SMCWBR14-G
2.4GHz 54Mbps Wireless Cable/DSL Broadband Router
www.smc.com
The Barricade™ g 2.4GHz 54Mbps Wireless Cable /DSL
Broadband Router (SMCWBR14-G) is the perfect networking
solution for the user that is looking for a simple, all-in-one
home or small offi ce network product.
This platform independent multi-functional router com-
bines a 4-port 10/100 Mbps dual-speed switch with
Automatic MDI-MDIX feature, and a high speed 54Mbps
wireless access point with security features that include
802.1x for authentication, Wi-Fi Protected Access (WPA),
MAC address fi ltering and 64/128-bit Wired Equivalent
Privacy (WEP).
The SMCWBR14-G also includes a firewall with Stateful
Packet Inspection, web-based network management and
support for Virtual Private Network (VPN) pass-through
for secure remote offi ce connections.
Supporting NAT, the SMCWBR14-G can provide simultaneous
Internet access for multiple PCs using a single purchased IP
address. Finally, installation is made simple and straight-
forward with the EZ 3-Click Installation Wizard utility.
FEATURES
Share your Cable/DSL connection
EZ 3-Click Installation Wizard
802.11g/ 802.11b compliant High Speed Wireless LAN connection
4-port 10/100 Mbps Auto MDI-MDIX switch and one
detachable antenna
Stateful Packet Inspection (SPI) Firewall
Access Control and URL Blocking
High Level of Security
Ability to connect to cable/xDSL modem for instant internet
access. Allows a single broadband Internet connection to be
used by multiple computers. Share fi les, printers, and other
devices on a network.
A new and improved way to install your Wireless Barricade. In 3
simple clicks, you will be connected to the Internet.
The new Barricade G offers a high data rate that is up to 5 times
faster than the widely used 802.11b wireless LAN and is backward
compatible with existing 802.11b network devices.
Multi-port auto-sensing switch for integration to your wired LAN
with Auto MDI-MDIX support. No need for the use of crossover
cable. One detachable antenna can be replaced with SMC high gain
antennas for added performance and coverage.
Robust Stateful Packet Inspection fi rewall provides a high level of
security against Denial of Service (DoS) attacks. The SPI fi rewall
analyzes each individual data packet as it passes through SMCBR14-G
and ensures that only authorized packets can access the local
network.
Access Control based on a pre defi ned-scheduled time, IP
address fi ltering, and Mac Address Filtering. Parental control to
protect your family with URL blocking capability.
Provides secure data transmissions across the network by using
robust security features include 802.1x for authentication, Wi-Fi
Protected Access (WPA), 64-bit/128-bit WEP encryption, disable
SSID broadcast and MAC address fi ltering.
BENEFITS
OVERVIEW

TECHNICAL SPECIFICATIONS SMCWBR14-G
STANDARDS
• IEEE 802.3, IEEE 802.3u, IEEE 802.11b,IEEE 802.11g
WAN INTERFACE
• 10BASE-T/100BASE-TX
LAN INTERFACES
• 10BASE-T/100BASE-TX
• 4 RJ-45 ports
DATA RATES
• 1/2/5.5/6/9/11/12/18/24/36/48/54 Mbps
• Supports “Nitro Lite” turbo mode (data rate increase of up to 30%)
FREQUENCY BAND
• IEEE 802.11b/g Radio: 2.4 GHz
• USA - FCC 2412~2462MHz (Ch1~Ch11)
• Canada - IC2412~2462MHz (Ch1~Ch11)
• Europe - ETSI 2412~2472MHz (Ch1~Ch13)
• Japan - STD-T66/STD-332412~2484MHz (Ch1~Ch14)
MODULATION TYPE
• OFDM, CCK
OPERATING CHANNELS
• 11 channels (US, Canada)
• 13 channels (ETSI)
• 14 channels (Japan)
ANTENNA TYPE
• 1 Dipole antenna with RP-SMA connector
ANTENNA GAIN
• 1.43 dBi
SENSITIVITY MODULATION RATE
• Modulation Rate Receive Sensitivity Typical (dBm)
• 802.11b - 1Mbps -90 802.11g - 12Mbps -84
• 802.11b - 2Mbps -88 802.11g - 18Mbps -82
• 802.11b - 5.5Mbps -85 802.11g - 24Mbps -79
• 802.11b- 11Mbps -82 802.11g - 36Mbps -75
• 802.11g - 6Mbps -88 802.11g - 48Mbps -68
• 802.11g - 9Mbps -87 802.11g - 54Mbps -68
RF OUTPUT POWER
• Modulation Rate Output Power (dBm)
• 802.11b - 1Mbps 16 802.11g - 12Mbps 15
• 802.11b - 2Mbps 16 802.11g - 18Mbps 15
• 802.11b - 5.5Mbps 16 802.11g - 24Mbps 15
• 802.11b- 11Mbps 16 802.11g - 36Mbps 15
• 802.11g - 6Mbps 15 802.11g - 48Mbps 12
• 802.11g - 9Mbps 15 802.11g - 54Mbps 12
MANAGEMENT
• Web-based management
ADVANCED FEATURES
• Dynamic IP Address Confi guration – DHCP, DNS
• Wireless Security – 64/128-bit WEP/WPA/TKIP/AES-CCM/AES-OCB/
802.1x, SSID broadcast disabled, MAC address filtering
• Firewall - SPI, Access Control, Event Logging
• Virtual Server via NAT
• Virtual Private Network – PPTP, L2TP, IPSec pass-through
• Intrusion Detection, email Alerts, Parental Control
• Wireless Distribution System (WDS)
• DDNS, UPnP, Port Forwarding
INDICATOR PANEL
• Power, WLAN, WAN (Link, Activity), LAN
(Link/Activity,Speed - 10/100 Mbps)
DIMENSIONS
• 155 x 130 x 26 mm
• 6.10 x 5.12 x 1.02 in
WEIGHT
• 410 g
• 14.46 oz
INPUT POWER
• 9 VDC, 1 A
• EU: DV-91AUP
POWER CONSUMPTION
• 5 Watts max. @ 100-240 VAC
INTERNET STANDARDS
• RFC 826 ARP, RFC 791 IP, RFC 792 ICMP, RFC 768 UDP, RFC 793
TCP, RFC 854-859 TELNET, RFC 1321 MD5, RFC 1497 BOOTP
Extension, RFC 1570 PPP LCP Extension, RFC 1631 NAT, RFC1661
PPP, RFC 1700 Assigned Numbers, RFC 1866 HTML, RFC 1945
HTTP, RFC 1994 CHAP, RFC 2131 DHCP, RFC 2637 PPTP
TEMPERATURE
• Operating 0 to 40 °C
• 32 to 104 °F
• Storage -40 to 70 °C
• -40 to 158 °F
HUMIDITY
• 5% to 95% (non-condensing)
COMPLIANCES
• CE Mark
EMISSIONS
• FCC Class B
• VCCI Class B
• Industry Canada Class B
• EN55022 (CISPR 22) Class B
• C-Tick - AS/NZS 3548 (1995) Class B
IMMUNITY
• EN 61000-3-2/3
• EN 61000-4-2/3/4/5/6/8/11
• DGT LP0002: 2004
SAFETY
• CSA/NRTL(UL1950,CSA 22.2.950)
• GS (EN60950)
• CB (IEC60950)
