SMEG COOKERS
Delivery & Connection Guide
Thank you for ordering your new Smeg cooker from John Lewis. In doing so you have qualied for a free of charge delivery
and connection service, including disconnection and disposal of your old cooker.
Smeg will provide a ‘hook up’ service to connect your new cooker to both the natural gas and/or electrical supply (please
note Smeg will not undertake disconnection or connection to LPG). This connection service is provided on the understanding
that existing fuel supplies have been prepared to a required standard and fall within the parameters laid out in the following
information.
Once your order has been processed our fullment partner will get in touch with you to arrange a home delivery booking.
When a date is agreed they will also give you a follow up call the day before delivery with a 4hr delivery window. You
can also choose to be contacted one hour prior to delivery on the actual day, should you wish.
To ensure everything runs smoothly, when making the booking our fullment partner will carry out a home delivery
questionnaire to ascertain information relating to both access at your property & the electrical/gas supply.
DISCONNECTION: Please note our team can only disconnect gas from a standard bayonet tting. Please ensure any
cooker for removal is cooled down prior to the team arriving.
GAS CONNECTION: Your cooker will be supplied with a one metre long mark 2 BS bayonet hose with a 1/2” BSP male
tting, which will be used to connect your cooker to the gas supply.
ELECTRICAL CONNECTION: Your electrical supply must be easy to access. If it’s inaccessible or the supply is faulty, we
wont be able to complete your connection. Your cooker will be supplied with the appropriate cable to connect to the
electrical supply. Please visit www.smeguk.com for information on the electrical loading requirement for your appliance.
Every home is different, so please ensure the electrical loading supply is suitable for the appliance you are purchasing. We
recommend you seek conrmation of this via the services of a qualied electrican. If you need help nding an electrican
please visit www.electricalsafetyrst.org.uk/nd-an-electrician/.
The instruction manual for your new appliance is available to view or download on our website www.smeguk.com/user-
manuals which contains detailed information regarding installation.
Cookers delivery and connection guide page 1/3

The gas bayonet tting must terminate to the left hand side of the cooker when viewed from the rear and must be within 100mm from the
edge of left hand side, it must not be directly behind the appliance. The bayonet tting must be no higher than 700mm and no lower than
600mm from the oor.
The gas bayonet tting must terminate to the right hand side of the cooker when viewed from the rear and must be within 100mm from the
edge of right hand side, it must not be directly behind the appliance. The bayonet tting must be no higher than 700mm and no lower
than 600mm from the oor.
Please ensure your electricity connection is no more than 1metre away from where the appliance will be situated.
Electrical
connection
point
A 15mm BSP
socket elbow
(bayonet tting)
Gas
supply
point
VIEW FROM REAR
600mm to 700mm
Electrical
connection
point
100mm
Gas
supply
point
Electrical
connection
point
MODELS: CC92/SUK91/SUK92/CPF9GP/CPF9IP/A1/A2/A3/A4/A5
MODELS: TR4110/ TR93/ TR90*/SYD4110/SY93
The gas bayonet tting must terminate to the right hand side of the cooker when viewed from the rear and must be within 100mm from
the edge of right hand side, it must not be directly behind the appliance. The bayonet tting must be no higher than 700mm and no
lower than 600mm from the oor.
A 15mm BSP
socket elbow
(bayonet tting)
Gas
supply
point
VIEW FROM REAR
600mm to 700mm
100mm
Gas
supply
point
Electrical
connection
point
MODELS: TR103
VIEW FROM REAR
Gas
supply
point
Electrical
connection
point
Gas
supply
point
A 15mm BSP
socket elbow
(bayonet tting)
600mm to 700mm
Electrical
connection
point
100mm
*The appliance must be secured to the wall using the brackets or chain provided
ELECTRIC COOKERS
Cookers delivery and connection guide page 2/3

What to expect from your connection…
• We’ll unpack your new appliance.
• We’ll connect it to your existing gas and/or electrics, where applicable.
• We’ll position and level it.
• We’ll take away all of the packaging.
• We’ll remove your old appliance, if this service was requested at point of purchase.
IMPORTANT
Please note this is a delivery, disconnection, disposal and connection service only. Our fulfilment
partner will only connect the gas and electric supply. All necessary gas pipework and electrical points
must be in place prior to connection, any remedial work will not be undertaken and the engineer
will not be able to complete connection. If we are unable to connect your new appliance due to
requirements in this guide not being met and you require a return visit, additional charges will be
incurred.
Should you need to make any changes, or have any questions, about your delivery and connection
please contact the relevant numbers below:
• Amendments or questions relating to the booked delivery/service, contact our fulfilment partner
- tel: [phone]
• Enquiries relating to your new appliance or details of your purchase, contact the Smeg St James store
- tel: [phone]
HOT ZONE
The hot zone is the area directly above your cooker. Before connection please ensure that this area is free from
ammable items including wood, wallpaper, plug sockets, wiring or an overhanging boiler. If the hot zone isn’t
clear, we may not be able to complete your connection.
Cookers delivery and connection guide page 3/3
