SMC Networks Barricade SMC7004VWBR User manual

Barricade
TM
Wireless Cable/DSL Broadband Router
Wireless Cable/DSL Broadband Router
◆ Multi-user Internet access via single user account
◆ EZ 3-Click Installation Wizard
◆ IEEE 802.11b compliant
◆ Wireless operation at 11, 5.5, 2, or 1 Mbps
◆ Integrated 4-port 10/100 Mbps switch
◆ Configurable parental control
◆ Stateful Packet Inspection (SPI) and Denial of Service
(DoS) support
◆ Supports a wide variety of Internet applications
◆ Virtual Private Network (VPN) using PPTP, L2TP,
IPSec pass-through
User Guide
SMC7004VWBR

Barricade
TM
Wireless Cable/
DSL Broadband Router
User Guide
From SMC’s Barricade line of Broadband Routers
Sept 2002
Revision Number: R01

iii
COMPLIANCES
FCC - Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that the interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
• Consult the dealer or an experienced radio/TV technician for help
FCC Caution: To assure continued compliance, (example - use only shielded interface cables
when connecting to computer or peripheral devices). Any changes or modifications not
expressly approved by the party responsible for compliance could void the user’s authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
CAUTION STATEMENT:
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a minimum
distance of 20 centimeters between the radiator and your body. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.

C OMPLIANCES
iv
EC Conformance Declaration - Class B
SMC contact for these products in Europe is:
SMC Networks Europe,
Edificio Conata II,
Calle Fructuós Gelabert 6-8, 2o, 4a,
08970 - Sant Joan Despí,
Barcelona, Spain.
This information technology equipment complies with the requirements of the Council
Directive 89/336/EEC on the Approximation of the laws of the Member States relating to
Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain
voltage limits and the Amendment Directive 93/68/EEC. For the evaluation of the
compliance with these Directives, the following standards were applied:
Industry Canada - Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus,” ICES-003 of the Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils
numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils
Numériques,” NMB-003 édictée par le ministère des Communications.
RFI
Emission: * Limit class B according to EN 55022:1998
* Limit class A for harmonic current emission according to EN 61000-3-2/1995
* Limitation of voltage fluctuation and flicker in low-voltage supply system
according to EN 61000-3-3/1995
Immunity: * Product family standard according to EN 55024:1998
* Electrostatic Discharge according to EN 61000-4-2:1995 (Contact Discharge: ±4
kV, Air Discharge: ±8 kV)
* Radio-frequency electromagnetic field according to EN 61000-4-3: 1996 (80 -
1000MHz with 1kHz AM 80% Modulation: 3V/m)
* Electrical fast transient/burst according to EN 61000-4-4:1995(AC/DC power
supply: ±1kV, Data/Signal lines: ±0.5kV)
* Surge immunity test according to EN 61000-4-5:1995(AC/DC Line to Line:
±1kV, AC/DC Line to Earth: ±2kV )
* Immunity to conducted disturbances, Induced by radio-frequency fields: EN
61000-4-6:1996(0.15 - 80MHz with 1kHz AM 80% Modulation: 3V/m)
* Power frequency magnetic field immunity test according to EN
61000-4-8:1993(1A/m at frequency 50Hz)
* Voltage dips, short interruptions and voltage variations immunity test according
to EN 61000-4-11:1994(>95% Reduction @10ms, 30% Reduction @500ms,
>95% Reduction @5000ms)
LVD: * EN60950(A1/1992; A2/1993; A3/1993; A4/1995; A11/1997)

C OMPLIANCES
vi
Safety Compliance
Underwriters Laboratories Compliance Statement
Important! Before making connections, make sure you have the correct cord set. Check it
(read the label on the cable) against the following:
The unit automatically matches the connected input voltage. Therefore, no additional
adjustments are necessary when connecting it to any input voltage within the range marked
on the rear panel.
Wichtige Sicherheitshinweise (Germany)
1. Bitte lesen Sie diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssi-
goder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen
könnte Beschädigungen hervorrufen.
7. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor Überhitzung
schützt. Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollte auch
nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz
trennen. Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in das
Operating Voltage Cord Set Specifications
120 Volts UL Listed/CSA Certified Cord Set
Minimum 18 AWG
Type SVT or SJT three conductor cord
Maximum length of 15 feet
Parallel blade, grounding type attachment plug rated 15A,
125V
240 Volts (Europe only) Cord Set with H05VV-F cord having three conductors with
minimum diameter of 0.75 mm2
IEC-320 receptacle
Male plug rated 10A, 250V

C OMPLIANCES
vii
Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen.
13. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit
nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von
einer qualifizierten Servicestelle zu überprüfen:
a. Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit
Hilfe dieser Anleitung keine Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. Stellen Sie sicher, da? die Stromversorgung dieses Ger‰tes nach der EN 60950 gepr¸ft
ist. Ausgangswerte der Stromversorgung sollten die Werte von AC 7,5-8V, 50-60Hz nicht
¸ber oder unterschreiten sowie den minimalen Strom von 1A nicht unterschreiten..
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder
weniger.

C OMPLIANCES
viii

ix
T ABLE OF C ONTENTS
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
About the Wireless Barricade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Connect the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Basic Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
3 Configuring Client PCs . . . . . . . . . . . . . . . . . . . . . . . . 3-1
TCP/IP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
4 Configuring the Wireless Barricade . . . . . . . . . . . . . . 4-1
Navigating the Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Making Configuration Changes . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Time Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Broadband Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Advanced Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
WAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Wireless Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
NAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33
5 Configuring Client TCP/IP . . . . . . . . . . . . . . . . . . . . 5-1
Installing TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Windows 95/98/ME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

T AB LE OF C ONTENTS
x
Setting Up TCP/ IP to Work with the Wireless Barricade . . . . . .. . . . . 5-5
Windows 95/ 98/ME . . . . .. . . . . . . .. . . . . . . .. . . . . . . .. . . . . 5-5
Windows 2000 . . . . . . . . . .. . . . . . . .. . . . . . . .. . . . . . . .. . . . . 5-6
Windows XP . . . . . . . . . . . .. . . . . . . .. . . . . . . .. . . . . . . .. . . . . 5-7
Configuring Your Computer with Windows 95/98/ME . . . . . . 5-8
Configuring Your Computer inWindows 2000 . . . . . . . .. . . . 5-15
Configuring Your Computer with Windows XP . . . . . . . . . . . 5-22
Configuring Your Computer with Windows NT 4.0 . . . . . . . . 5-29
Configuring Your Macintosh Computer . . . . . .. . . . . . . .. . . . 5-35
Dynamic IP Allocation via a DHCP Server . . . . . . . . . . .. . . . 5-41
Manual IP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-42
Verifying Your TCP/IP Connection . . . . . . . . .. . . . . . . .. . . . 5-43
A Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
B Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
Ethernet Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Specifications . . . . . . . . . . .. . . . . . . .. . . . . . . .. . . . . . . .. . . . . B-1
Twisted-pair Cable . . . . . . .. . . . . . . .. . . . . . . .. . . . . . . .. . . . .B-1
RJ-45 Port Pin Assignments . . . . .. . . . . . . .. . . . . . . .. . . . . . . .. . . . .B-3
C Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1
NOTE:
For information on PPTP, DDNS and UPnP please visit 
www.smc-europe.com or contact the SMC technical support team.

1-1
C HAPTER 1
I NTRODUCTION
Congratulations on your purchase of a Barricade™Wireless Cable/DSL
Broadband Router. SMC is proud to provide you with a powerful yet
simple communication device for connecting your local area network
(LAN) to the Internet. For those who want to surf the Internet at the
lowest possible cost, the Wireless Barricade™ is the convenient, easy
solution.
About the Wireless Barricade
The Wireless Barricade provides Internet access to multiple users by
sharing a single-user account. The Wireless Barricade features a
WAN
interface that allows you to connect either a DSL or cable
modem. The
Wireless Barricade provides extensive firewall protection and Virtual
Private Network (VPN) services.
The Wireless Barricade provides many cost-effective functions and
management benefits. It is simple to configure and can be up and running
in minutes.

I NTRODUCTION
1-2
Features and Benefits
• Internet connection to DSL or cable modem via a 10/100 Mbps WAN
port
• Local network connection via 10/100 Mbps Ethernet ports or
11 Mbps wireless interface (supporting up to 128 mobile users)
• 802.11b Compliant – interoperable with multiple vendors
• Provides seamless roaming within 802.11b WLAN environment
• DHCP for dynamic IP configuration, and DNS for domain name
mapping
• Firewall with Stateful Packet Inspection, client privileges, hacker
prevention, DoS, and NAT
• NAT also enables multi-user access with a single-user account, and
virtual server functionality (providing protected access to Internet
services such as web, mail, FTP, and Telnet)
• Virtual Private Network support using PPTP, L2TP, or IPSec
pass-through
• User-definable application sensing tunnel supports applications
requiring multiple connections
• Parental controls allows the user to limit certain web sites
• Email alerts when the users network is being compromise
• Easy setup through a web browser on any operating system that
supports TCP/IP
• Compatible with all popular Internet applications

I NTRODUCTION
1-3
Applications
Many advanced applications are provided by the Wireless Barricade, such as:
• LAN Access
The Wireless Barricade provides connectivity to 10/100 Mbps
devices, making it easy to create a network in small offices or homes.
• Internet Access
This device supports Internet access through a DSL or cable
connection. Since many DSL providers use PPPoE to establish
communications with end users, the Wireless Barricade includes a
built-in client for this protocol, eliminating the need to install this
service on your computer.
• Shared IP Address
The Wireless Barricade shares a single IP address with up to 253
users. Using only one ISP account, multiple users on your network
can simultaneously browse the Internet.
•VirtualServer
If you have a static IP address, you can set up the Wireless Barricade
to act as a virtual host for network address translation. Remote users
access various services at your site using the static IP address. Then,
depending on the requested service (or port number), the Wireless
Barricade routes the request to the appropriate server (at an internal
network IP address). This secures your network from direct attack by
hackers, and provides more flexible management by allowing you to
change internal network IP addresses without affecting outside access
to your network.

I NTRODUCTION
1-4
• User-Definable Application Sensing Tunnel
You may define special applications that require multiple connections
such as Internet gaming, video conferencing, and Internet telephony.
The Wireless Barricade will then sense the application type and open a
multi-port tunnel for it.
• DMZ Hosts Support
Allows a networked computer to be fully exposed to the Internet.
This function is used when the special application sensing tunnel
feature is insufficient to allow an application to function correctly.
• Security
The Wireless Barricade supports security features that deny Internet
access to specified users, or drop requests for specific services. The
Wireless Barricade’s firewall also blocks common hacker attacks,
including IP Spoofing, Land Attack, Ping of Death, IP with zero
length, Smurf Attack, UDP port loopback, Snork Attack, TCP null
scan, and TCP SYN flooding.
• Virtual Private Network
The Wireless Barricade supports three of the most commonly used
VPN protocols – PPTP, L2TP, and IPSec. These protocols allow
remote users to establish a secure connection to their corporate
network. If your service provider supports VPNs, then any of these
protocols can be used to create an authenticated and encrypted tunnel
for passing secure data over the Internet (i.e., a traditionally shared
data network). The VPN protocols supported by the Wireless
Barricade are briefly described below.

I NTRODUCTION
1-5
• Point-to-Point Tunneling Protocol – Provides a secure tunnel for
remote client access to a PPTP security gateway. PPTP includes
provisions for call origination and flow control required by ISPs.
• Layer Two Tunneling Protocol – Includes most of the features
provided by PPTP, but has less overhead and is more suited for
managed networks.
• IP Security – Provides IP network-layer encryption. IPSec can
support large encryption networks (such as the Internet) by using
digital certificates for device authentication.

I NTRODUCTION
1-6

2-1
C HAPTER 2
I NSTALLATION
Before installing the Wireless Barricade™, verify that you have the items
listed under “Package Contents.” Also be sure that you have the necessary
cabling.
Package Contents
If any of the items are missing or damaged, contact your local SMC
distributor.
• Wireless Barricade Broadband Router
• Power adapter
• One CAT-5 Ethernet cable
• Four rubber feet
• Installation CD with this User Guide and EZ 3 Click Installation
Wizard
• Quick Installation Guide
• SMC Warranty Registration Card
If possible, retain the carton and original packing materials in case there is
a need to return the product.

I NSTALLATION
2-2
Please fill out and return the Warranty Registration Card to SMC, or
register on SMC’s web site atwww.smc-europe.com. The Wireless Barricade
Broadband Router is covered by a limited lifetime warranty.
Hardware Description
The Wireless Barricade Broadband Router may be connected to the
Internet or to a remote site using its RJ-45 WAN port. It may be
connected directly to your PC or to a local area network using any of the
four 10/100 autosensing switch ports.
These RJ-45 ports auto-negotiate the operating speed (10/100 Mbps) and
the duplex mode (half/full duplex).
Access speed to the Internet depends on your service type. Full-rate
Asymmetric Digital Subscriber Line (ADSL) provides up to 8 Mbps
downstream and 640 Kbps upstream; G.lite (or splitterless) ADSL
provides up to 1.5 Mbps downstream and 512 Kbps upstream; Cable
modems provide up to 36 Mbps downstream and 2 Mbps upstream.
However, you should note that the actual rate provided by specific service
providers may vary dramatically from these upper limits.
Though Internet access speed is determined by the modem type
connected to your Wireless Barricade, data passing between devices
connected to your local area network can run up to 100 Mbps over the
Fast Ethernet ports.
The Wireless Barricade includes LED indicators on the front panel that
simplify installation and network troubleshooting.

I NSTALLATION
2-3
Front Panel
Figure 2-1. Front Panel
LED Indicators
The Wireless Barricade includes LED indicators on the front panel that
simplify installation and network troubleshooting.
Check the power and port indicators as shown in the following table .
LED Condition Status
Power
(Green)
On Wireless Barricade is receiving power.
WLAN
(Green)
On
The Wireless Barricade has established a valid
wireless connection
.
WAN
(Green)
On The WAN port has established a valid network
connection.
LAN
Link
(Green)
On The indicated LAN port has established a valid
network connection.
Activity
(Amber)
Flashing The indicated LAN port is transmitting or receiving
traffic.
SMC7004VWBR
4

I NSTALLATION
2-4
Rear Panel
Figure 2-2. Rear Panel
Item Description
9V 1A Connect the included power adapter to this port.
Warning: Using the wrong type of power adapter may cause
damage.
Reset Use this button to reset the power or restore the default factory
settings. Reboot by pushing 1 second. Return all settings to the
factory defaults by pushing 5 seconds.
WAN WAN port (RJ-45). Connect a cable modem, DSL modem, or an
Ethernet router to this port.
LAN Four 10/100 Autosensing switch ports (RJ-45). Connect devices on
your local area network to these ports (such as a PC, hub, or switch).
RESET 9V
2 A MAX
9 V
2 A MAX
WAN LAN1 LAN2 LAN3 LAN4
