Smeg FD432PXNFE4 User manual

smeg
FROST FREE REFRIGERATOR
Freezer - Fridge
Instruction booklet
ELETTRONICO FROST FREE
Congelatore – Frigo
Istruzioni per l'uso
NO-FROST-KÜHLSCHRANK
Gefrierschrank - Kühlschrank
Bedienungsanleitung
RÉFRIGÉRATEUR A FROID VENTILE
Congélateur - Réfrigérateur
Guide d'utilisation
FRIGORÍFICO NO FROST
Congelador - Frigorífico
Manual do utilizador
FD432PXNFE4
FD432PMNFE4

EN -1-
Index
BEFORE USING THE APPLIANCE ..................................................................... 2
General warnings .........................................................................................................2
Old and out-of-order fridges .........................................................................................4
Safety warnings............................................................................................................4
Installing and operating your fridge ..............................................................................5
Before Using your Fridge..............................................................................................6
THE VARIOUS FUNCTION AND POSSIBILITIES ............................................... 7
Information about New Generation Cooling Technology ..............................................7
Display and control panel .............................................................................................8
Operating your fridge....................................................................................................9
Super freeze mode.......................................................................................................9
Super cool mode ..........................................................................................................9
Economy mode.............................................................................................................9
Holliday mode.............................................................................................................10
Drink cool mode..........................................................................................................10
Light cancelling mode.................................................................................................11
Screen saver mode ....................................................................................................12
Cooler temperature settings .......................................................................................12
Freezer temperature settings .....................................................................................13
Warnings about Temperature Adjustments.................................................................13
Accessories ................................................................................................................14
Icematic................................................................................................................................14
Chiller Shelf..........................................................................................................................14
Fresh dial .............................................................................................................................15
Adjustable door shelf ..........................................................................................................15
ARRANGING FOOD IN THE APPLIANCE ........................................................ 16
Refrigerator compartment...........................................................................................16
Freezer compartment .................................................................................................17
CLEANING AND MAINTENANCE ..................................................................... 19
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION ........... 21
Repositioning the Door...............................................................................................21
BEFORE CALLING YOUR AFTER SALES SERVICE....................................... 21
Tips for saving energy ................................................................................................24
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS .................... 25

EN -2-
PART - 1. BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the
appliance, it must be xed in accordance with the instructions.
• If your appliance uses R600a as a refrigerant – you can learn
this information from the label on the cooler- you should
be careful during shipment and installation to prevent your
appliance’s cooler elements from being damaged. Although
R600a is an environmentally friendly and natural gas. As it is
explosive, in the event of a leak due to damage to the cooler
elements, move your fridge from open ame or heat sources
and ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
• This appliance is intended to be used in household and similar
applications such as;
- staff kitchen areas in shops, ofces and other working en-
vironments

EN -3-
- farm houses and by clients in hotels, motels and other resi-
dential type environments
- bed and breakfast type environments;
- catering and similar non-retail applications
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes. If there is no such
socket in your house, please have it installed by an authorized
electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazard
involved. Children shall not play with the appliance. Cleaning
and user maintenance, shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualied persons
in order to avoid a hazard.

EN -4-
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding it, because
children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
Disposal of your old appliance
This symbol on the product or package implies that the product should not be
treated as domestic waste. Instead, it should be delivered to applicable waste
collection places recycling electrical and electronic equipment. You will contrib-
ute to avoid potential negative results regarding environment and human health,
which will arise due to wrong waste procedure for the product by ensuring that this
product is annihilated properly. Recycling materials will help natural resources be preserved.
For more detailed information regarding recycling of this product, please contact local mu-
nicipality, domestic waste annihilation service or the shop you have purchased the product.
Please ask your municipal authority about the disposal of the WEEE for the reuse, recycle
and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or common
use. Such use will cause the guarantee of the appliance to be cancelled and our company
will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
foods. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for the losses to be occurred in the
contrary case.
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to
play with the appliance or let them hang off the door.
• Do not plug-in or out the plug from the receptacle with wet hands to
prevent electrocution!

EN -5-
• Do not place glass bottles or beverage cans in the freezer department.
Bottles or cans may explode.
• Do not place explosive or ammable material in your fridge for your
safety. Place drinks with higher alcohol amount vertically and by closing
their necks tightly in the fridge department.
• When taking ice made in the freezer department, do not touch it, ice may
cause ice burns and/or cuts.
• Do not touch frozen goods with wet hands! Do not eat ice-cream and ice cubes
immediately after you have taken them out of the freezer department!
• Do not re-freeze frozen goods after they have melted. This may cause health issues
like food poisoning.
• Do not cover the body or top of fridge with lace. This affects the performance of your fridge.
• Fix the accessories in the fridge during transportation to prevent damage to accessories.
Installing and operating your fridge
Before starting to use your fridge, you should pay attention to the following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• We do not take the responsibility of the damages that occur due to ungrounded usage.
• Place your fridge in a place that it would not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, Gas ovens and heater cores,
and should be at least 5 cm away from electrical ovens.
• Your fridge should never be used outdoors or left under the rain.
• When your fridge is placed next to a deep freezer, there should be at least
2 cm between them to prevent humidity on the outer surface.
• Do not place anything on your fridge, and install your fridge in a suitable
place so that at least 15 cm is available on the upper side.
• The adjustable front legs should be adjusted to make sure your appliance
is level and stable. You can adjust the legs by turning them clockwise (or in the opposite
direction). This should be done before placing food in the fridge.
• Before using your fridge, wipe all parts back with warm water added with a tea spoonful
of sodium bicarbonate, and then rinse with clean water and dry. Place all parts after
cleaning.
If your refrigerator has a fan condenser:
The condenser of your fridge is placed at the bottom of cabinet. As a result of that, details
that arranges the distance between the refrigerator and the back wall at where you place the
fridge, exist at the cover of the bottom of cabinet. You can move the fridge towards the back
wall until that point.
Plastic for distance setting

EN -6-
If your fridge doesn’t have a fan condenser, in other words, back side of your fridge
is like below:
• Install the plastic distance guide (the part with black vanes
at the rear) by turning it 90° as shown in the gure to
prevent the condenser from touching the wall.
• Refrigerator should be placed against a wall with a free
distance not exceeding 75 mm.
Before Using your Fridge
• When it is operated for the rst time or after transportation, keep your
fridge in the upright position for 3 hours and plug it on to allow efcient
operation. Otherwise, you may damage the compressor.
• Your fridge may have a smell when it is operated for the rst time; the smell will fade
away when your fridge starts to cool.

EN -7-
PART - 2. THE VARIOUS FUNCTION AND POSSIBILITIES
Information about New Generation Cooling Technology
Fridges with new generation cooling technology
have a different working system than static fridges.
In normal fridges, humid air that enters into fridge
and the water vapor that comes out from the foods,
accumulates frost formation in freezer compart-
ment. In order to melt this frost, in other words
defrost, the fridge has to be stopped. During the
stopping period, to keep the foods cold, user has
to extract the food to outside of fridge and user
has to clear the ice during this period.
In the fridges with new generation cooling tech-
nology, situation in the freezer compartment is
completely different. With the aid of fan, cold and
dry air is blown out through many points into the
freezer compartment. As a result of the homoge-
nously blown cold air, even in the spaces between
shelves, foods are frozen equally and correctly.
On the other hand there will be no frost formation.
In the refrigerator compartment, there will be
nearly same conguration with freezer compart-
ment. Air, that is emitted with the fan, located at
the top of refrigerator compartment, is cooled while
passing through the gap behind the air duct. At the
same time, air is blown out through the holes on
the air duct so that cooling process is successfully
completed in the refrigerator compartment. Holes
on the air duct are designed such that the air distri-
bution becomes homogenous in this compartment.
As there is no air passage between freezer and
refrigerator compartment, there will be no odor
mixing.
As a result of these, your fridge with new genera-
tion cooling technology, gives you, ease of use
beside the huge volume and esthetic appearance.

EN -8-
Display and control panel
1. It is super freeze indicator.
2. It is freezer set value screen.
3. It is super cooling indicator.
4. It is cooler set value screen.
5. It is alarm symbol.
6. It is economy mode symbol.
7. It is holiday mode symbol.
8. It is child-lock symbol.
9. It enables the setting value
of freezer to be modied and
super freeze mode to be
activated if desired. Freezer
may be set to -16, -18, -20, -22,
-24°C super freeze.
10. It enables the setting value of
cooler to be modied and super
cool mode to be activated if
desired. Cooler maybe set to 8,
6, 5, 4, 2 °C super cool.
11. It enables the modes
(economy, holiday…) to be
activated if desired.
1
2
3
4
5
6
7
9
10
11
8

EN -9-
Operating your fridge
Super freeze mode
How would it be used?
Press freezer set button until Super freeze symbol will be seen on
the screen. Buzzer will sound beep beep. Mode will be set.
During this mode:
• Temperature of cooler and super cool mode may be adjusted.
In this case super freeze mode continues.
• Economy and Holiday mode can not be selected.
• Super freeze mode can be cancelled by the same operation of
selecting.
Super cool mode
How would it be used?
Press cooler set button until Super cool symbol will be seen on the
screen. Buzzer will sound beep beep. Mode will be set.
During this mode:
• Temperature of freezer and super freeze mode may be adjusted.
In this case super cool mode continues.
• Economy and Holiday mode can not be selected.
• Super cool mode can be cancelled by the same operation of
selecting.
Economy mode
How would it be used?
• Push "mode button" until eco symbol appears.
• If no button is pressed for 1 second. Mode will be set. Eco
symbol will blink 3 times. When mode is set, buzzer will sound
beep beep.
• Freezer and refrigerator temperature segments will show "E".
• Economy symbol and E will light till mode nishes.
During this mode:
• Freezer may be adjusted. When economy mode will be
cancelled, the selected setting values will proceed.
• Cooler may be adjusted. When economy mode will be cancelled,
