SMC Networks Barricade SMC7008ABR User manual

Cable/DSL Broadband Router
Built-in 8-Port 10/100Mbps Switch and Integrated Print Server
USER GUIDE
SMC7008ABR

7008ABR – Manual
2
COMPLIANCES
FCC - Class B
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with instructions, may
cause harmful interference to radio communications. However, there is no guarantee that the
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
EC Conformance Declaration - Class B
SMC contact for these products in Europe is:
SMC Networks Europe,
Edificio Conata II,
Calle Fructuós Gelabert 6-8, 2o, 4a,
08970 - Sant Joan Despí,
Barcelona, Spain.
This information technology equipment complies with the requirements of the Council Directive
89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic
Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the
Amendment Directive 93/68/EEC. For the evaluation of the compliance with these Directives, the
following standards were applied:
RFI Emission:
•Limit class B according to EN 55022:1998
•Limit class A for harmonic current emission according to EN 61000-3-2/1995
•Limitation of voltage fluctuation and flicker in low-voltage supply system according to EN
61000-3-3/1995
Immunity:
•Product family standard according to EN 55024:1998
•Electrostatic Discharge according to EN 61000-4-2:1995 (Contact Discharge: ±4 kV, Air
Discharge: ±8 kV)
•Radio-frequency electromagnetic field according to EN 61000-4-3: 1996 (80 - 1000MHz with
1kHz AM 80% Modulation: 3V/m)

7008ABR – Manual
3
COMPLIANCES
Industry Canada - Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,”
ICES-003 of the Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils
numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils
Numériques,” NMB-003 édictée par le ministère des Communications.
Japan VCCI Class B
Australia AS/NZS 3548 (1995) - Class B
SMC contact for products in Australia is:
SMC Communications Pty. Ltd.
Suite 18, 12 Tryon Road,
Lindfield NSW2070,
Phone: [phone]
Fax: [phone]
Electrical fast transient/burst according to EN 61000-4-4:1995(AC/DC power supply: ±1kV,
Data/Signal lines: ±0.5kV)
•Surge immunity test according to EN 61000-4-5:1995(AC/DC Line to Line: ±1kV, AC/DC Line
to Earth: ±2kV)
•Immunity to conducted disturbances, Induced by radio-frequency fields: EN 61000-4-
6:1996(0.15 - 80MHz with 1kHz AM 80% Modulation: 3V/m)
•Power frequency magnetic field immunity test according to EN 61000-4-8:1993(1A/m at
frequency 50Hz)
•Voltage dips, short interruptions and voltage variations immunity test according to EN 61000-
4-11:1994(>95% Reduction @10ms, 30% Reduction @500ms, >95% Reduction @5000ms)
LVD:
•EN60950(A1/1992; A2/1993; A3/1993; A4/1995; A11/1997) COMPLIANCES
Safety Compliance
Underwriters Laboratories Compliance Statement
Important! Before making connections, make sure you have the correct cord set. Check it
(read the label on the cable) against the following:
The unit automatically matches the connected input voltage. Therefore, no additional adjustments
are necessary when connecting it to any input voltage within the range marked on the rear panel.
Wichtige Sicherheitshinweise (Germany)
1. Bitte lesen Sie diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine
Flüssigoder
4. Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
5. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
6. Das Gerät ist vor Feuchtigkeit zu schützen.
7. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen
könnte Beschädigungen hervorrufen.
8. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor Überhitzung schützt.
Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt werden.
9. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.

7008ABR – Manual
4
10. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollte auch
nichts auf der Leitung abgestellt werden.
11. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
12. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz
trennen. Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
13. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in das
Operating Voltage Cord Set Specifications
•120 Volts UL Listed/CSA Certified Cord Set
•Minimum 18 AWG
•Type SVT or SJT three conductor cord
•Maximum length of 15 feet
•Parallel blade, grounding type attachment plug rated 15A, 125V
•240 Volts (Europe only) Cord Set with H05VV-F cord having three conductors with minimum
diameter of 0.75 mm2
•IEC-320 receptacle
•Male plug rated 10A, 250V
COMPLIANCES
Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen.
1. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von
authorisiertem Servicepersonal geöffnet werden.
2. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer
qualifizierten Servicestelle zu überprüfen:
a. Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie
mit Hilfe dieser Anleitung keine Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
3. Stellen Sie sicher, da? die Stromversorgung dieses Ger‰tes nach der EN 60950 gepr¸ft ist.
Ausgangswerte der Stromversorgung sollten die Werte von AC 7,5-8V, 50-60Hz nicht ¸ber
oder unterschreiten sowie den minimalen Strom von 1A nicht unterschreiten.. Der
arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder
weniger.

7008ABR – Manual
5
TABLE OF CONTENTS
COMPLIANCES
CHAPTER 1 | Introduction ……………………………………………………………… 6
Features and Benefits
Package Contents
Minimum Requirements
CHAPTER 2 | Getting to know the Barricade ……………………………………… 7
LED Indicators
Resetting the Barricade
CHAPTER 3 | Getting Connected …………………………………………………….. 8
Basic Installation Procedure
3-Click Installation Wizard
CHAPTER 4 | Configuring your Computer …………………………………………. 9
Configuring Windows 95/98/Me
Configuring Windows 2000
Configuring Windows XP
Configuring a Macintosh Computer
CHAPTER 5 | Configuring the Barricade ……………………………………………. 13
Browser Configuration
Disable Proxy Connection
Accessing the Barricade Management
CHAPTER 6 | Navigating the Web-based Administration ………………………. 15
Making Configuration Changes
Setup Wizard
Advanced Setup
Chapter 7 | Setting up the Print Server …………………………………………….. 32
Install the SMC Printer Port Monitor
Configure the Print Server using the SMC Printer Port Monitor
Configure LPR port on Windows 2000/XP
Confirm printer Connection
APPENDIX A | Troubleshooting ………………………………………………………………………….. 40
APPENDIX B | Technical Specifications ……………………………………………………………….. 43

7008ABR – Manual
6
CHAPTER 1 | Introduction
Congratulations on your purchase of a Barricade™ Broadband Router. SMC is proud to provide you
with a powerful yet simple communication device for connecting your local area network (LAN) to the
Internet. For those who want to surf the Internet at the lowest possible cost, the Barricade™
Broadband Router is the convenient, easy solution.
1.0 | Features and Benefits
•Internet connection to DSL or cable modem via a 10/100 Mbps WAN port
•Local network connection via 10/100 Mbps Ethernet switch ports
•DHCP for dynamic IP configuration, and DNS for domain name mapping
•Firewall with Stateful Packet Inspection, client privileges, hacker prevention, DoS, and NAT
•NAT also enables multi-user access with a single-user account, and virtual server functionality
(providing protected access to Internet services such as web, mail, FTP, and Telnet)
•Virtual Private Network support using PPTP, L2TP, or IPSec pass-through
•User-definable application sensing tunnel supports applications requiring multiple connections
•Parental controls allows the user to limit certain web sites
•Email alerts when the users network is being compromised
•Easy setup through a web browser on any operating system that supports TCP/IP
•Compatible with all popular Internet applications
1.1 | Package Contents
Before installing the Barricade™ Broadband Router, verify that you have the items listed under
“Package Contents.” Also be sure that you have the necessary cabling. If any of the items are
missing or damaged, contact your local SMC distributor.
•Barricade Broadband Router
•Power adapter
•One CAT-5 Ethernet cable
•Four rubber feet
•CD with User Guide and EZ 3-Click Installation Wizard
•Quick Installation Guide
If possible, retain the carton and original packing materials in case there is a need to return the
product.
Please remember to fill out and return the Warranty Registration Card to SMC, or register on SMC’s
web site at www.smc.com to activate the Barricade Broadband Routers warranty.
1.2 | Minimum Requirements
•Cable or DSL Modem with Ethernet Connection and Internet Access Internet access from
your local telephone company or Internet Service Provider (ISP) using a DSL modem or cable
modem.
•A computer equipped with a 10 Mbps, 100 Mbps, or 10/100 Mbps Fast Ethernet card, or a
USB-to-Ethernet converter.
•Network Adapter with Ethernet (UTP CAT 5) Cabling and TCP/IP Protocol Installed per PC
•Internet Explorer 4.0 (or Higher) or Netscape Navigator 4.7 (or Higher) for Web-based
Configuration of the Barricade

7008ABR – Manual
7
CHAPTER 2 | Getting to know the Barricade
The Barricade Broadband Router is the perfect solution for the office environment. This full-featured
router offers:
•8 - 10/100 Mbps Auto-Sensing LAN ports
•1 - 10/100 Mbps WAN port
•1 - Printer Server Port
•1 - COM (RS232) port for ISDN or external dial-up modem
•Comprehensive LEDs for network status and troubleshooting
•Reset Button
2.1 | LED Indicators
The Barricade includes LED indicators on the front panel that simplify installation and network
troubleshooting.
LED ON OFF FLASHING
POWER Receiving power Not receiving power Initializing or upgrading
firmware
WAN Good WAN connection
detected
No WAN connection
detected
Transmitting or receiving
traffic
LINK/ACT Good LAN connection
detected
No LAN connection
detected
Transmitting or receiving
traffic
10/100 Mbps LAN port operating at
100 Mbps
LAN port operating at 10
Mbps
N/A
FDX/COL Full-Duplex connection Half-Duplex Connection Data Collision
Resetting the Barricade
The Reset button is located on the front panel of the Barricade Broadband Router. This Reset button
works 2 different ways depending on how long you hold the button down. Use a paper clip or a
pencil tip to push the Reset button.
Reset
If the Router is having problems connecting to the Internet press and hold the Reset button for 1
second to reset the router. Resetting the router keeps all of the Router’s settings.
Restore Factory Defaults
If Resetting the router does not resolve your issue, then you can press the Reset Button and hold it
down for 5 seconds to restore factory defaults and clear all of the Router’s settings, including settings
such as IP addresses or a new password.

7008ABR – Manual
8
CHAPTER 3 | Getting Connected
The Barricade Broadband router is connected between the Cable/DSL Broadband Modem and your
computers. If you have more then one computer to connect, simply plug the other computers into
the LAN ports on the front of the router.
3.1 | Basic Installation Procedure
1. Connect the LAN
Run an Ethernet cable from one of the LAN ports on the front of the Barricade to your
computer’s network adapter.
2. Connect the WAN
Connect an Ethernet cable from your cable or DSL modem or the Barricade’s WAN port on
the back on the router.
3. Power on
Connect the power cable to the Barricade.
Once you have completed connecting all of the hardware, simply insert the Barricade CD-ROM and
the 3-Click EZ Installation Wizard will automatically connect you to the Internet.
For manual Configuration of the PCs see Chapter 4.
For advanced Configuration of the Barricade Broadband Router see Chapter 5.
M
O
DEM
CO
MP
U
TER

7008ABR – Manual
9
CHAPTER 4 | Configuring your Computer
The information outlined in this chapter will guide you through the configuration for the following
Operating Systems:
•Windows 95/98
•Windows Me
•Windows 2000
•Windows XP
•Apple Macintosh
For installation information on Windows NT, please see your Windows Manual.
4.1 | Configuring Windows 95/98/Me
1. Access your Network settings by clicking [Start], then choose [Settings] and then select
[Control Panel].
2. In the Control Panel, locate and double-click the [Network] icon.
3. Highlight the TCP/IP line that has been assigned to your network card on the [Configuration]
tab of the [Network] properties window.

7008ABR – Manual
10
4. Next, click the [Properties] button to view that adapters TCP/IP settings.
5. From the TCP/IP Properties dialog box click the [Obtain an IP address automatically] option.
6. Next click on the [Gateway] tab and verify the Gateway field is blank. If there are IP
addresses listed in the Gateway section, highlight each one and click [Remove] until the
section is empty.
7. Click the [OK] button to close the TCP/IP Properties window.
8. On the Network Properties Window, click the [OK] button to save these new changes.
NOTE: Windows may ask you for the original Windows installation disk or additional files.
Check for the files at c:\windows\options\cabs, or insert your Windows CD-ROM into your
CDROM drive and check the correct file location, ex., D:\win98, D:\win9x, etc. (if “D” is the
letter of your CD-ROM drive).
9. Windows may prompt you to restart the PC. If so, click the [Yes] button. If Windows does
not prompt you to restart your computer, do so anyways to insure your settings.
4.2 | Configuring Windows 2000
1. Access your Network settings by clicking [Start], then choose [Settings] and then select
[Control Panel]
2. In the Control Panel, locate and double-click the [Network and Dial-up Connections] icon
3. Locate and double-click the [Local Area Connection] icon for the Ethernet adapter that is
connected to the Barricade. When the Status dialog box window opens, click the [Properties]
button.

7008ABR – Manual
11
4. On the [Local Area Connection] Properties box, verify the box next to Internet Protocol
(TCP/IP) is checked. Then highlight the Internet Protocol (TCP/IP), and click the Properties
button.
5. Select Obtain an IP address automatically to configure your computer for DHCP. Click the
[OK] button to save this change and close the Properties window.
6. Click the [OK] button again to save these new changes.
7. Reboot your PC.
4.3 | Configuring Windows XP
The following instructions assume you are running Windows XP with the default interface. If you are
using the Classic interface (where the icons and menus look like previous Windows versions), please
follow the instructions for Windows 2000 outlined above.
1. Access your Network settings by clicking [Start], choose [Control Panel], select [Network and
Internet Connections] and then click on the [Network Connections] icon.
2. Locate and double-click the Local Area Connection icon for the Ethernet adapter that is
connected to the Barricade Router. Next, click the [Properties] button.

7008ABR – Manual
12
3. On the [Local Area Connection] Properties box, verify the box next to Internet Protocol
(TCP/IP) is checked. Then highlight the Internet Protocol (TCP/IP), and click the Properties
button.
4. Select Obtain an IP address automatically to configure your computer for DHCP. Click the
[OK] button to save this change and close the Properties window.
5. Click the [OK] button again to save these new changes.
6. Reboot your PC.
4.4 | Configuring a Macintosh Computer
You may find that the instructions here do not exactly match your screen. This is because these steps
and screenshots were created using Mac OS 8.5. Mac OS 7.x and above are all very similar, but may
not be identical to Mac OS 8.5.
1. Pull down the Apple Menu. Click [Control Panel] and select TCP/IP.
2. In the TCP/IP dialog box, make sure that [Ethernet] is selected in the [Connect Via:] field.
If [Using DHCP Server] is already selected in the [Configure] field, your computer is already
configured for DHCP. Close the TCP/IP dialog box, and skip to Step 2 Disable HTTP Proxy
(bottom of this page).
3. All the information that you need to record is on the [TCP/IP] dialog box. Use the space
below to record the information.
4. Select [Using DHCP Server] in the [Configure] field and close the window.
5. Another box will appear asking whether you want to save your TCP/IP settings. Click [Save].

7008ABR – Manual
13
CHAPTER 5 | Configuring the Barricade
After you have configured TCP/IP on a client computer, use a web browser to configure the
Barricade™ Broadband Router. The Barricade can be configured by any Java-supported browser
including Internet Explorer 4.0 or above, or Netscape Navigator 4.0 or above. Using the web
management interface, you may configure the Barricade and view statistics to monitor network
activity.
Before you attempt to log into the Barricades Web-based Administration, please verify the following:
1. Your browser is configured properly. (see below)
2. Disable any firewall or security software that may be running.
3. Confirm that you have a good “link” LED where your computer is plugged into the Barricade.
If you don’t have a “link” light – then try another cable until you get a good link.
5.1 | Browser Configuration
Confirm your browser is configured for a direct connection to the Internet using the Ethernet cable that
is installed in the computer. This is configured through the options/preference section of your browser.
5.2 | Disable Proxy Connection
You will also need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so
that your web browser will be able to view the Barricade configuration pages. The following steps are
for Internet Explorer and for Netscape. Determine which browser you use and follow the appropriate
steps.
Internet Explorer (5 or above)
1. Open Internet Explorer. Click [Tools], and then select [Internet Options].
2. In the [Internet Options] window, click the [Connections] tab.
3. Click the [LAN Settings] button.
4. Clear all the check boxes and click [OK] to save these LAN settings changes.
5. Click [OK] again to close the [Internet Options] window.
Netscape (4 or above)
1. Open Netscape. Click [Edit], and then select [Preferences].
2. In the [Preferences] window, under [Category], double-click [Advanced], then select the
[Proxies] option.
3. Check [Direct connection to the Internet].
4. Click the [OK] button to save the changes.
NOTE: Before you attempt to configure your router, if you have access to the Internet
please visit www.smc.com and download the latest firmware update to insure your
router is running the latest firmware.

7008ABR – Manual
14
5.3 | Accessing the Barricade Management
To access the Barricade’s web-based management screens follow the steps below:
1. Launch your web-browser.
NOTE: Your computer does not have to be ONLINE to configure the Barricade Router.
2. In the Address Bar, type: http://192.168.2.1
3. When the Barricades Login screen loads up, click the [Login] button to access the router.
NOTE: The Barricade does not ship with a default password.
4. Once you have logged into the Barricade web-based admin screens you have 2 options,
which are outlined in Chapter 6 | Navigating the Web-based Administration

7008ABR – Manual
15
CHAPTER 6 | Navigating the Web-based Administration
The Barricade’s management interface features a Setup Wizard and an Advanced Setup section. Use
the Setup Wizard if you want to quickly setup the Barricade for use with a cable modem or DSL
modem. Advanced setup supports more advanced functions like hacker attack detection, IP and MAC
address filtering, intrusion detection, virtual server setup, virtual DMZ hosts, as well as other
advanced functions.
6.1 | Making Configuration Changes
Configurable parameters have a dialog box or a drop-down list. Once a configuration change has
been made on a page, be sure to click the “Apply” or “Next” button at the bottom of the page to
enable the new setting.
Note: To ensure proper screen refresh after a command entry, be sure that Internet Explorer 5.0 is
configured as follows: Under the menu “Tools/Internet Options/General/Temporary Internet
Files/Settings,” the setting for “Check for newer versions of stored pages” should be “Every visit to
the page.”

7008ABR – Manual
16
6.1 | Setup Wizard
Below is an outline of each option available from the Setup Wizard section. This wizard takes 3 steps
to complete an ISP configuration.
6.1.1 | Step One: Time Zone
The first step is to configure the Time Zone you are located in. This setting is used for accurate
timing of client filtering and log events.
6.1.2 | Step Two: Broadband Type
Select the type of broadband connection you have.
•Cable Modem
Your ISP may have given you a host name. If so, enter it into this field.
•Fixed-IP xDSL
Some xDSL Internet Service Providers may assign a fixed (static) IP address for your
gateway. If you have been provided with this information, choose this option and enter the
assigned IP address, subnet mask, gateway IP, and DNS IP addresses for the Barricade.
•PPPoE
Enter the PPPoE user name and password assigned by your Service Provider. The Service

7008ABR – Manual
17
Name is normally optional, but may be required by some service providers. Leave the
Maximum Transmission Unit (MTU) on the default value (1492) unless you have a particular
reason to change it. Enter a Maximum Idle Time (in minutes) to define a maximum period of
time for which the Internet connection is maintained during inactivity. If the connection is
inactive for longer than the Maximum Idle Time, it will be dropped. Enable the Auto-
reconnect option to automatically re-establish the connection as soon as you attempt to
access the Internet again.
6.1.2 | Step Three: Finish Configuration
Once you have configured your type of ISP connection, simply click the [Finish] button and the
Barricade will automatically configure your Internet connection.

7008ABR – Manual
18
6.2 | Advanced Setup
Below is an outline of the Advanced Setup section. This section is used to manually configure your
ISP connection and also define the advanced system parameters, manage and control the Barricade
and its ports, or monitor network conditions.
6.2.1 | System
This section is used to configure the local time zone, password for administrator access, and the IP
address of a PC that will be allowed to manage the Barricade remotely.
•Time Zone
Use this option to the time zone for the Barricade. This information is used for log entries
and client access control.
•Password Settings
Use this menu to restrict access based on a password. By default, there is no password. For
security you should assign one before exposing the Barricade to the Internet.
NOTE: Passwords can contain from 3–12 alphanumeric characters and are not case
sensitive.
•Remote Management
This feature allows a remote PC to configure, manage, and monitor the Barricade using a
standard web browser. Check “Enable” and enter the IP address of the remote host. Click
“Apply.”
NOTE: If you specify an IP address of 0.0.0.0, any host can manage the Barricade.

7008ABR – Manual
19
6.2.2 | WAN
Specify the WAN connection type provided by your Internet Service Provider, then click “More
Configuration” to enter detailed configuration parameters for the selected connection type.
•Dynamic IP
The Host Name is optional, but may be required by some ISPs. The default MAC address is
set to the WAN’s physical interface on the Barricade. Use this address when registering for
Internet service, and do not change it unless required by your ISP. If your ISP used the MAC
address of an Ethernet card as an identifier when first setting up your broadband account,
connect only the PC with the registered MAC address to the Barricade and click the “Clone
MAC Address” button. This will replace the current Barricade MAC address with the already
registered Ethernet card MAC address.
If you are unsure of which PC was originally set up by the broadband technician, call your
ISP and request they register a new MAC address for your account. Register using the
default Barricade MAC address.

7008ABR – Manual
20
•PPPoE
Enter the PPPoE user name and password assigned by your Service Provider. The Service
Name is normally optional, but may be required by some service providers. The MTU
(Maximum Transmission Unit) governs the maximum size of the data packets. Leave this on
the default value (1492) unless you have a particular reason to change it.
Enter a Maximum Idle Time (in minutes) to define a maximum period of time for which the
Internet connection is maintained during inactivity. If the connection is inactive for longer
than the Maximum Idle Time, it will be dropped. Enable the Auto-reconnect option to
automatically re-establish the connection when an application attempts to access the Internet
again.
•PPTP
Point-to-Point Tunneling Protocol (PPTP) allows the secure remote access over the Internet
by simply dialing in a local point provided by an ISP. Using the above screen allows client PCs
to establish a normal PPTP session and provides hassle-free configuration of the PPTP client
on each client PC.
