Smeg DDW119.1 User manual

MANUALE D’USO
INSTRUCTION MANUAL
NOTICE D’UTILISATION
GEBRAUCHSANWEISUNG
MANUAL DE USO
LAVASTOVIGLIE
DISHWASHER
LAVE-VAISSELLE
GESCHIRRSPÜLER
LAVAVAJILLAS

ITALIANO 3-30
ENGLISH 31-58
FRANÇAIS 59-86
DEUTSCH 87-114
ESPAÑOL 115-142

Contents
31
1. Safety and operating instructions __________________________32
2. Installation and hook-up _________________________________35
3. Description of the controls________________________________37
4. Operating instructions ___________________________________43
5. Cleaning and maintenance _______________________________55
Thank you for choosing this product.
We advise you to carefully read all the instructions contained in this
manual, in order to understand how to operate your dishwasher safely
and correctly.
The manual is divided into paragraphs, which provide a step by step
description of the dishwasher functions, with clear instructions
accompanied by detailed illustrations.
Recommendations are given for the correct use of the baskets, spray
arms, containers, filters, washing programs, and for operating the
controls.
Follow the recommended cleaning procedures to ensure that your
dishwasher always remains in perfect working order.
This manual provides a quick and easy reference for answering all your
questions concerning the use of your new dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified
technician who must carry out the installation, hook-up and testing of
the appliance.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.

Safety instructions
32
1. Safety and operating instructions
THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST
ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE
USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS
CONTAINED IN THIS MANUAL.
INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN
COMPLIANCE WITH THE REGULATIONS IN FORCE. THIS APPLIANCE IS
INTENDED FOR DOMESTIC USE, AND COMPLIES WITH THE EEC
DIRECTIVES 72/23, 897336 (INCLUDING 92/31) CURRENTLY IN FORCE,
INCLUDING THE PREVENTION AND ELIMINATION OF RADIO FREQUENCY
INTERFERENCE.
THE APPLIANCE IS DESIGNED FOR THE FOLLOWING PURPOSE: WASHING
AND DRYING OF DISHES; ANY OTHER USE SHALL BE CONSIDERED
IMPROPER. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR
USES OTHER THAN THOSE DESCRIBED ABOVE.
THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER
AND MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE
DOOR. THE NAME PLATE ON THE INNER EDGE OF THE DOOR MUST
NEVER BE REMOVED.
DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED
WITHIN THE HOME. SEPARATE THE VARIOUS MATERIALS WHICH MAKE
UP THE PACKAGING AND TAKE THEM TO THE NEAREST SORTED WASTE
COLLECTION CENTRE.
THE APPLIANCE MUST BE PROVIDED WITH AN EARTH CONNECTION IN
ACCORDANCE WITH THE ELECTRICAL SAFETY REGULATIONS IN FORCE.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE TO
PERSONS OR PROPERTY RESULTING FROM THE FAILURE TO EARTH THE
APPLIANCE OR FROM A DEFECTIVE EARTH CONNECTION.
IF THE APPLIANCE IS NOT CONNECTED TO THE ELECTRICAL POWER
SUPPLY BY MEANS OF A PLUG, IT IS NECESSARY TO INSTALL AN
ISOLATION SWITCH WITH A CONTACT OPENING GAP OF AT LEAST 3 MM.
THE PLUG ON THE POWER CORD AND THE CORRESPONDING SOCKET
OUTLET MUST BE OF THE SAME TYPE, AND MUST CONFORM TO THE
REGULATIONS IN FORCE. CHECK THAT THE VOLTAGE AND FREQUENCY
OF THE ELECTRICAL POWER SUPPLY MATCH THE RATINGS ON THE
NAME PLATE. AVOID USING ADAPTORS OR SHUNT CONNECTIONS.
NEVER UNPLUG THE APPLIANCE BY PULLING THE POWER CORD.

Safety instructions
33
•AFTER INSTALLATION, THE PLUG MUST REMAIN ACCESSIBLE.
•IN THE EVENT OF DAMAGE TO THE POWER CORD, HAVE IT
REPLACED BY A QUALIFIED TECHNICIAN.
•AFTER REPLACING THE POWER CORD, MAKE SURE THAT THE
TERMINAL BLOCK COMPARTMENT COVER IS CLOSED CORRECTLY.
IF THE APPLIANCE IS INSTALLED ON A CARPETED OR COVERED FLOOR,
ENSURE THAT THE OPENINGS ON ITS UNDERSIDE ARE NOT
OBSTRUCTED.
ALWAYS SWITCH OFF THE DISHWASHER AFTER EACH USE TO AVOID
WASTING ELECTRICITY.
OBSOLETE APPLIANCES MUST BE RENDERED UNUSABLE. CUT OFF THE
MAINS POWER CORD AFTER UNPLUGGING IT FROM THE WALL OUTLET,
AND MAKE SAFE ANY COMPONENTS WHICH MIGHT BE DANGEROUS FOR
CHILDREN (LOCKS, DOORS, ETC.). THE APPLIANCE MUST THEN BE TAKEN
TO A SORTED WASTE COLLECTION CENTRE.
IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE
ELECTRICAL POWER SUPPLY AND SHUT OFF THE WATER TAP. THEN
CALL IN A QUALIFIED TECHNICIAN.
DO NOT USE APPLIANCES WHICH HAVE BEEN DAMAGED DURING
TRANSIT! IF IN DOUBT, CONSULT YOUR DEALER.
THE APPLIANCE MUST BE INSTALLED AND CONNECTED IN ACCORDANCE
WITH THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER OR BY A
QUALIFIED TECHNICIAN.
THE APPLIANCE IS INTENDED FOR USE BY ADULTS. DO NOT ALLOW
CHILDREN TO COME NEAR OR PLAY WITH THE DISHWASHER. KEEP
CHILDREN AWAY FROM DETERGENTS AND FROM THE OPEN
DISHWASHER DOOR. THE PACKAGING MATERIALS (PLASTIC BAGS,
POLYSTYRENE, METAL BARS, ETC.) MUST NOT BE LEFT WITHIN THE
REACH OF CHILDREN.
KEEP CHILDREN AWAY FROM THE OPEN DISHWASHER. THE APPLIANCE
MAY CONTAIN RESIDUES OF DETERGENT WHICH CAN CAUSE
IRREVERSIBLE DAMAGE TO THE EYES, MOUTH, AND THROAT, AS WELL
AS POSSIBLE DEATH BY SUFFOCATION.
DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE
WHICH MAY CAUSE AN EXPLOSION.
DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINTS.

Safety instructions
34
DO NOT LEAN OR SIT ON THE OPEN DOOR: THIS MAY CAUSE THE
DISHWASHER TO OVERTURN.
DO NOT UNDER ANY CIRCUMSTANCES TOUCH THE HEATING ELEMENT
IMMEDIATELY AFTER THE END OF A WASHING PROGRAM.
DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE
THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM
AND BEFORE THE DRYING CYCLE.
AQUASTOP MODELS
THE AQUASTOP DEVICE PREVENTS FLOODING IN THE EVENT OF A
WATER LEAK. WHEN THE AQUASTOP DEVICE IS TRIPPED, CALL IN A
QUALIFIED TECHNICIAN TO IDENTIFY AND REPAIR THE FAULT.
IN MODELS EQUIPPED WITH THE AQUSTOP DEVICE, THERE IS A
SOLENOID VALVE INSIDE THE WATER INTAKE HOSE. DO NOT CUT THE
HOSE AND DO NOT ALLOW THE SOLENOID VALVE TO DROP INTO
WATER. IN THE EVENT OF DAMAGE TO THE WATER INTAKE HOSE,
DISCONNECT THE APPLIANCE FROM THE ELECTRICAL POWER SUPPLY
AND FROM THE WATER SUPPLY.
IMMEDIATELY AFTER INSTALLING THE DISHWASHER, PERFORM A QUICK
TEST OF THE APPLIANCE FOLLOWING THE INSTRUCTIONS BELOW. IF
THE DISHWASHER FAILS TO OPERATE CORRECTLY, DISCONNECT IT
FROM THE ELECTRICAL POWER SUPPLY AND CALL THE NEAREST
TECHNICAL SERVICE CENTRE. DO NOT ATTEMPT TO REPAIR THE
APPLIANCE.
THE DISHWASHER MEETS ALL THE REQUIREMENTS SET OUT BY THE
REGULATIONS IN FORCE CONCERNING SAFETY AND ELECTRICAL
EQUIPMENT. ANY TECHNICAL CHECKS SHOULD BE CONDUCTED
EXCLUSIVELY BY A TRAINED AND AUTHORISED TECHNICIAN: REPAIRS
CARRIED OUT BY UNAUTHORISED PERSONS WILL INVALIDATE THE
WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER.
The manufacturer declines all responsibility for damage to persons or property
resulting from failure to observe the above precautions, from tampering with
even a single component of the appliance, or from the use of non original
spare parts.

Installation instructions
35
2. Installation and hook-up
Remove the polystyrene basket retainers.
Position the appliance in the desired place of installation. The back or
sides of the dishwasher may be placed up against walls or other
furniture units. If the dishwasher is installed near a heat source, fit the
special insulating panel to prevent overheating and malfunction of the
appliance.
To ensure stability, install integrated or built-under dishwashers only
under continuous worktops, and screw them to the adjacent units.
To facilitate the installation procedure, the intake and drain hoses can be
positioned in any direction; make sure that the hoses are not kinked,
crushed or pulled too tightly.
Level the appliance on the floor using its adjustable feet. This operation
is essential for ensuring correct operation of the dishwasher.
Some models are equipped with only one adjustable foot at the rear,
which can be adjusted by turning the screw on the lower front part of the
appliance.
2.1 Water supply connection
Preventing the risk of clogging or damage: if the water pipe is new or
has not been used for a long time, before connecting to the water supply
check that the water is clear and free of impurities, to prevent damage to
the appliance.
CONNECTING TO THE WATER SUPPLY
Connect the intake hose to a cold water supply
with 3/4” gas thread, inserting the filter Asupplied
with the dishwasher, and taking care to screw it
firmly into the tap.
In dishwashers equipped with the AQUASTOP
device, the filter is already fitted inside the
threaded ring.

Installation instructions
36
The dishwasher can also be connected to a hot water supply not
exceeding 60°C. Supplying the appliance with hot water cuts down the
washing time by approximately 20 minutes, but slightly reduces its
effectiveness. Make the connection to the domestic hot water supply
using the same procedure described for connecting to the cold water
supply.
DRAIN CONNECTION
Insert the dishwasher’s drain
hose into a drain pipe having a
diameter of at least 4 cm, or
alternatively, place it inside the
kitchen sink using the plastic
support provided, taking care not
to crush or excessively bend the
hose. It is important to prevent
the hose from coming loose and
falling. For this purpose, the
plastic support is equipped with a
hole for tying it to the wall or
water tap.
The free end should be positioned at a height of between 30 and 100
cm,and should never be submerged in water.
If a horizontal drain extension hose is used (for a maximum of 3 m) the
drain hose can be placed at a maximum height of 85 cm from the
ground.
2.2 Electrical connection
Plug the power cord into a suitable electrical outlet, according to the
instructions given in chapter "1. Safety and operating instructions".

User instructions
37
3. Description of the controls
3.1 Front panel
All the dishwasher controls are grouped on the front panel, which is of
different shape depending on the model.
CONTROL LEGEND (for models with ½ load function)
1WASHING PROGRAM SELECTOR
2SELECTED PROGRAM INDICATOR DISC (certain models only)
3ON/OFF BUTTON
4½ LOAD WASH BUTTON
5ECO (55°C) PROGRAM BUTTON
6SUPER PROGRAM BUTTON
7POWER ON LIGHT
8SALT WARNING LIGHT (certain models only)
9RINSE AID WARNING LIGHT (certain models only)
10 SELECTOR SWITCH FOR DELAYED START FROM 1 TO 12 HOURS
(certain models only)
11 DELAYED START INDICATOR DISC (certain models only)
12 BUTTON FOR DELAYED START FROM 1 TO 9 HOURS
(certain models only)

User instructions
38
13 DELAYED START INDICATOR DISPLAY (certain models only)
14 RECESSED DOOR HANDLE
CONTROL LEGEND (for models without ½ load function)
1WASHING PROGRAM SELECTOR
2SELECTED PROGRAM INDICATOR DISC (certain models only)
3ON/OFF BUTTON
4ECO (55°C) PROGRAM BUTTON
5SUPER PROGRAM BUTTON
6not present
7POWER ON LIGHT
8SALT WARNING LIGHT (certain models only)
9RINSE AID WARNING LIGHT (certain models only)
10 SELECTOR SWITCH FOR DELAYED START FROM 1 TO 12 HOURS
(certain models only)
11 DELAYED START INDICATOR DISC (certain models only)
12 BUTTON FOR DELAYED START FROM 1 TO 9 HOURS
(certain models only)
13 DELAYED START INDICATOR DISPLAY (certain models only)
14 RECESSED DOOR HANDLE
SETTING THE WASHING PROGRAM
To select the most suitable washing program, refer to the table below
which indicates the recommended washing according to dish type and
the degree of soiling.
After using the table to identify the most appropriate washing program,
turn the PROGRAM SELECTION knob (1) to set the program of choice
by aligning the pointer with the program number.
If necessary, depending on the program chosen, press one of the keys
(4,5,6) which allow selection of the ½ LOAD, at 55°C, or the SUPER
wash program.
If the appliance is fitted with the SELECTED PROGRAM (2) indicator
disc, this will show the number of the program set. Now simply pressing
the ON/OFF key (3) will start the program. The PILOT LIGHT (7) lights
up.

User instructions
39
TABLE OF PROGRAMS
AMOUNT OF
DETERGENT DURATION CONSUMPTION
SWITCH
CYCLE AND
BUTTON
TYPE AND
DEGREE
OF DIRT
ON DISHES
PROGRAM
SEQUENCE GRAMS MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
SOAK
1_
Pans and dishes
while waiting
for load to be
completed
Cold prewash _6' 4_
SUPER
2SUPER
(65°C)
(1/2)
Heavily
soiled pans and
dishes, including
dried-on residue
Prewash at 45°C
Wash at 65°C
2 cold rinses
Rinse at 65°C
Dry
10 + 25 110' 22 1,65
BIO 55°C
(*)
2ECO
55°C
(1/2)
Normally
soiled pans and
dishes, including
dried-on residue
Cold prewash
Wash at 55°C
Cold rinse
Rinse at 65°C
Dry
30 96' 18 1,28
NORMAL
65°C
2
(1/2)
Normally soiled
pans and dishes
Cold prewash
Wash at 65°C
Cold rinse
Rinse at 65°C
Dry
30 100' 18 1,45
ECO 55°C
(**) EN 50242
3ECO
55°C
(1/2)
Slightly
soiled pans and
dishes, including
dried-on residue
Wash at 55°C
Cold rinse
Rinse at 65°C
Dry
30 90' 16 1,24
DAILY
65°C
3
(1/2)
Normally soiled
pans and dishes
Wash at 65°C
Cold rinse
Rinse at 65°C
Dry
30 92' 16 1,40
DELICATE
45°C
4
(1/2)
Slightly
soiled dishes
Wash at 45°C
Cold rinse
Rinse at 65°C
Dry
25 62' 13 1,10
Only run the soak program with half loads.
The HALF LOAD option (4) is available for all programs except the soak program.
(*) Program recommended when using “new generation” detergents containing enzymes.
(**) Reference program as per EN 50242 standard.
(–) Not present.
(1) Average power consumption with the softener set on level 2.
(2) The cycle duration and power consumption may vary according to the water and room
temperatures, and the type and amount of dishes.

User instructions
40
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.
TABLE FOR CERTIFICATION BODIES
Reference standard EN 50242
Reference program Selector on 3+ ECO 55°C button
Load 12 place-settings
Type of detergent B
Amount of detergent 30 g
Rinse aid setting Depending on the model 3/4 or 4/6
EN 50242
3.2 Washing programs
Before starting a washing program make sure that:
•The water supply tap is open.
•The correct amount of detergent has been added to the
dispenser.
•The baskets have been correctly loaded.
•The spray arms are able to rotate freely and without
obstruction.
•The dishwasher door is securely closed.
HALF LOAD WASH SETTING
This function is especially suitable for loads up to 6
place settings and allows saving of water and
electricity. It is controlled by the HALF LOAD
button (4) (see section "3. Description of the
controls") and allows washing in the upper basket
only.

User instructions
41
IMPORTANT: at the end of the program remember to deactivate the
function to ensure the next wash is not also carried out in half load
mode by mistake.
A cutlery basket can be placed in the upper basket, while the lower basket
must be left empty.
CAUTION: there is no point in loading dishes and cutlery in the lower
basket, since the jet of water will only reach the upper basket.
CANCELLING THE CURRENT PROGRAM
To cancel the program in progress the dishwasher must be switched off
by pressing the ON/OFF key (3) (see section "3. Description of the
controls").
Turn the program selector to SOAK and wait for the dishwasher to start.
On completion of the program, switch off the dishwasher by pressing the
ON/OFF key (3).
CHANGING THE PROGRAM
To change the program in progress the dishwasher must be switched off
by pressing the ON/OFF key (3) (see section "3. Description of the
controls").
Turn the program selector to the program required and then switch the
dishwasher on again by pressing ON/OFF key (3). The dishwasher will
carry out the new program automatically.
PROGRAM DELAY
The start of the washing program can be delayed by from 1 to 9 or from
1 to 12 hours, depending on model. This allows you to operate the
dishwasher at the time of day most convenient to you.
Models with delay up to 9 hours:
after carrying out the operations described in the "SETTING THE
WASHING PROGRAM" section you have about 1 minute to set the
“delay” you require, by pressing the button DELAYED START (12) (see
section "3. Description of the controls"). The hours left before the start of
the program will be shown on the DISPLAY (13).
Models with delay up to 12 hours:
using the DELAYED START switch (10) (see section "3. Description of
the controls") set the “delay” required by setting the pointer against the
number indicating the hours. Then carry out the usual program setting
procedures.
CAUTION: always turn the switch clockwise.

User instructions
42
TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT
•Always try to run the dishwasher fully loaded.
•Do not wash the dishes in running water.
•Use the washing program that is most appropriate for each type of
load.
•Do not carry out any preliminary rinsing.
•If available, connect the dishwasher to a hot water supply up to
60°C.
•When possible, disable the drying cycle and leave the door open
at the end of the washing cycle: the residual air and heat will dry the
dishes perfectly.
TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT
THE ENVIRONMENT
The phosphates contained in dishwasher detergents are harmful to the
environment. To avoid using excessive amounts of detergent and to
save on electricity, observe the following:
•separate the more delicate items from dishes that are more
resistant to aggressive detergents and high temperatures;
•do not pour the detergent directly on the dishes.
If it is necessary to open dishwasher door during the washing cycle,
there will be a 1-minute delay before the program can be resumed.
After correctly closing the door, the washing program will start again from
where it was interrupted. This operation may negatively affective the
progress of the washing cycle.
END OF CYCLE
At the end of the washing program the selector will be on one of the
STOP markers, depending on the program carried out. Switch off the
dishwasher by pressing the ON/OFF key (3) (see section "3. Description
of the controls").
REMOVING THE DISHES
At the end of the washing program, wait at least 20 minutes before
removing the dishes, to allow them to cool down. To prevent any water
droplets on the upper basket from falling on the dishes in the lower
basket, it is advisable to unload the lower basket first, and then the
upper basket.

User instructions
43
4. Operating instructions
Once the dishwasher has been correctly installed, prepare for use as
follows:
•Adjust the water softening system;
•Add the regenerating salt;
•Add the rinse aid and detergent.
4.1 Using the water softening system
The amount of scale contained in the
water (water hardness index) can cause
whitish staining on the dry dishes, which
tend to become dull over time. The
dishwasher is equipped with an automatic
softening system which uses a special
regenerating salt to reduce the hardness
of the water.
The dishwasher is factory set for water
hardness level 3 (average hardness
41-60°dF – 24-31°dH).
When using water of medium hardness, the regenerating salt container
should be refilled after approximately 20 washing cycles. The salt
container can hold approximately 1.7 Kg of salt in grains. The container
is situated at the bottom of the dishwasher. After removing the lower
basket, unscrew the salt container cap by turning it anticlockwise and
pour in the salt using the funnel supplied with the dishwasher. Before
replacing the cap, remove any salt residues from around the opening.
•When using the dishwasher for the first time, in addition to the salt it
is also necessary to add one litre of water to the container.
•Each time the salt container is refilled, make sure that the cap is
securely closed. The mixture of water and detergent must never
penetrate the salt container, as this would compromise the operation
of the regeneration system. In the event of this occurring, the
warranty will be invalidated.
•Only use regenerating salt specially formulated for domestic
dishwashers. If using salt tablets, do not fill the container
completely.
SALT

User instructions
44
•Do not use table salt as it contains insoluble substances which,
over time, may damage the water softening system.
•When necessary, refill the regenerating salt container before
starting the washing program. In this way, the excess saline
solution will be immediately removed by the water; the prolonged
presence of salt water inside the tank may lead to corrosion.
Be careful not to confuse the salt and detergent packages; adding
detergent to the salt container will damage the water softening system.
ADJUSTING THE WATER SOFTENING SYSTEM
The dishwasher is equipped with an device for the user to adjust the
water softening system according to the hardness of the water supply.
According to the machine model, the selector which acts on the
adjustment may be located:
A inside the plastic locking ring located on the right-hand side, inside
the dishwasher;
B in the top right-hand corner under the door.
Both allow for adjustment to 5settings:

User instructions
45
WATER HARDNESS TABLE
WATER HARDNESS
German Degrees (°dH) French Degrees (°dF)
TYPE A TYPE B TYPE A TYPE B
SETTING
0 - 4 0 - 4 0 - 7 0 - 7 Setting N. 1 NO SALT
5 - 9 5 - 15 8 - 15 8 - 25 Setting N. 1
10 - 22 16 - 23 16 - 37 26 - 40 Setting N. 2
23 - 29 24 - 31 38 - 50 41 - 60 Setting N. 3
30 - 35 32 - 47 51 - 60 61 - 80 Setting N. 4
36 - 41 48 - 58 61 - 70 81 - 100 Setting N. 5
Contact your local water board for information on the hardness of your
water supply.
4.2 Using the rinse aid and detergent dispensers
The detergent and rinse aid
dispensers are situated on the inner
part of the door: the detergent
dispenser is on the left, and the
rinse aid dispenser is on the right.
With the exception of the SOAK program, before every washing cycle it
is necessary to add the required amount of detergent to the detergent
dispenser. The rinse aid, on the other hand, should only be added as
required.

User instructions
46
ADDING THE RINSE AID
The rinse aid helps the dishes dry faster and
prevents the formation of scale deposits and
staining; it is automatically added to the water
during the final rinse cycle, from the container
situated on the inner side of the door.
•Open the door.
•Rotate the container cap anticlockwise by 1/4 of a turn and remove
it.
•Add the rinse aid until the container is full (approximately 140 cc).
The optical level indicator on the side of the cap should be
completely obscured. Refill the rinse aid when the optical level
indicator becomes clear again, or when the rinse aid warning light
illuminates.
•Replace the cover and turn it in a clockwise direction.
•Use a cloth to remove any spillage of rinse aid which might lead to
the formation of excess foam.
ADJUSTING THE RINSE AID DISPENSER SETTING
The dishwasher is factory set for medium water hardness. However it
possible to change the setting by turning the dispenser’s selector to the
desired position: the amount of rinse aid dispensed is proportional to the
selector position.
The setting must be increased when the washed dishes appear dull or
have circular staining.
•To adjust the rinse aid setting, rotate the dispenser cap through a
quarter turn in an anticlockwise direction and remove it.
•Then use a screwdriver to rotate the rinse aid selector to the desired
position.
•Replace the cap, turning it clockwise.
•The amount of rinse aid must be increased if the washed dishes
appear dull or feature circular stains.
•If, on the other hand, the dishes are sticky or have white streaks, it
is necessary to reduce the rinse aid setting.

User instructions
47
ADDING THE DETERGENT
To open the detergent dispenser cap, lightly press
the button P. Add the detergent and close the cap
carefully.
During the washing cycle, the dispenser will be
opened automatically.
•When a SUPER program is selected, in addition to the normal dose
of detergent, it is necessary to add an additional amount inside
compartment G or H.
•Use only detergents specially formulated for dishwashers. For
optimal washing results it is important to use a good quality
detergent.
•The detergent packs must be sealed and stored in a dry place to
prevent the formation of lumps which may negatively affect washing
results. Once opened the detergent packs should not be kept for too
long, otherwise the detergent loses its effectiveness.
•Do not use detergents formulated for washing dishes by hand,
because they produce a great deal of foam and may negatively
affect the operation of the dishwasher.
•Add the correct amount of detergent. An insufficient amount of
detergent will result in a partial removal of dirt from the dishes,
whereas an excessive amount is wasteful and does not improve the
washing results.

User instructions
48
There are various types of detergents available on the market - liquid,
powder and tablet forms - characterised by different chemical
compositions: some contain phosphates, whereas others are phosphate
free and based on natural enzymes.
-Detergents containing phosphates are more effective against grease
and starch at temperatures above 60°C.
-Enzyme detergents, on the other hand, are also effective at lower
temperatures (from 40 to 55°C) and are more easily biodegradable.
With enzyme detergents it is possible to obtain at low temperatures
comparable results to those which can only be achieved at 65°C using
traditional detergents.
For the safeguarding of the environment we recommend the use of
phosphate- and chlorine free detergents.
The introduction of detergent into the rinse aid dispenser, even in
liquid form, will damage the dishwasher.
