WIRELESS SMCWBR14S-N
Draft 11n Wireless 4-port Broadband Router
The Barricade™ N Draft 11n Broadband Router (SMCWBR14S-N) is the perfect
all-in-one networking solution for connecting and sharing your high speed
cable/xDSL internet connection. Designed for the home and office, this
platform independent multi-functional router combines a 4-port 10/100 LAN
switch, High speed Wireless-N (draft 802.11n) access point, NAT firewall with
Stateful Packet Inspection (SPI) and User friendly web-based management
interface in one convenient device.
The built-in wireless access point is Wi-Fi certified for full compliance with
the 802.11n draft v2.0 standard, as well as the popular Wireless-G (802.11g)
and Wireless-B (802.11b) standards. This next generation wireless networking
standard utilizes advanced MIMO (Multiple-In, Multiple-Out) technology to
deliver incredible speed and range. With wireless speeds up to 300Mbps
and up to 2x the coverage, the SMCWBR14S-N provides better performance
than existing 802.11g technology. Upgrading to Wireless N provides an
excellent solution for sharing an Internet connection and files such as video,
music, photos, and documents. With security being a key consideration,
SMCWBR14S-N supports the latest WPA and WPA2 wireless encryption
standards, which prevent unauthorized access to wireless networks and
ensure data is secure. Wireless security can also be set up easily using Wi-Fi
Protected Setup™ (WPS) that enables push button or PIN configuration.
The integrated NAT firewall with SPI provides protection from hackers and
Denial of Service attacks by analyzing individual data packets, to ensure
that only authorized packets are allowed access to the network. Using the
Access Control feature parents or network administrators can block certain
websites, limit web access based on time or dates, and/or block internet
access for applications like P2P utilities or games. Finally, configuration of
your internet connection and advanced router functions is made simple and
straightforward with the EZ™ Installation Wizard and intuitive web-based
management interface.
OVERVIEW
FEATURES BENEFITS
Share your high speed cable/xDSL internet connection Simply connect your cable or xDSL modem with Ethernet connection to the
10/100 WAN port for instant always on internet.
4-port 10/100 LAN switch with auto MDI-MDIX Directly connect four computers or expand your network by connecting additional
switches. Auto MDI-MDIX means you do not need to worry about cross-over cables.
Built-in Wireless-N (draft 802.11n) access point With wireless speeds up to 300Mbps and up to 2x the coverage, the
SMCWBR14S-N provides better performance than existing 802.11g technology.
NAT firewall with Stateful Packet Inspection (SPI) Provides protection from hackers and Denial of Service attacks by analyzing
individual data packets, to ensure that only authorized packets are allowed access
to your network.
WPA/WPA2 Encryption Prevents unauthorized access to your wireless network and insures your data is
secure.
Wi-Fi Protected Setup™ (WPS) Makes wireless security setup easy with push button and PIN configuration methods.
Web-Based management interface Simple and straightforward set-up with the intuitive web-based management
interface and EZ™ Installation Wizard.
www.smc.com

TECHNICAL SPECIFICATIONS SMCWBR14S-N
PHYSICAL
• One 10/100Mbps WAN port
• 4-port 10/100Mbps LAN switch
• Two 2dBi fixed antennas
• WPS button
• Reset button
MANAGEMENT FEATURES
• EZ Installation Wizard
• Web based management interface (HTTP)
• Remote management
SECURITY FEATURES
• NAT Firewall with SPI
• Denial-of-Service protection
• Intrusion Detection System
• Access Control
• Web Filter
• DMZ Host
• IPSec, PPTP and L2TP VPN pass-through
• SSID Broadcast disable
• MAC address Filtering
• WEP 64-/128-Bit Encryption
• WPA-/WPA2-PSK (Pre Shared Key)
• WPA/WPA2 Enterprise mode (802.1x)
ROUTER FEATURES
• NAT (Network Address Translation) / PAT (Port Address Translation)
• ALG (Application Level Gateways)
• Virtual Server
• Virtual DMZ Host
• UPnP IGD compliant
• DHCP Server
• DNS Proxy/Relay
• Dynamic DNS (DynDNS.org and TZO.com)
• System log
STANDARDS
• IEEE802.3 (10Base-T), IEEE802.3u (100Base-TX)
• IEEE802.11b, IEEE802.11g, IEEE802.11n draft v2.0
OPERATING FREQUENCY
• FCC: 2412~2462MHz (Ch1~Ch11)
• ETSI: 2412~2472MHz (Ch1~Ch13)
TYPICAL RF OUTPUT POWER
• 11n Mode: 14dBm
• 11g Mode: 17dBm
• 11b Mode : 20dBm
TEMPERATURE
• Operating: 0 degrees C to 40 degrees C
• Storage: -20 degrees C to 70 degrees C
HUMIDITY
• Operating: 10% to 85% Non-condensing
• Storage: 5% to 95% Non-condensing
DIMENSIONS
• 189 x 154 x 30 mm
• 7.4 x 6.06 x 1.18 in
WEIGHT
• 0.285 Kg
• 0.63 Ibs
POWER INPUT
• 12V/1A
CERTIFICATIONS
• FCC
• CE
SYSTEM REQUIREMENTS
• Broadband (Cable/xDSL) Internet service and Modem with Ethernet
connection.
• 2.4GHz 802.11n draft wireless adapter or 2.4GHz 802.11b/g wireless
adapter installed on each PC. Alternatively an Ethernet adapter can be
used.
• Internet Explorer 5.5 or above, Netscape 4.7 or above, Mozilla Firefox 1.0
or above
• We recommend using this product with the SMCWCB-N, SMCWPCI-N and
SMCWUSB-N EZ ConnectTM N wireless adapters
PACKAGE CONTENTS
• Barricade™ N Broadband Router (SMCWBR14S-N)
• Power Supply
• RJ-45 Ethernet cable
• Documentation CD
• Quick Installation Guide
• Warranty Information Card
WARRANTY
• Limited Lifetime
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
