Smeg LBS107F User manual

Washing Machine
Lavatrice
LBS107F

2EN
1 Important safety instructions
This section contains safety instructions that will
help protect from risk of personal injury or property
damage. Failure to follow these instructions shall
void any warranty.
General safety
• Thisproductshouldnotbeusedbypersons
with physical, sensory or mental disorders or
unlearned or inexperienced people (including
children)unlesstheyareattendedbyaperson
whowillberesponsiblefortheirsafetyorwho
will instruct them accordingly for use of the
product.
• Neverplacetheproductonacarpet-covered
floor;otherwise,lackofairflowbeneath
the machine will cause electrical parts to
overheat.Thiswillcauseproblemswithyour
product.
• Donotoperatetheproductifthepower
cable/plugisdamaged.CalltheAuthorized
ServiceAgent.
• Haveaqualifiedelectricianconnecta
16-Amperefusetotheinstallationlocationof
the product.
• Iftheproducthasafailure,itshouldnot
beoperatedunlessitisrepairedbythe
AuthorizedServiceAgent.Thereistheriskof
electric shock!
• Thisproductisdesignedtoresumeoperating
in the event of powering on after a power
interruption.Ifyouwishtocancelthe
programme,see"Cancellingtheprogramme"
section.
• Connecttheproducttoagroundedoutlet
protectedbyafusecomplyingwiththevalues
inthe"Technicalspecifications"table.Donot
neglect to have the grounding installation
madebyaqualifiedelectrician.Ourcompany
shallnotbeliableforanydamagesthat
will arise when the product is used without
grounding in accordance with the local
regulations.
• Thewatersupplyanddraininghosesmustbe
securely fastened and remain undamaged.
Otherwise,thereistheriskofwaterleakage.
• Neveropentheloadingdoororremovethe
filter while there is still water in the drum.
Otherwise,riskoffloodingandinjuryfromhot
water will occur.
• Donotforceopenthelockedloadingdoor.
Theloadingdoorwillbereadytoopenjusta
few minutes after the washing cycle comes to
anend.Incaseofforcingtheloadingdoorto
open, the door and the lock mechanism may
get damaged.
• Unplugtheproductwhennotinuse.
• Neverwashtheproductbyspreadingor
pouring water onto it! There is the risk of
electric shock!
• Nevertouchtheplugwithwethands!Never
unplugbypullingonthecable,alwayspullout
bygrabbingtheplug.
• Usedetergents,softenersandsupplements
suitableforautomaticwashingmachinesonly.
• Followtheinstructionsonthetextiletagsand
on the detergent package.
• Theproductmustbeunpluggedduring
installation, maintenance, cleaning and
repairing procedures.
• Alwayshavetheinstallationandrepairing
procedurescarriedoutbytheAuthorized
ServiceAgent.Manufacturershallnotbe
heldliablefordamagesthatmayarisefrom
procedurescarriedoutbyunauthorized
persons.
Intended use
• Thisproducthasbeendesignedfordomestic
use.Itisnotsuitableforcommercialuseand
itmustnotbeusedoutofitsintendeduse.
• Theproductmustonlybeusedforwashing
and rinsing of laundry that are marked
accordingly.
• Themanufacturerwaivesanyresponsibility
arisen from incorrect usage or transportation.
Children's safety
• Electricalproductsaredangerousforthe
children. Keep children away from the product
whenitisinuse.Donotletthemtotamper
withtheproduct.Usechildlocktoprevent
children from intervening with the product.
• Donotforgettoclosetheloadingdoor
when leaving the room where the product is
located.
• Storealldetergentsandadditivesinasafe
place away from the reach of the children.

3EN
2 Installation
RefertothenearestAuthorisedServiceAgentfor
installation of the product. To make the product
ready for use, review the information in the user
manual and make sure that the electricity, tap
water supply and water drainage systems are
appropriatebeforecallingtheAuthorizedService
Agent.Iftheyarenot,callaqualifiedtechnician
andplumbertohaveanynecessaryarrangements
carried out.
CPreparation of the location and electrical,
tap water and waste water installations at
the place of installation is under customer's
responsibility.
B Installationandelectricalconnectionsof
theproductmustbecarriedoutbythe
AuthorizedServiceAgent.Manufacturershall
notbeheldliablefordamagesthatmayarise
fromprocedurescarriedoutbyunauthorized
persons.
APrior to installation, visually check if the
producthasanydefectsonit.Ifso,donot
haveitinstalled.Damagedproductscause
risks for your safety.
C Makesurethatthewaterinletanddischarge
hosesaswellasthepowercablearenot
folded, pinched or crushed while pushing
the product into its place after installation or
cleaning procedures.
Appropriate installation location
• Placethemachineonarigidfloor.Donot
place it on a long pile rug or similar surfaces.
• Totalweightofthewashingmachineandthe
dryer-withfullload-whentheyareplaced
on top of each other reaches to approx.
180 kilograms. Place the product on a solid
and flat floor that has sufficient load carrying
capacity!
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductatplaceswhere
temperaturemayfallbelow0ºC.
• Placetheproductatleast1cmawayfrom
the edges of other furniture.
Removing packaging reinforcement
Tiltthemachinebackwardstoremovethe
packaging reinforcement. Remove the packaging
reinforcementbypullingtheribbon.
Removing the transportation locks
A Donotremovethetransportationlocksbefore
taking out the packaging reinforcement.
A Removethetransportationsafetyboltsbefore
operating the washing machine, otherwise,
theproductwillbedamaged.
1. Loosenalltheboltswithaspanneruntilthey
rotatefreely(C).
2. Removetransportationsafetyboltsbyturning
them gently.
3. AttachtheplasticcoverssuppliedintheUser
Manualbagintotheholesontherearpanel.
(P)
C Keepthetransportationsafetyboltsinasafe
place to reuse when the washing machine
needstobemovedagaininthefuture.
CNever move the product without the
transportationsafetyboltsproperlyfixedin
place!
Connecting water supply
C Thewatersupplypressurerequiredtorun
theproductisbetween1to10bars(0.1–10
MPa).Itisnecessarytohave10–80litersof
water flowing from the fully open tap in one
minute to have your machine run smoothly.
Attachapressurereducingvalveifwater
pressure is higher.
C Ifyouaregoingtousethedoublewater-inlet
productasasingle(cold)water-inletunit,you
must install the supplied stopper to the hot
watervalvebeforeoperatingtheproduct.
(Appliesfortheproductssuppliedwithablind
stopper group.)
C Ifyouwanttousebothwaterinletsofthe
product, connect the hot water hose after
removing the stopper and gasket group from
thehotwatervalve.(Appliesfortheproducts
suppliedwithablindstoppergroup.)
A Modelswithasinglewaterinletshouldnot
beconnectedtothehotwatertap.Insuch
a case the laundry will get damaged or the
product will switch to protection mode and
will not operate.
A Donotuseoldorusedwaterinlethoseson
thenewproduct.Itmaycausestainsonyour
laundry.
1. Connectthespecialhosessuppliedwiththe
product to the water inlets on the product.
Redhose(left)(max.90ºC)isforhotwater
inlet,bluehose(right)(max.25ºC)isforcold
water inlet.
AEnsure that the cold and hot water
connections are made correctly when
installingtheproduct.Otherwise,yourlaundry
will come out hot at the end of the washing
process and wear out.
2. Tightenallhosenutsbyhand.Neverusea
wrench when tightening the nuts.

4EN
3. Openthetapscompletelyaftermakingthe
hose connection to check for water leaks at
theconnectionpoints.Ifanyleaksoccur,turn
off the tap and remove the nut. Retighten
the nut carefully after checking the seal. To
prevent water leakages and damages caused
bythem,keepthetapsclosedwhenthe
machine is not in use.
Connecting to the drain
• Theendofthedrainhosemustbedirectly
connected to the wastewater drain or to the
washbasin.
A Yourhousewillbefloodedifthehosecomes
out of its housing during water discharge.
Moreover,thereisriskofscaldingdueto
high washing temperatures! To prevent such
situations and to ensure smooth water intake
and discharge of the machine, fix the end of
the discharge hose tightly so that it cannot
come out.
• Thehoseshouldbeattachedtoaheightofat
least 40 cm, and 100 cm at most.
• Incasethehoseiselevatedafterlayingiton
the floor level or close to the ground (less than
40cmabovetheground),waterdischarge
becomesmoredifficultandthelaundrymay
come out excessively wet. Therefore, follow
theheightsdescribedinthefigure.
• Topreventflowingofdirtywaterbackintothe
machine and to allow for easy discharge, do
not immerse the hose end into the dirty water
ordriveitinthedrainmorethan15cm.Ifitis
too long, cut it short.
• Theendofthehoseshouldnotbebent,it
shouldnotbesteppedonandthehosemust
notbepinchedbetweenthedrainandthe
machine.
• Ifthelengthofthehoseistooshort,useit
byaddinganoriginalextensionhose.Length
ofthehosemaynotbelongerthan3.2m.
To avoid water leak failures, the connection
betweentheextensionhoseandthedrain
hoseoftheproductmustbefittedwellwith
an appropriate clamp as not to come off and
leak.
Adjusting the feet
A Inordertoensurethattheproductoperates
moresilentandvibration-free,itmuststand
levelandbalancedonitsfeet.Balancethe
machinebyadjustingthefeet.Otherwise,the
product may move from its place and cause
crushingandvibrationproblems.
1. Loosenthelocknutsonthefeetbyhand.
2. Adjustthefeetuntiltheproductstandslevel
andbalanced.
3. Tightenalllocknutsagainbyhand.
A Donotuseanytoolstoloosenthelocknuts.
Otherwise,theywillgetdamaged.
Electrical connection
Connecttheproducttoagroundedoutlet
protectedbyafusecomplyingwiththevaluesin
the"Technicalspecifications"table.Ourcompany
shallnotbeliableforanydamagesthatwillarise
when the product is used without grounding in
accordance with the local regulations.
• Connectionmustcomplywithnational
regulations.
• Powercableplugmustbewithineasyreach
after installation.
• Thevoltageandallowedfuseorbreaker
protection are specified in the “Technical
specifications”section.Ifthecurrentvalueof
thefuseorbreakerinthehouseislessthan
16Amps,haveaqualifiedelectricianinstalla
16Ampfuse.
• Thespecifiedvoltagemustbeequaltoyour
mains voltage.

5EN
• Donotmakeconnectionsviaextension
cablesormulti-plugs.
B Damagedpowercablesmustbereplacedby
theAuthorizedServiceAgents.
First use
Beforestartingtousetheproduct,makesure
that all preparations are made in accordance
withtheinstructionsinsections"Importantsafety
instructions"and"Installation".
To prepare the product for washing laundry,
performfirstoperationinDrumCleaning
programme.Ifyourmachineisnotfeaturedwith
DrumCleaningprogramme,useCottons-90
programmeandselectAdditionalWaterorExtra
Rinseauxiliaryfunctionsaswell.Beforestarting
the programme, put max. 100 g of powder
anti-limescaleintothemainwashdetergent
compartment(compartmentnr.II).Iftheanti-
limescaleisintabletform,putonlyonetabletinto
compartmentnr.II.Drytheinsideofthebellow
with a clean piece of cloth after the programme
has come to an end.
C Useananti-limescalesuitableforthewashing
machines.
CSome water might have remained in the
productduetothequalitycontrolprocesses
intheproduction.Itisnotharmfulforthe
product.
Disposing of packaging material
Packaging materials are dangerous to children.
Keep packaging materials in a safe place away
from reach of the children.
Packaging materials of the product are
manufacturedfromrecyclablematerials.Dispose
of them properly and sort in accordance with
recycledwasteinstructions.Donotdisposeof
them with normal domestic waste.
Transportation of the product
Unplugtheproductbeforetransportingit.Remove
waterdrainandwatersupplyconnections.Drain
the remaining water in the product completely;
see,"Drainingremainingwaterandcleaningthe
pumpfilter".Installtransportationsafetybolts
in the reverse order of removal procedure; see,
"Removing the transportation locks".
CNever move the product without the
transportationsafetyboltsproperlyfixedin
place!
Disposing of the old product
Disposeoftheoldproductinanenvironmentally
friendly manner.
Refer to your local dealer or solid waste collection
centre in your area to learn how to dispose of your
product.
Forchildren'ssafety,cutthepowercableand
breakthelockingmechanismoftheloadingdoor
sothatitwillbenonfunctionalbeforedisposingof
the product.

6EN
3 Preparation
Things to be done for energy saving
Following information will help you use the product
inanecologicalandenergy-efficientmanner.
• Operatetheproductinthehighestcapacity
allowedbytheprogrammeyouhaveselected,
butdonotoverload;see,"Programmeand
consumptiontable".
• Alwaysfollowtheinstructionsonthe
detergent packaging.
• Washslightlysoiledlaundryatlow
temperatures.
• Usefasterprogrammesforsmallquantitiesof
lightly soiled laundry.
• Donotuseprewashandhightemperatures
for laundry that is not heavily soiled or stained.
• Ifyouplantodryyourlaundryinadryer,select
the highest spin speed recommended during
washing process.
• Donotusedetergentinexcessoftheamount
recommended on the detergent package.
Sorting the laundry
• Sortlaundryaccordingtotypeoffabric,
colour,anddegreeofsoilingandallowable
water temperature.
• Alwaysobeytheinstructionsgivenonthe
garment tags.
Preparing laundry for washing
• Laundryitemswithmetalattachmentssuch
as,underwiredbras,beltbucklesormetal
buttonswilldamagethemachine.Remove
themetalpiecesorwashtheclothesby
puttingtheminalaundrybagorpillowcase.
• Takeoutallsubstancesinthepocketssuch
as coins, pens and paper clips, and turn
pocketsinsideoutandbrush.Suchobjects
may damage the product or cause noise
problem.
• Putsmallsizeclothessuchasinfant'ssocks
andnylonstockingsinalaundrybagorpillow
case.
• Placecurtainsinwithoutcompressingthem.
Remove curtain attachment items.
• Fastenzippers,sewloosebuttonsandmend
rips and tears.
• Wash“machinewashable”or“hand
washable”labeledproductsonlywithan
appropriate programme.
• Donotwashcoloursandwhitestogether.
New, dark coloured cottons release a lot of
dye.Washthemseparately.
• Toughstainsmustbetreatedproperlybefore
washing.Ifunsure,checkwithadrycleaner.
• Useonlydyes/colourchangersandlimescale
removerssuitableformachinewash.Always
follow the instructions on the package.
• Washtrousersanddelicatelaundryturned
inside out.
• KeeplaundryitemsmadeofAngorawoolin
thefreezerforafewhoursbeforewashing.
This will reduce pilling.
• Laundrythataresubjectedtomaterialssuch
as flour, lime dust, milk powder, etc. intensely
mustbeshakenoffbeforeplacingintothe
machine. Such dusts and powders on the
laundrymaybuildupontheinnerpartsofthe
machine in time and can cause damage.
Correct load capacity
The maximum load capacity depends on the type
of laundry, the degree of soiling and the washing
programme desired.
The machine automatically adjusts the amount
of water according to the weight of the loaded
laundry.
AFollow the information in the “Programme
andconsumptiontable”.Whenoverloaded,
machine's washing performance will drop.
Moreover,noiseandvibrationproblemsmay
occur.
Loading the laundry
• Opentheloadingdoor.
• Placelaundryitemslooselyintothemachine.
• Pushtheloadingdoortocloseuntilyouhear
a locking sound. Ensure that no items are
caught in the door.
CThe loading door is locked while a programme
isrunning.Thedoorcanonlybeopeneda
while after the programme comes to an end.
A Incaseofmisplacingthelaundry,noiseand
vibrationproblemsmayoccurinthemachine.
Using detergent and softener
Detergent Drawer
The detergent drawer is composed of three
compartments:
-(I)forprewash
-(II)formainwash
–(III)forsoftener
–(*)inaddition,thereissiphonpieceinthe
softener compartment.
C Thedetergentdispensermaybeintwo
different types according to the model of your
machineasseenabove.
Detergent, softener and other cleaning agents
• Adddetergentandsoftenerbeforestartingthe
washing programme.
• Neveropenthedetergentdrawerwhilethe
washing programme is running!
• Whenusingaprogrammewithoutprewash,
do not put any detergent into the prewash
compartment(compartmentnr.I).
• Inaprogrammewithprewash,donot
putliquiddetergentintotheprewash

7EN
compartment(compartmentnr.I).
• Donotselectaprogrammewithprewashif
youareusingadetergentbagordispensing
ball.Placethedetergentbagorthe
dispensingballdirectlyamongthelaundryin
the machine.
• Ifyouareusingliquiddetergent,donotforget
toplacetheliquiddetergentcupintothemain
washcompartment(compartmentnr.II).
Choosing the detergent type
Thetypeofdetergenttobeuseddependsonthe
typeandcolourofthefabric.
• Usedifferentdetergentsforcolouredand
white laundry.
• Washyourdelicateclothesonlywithspecial
detergents(liquiddetergent,woolshampoo,
etc.) used solely for delicate clothes.
• Whenwashingdarkcolouredclothesand
quilts,itisrecommendedtouseliquid
detergent.
• Washwoolenswithspecialdetergentmade
specifically for woolens.
A Useonlydetergentsmanufacturedspecifically
for washing machines.
A Donotusesoappowder.
Adjusting detergent amount
Theamountofwashingdetergenttobeused
depends on the amount of laundry, the degree
of soiling and water hardness. Read the
manufacturer's instructions on the detergent
package carefully and follow the dosage values.
• Donotuseamountsexceedingthedosage
quantitiesrecommendedonthedetergent
packagetoavoidproblemsofexcessive
foam, poor rinsing, financial savings and finally,
environmental protection.
• Uselesserdetergentforsmallamountsor
lightly soiled clothes.
• Useconcentrateddetergentsinthe
recommended dosage.
Using softeners
Pour the softener into the softener compartment of
the detergent drawer.
• Usethedosagesrecommendedonthe
package.
• Donotexceedthe(>max<)levelmarkingin
the softener compartment.
• Ifthesoftenerhaslostitsfluidity,diluteitwith
waterbeforeputtingitinthedetergentdrawer.
Using liquid detergents
If the product contains a liquid detergent cup:
• Makesurethatyouhaveplacedtheliquid
detergentcupincompartmentnr."II".
• Usethedetergentmanufacturer'smeasuring
cup and follow the instructions on the
package.
• Usethedosagesrecommendedonthe
package.
• Iftheliquiddetergenthaslostitsfluidity,dilute
itwithwaterbeforeputtinginthedetergent
cup.
If the product does not contain a liquid
detergent cup:
• Donotuseliquiddetergentfortheprewashin
a programme with prewash.
• Usethedetergentmanufacturer'smeasuring
cup and follow the instructions on the
package.
• Liquiddetergentstainsyourclotheswhen
usedwithDelayedStartfunction.Ifyouare
goingtousetheDelayedStartfunction,do
notuseliquiddetergent.
Using gel and tablet detergent
Whenusingtablet,gel,etc.detergents,read
the manufacturer's instructions on the detergent
packagecarefullyandfollowthedosagevalues.If
there is not any instruction on the package, apply
the following.
• Ifthegeldetergentthicknessisfluidaland
yourmachinedoesnotcontainaspecialliquid
detergent cup, put the gel detergent into the
main wash detergent compartment during first
waterintake.Ifyourmachinecontainsaliquid
detergent cup, fill the detergent into this cup
beforestartingtheprogramme.
• Ifthegeldetergentthicknessisnotfluidalor
intheshapeofcapsuleliquidtablet,putit
directlyintothedrumbeforewashing.
• Puttabletdetergentsintothemainwash
compartment(compartmentnr.II)ordirectly
intothedrumbeforewashing.
C Tabletdetergentsmayleaveresiduesinthe
detergentcompartment.Ifyouencounter
suchacase,placethetabletdetergent
betweenthelaundry,closetothelowerpartof
the drum in future washings.
C Usethetabletorgeldetergentwithout
selecting the prewash function.
Using starch
• Addliquidstarch,powderstarchorthe
dyestuff into the softener compartment as
instructed on the package.
• Donotusesoftenerandstarchtogetherina
washing cycle.
• Wipetheinsideofthemachinewithadamp
and clean cloth after using starch.
Using bleaches
• Selectaprogrammewithprewashand
addthebleachingagentatthebeginning
oftheprewash.Donotputdetergentinthe
prewashcompartment.Asanalternative
application, select a programme with extra

8EN
rinseandaddthebleachingagentwhilethe
machine is taking water from the detergent
compartment during first rinsing step.
• Donotusebleachingagentanddetergent
bymixingthem.
• Usejustalittleamount(approx.50ml)of
bleachingagentandrinsetheclothesvery
wellasitcausesskinirritation.Donotpour
thebleachingagentontotheclothesanddo
not use it for coloured clothes.
• Whenusingoxygenbasedbleaches,
follow the instructions on the package and
select a programme that washes at a lower
temperature.
• Oxygenbasedbleachescanbeused
together with detergents; however, if
its thickness is not the same with the
detergent, put the detergent first into
thecompartmentnr."II"inthedetergent
drawer and wait until the detergent flows
while the machine is taking in water.
Addthebleachingagentfromthesame
compartment while the machine is still
taking in water.
Using limescale remover
• Whenrequired,uselimescaleremovers
manufactured specifically for washing
machines only.
• Alwaysfollowinstructionsonthepackage.

9EN
Tips for efficient washing
Clothes
Light colours and
whites Colors Dark colors Delicates/ Woolens/Silks
(Recommended
temperature range
based on soiling
level: 40-90C)
(Recommended
temperature range
based on soiling level:
cold-40C)
(Recommended
temperature
range based on
soiling level: cold-
40C)
(Recommended
temperature
range based
on soiling level:
cold-30C)
Soiling Level
Heavily Soiled
(difficult stains
such as grass,
coffee, fruits
and blood.)
It may be necessary
to pre-treat the
stains of perform
prewash. Powder
and liquid detergents
recommended
for whites can be
used at dosages
recommended for
heavily soiled clothes.
It is recommended
to use powder
detergents to clean
clay and soil stains
and the stains that
are sensitive to
bleaches.
Powder and
liquid detergents
recommended for
colours can be
used at dosages
recommended for
heavily soiled clothes.
It is recommended
to use powder
detergents to clean
clay and soil stains
and the stains that are
sensitive to bleaches.
Use detergents
without bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for heavily soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woollen and silk
clothes must
be washed with
special woollen
detergents.
Normally
Soiled
(For example,
stains caused
by body on
collars and
cuffs)
Powder and
liquid detergents
recommended
for whites can be
used at dosages
recommended
for normally soiled
clothes.
Powder and
liquid detergents
recommended for
colours can be
used at dosages
recommended for
normally soiled clothes.
Use detergents
without bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for normally
soiled clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woollen and silk
clothes must
be washed with
special woollen
detergents.
Lightly Soiled
(No visible
stains exist.)
Powder and
liquid detergents
recommended
for whites can be
used at dosages
recommended for
lightly soiled clothes.
Powder and
liquid detergents
recommended for
colours can be
used at dosages
recommended for
lightly soiled clothes.
Use detergents
without bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for lightly soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woollen and silk
clothes must
be washed with
special woollen
detergents.

10 EN
4 Operating the product
Control panel
1 - SpinSpeedAdjustmentbutton
2 - Display
3 - TemperatureAdjustmentbutton
4 - ProgrammeSelectionknob
5 - On/Offbutton
51
6 7 8
32 4
6 - DelayedStartbuttons(+/-)
7 - AuxiliaryFunctionbuttons
8 - Start/Pause/Cancelbutton
Display symbols
F1 F2 F3 F4
a - SpinSpeedindicator
b - Temperatureindicator
c - Spinsymbol
d - Temperaturesymbol
e - RemainingTimeandDelayedStart
indicator
f - ProgrammeIndicatorsymbols(Prewash
/MainWash/Rinse/Softener/Spin)
g - Economysymbol
h - DelayedStartsymbol
i - DoorLockedsymbol
j - Startsymbol
k - Pausesymbol
l - AuxiliaryFunctionsymbols
m - NoWatersymbol
Preparing the machine
Makesurethatthehosesareconnectedtightly.
Plug in your machine. Turn the tap on completely.
Placethelaundryinthemachine.Adddetergent
andfabricsoftener.
Programme selection
1. Selecttheprogrammesuitableforthetype,
quantityandsoilingdegreeofthelaundry
in accordance with the "Programme and
consumptiontable"andthetemperaturetable
below.
90˚C Heavilysoiledwhitecottonsandlinens. (coffeetablecovers,tableclothes,
towels,bedsheets,etc.)
60˚C
Normally soiled, coloured, fade proof
cottons or synthetic clothes (shirt,
nightgown, pajamas, etc.) and lightly
soiled white linens (underwear, etc.)
40˚C-
30˚C-
Cold
Blendedlaundryincludingdelicate
textile (veil curtains, etc.), synthetics
and woolens.
2. Select the desired programme with the
ProgrammeSelectionbutton.
CProgrammes are limited with the highest spin
speed appropriate for that particular type of
fabric.
C Whenselectingaprogramme,always
considerthetypeoffabric,colour,degreeof

11 EN
soilingandpermissiblewatertemperature.
C Alwaysselectthelowestrequired
temperature.Highertemperaturemeans
higher power consumption.
CFor further programme details, see
"Programmeandconsumptiontable".
Main programmes
Dependingonthetypeoffabric,usethefollowing
main programmes.
• Cotone (Cottons)
Usethisprogrammeforyourcottonlaundry(such
asbedsheets,duvetandpillowcasesets,towels,
bathrobes,underwear,etc.).Yourlaundrywillbe
washed with vigorous washing action for a longer
washing cycle.
• Sintetici (Synthetics)
Usethisprogrammetowashyoursynthetic
clothes(shirts,blouses,synthetic/cottonblends,
etc.).Itwasheswithagentleactionandhasa
shorterwashingcyclecomparedtotheCottons
programme.
Forcurtainsandtulle,usetheSynthetic40˚C
programmewithprewashandanti-creasing
functionsselected.Astheirmeshedtexture
causesexcessivefoaming,washtheveils/tulle
byputtinglittleamountofdetergentintothemain
washcompartment.Donotputdetergentinthe
prewash compartment.
• Lana (Woollens)
Usethisprogrammetowashyourwoolenclothes.
Select the appropriate temperature complying
withthetagsofyourclothes.Useappropriate
detergents for woolens.
Additional programmes
For special cases, additional programmes are
availableinthemachine.
C Additionalprogrammesmaydifferaccording
to the model of the machine.
• Cotone Eco (Cotton Economic)
Youmaywashyournormallysoileddurablecotton
and linen laundry in this programme with the
highest energy and water saving compared to
allotherwashprogrammessuitableforcottons.
Actualwatertemperaturemaydifferfromthe
declared cycle temperature. Programme duration
mayautomaticallybeshortenedduringlaterstages
of the programme if you wash less amount (e.g. ½
capacityorless)oflaundry.Inthiscaseenergyand
waterconsumptionwillbefurtherdecreasedgiving
you the opportunity for a more economical wash.
Thisfeatureisavailableforcertainmodelshaving
remaining time display.
• Antiallergico (Antiallergic)
Usethisprogrammetowashbabylaundry,and
thelaundrythatbelongstoallergicpersons.
Longer heating time and an additional rinsing step
provide a higher level of hygiene.
• Delicati (Delicate)
Usethisprogrammetowashyourdelicateclothes.
Itwasheswithagentleactionwithoutanyinterim
spin compared to the Synthetics programme.
• Lavaggio a mano (Hand wash)
Usethisprogrammetowashyourwoolen/delicate
clothesthatbear“notmachine-washable”tags
andforwhichhandwashisrecommended.It
washes laundry with a very gentle washing action
to not to damage clothes.
• Rapido ( Daily Express)
Usethisprogrammetowashyourlightlysoiled
cotton clothes in a short time.
• Eco 40
Usethisprogrammetowashyourlaundryfor
whichyoucannotuseCottons60°Cprogramme.
ItgivesthesameresultwiththeCottons60°C
programmebywashingforalongertimeat40°C,
thusenablingenergysaving.
• Mix 40
Usethisprogrammetowashyourcottonand
synthetic clothes together without sorting them.
• Intensivo (Intensive)
Youcanwashyourdurableandheavilysoiled
clothesonthisprogram.Inthisprogram,your
clotheswillbewashedforalongertimeand
anextrarinsecyclewillbemadecomparedto
the“Cottons”program.Youcanuseitforyour
heavilysoiledclothesthatyouwishtoberinsed
gently.
• Quotidiano (Shirts)
Usethisprogrammetowashtheshirtsmadeof
cotton,syntheticandsyntheticblendedfabrics
together.
• Tende (Curtain)
Usethisprogrammetowashyourtullesand
curtains. Thanks to the special spin profile of the
programme, tulles and curtains crease lesser.
Astheirmeshedtexturecausesexcessive
foaming,washtheveils/tullebyputtinglittle
amount of detergent into the main wash
compartment.Donotputdetergentinthe
prewash compartment. Prewash is used to clean
thedirt(dust,sooth,etc.)onthetulles/curtains
thatcanberemovedeasily.
C Itissuggestedtouserecommended
detergents for curtains in this programme.
• Lavaggio a freddo (Coton 20)
Usethisprogramme,whichismuchmoresensitive
to environment and natural resources, to wash
your lightly soiled and unstained cotton laundry
(max.3.5kg)inashorttimeandeconomically.
C Itisrecommendedtouseliquiddetergentor
gel washing detergent.
Special programmes
For specific applications, select any of the following
programmes.
• Risciacquo (Rinse)
Usethisprogrammewhenyouwanttorinseor
starch separately.
• Centrifuga+Scarico (Spin + Drain)
Usethisprogrammetoapplyanadditionalspin
cycle for your laundry or to drain the water in the

12 EN
machine.
Beforeselectingthisprogramme,selectthe
desiredspinspeedandpressStart/Pause/
Cancelbutton.Themachinewillspinthelaundry
with the set spin speed and drain the water
coming out of them.
Ifyouwishtodrainonlythewaterwithout
spinningyourlaundry,selectthePump+Spin
programme and then select the No Spin function
withthehelpofSpinSpeedAdjustmentbutton.
PressStart/Pause/Cancelbutton.
C Usealowerspinspeedfordelicate
laundries.
Temperature selection
Wheneveranewprogrammeisselected,
the maximum temperature for the selected
programme appears on the temperature
indicator.
To decrease the temperature, press the
TemperatureAdjustmentbutton.Temperature
decreaseswithincrementsof10°andfinally,“-”
symbolindicatingthecoldwashoptionappears
on the display.
C Ifyouscrolltocoldwashoptionandpress
TemperatureAdjustmentbuttonagain,the
recommended temperature for the selected
programme appears on the display. Press
theTemperatureAdjustmentbuttonagainto
decrease the temperature.
Economy symbol
Indicatestheprogrammesandtemperaturesthat
provide energy savings.
C Economysymbolcannotbeselectedin
IntensiveandHygieneprogrammessince
washing is performed in long times and
at high temperatures in order to provide
hygiene.Similarly,Economysymbolcan
notbeselectedinBaby,Refresh,Drum
Cleaning,SpinandRinseprogrammesas
well.
Spin speed selection
Wheneveranewprogrammeisselected,the
recommended spin speed of the selected
programme is displayed on the spin speed
indicator.
To decrease the spin speed, press the Spin
SpeedAdjustmentbutton.Spinspeed
decreases gradually. Then, depending on
themodeloftheproduct,"RinseHold"and
"No Spin" options appear on the display.
See"Auxiliaryfunctionselection"sectionfor
explanations of these options.
C RinseHoldoptionisindicatedwith“ ”
symbolandNoSpinoptionisindicatedwith
“”symbol.

13 EN
Programme and consumption table
•:Selectable
*:Automaticallyselected,nocanceling.
**:EnergyLabelprogramme(EN60456Ed.3)
***:Ifmaximumspinspeedofthemachineislowerthenthisvalue,youcanonlyselectuptothe
maximum spin speed.
-:Seetheprogrammedescriptionformaximumload.
C Theauxiliaryfunctionsinthetablemayvaryaccordingtothemodelofyourmachine.
C Waterandpowerconsumptionmayvarysubjecttothechangesinwaterpressure,waterhardness
andtemperature,ambienttemperature,typeandamountoflaundry,selectionofauxiliaryfunctions
and spin speed, and changes in electric voltage.
CYou can see the washing time of the programme you have selected on the display of the machine.
Itisnormalthatsmalldifferencesmayoccurbetweenthetimeshownonthedisplayandthereal
washing time.
EN 2Auxiliaryfunctions
Programme(°C)
Max.Load(kg) WaterConsumption(l) EnergyConsumption (kWh) Max.Speed*** Prelavaggio Rapido RisciacquoAggiuntivo Antipiega RinseHold Pet hair removal
Selectabletemperature
range°C
Cotone 90 7 74 2.3 1600 • • • • • • 90-Cold
Cotone 60 7 72 1.5 1600 • • • • • • 90-Cold
Cotone 40 7 72 0.85 1600 • • • • • • 90-Cold
Antiallergico 90 7 66 2.7 1600 * • 90-30
CotoneEco 60** 7 44 1.103 1600 • 60-Cold
CotoneEco 60** 3.5 38 0.875 1600 • 60-Cold
CotoneEco 40** 3.5 38 0.699 1600 • 60-Cold
CotoneEco 40 7 64 0.72 1600 • 60-Cold
Sintetici 60 3 45 1 1200 • • • • • • 60-Cold
Sintetici 40 3 45 0.45 1200 • • • • • • 60-Cold
Lavaggio a freddo 20 3.5 39 0.16 1600 •20
Quotidiano 40 3.5 45 0.55 800 • • • * • 60-Cold
Eco 40 40 7 52 0.9 1600 •40
Mix40 40 3.5 45 0.55 1200 • • • • • • 40-Cold
Intensivo 60 7 66 1.4 1600 * • • 60-40
Rapido 90 7 60 2 1400 • • 90-Cold
Rapido 60 7 60 1.15 1400 • • 90-Cold
Rapido 30 7 70 0.2 1400 • • 90-Cold
Delicati 40 2 55 0.3 1200 • • • 40-Cold
Lana 40 1.5 56 0.3 1200 • • 40-Cold
Lavaggio a mano 30 1 40 0.25 1200 30-Cold
Tende 40 2 67 0.5 800 * * * • 40-Cold

14 EN
Auxiliary function selection
Selectthedesiredauxiliaryfunctionsbefore
starting the programme. Furthermore, you may
also select or cancel auxiliary functions that are
suitabletotherunningprogrammebypressingthe
Start/Pause/Cancelbuttonwhenthemachineis
operating.Forthis,themachinemustbeinastep
beforetheauxiliaryfunctionyouaregoingtoselect
or cancel.
Dependingontheprogramme,press2a,2b,2cor
2dbuttonstoselectthedesiredauxiliaryfunction.
Symboloftheselectedauxiliaryfunctionappears
on the display.
C Somefunctionscannotbeselectedtogether.
Ifasecondauxiliaryfunctionconflictingwith
thefirstoneisselectedbeforestartingthe
machine,thefunctionselectedfirstwillbe
canceled and the second auxiliary function
selection will remain active. For example,
ifyouwanttoselectQuickWashafteryou
haveselectedthePrewash,Prewashwillbe
canceledandQuickWashwillremainactive.
C Anauxiliaryfunctionthatisnotcompatible
withtheprogrammecannotbeselected.(See
"Programmeandconsumptiontable")
C AuxiliaryFunctionbuttonsmayvaryaccording
to the model of the machine.
• Prelavaggio (Prewash)
APrewashisonlyworthwhileforheavilysoiled
laundry. Not using the Prewash will save energy,
water, detergent and time.
F1 appears on the display when you select this
function (a).
• Rapido (Quick Wash)
ThisfunctioncanbeusedinCottonsand
Syntheticsprogrammes.Itdecreasesthewashing
timesandalsothenumberofrinsingstepsfor
lightly soiled laundry.
F2 appears on the display when you select this
function.
C Whenyouselectthisfunction,loadyour
machine with half of the maximum laundry
specifiedintheprogrammetable.
• Risciacquo Aggiuntivo (Rinse Plus)
Thisfunctionenablesthemachinetomake
another rinsing in addition to the one already made
after the main wash. Thus, the risk for sensitive
skins(babies,allergicskins,etc.)tobeeffectedby
the minimal detergent remnants on the laundry can
bereduced.
F3 appears on the display when you select this
function .
• Antipiega (Anti-Creasing)
This function creases the clothes lesser when they
arebeingwashed.Drummovementisreduced
and spinning speed is limited to prevent creasing.
Inaddition,washingisdonewithahigherwater
level.
F4 appears on the display when you select this
function.
• Rinse Hold
Ifyouarenotgoingtounloadyourclothes
immediately after the programme completes, you
may use rinse hold function to keep your laundry
in the final rinsing water in order to prevent them
from getting wrinkled when there is no water in the
machine.PressStart/Pause/Cancelbuttonafter
this process if you want to drain the water without
spinning your laundry. Programme will resume and
complete after draining the water.
Ifyouwanttospinthelaundryheldinwater,adjust
theSpinSpeedandpressStart/Pause/Cancel
button.
Theprogrammeresumes.Waterisdrained,
laundry is spun and the programme is completed.
• Soaking
TheSoakingauxiliaryfunctionensuresbetter
removalofstainsingrainedintotheclothesby
holding them in the detergent water prior to startup
of the programme.
Time display
Remaining time to complete the programme
appears on the display while the programme is
running. Tim is displayed as “01:30” in hours and
minutes format.
CProgramme time may differ from the values
in the "Programme and consumption
table"dependingonthewaterpressure,
waterhardnessandtemperature,ambient
temperature, amount and the type of laundry,
auxiliary functions selected and the changes
at the mains voltage.
Delayed start
WiththeDelayedStartfunctionthestartupof
theprogrammemaybedelayedupto24hours.
Delayedstarttimecanbeincreasedbyincrements
of 30 minutes.
C Donotuseliquiddetergentswhenyouset
DelayedStart!Thereistheriskofstainingof
the clothes.
Opentheloadingdoor,placethelaundryandput
detergent, etc. Select the washing programme,
temperature,spinspeedand,ifrequired,the
auxiliary functions. Set the desired delayed start
timebypressingtheDelayedStart+or-buttons.
DelayedStartsymbolflashes.PressStart/Pause
/Cancelbutton.Delayedstartcountdownstarts.
DelayedStartsymbolilluminatessteadily.Start
symbolappears.“:”signinthemiddleofthe
delayed start time on the display starts flashing.
C Additionallaundrymaybeloadedduring
thedelayedstartperiod.Attheendofthe
countdown,DelayedStartsymboldisappears,
washing cycle starts and the time of the
selected programme appears on the display.
Changing the delayed start period
Ifyouwanttochangethetimeduringcountdown:
PressStart/Pause/Cancelbutton.“:”signin
the middle of the delayed start time on the display
stopsflashing.Pausesymbolappears.Delayed
Startsymbolflashes.Startsymboldisappears.

15 EN
Setthedesireddelayedstarttimebypressingthe
DelayedStart+or-buttons.PressStart/Pause
/Cancelbutton.DelayedStartsymbolilluminates
steadily.Pausesymboldisappears.Startsymbol
appears. “:” sign in the middle of the delayed start
time on the display starts flashing.
Canceling the Delayed Start function
Ifyouwanttocancelthedelayedstartcountdown
and start the programme immediately:
PressStart/Pause/Cancelbutton.“:”sign
in the middle of the delayed start time on the
displaystopsflashing.Startsymboldisappears.
PausesymbolandDelayedStartsymbolflashes.
Decreasethedelayedstarttimebypressingthe
DelayedStart-button.Programmeduration
appearsafter30minutes.PressStart/Pause/
Cancelbuttontostarttheprogramme.
Starting the programme
PressStart/Pause/Cancelbuttontostartthe
programme.Startsymbolshowingthestartupof
the programme will turn on. Loading door is locked
andDoorLockedsymbolappearsonthedisplay.
Thesymbolofthestepfromwhichtheprogramme
hasstartedappearsonthedisplay(Prewash,Main
Wash,Rinse,SoftenerandSpin).
Progress of programme
Progress of a running programme is indicated on
thedisplaywithasetofsymbols.
Relevantsymbolappearsonthedisplayat
thebeginningofeachprogrammestepandall
symbolsremainlitattheendoftheprogramme.
Thefarthermostrightsymbolindicatesthecurrent
programme step.
Prewash
IfthePrewashauxiliaryfunctionisselected,
Prewashsymbolappearsonthedisplayindicating
that the prewash step has started.
Main Wash
MainWashsymbolindicatingthatthemainwash
step has started appears on the display.
Rinse
Rinsesymbolindicatingthattherinsingstephas
started appears on the display.
Softener
Softenersymbolindicatingthatthesoftenerstep
has started appears on the display.
Spin
Appearsatthebeginningofthefinalspinstep
and remains lit during Spin and Pump special
programmes.
C Ifthemachinedoesnotpasstothespinning
step,RinseHoldfunctionmightbeactive
ortheautomaticunbalancedloaddetection
systemmightbeactivatedduetothe
unbalanceddistributionofthelaundryinthe
machine.
Loading door lock
There is a locking system on the loading door of
the machine that prevents opening of the door in
caseswhenthewaterlevelisunsuitable.
DoorLockedsymbolappearswhentheloading
doorislocked.Thissymbolwillflashuntilthe
loadingdoorbecomesreadytoopenwhen
programme completes or the machine is paused.
Donotforcetoopentheloadingdoorinthisstep.
Symboldisappearswhenthedoorisreadyto
open.Youcanopenthedoorwhenthesymbol
disappears.
Changing the selections after
programme has started
Switching the machine to pause mode
PresstheStart/Pause/Cancelbuttontoswitch
themachinetopausemode.Pausesymbol
appears on the display indicating that the machine
ispaused.Startsymboldisappears.
Changing the speed and temperature settings
for auxiliary functions
Dependingonthesteptheprogrammehas
reached, you may cancel or activate the auxiliary
functions;see,"Auxiliaryfunctionselection".
You may also change the speed and temperature
settings; see, "Spin speed selection" and
"Temperature selection".
Adding or taking out laundry
PresstheStart/Pause/Cancelbuttontoswitch
the machine to pause mode. The programme
follow-uplightoftherelevantstepduringwhichthe
machine was switched into the pause mode will
flash. WaituntiltheLoadingDoorcanbeopened.
OpentheLoadingDoorandaddortakeoutthe
laundry.ClosetheLoadingDoor.Makechangesin
auxiliary functions, temperature and speed settings
ifnecessary.PressStart/Pause/Cancelbuttonto
start the machine.
CThe loading door will not open if the water
temperature in the machine is high or the
waterlevelisabovethedooropening.
Child Lock
UseChildLockfunctiontopreventchildrenfrom
tampering with the machine. Thus you can avoid
any changes in a running programme.
CYou can switch on and off the machine with
On/OffbuttonwhentheChildLockisactive.
Whenyouswitchonthemachineagain,
programme will resume from where it has
stopped.
ToactivatetheChildLock:
Press and hold 2nd and 4thAuxiliaryFunction
buttonsfor3seconds.“Con”appearsonthe
display.
CSame phrase will appear on the display if you
pressanybuttonwhenChildLockisenabled.
TodeactivatetheChildLock:
Press and hold 2nd and 4thAuxiliaryFunction
buttonsfor3seconds.“COFF”appearsonthe
display.

16 EN
5 Maintenance and cleaning
Servicelifeoftheproductextendsandfrequently
facedproblemsdecreaseifcleanedatregular
intervals.
Cleaning the detergent drawer
Cleanthedetergentdraweratregularintervals
(every4-5washingcycles)asshownbelow
in order to prevent accumulation of powder
detergent in time.
Press the dotted point on the siphon in the
softener compartment and pull towards you until
the compartment is removed from the machine.
C Ifmorethannormalamountofwaterand
softener mixture starts to gather in the
softenercompartment,thesiphonmustbe
cleaned.
Washthedetergentdrawerandthesiphonwith
plentyoflukewarmwaterinawashbasin.Wear
protectiveglovesoruseanappropriatebrushto
avoid touching of the residues in the drawer with
yourskinwhencleaning.Insertthedrawerback
into its place after cleaning and make sure that it is
seated well.
Cleaning the water intake filters
There is a filter at the end of each water intake
valve at the rear of the machine and also at the
end of each water intake hose where they are
connected to the tap. These filters prevent foreign
substancesanddirtinthewatertoenterthe
washingmachine.Filtersshouldbecleanedas
they do get dirty.
Closethetaps.Removethenutsofthewater
intake hoses to access the filters on the water
intakevalves.Cleanthemwithanappropriate
brush.Ifthefiltersaretoodirty,takethemout
bymeansofpliersandcleanthem.Takeoutthe
filters on the flat ends of the water intake hoses
together with the gaskets and clean thoroughly
under running water. Replace the gaskets and
filters carefully in their places and tighten the hose
C Donotforgettodisablethechildlockat
theendoftheprogrammeifitwasenabled
before.Otherwise,machinewillnotallowto
select a new programme.
Canceling the programme
PressandholdStart/Pause/Cancelbuttonfor3
seconds.Startsymbolflashes.Symbolofthestep
at which the programme was cancelled remains lit.
"END" appears on the display and the programme
is cancelled.
C Ifyouwanttoopentheloadingdoorafteryou
havecancelledtheprogrammebutitisnot
possibletoopentheloadingdoorsincethe
waterlevelinthemachineisabovetheloading
door opening, then turn the Programme
SelectionknobtoPump+Spinprogramme
and discharge the water in the machine.
Machine is in Rinse Hold mode
SpinsymbolflashesandPausesymbolilluminates
whenthemachineisinRinseHoldmode.
Ifyouwanttospinyourlaundrywhenthemachine
is in this mode:
AdjustthespinspeedandpressStart/Pause
/Cancelbutton.Pausesymboldisappearsand
Startsymbolappears.Programmeresumes,
discharges the water and spins the laundry.
Ifyouonlywanttodrainthewaterwithout
spinning:
JustpressStart/Pause/Cancelbutton.Pause
symboldisappears.Startsymbolappears.
Programme resumes and discharges the water
only.
End of programme
“End” appears on the display at the end of the
programme.Symbolsoftheprogrammesteps
remainlit.Auxiliaryfunction,spinspeedand
temperaturethatwereselectedatthebeginningof
the programme remain selected.

17 EN
nutsbyhand.
Draining remaining water and
cleaning the pump filter
The filter system in your machine prevents solid
itemssuchasbuttons,coinsandfabricfibers
clogging the pump impeller during discharge of
washingwater.Thus,thewaterwillbedischarged
withoutanyproblemandtheservicelifeofthe
pump will extend.
Ifthemachinefailstodrainwater,thepumpfilter
isclogged.Filtermustbecleanedwheneverit
iscloggedorinevery3months.Watermustbe
drained off first to clean the pump filter.
Inaddition,priortotransportingthemachine
(eg., when moving to another house) and in case
offreezingofthewater,watermayhavetobe
drained completely.
A Foreignsubstancesleftinthepumpfiltermay
damage your machine or may cause noise
problem.
Inordertocleanthedirtyfilteranddischargethe
water:
Unplugthemachinetocutoffthesupplypower.
ATemperature of the water inside the machine
mayriseupto90ºC.Toavoidburningrisk,
filtermustbecleanedafterthewaterinthe
machine cools down.
Openthefiltercap.
 Ifthefiltercapiscomposedoftwopieces,
pressthetabonthefiltercapdownwardsand
pull the piece out towards yourself.
Ifthefiltercapisonepiece,pullthecapfromboth
sides at the top to open.
C Youcanremovethefiltercoverbyslightly
pushing downwards with a thin plastic tipped
tool,throughthegapabovethefiltercover.
Donotusemetaltippedtoolstoremovethe
cover.
Some of our products have emergency draining
hose and some does not have. Follow the steps
belowtodischargethewater.
Dischargingthewaterwhentheproducthasan
emergency draining hose:
Pull the emergency draining hose out from its seat
Place a large container at the end of the hose.
Drainthewaterintothecontainerbypullingoutthe
plugattheendofthehose.Whenthecontainer
isfull,blocktheinletofthehosebyreplacingthe
plug.Afterthecontainerisemptied,repeatthe
aboveproceduretodrainthewaterinthemachine
completely.Whendrainingofwaterisfinished,
closetheendbytheplugagainandfixthehosein
its place. Turn the pump filter to take it out.
Dischargingthewaterwhentheproductdoesnot
have an emergency draining hose:
Place a large container in front of the filter to
catch water from the filter. Loosen pump filter
(anticlockwise) until water starts to flow. Fill the
flowing water into the container you have placed
infrontofthefilter.Alwayskeepapieceofcloth
handytoabsorbanyspilledwater.Whenthewater
inside the machine is finished, take out the filter
completelybyturningit.Cleananyresiduesinside
thefilteraswellasfibers,ifany,aroundthepump
impellerregion.Installthefilter.
A Ifyourproducthasawaterjetfeature,be
sure to fit the filter into its housing in the
pump. Never force the filter while installing it
into its housing. Seat the filter into its place
completely.Otherwise,watermayleakfrom
the filter cap.
Ifthefiltercapiscomposedoftwopieces,close
thefiltercapbypressingonthetab.Ifitisone
piece,seatthetabsinthelowerpartintotheir
places first, and then press the upper part to close.

18 EN
6 Technical specifications
C Technicalspecificationsmaybechangedwithoutpriornoticetoimprovethequalityoftheproduct.
CFigures in this manual are schematic and may not match the product exactly.
C Valuesstatedontheproductlabelsorinthedocumentationaccompanyingitareobtainedin
laboratoryconditionsinaccordancewiththerelevantstandards.Dependingonoperationaland
environmental conditions of the product, these values may vary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
Net weight (±4 kg.)
Electricalinput(V/Hz)
Totalcurrent(A)
Totalpower(W)
Spin speed (rpm max.)
Stand-bymodepower(W)
Off-modepower(W)
Thisappliance’spackagingmaterialisrecyclable.Helprecycleitandprotectthe
environmentbydroppingitoffinthemunicipalreceptaclesprovidedforthispurpose.
Yourappliancealsocontainsagreatamountofrecyclablematerial.Itismarkedwith
thislabeltoindicatetheusedappliancesthatshouldnotbemixedwithotherwaste.
Thisway,theappliancerecyclingorganisedbyyourmanufacturerwillbedoneunder
thebestpossibleconditions,incompliancewithEuropeanDirective2002/96/ECon
WasteElectricalandElectronicEquipment.Contactyourtownhalloryourretailerforthe
usedappliancecollectionpointsclosesttoyourhome.Wethankyoudoingyourpartto
protect the environment.
LBS107F
7
84
60
54
71
230V/50Hz
10
2200
1000
1.40
0.20

19 EN
7 Troubleshooting
Programmecannotbestartedorselected.
• Washingmachinehasswitchedtoselfprotectionmodeduetoasupplyproblem(linevoltage,
waterpressure,etc.).>>>Press and hold Start / Pause button for 3 seconds to reset the
machine to factory settings. (See "Canceling the programme")
Waterinthemachine.
• Somewatermighthaveremainedintheproductduetothequalitycontrolprocessesinthe
production.>>>This is not a failure; water is not harmful to the machine.
Machinevibratesormakesnoise.
• Machinemightbestandingunbalanced.>>>Adjust the feet to level the machine.
• Ahardsubstancemighthaveenteredintothepumpfilter.>>>Clean the pump filter.
• Transportationsafetyboltsarenotremoved.>>>Remove the transportation safety bolts.
• Laundryquantityinthemachinemightbetoolittle.>>>Add more laundry to the machine.
• Machinemightbeoverloadedwithlaundry.>>>Take out some of the laundry from the machine
or distribute the load by hand to balance it homogenously in the machine.
• Machinemightbeleaningonarigiditem.>>>Make sure that the machine is not leaning on
anything.
Machinestoppedshortlyaftertheprogrammestarted.
• Machinemighthavestoppedtemporarilyduetolowvoltage.>>>It will resume running when the
voltage restores to the normal level.
Programmetimedoesnotcountdown.(Onmodelswithdisplay)
• Timermaystopduringwaterintake.>>>Timer indicator will not countdown until the machine
takes in adequate amount of water. The machine will wait until there is sufficient amount of water
to avoid poor washing results due to lack of water. Timer indicator will resume countdown after
this.
• Timermaystopduringheatingstep.>>>Timer indicator will not countdown until the machine
reaches the selected temperature.
• Timermaystopduringspinningstep.>>>Automatic unbalanced load detection system might
be activated due to the unbalanced distribution of the laundry in the drum.
C Machinedoesnotswitchtospinningstepwhenthelaundryisnotevenlydistributedinthedrum
topreventanydamagetothemachineandtoitssurroundingenvironment.Laundryshouldbe
rearrangedandre-spun.
Foam is overflowing from the detergent drawer.
• Toomuchdetergentisused.>>>Mix 1 tablespoonful softener and ½ l water and pour into the
main wash compartment of the detergent drawer.
C Putdetergentintothemachinesuitablefortheprogrammesandmaximumloadsindicatedin
the“Programmeandconsumptiontable”.Whenyouuseadditionalchemicals(stainremovers,
bleachsandetc),reducetheamountofdetergent.
Laundry remains wet at the end of the programme
• Excessivefoammighthaveoccurredandautomaticfoamabsorptionsystemmighthavebeen
activatedduetotoomuchdetergentusage.>>>Use recommended amount of detergent.
C Machinedoesnotswitchtospinningstepwhenthelaundryisnotevenlydistributedinthedrum
topreventanydamagetothemachineandtoitssurroundingenvironment.Laundryshouldbe
rearrangedandre-spun.
A Ifyoucannoteliminatetheproblemalthoughyoufollowtheinstructionsinthissection,consultyour
dealerortheAuthorizedServiceAgent.Nevertrytorepairanonfunctionalproductyourself.
2820521961_EN/290311.1134
