depending on the operating pressure.
Refer to “Flow Characteristics” (page 156) and “Maximum Air Flow” below.
18,14
750
0.55
14,38
1500
0.9
38,12
2200
1.4
1
12,34
3700
2.1
34,2112,
11, 12
6000
4.2
12000
10.5
12000
50
50(2B) 80(3B) 100(4B) 100(4B)
22000 28000 42000
52 72 87
Note)
Model
JIS 10K FF flange
0.05 MPa
1.5 MPa
Fluid
Max. operating pressure
Min. operating pressure∗
Proof pressure
Ambient and fluid temperature
Nominal filtration rating
Element life
Compressed air
1.0 MPa
5 to 60°C
3 μm (Filtration efficiency: 99%)
2 years (1 year for A type) or when pressure drop reached 0.1 MPa
∗With auto drain: 0.1 MPa (N.O. type) or 0.15 MPa (N.C. type)
Specifications
Modular connection is possible
with AFF2C to 22C.
(For details, refer to page 204.)
AFF37B/75B AFF75A to 220A
AFF2C to 22C
Made to Order
(For details, refer to page 210.)
Note) Make sure to select a model that
has the max. flow line above the
obtained intersecting point. With a
model that has the max. flow line
below the obtained intersecting
point, the flow rate will be ex-
ceeded, thus leading to a problem
such as being unable to satisfy the
specifications.
Max. air flow rate (m3/min (ANR))
Inlet pressure (MPa)
Caution
Be sure to read before han-
dling.
Refer to front matters 42 and
43 for Safety Instructions and
pages 6 to 8 for Air Preparation
Equipment Precautions.
153
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 153

How to Order
AFF2C to 22C
AFF 22C 10
Options
Symbol T: With element service indicator
Saturation of the
separator can be
observed visually.
(Element life check)
Pressure
drop
0.1 MPa
SMC
MPa 0.2
0.15
0.1
.05
SMC
MPa 0.2
0.15
0.1
.05
Symbol F: Rubber material: Fluororubber
Fluororubber is used for the parts
such as O-ring and gasket.
Symbol H: For medium air pressure
(1.6 MPa)
Can be used up to 1.6 MPa at
maximum.
Symbol R: IN-OUT reversal direction
Air flow in the separator is changed to
right to left.
(Air flow direction of the standard: Left
to right.)
∗3Refer to “Auto Drain Specifications/Option
Combinations”.
Auto drain ∗3
C
D
Drain cock (Without auto-drain)
N.C. auto drain
N.O. auto drain
Symbol
Nil
Description
Body size
2C
4C
8C
11C
22C
2.2 kW
3.7 kW
7.5 kW
11 kW
22 kW
Symbol Applicable compressor
output (guide)
Port size
01
02
03
04
06
10
1/8
1/4
3/8
1/2
3/4
1
Symbol Size 2C
Applicable body size
4C 8C 11C 22C
Thread type
F
N
Rc
G∗1
NPT
Symbol
Nil
Type
∗1 Conforms to
ISO1179-1.
Accessory
B
—
Bracket ∗2
Symbol
Nil
Description
∗2 Bracket is included,
(but not assembled).
X6
X15
—
With differential pressure gauge (GD40-2-01)
With IN-OUT flange
With differential pressure gauge (GD40-2-01)
and IN-OUT flange
N.C., N.O. auto drain, drain piping type
Symbol
Nil
Description Page for details
—
P.211
P.212
X17
X26
P.212
P.213
Option ∗3
F
H
J
R
S
U
T
V
—
Rubber material: Fluororubber
For medium air pressure (1.6 MPa)
Drain guide 1/4 female threaded ∗4
IN-OUT reversal direction
With differential pressure switch (125 VAC, 30 VDC) ∗5, Note)
With differential pressure switch (30 VDC) ∗5
With element service indicator
Degreasing wash,∗6white vaseline
Symbol
Nil
Description
∗4 Drain piping and piping for a stop valve such as ball valve are required.
∗5 Differential pressure gauge is included, (but not assembled).
∗6 Only body/housing is degreasing washed.
Note) Order “U” if conformity to the EU directive is required.
C
D
J
Symbol
Auto drain specifications
Nil
F H R S U T V
Auto Drain Specifications/Option Combinations
Made to Order
(“How to Order” and the applicable models are different from those shown
on this page. Be sure to refer to “Made to Order”.)
: Available
: Plural options cannot be selected.
(i.e. Combinations such as C-FV, D-FHV, J-ST are not possible.)
: Not available
Symbol V: Degreasing wash,
white vaseline
Body/housing is degreasing washed. The
lubrication grease for O-ring and gasket is
changed to white vaseline.
Symbol S: With differential pressure
switch (with indicator)
Saturation of the
separator can be
observed visually or by
an electrical signal.
(Element life check)
Max. contact capacity: 10 VA AC, 10 W DC
Rated contact voltage (max. operating
current): 125 V AC (0.08 A), 30 V DC (0.33 A)
∗The rated contact voltage is different
from “U”.
Reed switch
Symbol J: Drain guide 1/4 female threaded
1/4 female thread
Can be pipied to the
drain exhaust port.
Symbol U: With differential pressure
switch (with indicator)
Saturation of the
separator can be
observed visually or by
an electrical signal.
(Element life check)
Max. contact capacity: 10 W DC
Rated contact voltage (max. operating
current): 30 V DC (0.33 A)
∗The rated contact voltage is different
from “S”.
Reed switch
154
Series AFF
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 154

How to Order
AFF37B/75B
AFF75A to 220A
AFF 37B 10
AFF 75A 20 D
Standard size
(Applicable compressor)
75A 75 kW
125A 110 to 125 kW
150A 150 kW
220A 180 to 220 kW
Compressor output
Symbol
37B
75B
37 kW
75 kW
Body size
Applicable compressor
output (guide)
Symbol
Nil Rc
Thread type
FG
NNPT
Type
Symbol
Description
With differential pressure gauge (GD40-2-01)
With differential pressure switch (With indicator,
125 VAC, 30 VDC)
With IN-OUT flange
With differential pressure gauge (GD40-2-01)
and IN-OUT flange
N.C., N.O. auto drain, drain piping type
White vaseline specifications
Page for details
—
P.211
X6
P.211
X37
P.212
X15
P.212
X17
P.213
P.213
X26
X12
Symbol
Made to Order
(“How to Order” and the applicable models are different from those shown on this
page. Be sure to refer to “Made to Order”.)
—
Nil
Accessory
Auto drain
Pressure gauge
Companion flange
Anchor bolt
Description
—
D
G
F
L
Symbol
Nil
Description
Mist separator for high flow rate
(Nominal filtration rating: 0.3 μm)
Page for details
P.214
—
X13
Symbol
Made to Order
(“How to Order” and the applicable models are different
from those shown on this page. Be sure to refer to
“Made to Order”.)
—
Nil
Port size
10
14
20
1
112
2
Size
Applicable body size
37B 75B
Symbol
Auto drain specifications/Option
Auto drain specifications
Option
OptionAuto drain specifications
D
J
R
DJT
R
Applicable model
AFF37B AFF75B
N.O. auto drain
Drain guide
IN-OUT reversal direction
T
With element service indicator
14
Auto Drain Specifications/Option Combinations
JDrain guide female threaded ∗4
RIN-OUT reversal direction
TWith element service indicator
Option ∗2
14
Description
—
Symbol
Nil
∗4 Drain piping and piping for a stop valve
such as ball valve are required.
Auto drain ∗2
D
∗2Refer to “Auto Drain Specifications/Option
Combinations”.
∗3 Body size 75B is equipped with a ball valve
(Rc 3/8 female threaded). Mount a piping
adapter IDF-AP609 (page 205) to the ball valve
if NPT 3/8 female threaded is required.
Description
Drain cock (Without auto drain) ∗3
N.O. auto drain
Symbol
Nil
20
30
40
50(2B) JIS 10K FF flange
80(3B) JIS 10K FF flange
100 ( 4B ) JIS 10K FF flange
Port size
Size
Symbol 75A
Applicable body size
125A 150A 220A
Accessory
Description
—
Bracket ∗1
Symbol
B
Nil
∗1 Bracket is included,
(but not assembled).
: Available : Not available
Note) Refer to “How to Order Bowl Assembly” on page 206.
155
Main Line Filter Series AFF
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 155

Note) Compressed air over max. flow line in the table below may not meet the specifications of the product.
It may cause damage to the element.
Flow Characteristics/Select the model taking the max. flow capacity into consideration. (Element oil saturation)
AFF2C AFF22C AFF75A
AFF4C AFF37B AFF125A
AFF8C AFF75B AFF150A
AFF11C AFF220A
Pressure drop (MPa)
Air flow rate (l/min (ANR))
Pressure drop (MPa)
Air flow rate (l/min (ANR))
Pressure drop (MPa)
Air flow rate (m3/min (ANR))
Pressure drop (MPa)
Air flow rate (l/min (ANR))
Pressure drop (MPa)
Air flow rate (l/min (ANR))
Pressure drop (MPa)
Air flow rate (m3/min (ANR))
Pressure drop (MPa)
Air flow rate (l/min (ANR))
Pressure drop (MPa)
Air flow rate (m3/min (ANR))
Pressure drop (MPa)
Air flow rate (m3/min (ANR))
Pressure drop (MPa)
Air flow rate (l/min (ANR))
Pressure drop (MPa)
Air flow rate (m3/min (ANR))
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
Max. flow line
156
Series AFF
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 156

Construction
(OUT side)
Guage port
Drain
Gauge port
(IN side)
No.
1
2
Description
SGP-E, SS400
Material Note
SS400
Case
Cover
No.
3
Description
Material Qty.
NBR
—
Model
AFF75A
Element
4Seal
1
1
EC700-003N
AL-33S
EC800-003N
AL-34S
EC900-003N
AL-35S
AFF125A AFF150A AFF220A
AFF2C to 22C, AFF37B
AFF75A to 220A
AFF75B
Component Parts
Replacement Parts
Note) Refer to “How to Order Bowl Assembly” on page 206.
Note) Sight glass is indicated in the figure for easy understanding
of component parts. However, it differs from the actual
construction. Please refer to pages 158 through to 160 for
details.
OUTIN
OUT
IN
q
r
w
e
∗Element assembly: With gasket (1 pc.) and O-ring (1 pc.)
∗Refer to page 219 for replacement of auto drain.
∗Element assemblies for Made to Order (X6, X12, X15, X17, X20, X26, X37) are same as those for standard (see the above table).
Replacement Parts
No.
4
Description Material
Cotton paper,
others
Element
assembly
AFF2C
AFF-EL2B
AFF-EL2B-F
AFF4C
AFF-EL4B
AFF-EL4B-F
AFF8C
AFF-EL8B
AFF-EL8B-F
AFF11C
Model
AFF-EL11B
AFF-EL11B-F
AFF22C
AFF-EL22B
AFF-EL22B-F
AFF37B
AFF-EL37B
—
AFF75B
AFF-EL75B
—
Applicable
model
Except option F
For option F
Component Parts
No.
2
3
1
Description Material Note
Aluminum die-casted∗
Aluminum die-casted
Tempered glass
Chrome treated
Epoxy coating on inner surface
—
Housing
Body
Sight glass
∗The AFF75B is aluminum casted.
Drain
OUTIN
157
Main Line Filter Series AFF
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 157

ø10 One-touch fitting
34
Drain cock
Gray: N.C.
Black: N.O.
20
1/4 female threaded
Z
Y
IN OUT
W
X
IN OUT
M
ø
V
Drain
IN OUT
(Accessory)
Bracket
G
U
D
I
L
T
K
J
C
H
Maintenance
space
R
S
P
Q
O
F
M5
A
EB
N
20
1/4 female threaded
AFF2C to 22C
(mm)
AFF2C
AFF4C
AFF8C
AFF11C
AFF22C
A
Model Port size Bracket related dimensions
Element
service
indicator related
dimensions
Differential
pressure
switch related
dimensions
158
172
204
225
259
1/8, 1/4
1/4, 3/8
3/8, 1/2
1/2, 3/4
3/4, 1
B
10
14
18
20
24
C
99
113
145
166
200
D
63
76
90
106
122
E
20
20
20
20
20
F
63
76
90
106
122
G
10
10
10
10
15
H
173
190
222
246
278
I
56
66
80
90
100
J
20
24
28
31
33
K
5
8
8
10
10
T
6
6
7
9
9
U
6
6
7
9
9
L
12
12
14
18
18
M
6
6
7
9
9
V
10
10
12
15
15
N
35
40
50
55
65
O
54
66
80
88
102
P
70
80
95
111
126
Q
26
28
34
50
60
R
4.5
5
5
9
10
S
1.6
2
2.3
3.2
3.2
W
24
27
32
37
39
X
37
37
37
37
37
Y
32
36
42
43
51
Z
41
41
41
41
41
Auto drain
C: With auto drain (N.C.)
D: With auto drain (N.O.)
Option
J: Drain guide 1/4 female threaded
Combination of D: With auto drain (N.O.)
and H: For medium air pressure
S, U: With differential pressure
switch (with indicator)
T: With element service indicator
Dimensions
158
Series AFF
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 158

159
Main Line Filter Series AFF
85
180
76
160 136 12
4.5
160
150
20
11
15
40
253
334
10
311
20 32
55
37
Maintenance
space
Drain
(Accessory)
Bracket
OUTIN
OUTIN
AFF37B
Auto drain
D: With auto drain (N.O.)
T: With element service indicator
Option
J: Drain guide 1/4 female threaded
20
1/4 female threaded
34
Drain cock: Black
ø10 One-touch fitting
Dimensions
AT
IDFA
IDFB
ID
IDG
AMG
AFF
AM
AMD
AMH
AME
AMF
SF
SFD
LLB
AD
GD
HAA
HAW
IDF
IDU
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 159

ORIENTATION
220
110
120
461
6
18
220 184
220
180
24
13
15
30
348
464
10
42
58
Rc 3/8 female threaded
Maintenance
space
Drain
Drain
Drain
IN
OUT
(Accessory)
Bracket
3 x ø20 holes
For foundation bolt
IN OUT
OUTIN
AFF75B
AFF75A to 220A
Auto drain
D: With auto drain (N.O.)
for AFF75B
Option
T: With element service indicator
23
3/8 female threaded
Model øA
200 (8B)
200 (8B)
250 (10B)
Port size
AFF75A
AFF125A
AFF150A
80(3B)JIS10K FF flange
100(4B)JIS10K FF flange
50(2B)JIS10K FF flange
B
380
380
450
C
1125
1125
1178
D
935
935
980
E
505
505
540
F
265
265
265
G
184
184
236
300 (12B)
AFF220A 100(4B)JIS10K FF flange 500 1291 1070 670 325 282
(mm)
Dimensions
Label
160
Series AFF
P0141-P0220-E.qxd 08.11.6 1:51 PM Page 160
