Smeg S9GMXU User manual

1. IMPORTANT SAFETY INSTRUCTIONS ................................................................................. 4
2. BEFORE USING YOUR RANGE FOR THE FIRST TIME ....................................................... 5
3. DESCRIPTION OF THE RANGE CONTROLS ....................................................................... 9
4. AVAILABLE ACCESSORIES ................................................................................................. 11
5. USING THE RANGETOP ...................................................................................................... 12
6. USING THE OVEN ................................................................................................................ 15
7. ELECTRONIC PROGRAMMER ............................................................................................ 16
8. SUGGESTIONS FOR COOKING .......................................................................................... 18
9. CLEANING AND MAINTENANCE ......................................................................................... 23
10. SPECIAL MAINTENANCE ................................................................................................... 25
NOTE: THIS APPLIANCE MUST BE INSTALLED SOLELY AND EXCLUSIVELY BY A QUALIFIED
TECHNICIAN. ANY TECHNICAL PROCEDURES MUST BE CARRIED OUT BY AN AUTHORIZED
TECHNICIAN.
INSTRUCTIONS FOR THE USER: these instructions contain user advice, a description of the controls
and the correct procedures for cleaning and maintenance of the appliance.
3
WARNING: If the instructions contained in this manual are not followed
precisely, fire or explosion may result causing property damage, personal
injury or loss of life.
- Do not store or use gasoline or other flammable vapors or liquids near this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switches.
• Do not use any telephones in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service
agency or gas supplier.
Table of Contents - Important Safety Instructions

4
Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS – Your safety and the safety of others are very important.
We have provided many important safety messages throughout this manual and on the appliance.
Read all the instructions before using the appliance and always obey all safety messages.
RECOGNIZE SAFETY INFORMATION
This is a safety alert symbol. This symbol alerts you to potential hazards that can result in severe
personal injury or loss of life.
UNDERSTAND SIGNAL WORDS
A signal word – DANGER, WARNING, or CAUTION – is used with the safety alert symbol. DANGER
denotes the most serious hazards. It means you could lose your life or be seriously injured if you do not
immediately follow the instructions. WARNING means you could lose your life or be seriously injured if
the instructions are not followed. CAUTION indicates a potentially hazardous situation which, if not
avoided, could result in minor to moderate injury.
WARNING
- This appliance is intended for use in the home only.
- Use this appliance only for its intended purpose. The manufacturer cannot be
held liable for damage caused by improper use of this range.
- This appliance complies with current safety regulations. Improper use of this
range can result in personal injury and material damage.
- Read all the instructions before installing or using the range for the first time.
- Keep these operating instructions in a safe place and pass them on to any future
user.
The safety messages will inform you of potential hazards, on how to avoid the risk of injury and what can
occur if the instructions are not followed.
IMPORTANT: Observe all governing codes and ordinances. Refer to the Installation Manual for
instructions on installing the appliance.
NOTE: This range is manufactured for use with natural gas. To convert the appliance to LP/Propane
gas, see the instructions in the Gas Conversion Kit provided in the literature package.
The proper gas supply connection must be available. See "Gas supply requirements”.
WARNING: for your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, or to prevent property damage, personal injury or death
Do not store or use gasoline or other flammable vapors, liquids or materials near this or any other
appliance.

5
Important Safety Instructions
2. BEFORE USING YOUR RANGE FOR THE FIRST TIME
WARNING
TIP OVER HAZARD
- A child or adult can tip the range and be killed.
- Make sure that the anti-tip device has been properly installed and
engaged. The wall-mounted brackets should anchor the sides of the
range (primary system) or, in case of floor-mounted brackets, they
should anchor the rear of the range to the ground.
- Make sure that the anti-tip device is re-engaged when the range is
moved. The wall-mounted brackets should anchor the sides of the range
(primary system) or, in case of floor-mounted brackets, they should
anchor the rear of the range to the ground.
- Do not operate the range without the anti-tip device in place and
engaged.
- Failure to do so can result in death or serious burns to children or
adults.
WARNING
PRIMARY FASTENING SYSTEM:
Visually check that the wall-mounted brackets are inserted into the
appropriate lateral hooks (on both sides).
SECONDARY FASTENING SYSTEM:
Visually check from the inside of the drawer that the floor-mounted
bracket is inserted into the appropriate lateral hooks (left or right).
NOTE: This range is NOT designed for installation in manufactured (mobile) homes or in recreational
vehicles (RVs).
DO NOT install this range outdoors.
WARNING To reduce the risk of fire, electrical shock, personal injury, or damage when
using the range, follow basic safety precautions, including the following:
- Proper installation is your responsibility. Make sure your appliance is properly installed and grounded
by a qualified installer.
- WARNING: NEVER use this appliance as a space heater to heat or warm the room. Doing so may
result in carbon monoxide poisoning and overheating of the oven.
- DO NOT LEAVE CHILDREN UNATTENDED: Children should not be left alone or unattended in the
area where the appliance is being used. Never allow children to sit or stand on any part of the
appliance.
- CAUTION - Do not store items of interest to children in cabinets above a range or on the backguard
of a range - children climbing on the range to reach itemscould be seriously injured.
- WEAR PROPER APPAREL: loose-fitting or hanging garments should never be worn while using the
appliance.
- For safety reasons and to avoid damage to your appliance, never sit, stand or lean on the oven door.

6
Important Safety Instructions
- FLAMMABLE MATERIALS SHOULD NEVER BE STORED IN THE OVEN OR NEAR THE
SURFACE BURNERS.
- GREASE IS FLAMMABLE: Allow hot grease to cool before attempting to handle it. Do not allow
deposits of grease to accumulate.
- DO NOT USE WATER ON GREASE FIRES: Turn the appliance off and smother the fire with baking
soda or use a dry chemical or a foam-type extinguisher.
- USE ONLY DRY POTHOLDERS: Moist or damp potholders on hot surfaces may cause burns from
steam. Do not allow potholders to touch hot surface burners. Do not use towels or other bulky cloth in
place of potholders.
- Never allow garments, potholders or other flammable materials to come into direct or indirect contact
with burners until they have completely cooled.
- DO NOT TOUCH SURFACE BURNERS OR THE INSIDE OF THE APPLIANCE: Heating elements
may be hot even though they are dark in color. The oven cavity can be hot enough to cause burns.
During and after use, do not touch areas near burners or the inside of the oven until they have had
sufficient time to cool. Do not allow garments or any flammable material to come into contact with hot
surfaces. If personal clothing or hair catches on fire, drop and roll immediately to extinguish the
flames.
- PLACE THE OVEN RACKS IN THE DESIRED POSITION WHILE THE OVEN IS COOL: If a rack
must be removed while the oven is hot, do not allow the potholders to come in contact with the broiler
burner.
- USE CAUTION WHEN OPENING THE OVEN DOOR: Allow hot air or steam to escape before
removing or placing foods in the oven.
- Do not leave the packing materials around the home. Sort the various items of waste and take them
to the nearest specialized waste collection facility.
- Do not obstruct oven vents or openings for air intake.
- ELECTRICAL GROUNDING IS REQUIRED. It is the customer’s responsibility:
a) To contact a qualified electrician.
b) To ensure that the electrical system is adequate and in compliance with the National Electrical
Code ANSI / NFPA 70 Electrical Code – latest edition – Or the CANADIAN ELECTRICAL CODE,
C22.11 – 1982 and C22.2 No. 01982 – or latest edition – and all local codes and ordinances.
- Always check that the controls are in the "zero" (off) position when the range is not in use.
- Use only pots or pans with a perfectly smooth, flat bottom on the range surface burners. NEVER
USE THE RANGETOP AS A WORK SURFACE.

7
Important Safety Instructions
- Do not attempt to repair or replace any part of this appliance unless specifically recommended in this
manual. All other servicing should be done by a qualified technician.
- Never use any part of the range or oven for storage. Flammable materials can ignite and plastic
items may melt or burst into flame.
- Do not hang articles on any part of the appliance or place anything against the oven. Some fabrics
are extremely flammable and could ignite.
- DO NOT USE ALUMINUM FOIL TO LINE ANY PART OF THE OVEN OR RANGETOP. Use of a foil
liner can result in an electrical shock or fire hazard or obstruct the flow of heat and air. Foil is an
excellent heat insulator, allowing heat to be trapped under it. This can interfere with cooking and can
damage the enamel of the oven.
- Prevent aluminum foil from contacting the heating elements.
- Never leave the range unattended when using high heat settings. Boilover can cause smoke and
spattered grease can ignite.
IMPORTANT: After a spill or boilover, turn off the burner and clean around it. After cleaning, check
that the burner functions properly.
- Not all types of glass, thermally resistant glass-ceramic, ceramic, earthenware, or other glazed
cookware are suitable for range use. This type of cookware can break with sudden temperature
changes. Use only on low or medium heat settings in accordance with the instructions supplied by
the manufacturer.
- DO NOT HEAT UNOPENED FOOD CONTAINERS: A buildup of pressure can cause the containers
to burst.
- DO NOT USE FLAMMABLE PRODUCTS TO CLEAN THE RANGE.
- Do not clean, rub, damage or remove the oven door gasket. It is essential for a good, tight seal
during baking and when the self-clean cycle is engaged. Replace the oven door gasket if it becomes
damaged or encrusted with food residue.
- Be sure all range surface burners controls are turned off and that the rangetop is cool before using
any type of cleaning product. The chemical elements in these products could, in the presence of
heat, ignite or cause metal parts to corrode.
- ONLY QUALIFIED SERVICE PERSONNEL SHOULD PERFORM REPAIRS. Service personnel must
disconnect the power supply before servicing this unit.
NOTE: The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of
California to publish a list of substances known to the State of California to cause cancer, birth defects
or other reproductive harm, and requires businesses to warn customers of potential exposure to such
substances.
WARNING: This product contains a chemical known by the State of California to cause cancer, birth
defects or other reproductive harm.
This appliance can cause low-level exposure to some of the substances listed, including benzene,
formaldehyde, carbon monoxide, toluene, and soot.

8
Important Safety Instructions
WARNING
TIP OVER HAZARD
- A child or adult can tip the range and be killed.
- Make sure that the anti-tip device has been properly installed and
engaged. The wall-mounted brackets should anchor the sides of the
range (primary system) or, in case of floor-mounted brackets, they
should anchor the rear of the range to the ground.
- Make sure that the anti-tip device is re-engaged when the range is
moved. The wall-mounted brackets should anchor the sides of the range
(primary system) or, in case of floor-mounted brackets, they should
anchor the rear of the range to the ground.
- Do not operate the range without the anti-tip device in place and
engaged.
- Failure to do so can result in death or serious burns to children or
adults.
MAKE SURE THAT YOUR RANGE IS PROPERLY SECURED AND THE ANTI-TIP DEVICE IS
CORRECTLY INSTALLED. REFER TO THE INSTRUCTIONS INSIDE THE INSTALLATION MANUAL.
- Do not stand or sit on the oven door or drawer.
- Remove all packing materials and temporary labels from the oven and rangetop.
- Record the Model and Serial number on Page 2 of this booklet. The Model and Serial numbers are
on the Range ID plate. The ID Plates are visibly located on the back of the appliance and on the oven
door frame. THE ID PLATE MUST NOT BE REMOVED.
- BEFORE BAKING OR BROILING FOR THE FIRST TIME, turn on the oven and broiler to burn off
any dirt, oil or grease remaining from the manufacturing process. Turn the oven on and set to 450°F
(230°C) for 20 to 30 minutes, then turn on the broiler for the same amount of time.
SAVE THESE INSTRUCTIONS

Instructions for the user
9
3. DESCRIPTION OF THE RANGE CONTROLS
All the range selectors and controls are located on the front panel.
FRONT CONTROL PANEL
THERMOSTAT KNOB
The cooking temperature is set by turning the knob clockwise to the desired
temperature, between 120° and 500° F. The tell-tale light comes on to
indicate that the oven is warming up. When it goes out it means that the
desired temperature has been reached. Regular flashing means that the
oven temperature is being constantly maintained at the programmed level.
OVEN FUNCTION SELECTOR KNOB
Turn this knob to select from the following functions:
NO FUNCTION SET
TOP AND BOTTOM HEAT
BOTTOM HEAT
SMALL BROILER
BROILER
CONVECTION BROILER
EUROPEAN CONVECTION WITH TOP AND BOTTOM HEAT
EUROPEAN CONVECTION
DEFROST

Instructions for the user
10
ELECTRONIC PROGRAMMER
Useful for displaying the current time, set programmed cooking operations
and program the timer.
RANGETOP BURNER COMMAND KNOB
To light surface burners, push and turn the appropriate knob
counterclockwise to the simmer flame symbol . To adjust the flame,
turn the knob to any position between the maximum and minimum
marks .
To turn off, turn the knob to the position.
NOTE: Do not use the appliance when the FAN FAILURE light remains constantly on.

Instructions for the user
11
4. AVAILABLE ACCESSORIES
The oven features 4 rack support for arranging oven trays and racks at
different heights.
Oven rack: for cooking food on oven trays, small cakes, roasts or food
requiring light broiling.
Oven tray: for catching grease and oil from foods placed on the rack
above and for baking cakes, pizza and desserts.
Anti-tip device: helps prevent pans from tipping.
The oven accessories which may come into contact with foods are made from materials compliant with
that required by the current regulations.
The anti-tip device is an integral part of the appliance. It needs to be fastened to the appliance before
installing the appliance.
4.1 Using the rack or tray
The racks and trays are equipped with a mechanical safety lock which
prevents them from being accidentally taken out. To insert the rack or
tray correctly, check that the lock is facing downwards (as shown in the
figure alongside).
To remove the rack or tray, lift the front slightly.
The mechanical lock (or raised rack, where present) must always face
the back of the oven.
Gently insert the racks and trays into the oven until they come to a stop.
Clean the trays before using them for the first time. Cleaning prevents any manufacturing residues from
leaving mild scratches on the side walls of the oven when the tray is inserted.

Instructions for the user
12
5. USING THE RANGETOP
WARNING
FIRE HAZARD
- For your safety: do not allow the burner flame to
extend beyond the edge of the pan.
- Turn off all controls when the range is not in use.
NOTE: Check that the burner heads, burner caps and grates are correctly positioned. Before lighting the
rangetop burners, check that each burner head is correctly positioned with its respective burner cap.
Before lighting the hob burners, make sure that the flame-spreader crowns are correctly positioned in
their housings with their respective burner caps. Make sure that the holes 1in the flame-spreader
crowns are aligned with the igniters 3and thermocouples 2.
5.1 Ignition safety device
Each burner knob has a marking corresponding to the burner it controls (the example at the left, shows
the front left burner).
The appliance is equipped with spark electrode ignition.
To light surface burners, push and turn the appropriate knob counterclockwise to the simmer flame
symbol . To adjust the flame, turn the knob to any position between the maximum and
minimum marks .
To turn off, turn the knob to the position.
REMEMBER: When the rangetop is in use, the entire range area may become hot.
NOTE: Do not try to manually relight the flame.

Instructions for the user
13
5.2 Practical advice on using the rangetop burners
NOTE: Do not obstruct the flow of heat and ventilation around the edges of the grate.
For more efficient use of the burners and lower gas consumption, use covered cookware that is
proportional in size to the burner to prevent the flame from extending beyond the sides (see paragraph
“5.3 Cookware diameter"). When water begins to boil, lower the flame so that it does not boil over. To
avoid burns or damage to the rangetop, all pots, pans or griddles must be placed within the perimeter of
the rangetop. All cookware must have a flat and smooth bottom. When cooking with grease or oil, be
extremely careful to avoid overheating and a potential grease fire. If the flame accidentally goes out, turn
the control knob to off and wait at least 1 minute before trying to relight the burner.
NOTE: Before turning on a burner, place filled cookware on the grate. Do not operate a burner with
empty cookware or without placing the cookware on the grate.
Do not leave empty cookware on a hot surface or burner.
NOTE: No attempt should be made to operate the appliance during a power failure.
5.3 Cookware diameter
BURNERS Ø min. and max. (cm) Ø min. - max. (inches)
1 Auxiliary 12 - 14 4 3/4” - 7”
2 Semi-rapid 20 - 26 6 5/16” - 9 1/2”
3 Rapid 18 - 26 7 1/8” - 10 1/4”
4 Ultra rapid 20 - 26 7 7/8” - 10 1/4”

Instructions for the user
14
5.4 Cookware
NOTE: Do not leave empty cookware on a hot surface or burner.
Ideally, cookware should have a flat bottom, straight sides, a tight-fitting lid and medium-to-heavy
thickness.
Rough cookware finishes may scratch the rangetop. Aluminum and copper may be used in cookware as
a core material or base. However, when used as a base they can leave permanent marks on the
rangetop or grates.
Cookware properties are a factor in how quickly and evenly heat is distributed, which affects cooking
results. A non-stick finish has the same characteristics as its base material. For example, a non- stick
finish on Aluminum cookware will take on the properties of aluminum.
Refer to the following chart as a guide to the physical properties of cookware.
COOKWARE PROPERTIES
Aluminum
• Heats quickly and evenly
• Suitable for all types of cooking
• Medium or heavy thickness is best for most cooking tasks.
Cast iron
• Heats slowly and evenly
• Good for browning and frying
• Maintains heat for slow cooking.
Ceramic or glass-ceramic
• Follow the manufacturer’s instructions
• Heats slowly but unevenly
• Best results with low to medium heat settings.
Copper • Heats very quickly and evenly
Earthenware • Follow the manufacturer’s instructions
• Use low heat settings
Porcelain enameled steel or cast
iron • See stainless steel or cast iron
Stainless steel
• Heats quickly but unevenly
• Stainless steel cookware with aluminum or copper as a core
material or bottom provides even heating.

Instructions for the user
15
6. USING THE OVEN
6.1 General Instructions
NOTE: Before using the oven for the first time, pre-heat it to the maximum temperature (500°F), long
enough to burn any manufacturing oily residues which could give the food a bad taste. After a power
failure, the display will flash at regular intervals, showing 0:00. To adjust, refer to paragraph “7.
ELECTRONIC PROGRAMMER”.
WARNING
BURN HAZARD
To prevent burns caused by steam in the oven,
open the door in two stages: partially open
(approximately 5 cm or 2 inches) for 4- 5
seconds, long enough to permit the steam to
escape, and then fully open.
When accessing the food in the oven, always
leave the door open the shortest possible time
to prevent the oven temperature from falling
and ruining the food.
WARNING Never cover any slots, ports or orifices in the oven bottom or cover an
entire rack with materials such as aluminum foil. Doing so blocks air flow
through the oven and may lead to carbon monoxide poisoning. Aluminum
foil linings may also trap heat, creating a fire hazard.
6.2 Oven light
It illuminates when the function selector knob is turned to the oven light setting .
NOTE: Do not obstruct the air intake vents located on the upper part of the storage compartment.

Instructions for the user
16
7. ELECTRONIC PROGRAMMER
LIST OF FUNCTIONS
Timer key
End of cooking key
Cooking duration key
Value decrease key
Value increase key
7.0.1 Setting the time
On the first use, or after a power failure, will be flashing on the oven's display. Press the
and keys together, and at the same time press the value adjustment keys or : this will
increase or decrease the setting by one minute for each pressure.
Press either of the value modification keys to display the current time.
Before each programmer setting, activate the required function and temperature.
7.0.2 Timed cooking
Timed cooking is the function which allows a cooking operation to be started and then ended after a
specific length of time set by the user.
Press the key and the display will light up showing the figures ; keep it pressed, and at the
same time use the keys or to set the cooking duration.
When is released, the count of the programmed cooking duration will start and the display will show
the current time together with and A (to indicate that a programmed cooking operation has been
set).
7.0.3 Programmed cooking
This function switches the oven on and off in fully automatic mode.
Press the key and the display will light up showing the figures ; keep it pressed, and at the
same time use the value modification keys or to set the cooking duration.
Press the key and the display will show the sum of the current time plus the cooking duration: keep
it pressed, and at the same time use the value modification keys or to adjust the end of cooking
time.
When the key is released, the programmed count will start and the display will show the current time
together with the symbols Aand .
After making the setting, press the key to view the remaining cooking time; press the key to view
the cooking end time. The logic prevents the setting of incompatible values (e.g. the programmer will not
accept a cooking end time with a duration which is too long for its value).

Instructions for the user
17
7.0.4 End of cooking
At the end of the cooking time the oven will switch off automatically and simultaneously a buzzer will start
to sound intermittently. After the buzzer has been deactivated, the display will return to show the current
time together with the symbol to indicate that the oven has returned to manual use mode.
7.0.5 Timer
The programmer can also be used as an ordinary timer.
Press the key and the display will show the figures ; keep pressed and simultaneously
press the value modification keys or . When the key is released the count will start and the
display will show the current time and the symbol .
After the setting, to display the time left press the key.
In timer mode, the oven operation will not be cut out at the end of the set time.
7.0.6 Adjusting the buzzer volume
The buzzer volume can be varied (3 settings) while it is in operation by pressing .
7.0.7 Stopping the buzzer
The buzzer stops automatically after about seven minutes. It can be deactivated manually by pressing
keys and together.
To switch off the appliance, return all the knobs to the 0 setting.
7.0.8 Deleting the set data
Having programmed a timed or programmed cooking operation, this programming can be cancelled by
holding down the key for the function which has just been programmed and simultaneously pressing
or until appears on the display.
The programmer will interpret the cancellation of the program as terminating the cooking operation.
7.0.9 Modifying the set data
The set cooking data can be modified at any time by holding down the function key and at the same time
pressing the keys or to change the value.

Instructions for the user
18
8. SUGGESTIONS FOR COOKING
WARNING BURN HAZARD
Keep the oven door closed during cooking.
NOTE : In fan-assisted mode, the oven should be preheated to 90-100°F above the recommended cooking
temperature. This considerably shortens the cooking time, reduces power consumption and provides more even
cooking.
8.1 Conventional cooking
FUNCTION SELECTOR
THERMOSTAT SELECTOR FROM 120° TO 500°F
In conventional cooking, heat circulates from bottom to top; this is
ideal for cooking food on a single rack. Preheat the oven to the
desired temperature and put the food in the oven only after the
thermostat light has gone out. Very fatty meats may be put in
when the oven is still cold. Frozen meat can be placed directly in
the oven without waiting for it to thaw. However, set the
temperature about 70°F lower and allow 25% more time for
cooking.
NOTE: Use pans with deep sides to prevent oil/grease from splattering and soiling
the walls of the oven.

Instructions for the user
19
8.2 Convection cooking
FUNCTION SELECTOR
THERMOSTAT SELECTOR FROM 120° TO 500°F
Convection can be used to cook food simultaneously on several
rack positions, even when different types of food (fish, meat etc.)
are used, without mixing tastes and aromas. Air circulation in the
oven ensures a uniform distribution of heat. Pre-heating is not
necessary.
NOTE: Simultaneous cooking of multiple foods is possible as long as the cooking temperature required
for the different foods is the same.
8.3 Broiler
FUNCTION SELECTOR
THERMOSTAT SELECTOR AT MAXIMUM AND DOOR
CLOSED
Browns food rapidly. It is recommended that the broiling pan be
placed on the 3rd rack.
For short cooking times or small quantities, place the rack on the
third runner from the bottom. For longer cooking times and for
broiling, put the rack on the lowest runner depending on the size
of the food.
NOTE: Keep the oven door closed during cooking.

Instructions for the user
20
8.4 Broiler with hot air
FUNCTION SELECTOR
THERMOSTAT SELECTOR AT MAXIMUM AND DOOR
CLOSED
This permits a uniform distribution of heat and greater heat
penetration. Food will be lightly browned on the outside and
remain tender inside.
NOTE: Keep the oven door closed during cooking. Heating time must not exceed 60 minutes.
8.5 Defrosting
FUNCTION SELECTOR
THERMOSTAT SELECTOR IN POSITION 0
The flow of air generated by the fan ensures rapid defrosting.
The air circulating inside the oven is at room temperature.
NOTE: The advantage of defrosting at room temperature is that it does not alter the taste or appearance
of the food.

Instructions for the user
21
8.6 Recommended cooking chart
Cooking times, especially for meats, can vary according to the thickness and quality of the food as well
as personal taste.
CONVENTIONAL COOKING
RACK
POSITION
TEMPERATURE
(°F)
TIME IN
MINUTES (*)
FIRST COURSES
LASAGNA
OVEN-BAKED PASTA
2 - 3
2 - 3
390 - 410
410 - 450
50 - 60
40
MEAT
VEAL ROAST
BEEF ROAST
PORK ROAST
CHICKEN
DUCK
GOOSE - TURKEY
RABBIT
LEG OF LAMB
2
2
1 - 2
1 - 2
2
2
2
2
350 - 390
410 - 470
350 - 400
350 - 400
350 - 400
300 - 350
350 - 400
350 - 400
15 - 20 /LB.
15 - 20 /LB.
100 - 110
80 - 90
110 - 130
45 - 60
100 - 120
40 - 50
FISH 1 338 - 392 ACCORDING TO THE
SIZE OF THE FISH
PIZZA 1 - 2 430 - 470 20 - 25
DESSERTS
SMALL PASTRIES
BUNDT CAKE
TA RT S
FRUIT CAKE
ANGEL CAKE
APPLE CAKE
RICE CAKE
1 - 2
1 - 2
1
1 - 2
1 - 2
1
1
340 - 400
340
360 - 400
340 - 400
320
400
360
15 - 20
60 - 70
30 - 40
20 - 30
60
60
60 - 70
(*) = PREHEATED OVEN
BROIL
RACK
POSITION
TIME IN
MINUTES (*)
FIRST SIDE SECOND SIDE
PORK CHOPS
FILLET OF PORK
FILLET OF BEEF
LIVER
VEAL CHOPS
HALF CHICKEN
SAUSAGES
MEATBALLS
FILLET OF FISH
TOAST
3
3
3
3
3
3
3
3
3
3
7 - 9
9 - 11
9 - 11
2 - 3
7 - 9
9 - 14
7 - 9
7 - 9
5 - 6
2 - 4
5 - 7
5 - 9
9 - 11
2 - 3
5 - 7
9 - 11
5 - 6
5 - 6
3 - 4
2 - 3

Instructions for the user
22
CONVECTION COOKING
RACK
POSITION
TEMPERATURE
(°F)
TIME IN
MINUTES (*)
FIRST COURSES
LASAGNA
OVEN-BAKED PASTA
2
2
370 - 400
370 - 400
40 - 50
25 - 30
MEAT
VEAL ROAST
PORK ROAST
BEEF ROAST
FILLET OF BEEF
ROASTED LAMB
BEEF ROAST
ROASTED CHICKEN
ROASTED DUCK
ROASTED TURKEY BREAST
ROASTED RABBIT
ROASTED HARE
ROASTED PIGEON
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
300 - 340
300 - 320
320 - 340
320 - 360
270 - 300
340 - 360
340
340 - 360
320 - 340
320 - 340
320 - 340
280 - 340
65 - 90
70 - 100
65 - 90
35 - 45
100 - 130
40 - 45
70 - 80
100 - 120
90
80 - 100
30 - 50
15 - 25
FISH 2 - 3 302 - 338 ACCORDING TO THE
SIZE OF THE FISH
PIZZA
BREAD
TOAST
2 - 3
2 - 3
1 - 2
410 - 450
370 - 400
430 - 470
15 - 20
40
7
DESSERTS
BUNDT CAKE
FRUIT CAKE - FRUIT FLAN
TA RT S
SMALL PASTRIES
RICE CAKE
APPLE CAKE
ANGEL CAKE
2 - 3
2 - 3
2 - 3
2 - 3
2 - 3
2 - 3
2 - 3
300 - 340
340 - 380
320 - 340
340 - 360
340
360
320
35 - 45
65 - 40
20 - 25
20
50 - 60
60
60
(*) = PREHEATED OVEN
